A Division of Snow Joe, LLC
OPERATOR’S MANUAL
Model 24V-HT16-LTE Form No. SJ-24V-HT16-LTE-880E-M
CORDLESS HEDGE TRIMMER
24V MAX* | 2.0 Ah |16-INCH
R
TM
*DISCLAIMER: Initial no-load voltage, when fully charged,
peaks at 24V; nominal voltage under typical load is 21.6V.
SAVE THESE INSTRUCTIONS
1
Original instructions.
© 2023 Snow Joe, LLC. All rights reserved.
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may result
in serious bodily injury or death.
General Power Tool Safety Warnings
m WARNING Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in serious injury or death.
mWARNING! This indicates a hazardous situation, which, if
not followed, could result in serious injury or death.
mCAUTION! This indicates a hazardous situation, which, if
not followed, could result in minor or moderate injury.
Work Area Safety
1. Keep work area clean and well lit – Cluttered or dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust – Power tools create sparks which may ignite the dust
or fumes.
3. Keep children and bystanders away while operating a
power tool – Distractions can cause you to lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators – There
is an increased risk of electric shock if your body is earthed
or grounded.
3. Do not expose power tools to rain or wet conditions –
Water entering a power tool will increase the risk of electric
shock.
4. Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
5. When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal Safety
1. Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the influence
of drugs, alcohol or medication – A moment of inattention
while operating power tools may result in serious personal
injury.
2. Use personal protective equipment. Always wear eye
protection – Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
3. Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or
battery pack, picking up or carrying the tool. – Carrying
power tools with your finger on the switch or energizing
power tools that have the switch on invites accidents.
4. Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating
part of the power tool may result in personal injury.
5. Do not overreach. Keep proper footing and balance at
all times – This enables better control of the power tool in
unexpected situations.
6. Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving
parts – Loose clothes, jewelry or long hair can be caught in
moving parts.
2
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
8. Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within
a fraction of a second.
Power Tool Use + Care
1. Do not force the power tool. Use the correct power tool
for your application – The correct power tool will do the job
better and safer at the rate for which it was designed.
2. Do not use the power tool if the switch does not turn it on
and off – Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or
remove the BATTERY pack, if detachable, from the
power tool before making any adjustments, changing
accessories, or storing power tools – Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
4. Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool – Power tools are
dangerous in the hands of untrained users.
5. Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool
repaired before use – Many accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and clean –
Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
– Use of the power tool for operations different from those
intended could result in a hazardous situation.
8. Keep handles and grasping surfaces dry, clean and
free from oil and grease – Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations.
Battery tool use and care
1. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
BATTERY pack may create a risk of fire when used with
another BATTERY pack.
2. Use power tools only with specifically designated
BATTERY packs. Use of any other BATTERY packs may
create a risk of injury and fire.
3. When BATTERY pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the
BATTERY terminals together may cause burns or a fire.
4. Under abusive conditions, liquid may be ejected from the
BATTERY; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the BATTERY may cause
irritation or burns.
5. Do not use a BATTERY pack or tool that is damaged
or modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, EXPLOSION or risk
of injury.
6. Do not expose a BATTERY pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130°C may cause explosion.
NOTE: The temperature "130 °C" can be replaced by the
temperature "265°F".
7. Follow all charging instructions and do not charge the
BATTERY pack or tool outside the temperature range
specified in the instructions. Charging improperly or at
temperatures outside the specified range may damage the
BATTERY and increase the risk of fire.
Service
Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
Never service damaged BATTERY packs. Service of BATTERY
packs should only be performed by the manufacturer or
authorized service providers.
Hedge Trimmer Safety Warnings
1. Keep all parts of the body away from the blade. Do not
remove cut material or hold material to be cut when
blades are moving. Blades continue to move after the
switch is turned off. A moment of inattention while operating
the hedge trimmer may result in serious personal injury.
2. Carry the hedge trimmer by the handle with the blade
stopped and taking care not to operate any power switch.
Proper carrying of the hedge trimmer will decrease the risk
of inadvertent starting and resultant personal injury from the
blades.
3. When transporting or storing the hedge trimmer, always
fit the blade cover. Proper handling of the hedge trimmer
will decrease the risk of personal injury from the blades.
4. When clearing jammed material or servicing the unit,
make sure all power switches are off and the battery
pack is removed or disconnected. Unexpected actuation
of the hedge trimmer while clearing jammed material or
servicing may result in serious personal injury.
3
5. Hold the hedge trimmer by insulated gripping surfaces
only, because the blade may contact hidden wiring.
Blades contacting a "live" wire may make exposed metal
parts of the hedge trimmer "live" and could give the operator
an electric shock.
6. Keep all power cords and cables away from cutting area.
Power cords or cables may be hidden in hedges or bushes
and can be accidentally cut by the blade.
7. Do not use the hedge trimmer in bad weather conditions,
especially when there is a risk of lightning. This decreases
the risk of being struck by lightning.
Training
1. Read the instructions carefully. Be familiar with the controls
and the proper use of the product.
2. Never allow people unfamiliar with these instructions or
children to use the product. Local regulations can restrict the
age of the operator.
3. Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.
Preparation
1. This product can cause serious injuries. Read the
instructions carefully for the correct handling, preparation,
maintenance, starting and stopping of the product. Become
familiar with all controls and the proper use of the product.
2. Never allow children to use the hedge trimmer.
3. Beware of overhead power lines.
4. Never operate the product while people, especially children,
or pets are nearby.
5. Dress properly. Do not wear loose clothing or jewelry, which
can be caught in moving parts. Use of sturdy gloves, non-
skid footwear and safety glasses is recommended.
6. Wear eye protection and stout shoes at all times while
operating the product.
7. If the cutting attachment strikes any foreign object or the
product starts making any unusual noise or vibration, switch
the product off, remove the battery, allow the product to stop
and take the following steps:
– inspect for damage;
– check for, and tighten, any loose parts;
– have any damaged parts replaced or repaired with parts
having equivalent specifications.
Operation
1. Use the product only in daylight or good artificial light.
2. Never operate the product with damaged guards or shields
or without guards or shields in place.
3. Keep hands and feet away from the cutting device at all
times and especially when switching on the motor.
4. Before using the product and after any impact, check for
signs of wear or damage and repair as necessary.
5. Always remove the battery
– whenever leaving the product unattended;
– adjusting the working position of the cutting device;
– before clearing a blockage;
– before checking, cleaning or working on the product;
– after striking a foreign object;
– whenever the product starts vibrating abnormally.
6. Ensure that the hedge trimmer is correctly located in a
designated working position before starting the motor.
7. While operating the hedge trimmer, always ensure that the
operating position is safe and secure, especially when using
steps or a ladder.
8. Do not operate the hedge trimmer with a damaged or
excessively worn cutting device.
9. Always ensure that all handles and guards are fitted
when using the hedge trimmer. Never attempt to use an
incomplete hedge trimmer or one fitted with an unauthorized
modification.
10. Always use two hands to operate a hedge trimmer fitted with
two handles.
11. Always be aware of your surroundings and stays alert for
possible hazards of which you may not be aware due to the
noise of the product.
12. Take care against injury to feet and hands from the cutting
device.
13. Always ensure that the air vents are kept clear of debris.
14. Wear slip-resistant foot protection and protective clothing
when using this product.
15. Always keep proper footing and operate the product only
when standing on a fixed, secure and level surface. Change
working positions regularly to avoid tiredness and ensure a
comfortable working position at all times.
16. Never use replacement parts or accessories not provided or
recommended by the manufacturer.
17. The use of this product may be restricted by regional or local
regulations.
Vibration + Noise Reduction
To reduce the impact of noise and vibration emission, limit the
time of operation, use low-vibration and low-noise operating
modes as well as wear personal protective equipment.
Take the following points into account to minimise the vibration
and noise exposure risks.
1. Only use the product as intended by its design and these
instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure they are
in good condition.
4
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these instructions
and keep it well lubricated (where appropriate).
6. Plan your work schedule to spread any high vibration tool
use across a longer period of time.
Emergency
Familiarize yourself with the use of this product by means of this
instruction manual. Memorize the safety directions and follow
them to the letter. This will help to prevent risks and hazards.
1. Always be alert when using this product, so that you can
recognize and handle risks early. Fast intervention can
prevent serious injury and damage to property.
2. Switch off and remove the battery if there are malfunctions.
Have the product checked by a qualified professional and
repaired, if necessary, before you operate it again.
Residual Risks
Even if you are operating this product in accordance with all the
safety requirements, potential risks of injury and damage remain.
The following dangers can arise in connection with the structure
and design of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately handled and properly maintained.
2. Injuries and damage to property due to broken cutting
attachments or the sudden impact of hidden objects during
use.
3. Danger of injury and property damage caused by flying
objects.
mWARNING! This product produces an electromagnetic
field during operation. This field may under some circumstances
interfere with active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend persons with
medical implants to consult their doctor and the medical implant
manufacturer before operating this product.
Battery & Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only be
guaranteed if undamaged cells are used. Incorrect handling of
the battery pack can cause cell damage.
IMPORTANT! Analyses confirm that incorrect use and poor care
of high-performance batteries are the main factors responsible
for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the hedge trimmer and cause it to
malfunction.
mCAUTION! To reduce the risk of injury, charge the
24V* IONMAX
TM
lithium-ion battery pack only in its designated
24V* IONMAX
TM
lithium-ion charger. Other types of chargers
present risk of fire, personal injury and damage. Do not wire
a battery pack to a power supply plug or car cigarette lighter.
Such misuse will permanently disable or damage the battery
pack.
• Avoid dangerous environments – Do not charge the battery
pack in rain, snow or in damp or wet locations. Do not use
the battery pack or charger in the presence of explosive
atmospheres (gaseous fumes, dust or flammable materials)
because sparks may be generated when inserting or
removing the battery pack, which could lead to a fire.
• Charge in a well-ventilated area – Do not block the charger
vents. Keep them clear to allow for proper ventilation. Do not
allow smoking or open flames near a charging battery pack.
Vented gases may explode.
NOTE: The safe temperature range for the battery is
41°F – 105°F (5°C – 40.5°C). Do not charge the battery
outside in freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger,
pull the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord.
Never carry the charger by its cord or yank it by the cord
to disconnect it from the receptacle. Keep the cord away
from heat, oil and sharp edges. Make sure the cord will
not be stepped on, tripped over or subjected to damage or
stress when the charger is in use. Do not use the charger
with a damaged cord or plug. Replace a damaged charger
immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly wired
extension cord poses a risk of fire and electric shock. If
an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• XZ2600-0450 charger is rated for 100-240 volt AC only –
The charger must be plugged into an appropriate receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery charger
or battery pack manufacturer may result in risk of fire,
electric shock or personal injury.
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
5
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning or
maintenance. Do not allow water to flow into the charger. Use a
Ground Fault Circuit Interrupter (GFCI) to reduce shock hazards.
• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage.
Toxic fumes and materials are created when battery packs
are burned.
• Do not crush, drop or damage battery packs – Do not use
the battery pack or charger if they have sustained a sharp blow,
been dropped, run over or have been damaged in any way (i.e.
pierced with a nail, hit with a hammer, stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, fire or exposure to toxic
battery chemicals. If the battery or charger are damaged,
please contact an authorized Snow Joe
®
+ Sun Joe
®
dealer
or call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth. If a
damaged battery pack leaks battery chemicals, use rubber
or neoprene gloves to safely dispose of it. If skin is exposed
to battery fluids, wash the affected area with soap and
water and rinse with vinegar. If eyes are exposed to battery
chemicals, immediately flush with water for 20 minutes and
seek medical attention. Remove and dispose of contaminated
clothing.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105°F (40.5°C), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger to
a power supply with the voltage marked on the rating plate.
Never connect it to a different mains voltage.
2. Protect the battery charger and its cord from damage. Keep
the charger and its cord away from heat, oil and sharp
edges. Have damaged cords repaired without delay by a
qualified technician at an authorized Snow Joe
®
+
Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify the plug
in any way. Do not use any adapter plugs with grounded
appliances. Unmodified plugs and matching outlets will
reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s) and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before inserting it into the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging and
cell damage. Do not leave batteries in the charger for days
on end.
8. Never use or charge batteries if you suspect that it has been
more than 12 months since the last time they were charged.
There is a high probability that the battery pack has already
suffered dangerous damage (exhaustive discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a fire.
Protection from environmental influences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and flammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41°F – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C).
In particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads, overcharging
and exposure to direct sunlight will result in overheating and
cell damage. Never charge or work with batteries that have
been overheated – replace them immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41°F – 105°F (5°C
– 40.5°C). Store your lithium-ion battery pack in a cool, dry
place at a temperature of 77°F (25°C). Protect the battery
pack, charger and cordless tool from humidity and direct
sunlight. Only place fully charged batteries in storage.
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than 60
minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.
6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
Symbols Symbols
Descriptions
Descriptions
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting to
assemble and operate.
WARNING! Do not expose the unit
to rain or wet conditions.
WEAR EYE AND HEARING
PROTECTION – For protection against
injury, wear ear defenders and safety
goggles.
Wear protective gloves and
non-slip footwear when using the
machine and handling debris.
DANGER! ROTATING BLADES –
Keep hands and feet away from
openings while the trimmer is
running.
Keep bystanders a safe
distance away from the
work area.
Indoor use only. Only use
battery charger indoors.
7
Know Your Cordless Hedge Trimmer
Read the owner’s manual and safety instructions carefully before operating the cordless hedge trimmer. Compare the illustration
below to the cordless hedge trimmer in order to become familiar with the location of the various controls and adjustments.
Save this manual for future reference.
1
2
15
3
5
4
6
7
8
9
11
13
12
10
14
1. Safety guard
2. Front handle
3. Safety lock switch
4. Rear handle
5. On/Off trigger
6. Battery compartment
7. Blade cover
8. Blade
9. Blade support
10. Charger plug
11. 24V* IONMAX
TM
lithium-ion battery
charger (XZ2600-0450)
12. Push lock button
13. Battery charge level indicators
14. Push button for battery indicator
15. 24V* IONMAX
TM
lithium-ion battery
(24VBAT-LTE) featuring exclusive
EcoSharp
®
technology
*DISCLAIMER: Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage under typical load is 21.6 volts.
Technical Data
Motor ............................................................................................. 250 W
Battery Voltage Max* ............................................................. 24V D.C.
Battery Capacity ......................................................................... 2.0 Ah
Charger Input ............................................................. 100 – 240V AC,
50/60 Hz, 0.4 A
Charger Output .................................................... 26V D.C.| 450 mA
Charging Time Max .................................................................. 5 hours
Blade Movement ................................................................ Dual-action
Blade Material ........................................................65Mn Steel blades
Blade Length ............................................................... 16 in. (40.6 cm)
Cutting Diameter Max .............................................. 0.55 in. (14 mm)
No-load speed ...................................................................... 2800 rpm
Net Weight ....................................................................4.8 lbs (2.2 kg)
8
Unpacking
Carton Contents
• Cordless hedge trimmer
• Blade cover
• 24V* IONMAX
TM
lithium-ion battery
• 24V* IONMAX
TM
lithium-ion charger
• Manual with registration card
1. Carefully remove the cordless hedge trimmer and check to
see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you find damaged or
missing parts, DO NOT return the unit to the store.
Please call the Snow Joe
®
+ Sun Joe
®
customer service
center at 1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use the cordless hedge
trimmer. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with local
regulations or save the packaging for long-term product
storage.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suffocation
risk!
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read off the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is maximum.
• 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is flat. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights
NOTE: If the charge level button does not appear to be working,
place the battery pack on the charger and charge as needed.
Immediately after using the battery pack, the charge level button
may display a lower charge than it will if checked a few minutes
later. The battery cells “recover” some of their charge
after resting.
Charger Operation
m
WARNING! Charge only 24V* IONMAX
TM
lithium-ion
battery packs with its compatible 24V* IONMAX
TM
lithium-ion
charger. Other types of batteries may cause personal injury and
damage. To reduce the risk of electric shock, do not allow water
to flow into the charger's AC/DC plug.
When to Charge the IONMAX
TM
24VBAT-
LTE Lithium-Ion Battery
NOTE: The IONMAX
TM
24VBAT-LTE lithium-ion battery packs
do not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the battery
pack before inserting the charger plug.
• Use the battery indicator lights to determine when to charge
your IONMAX
TM
24VBAT-LTE lithium-ion battery pack.
• You can "top-off" your battery pack's charge before starting
a big job or after a long day of use.
Charging the Battery
1. Push the push lock buttons on the battery to pull the battery
pack out of the equipment (Fig. 1).
Fig. 1
Push lock
button
9
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, plug the
charger adapter into an appropriate AC power outlet.
Connect the charger plug into the charge socket of the
battery to start charging (Fig. 2).
3. The battery will take approximately 80 minutes to charge.
The battery indicator LEDs will twinkle and illuminate one
by one during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from the
outlet first, then disconnect the charger from the battery
mWARNING! This charger does not automatically turn
off when the battery is fully charged. Please take care not
to leave the battery plugged into the charger. Switch off or
unplug the charger at the mains when charging is complete.
4. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when you
notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the battery.
Assembly
This cordless hedge trimmer comes completely assembled.
Operation
mWARNING! Always wear safety goggles or safety glasses
with side shields when operating power tools. Failure to do so
could result in objects being thrown into your eyes, resulting in
possible serious injury.
Fig. 2
Battery
indicators
mWARNING! Do not use any attachments or accessories
not recommended by the manufacturer of this product.
The use of attachments or accessories not recommended can
result in serious personal injury.
Holding the Trimmer
Before operating the hedge trimmer, stand in the operating
position and perform the following checks:
1. You are wearing all of the necessary personal protective
equipment, including protective gloves, non-slip footwear,
safety goggles, ear defenders, and close-fitting clothing.
2. You are holding the unit firmly with both hands. Your right
arm is slightly bent and is holding the rear handle, and your
left arm is straight and is holding the front handle.
3. You are standing with proper footing and are holding the
hedge trimmer so that the cutting blades are always away
from your body.
mWARNING! Always keep both hands on the hedge
trimmer handles. Never hold shrubs with one hand and operate
the hedge trimmer with the other. Improper handling of the
hedge trimmer could result in serious injury.
Starting + Stopping
mWARNING! Ensure the blade does not touch any objects
before turning on the hedge trimmer.
mCAUTION! Starting, stopping, and restarting a DC motor
repeatedly within a few seconds can generate a great deal of
heat and damage the motor. To protect the life of your cordless
hedge trimmer, always wait at least five seconds after stopping
before restarting the hedge trimmer.
1. Remove the blade cover and insert the battery in the battery
compartment (Fig. 3).
2. To start the tool, slide the safety lock switch upward,
then squeeze the On/Off trigger. (Fig. 4).
Fig. 3
Battery
Battery compartment
Fig. 4
Safety lock switch
On/Off trigger
10
3. To turn the tool OFF, release the On/Off trigger (Fig. 4).
NOTE: Do not press the On/Off trigger until you are ready
to make a cut.
Cutting Procedures
mWARNING! Never cut near electric cords or power lines.
If the blade jams on any electrical cable, DO NOT TOUCH
THE BLADE. IT CAN CONDUCT ELECTRICITY AND FATALLY
SHOCK YOU! Instead, continue to hold the hedge trimmer by
the insulated rear handle, and lay it down and away from you in
a safe manner. Make sure that electrical service to the damaged
electrical cable is disconnected before attempting to free the
hedge trimmer blade. Contact with the blade, other conductive
parts of the hedge trimmer, or live electric cords or power lines
will result in death by electrocution or serious injury.
mWARNING! Do not allow familiarity with this type of
product to make you careless. Remember that a careless
fraction of a second is sufficient to inflict serious injury.
mWARNING! Clear the area to be cut before each use.
Remove all objects such as cords, lights, wire, or loose string
which can become entangled in the cutting blade and create a
risk of electric shock and serious personal injury.
1. When trimming new growth, use a wide sweeping action
so that the stems are fed directly into the blade. Do not try
to cut branches that are thicker than 0.55 in. (1.4 cm) or
those that are obviously too large to feed into the blade. Use
lopping shears, a hand saw, or a pruning saw to cut out thick
branches first. If a substantial cut is necessary, cut a little
at a time in several passes. Cut both sides of the hedge first
and then the top.
2. To perform a horizontal cut, hold the hedge trimmer with the
blade tilted 5-10 degrees to your cutting object; this makes
the operation easier and ensures a better cut
(Fig. 5).
3. To perform a vertical cut, start trimming at the bottom and
sweep up for even cutting. Swing the blades in an arc
towards the outsides of the hedge so that the cuttings are
swept on the ground (Fig. 6).
Fig. 5
5° – 10°
Cutting Tips
mWARNING! Hold the tool firmly in both hands.
Always keep your dominant hand on the switch handle and your
non-dominant hand on the front. Never hold the tool by the blade
guard. Keep unit below waist level.
• A wide, sweeping motion, feeding the blade teeth through the
twigs is most effective. A slight downward tilt of the blade in
the direction of the motion gives the best cut.
• Begin at the bottom and sweep up.
• Do not force the hedge trimmer through heavy shrubbery.
This can cause the blades to bind and slow down. If the
blades slow down, reduce the pace.
• If blades do become jammed, stop the motor, allow the
blades to stop, and remove the battery before attempting to
remove the obstruction.
• If desired, you can use a string to help cut your hedge level.
Decide how high you want the hedge. Stretch a piece of
string along the hedge at the desired height.
Trim the hedge just above the guide line of string. Trim the
side of a hedge so that it will be slightly narrower at the top.
More of the hedge will be exposed when shaped this way,
and it will be more uniform.
• Wear gloves when trimming thorny or prickly growth. When
trimming new growth, use a wide sweeping action, so that
the stems are fed directly into the cutting blade. Older
growth will have thicker stems and will be trimmed easiest by
using a sawing movement.
Care + Maintenance
m
ATTENTION! Before performing any cleaning or
maintenance, remove the battery from the battery compartment.
Never touch the moving blades.
Fig. 6
11
mWARNING! Never spray or clean the hedge shears with
water.
1. Clean the hedge shears with a dry towel, particularly the
ventilation slits, after each use, or use a brush in the event of
heavy soiling. Spray the blades with lightweight machine oil
after each use.
2. Store the hedge trimmer in the blade cover provided. Store
the hedge trimmer in a dry location out of the reach of
children.
3. When servicing, use only identical replacement parts. Use
of any other parts can create a hazard or cause product
damage. Please contact an authorized Snow Joe
®
+
Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563) for all
replacement parts and accessories for your product.
Lubricate the Blades
For easier operation and longer blade life, lubricate the hedge
trimmer blade before and after each use.
1. Stop the motor and remove the battery.
2. Lay the hedge trimmer on a flat surface. Apply any lightweight
machine oil along the edge of the top blade (Fig. 7).
If you will be using the hedge trimmer for an extended period,
it is advisable to stop work intermittently in order to re-oil the
blade.
NOTE: Do not oil while the hedge trimmer is running.
1. Stop the motor and remove the battery.
2. Lubricate the hedge trimmer as described above.
3. Insert the battery and resume use.
Sharpening the Blades
The blade must be re-sharpened if cutting performance and
behavior begin to deteriorate (i.e. if blades frequently snag on
branches).
Fig. 7
1. Stop the motor and remove the battery. Clamp the blade in a
vise.
2. File the exposed cutting surface of each blade tooth with a
smooth round file. Be sure to retain the original angle of the
tooth when filing.
3. Remove the blade from the vise, and power on the motor
until the unsharpened edges of the remaining blade teeth are
exposed.
4. Remove the battery and repeat the sharpening procedure as
necessary.
mWARNING! Do not operate the hedge trimmer with dull or
damaged cutting blades. This may cause overload and will give
unsatisfactory cutting results.
Cleaning the Hedge Trimmer
1. Stop the motor and remove the battery.
2. Clean dirt and debris from the body of the hedge trimmer
using a damp cloth and mild detergent.
NOTE: Do not use any strong detergents on the plastic housing
or the handle. These parts can be damaged by certain aromatic
oils such as pine and lemon, and by solvents such as kerosene.
Storage
1. Stop the motor and remove the battery.
2. Clean the hedge trimmer thoroughly before storing.
3. Always place the blade cover on the blade before storing
or transporting the hedge trimmer. Use caution to avoid the
sharp teeth of the blade.
4. Store the hedge trimmer indoors, in a dry place that is
inaccessible to children. Keep away from corrosive agents
such as garden chemicals and de-icing salts.
5. Always store the hedge trimmer in a place that is
inaccessible to children. The ideal storage temperature is
between 50°F and 86°F (10°C and 30°C).
6. We recommend using the original package for storage or
covering the product with a suitable cloth or enclosure to
protect it against dust.
Recycling + Disposal
The product comes in a package that protects it against damage
during shipping. Keep the package until you are sure that
all parts have been delivered and the product is functioning
properly. Recycle the package afterwards.
WEEE symbol. Waste electrical product should not be
disposed of with household waste. Please recycle where
facilities exist. Check with you local authority or local
store for recycling advice.
12
Battery Caution + Disposal
Always dispose of your battery pack according to federal, state,
and local regulations. Contact a recycling agency in your area
for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover the
terminals to prevent the battery pack from shorting, which could
cause a fire or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead, or completely discharged. When burned, toxic fumes and
materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual for
specific information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as indicated
in the battery compartment or manual, may shorten the life of
the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc),
or Rechargeable (Nickel Cadmium, Nickel Metal Hydride,
or Lithium-Ion) batteries.
6. Do not dispose of batteries in fire.
7. Batteries should be recycled or disposed of as per state and
local guidelines.
Service + Support
If your Sun Joe
®
24V* IONMAX cordless hedge trimmer requires
service or maintenance, please call the Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model + Serial Numbers
When contacting the company or reordering parts, you will need
to provide the model and serial numbers of your product. These
are found on the decal affixed to the housing or handle of your
cordless hedge trimmer. Copy these numbers into the space
provided below.
Record the following numbers from the housing or handle of your
new product:
Model #:
Serial #:
24V-HT16-LTE
XZ2600-0450
Federal Communications Commission
(FCC)
mWARNING! Any changes or modifications to this unit not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Class B Device:
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in
a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment to an outlet on a circuit different
than the one the receiver is connected to.
• Consult the dealer or an experienced radio/TV technician
for help
13
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe
®
+ Sun Joe
®
replacement parts and accessories. NEVER use replacement
parts or accessories that are not intended for use with this hedge trimmer. Contact Snow Joe
®
+ Sun Joe
®
if you are unsure whether
it is safe to use a particular replacement part or accessory with your hedge trimmer. The use of any other attachment or accessory
can be dangerous and could cause injury or mechanical damage.
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe
®
+ Sun Joe
®
to provide notice of such
changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe
®
+ Sun Joe
®
customer service
center at 1-866-SNOWJOE (1-866-766-9563).
Accessories Item Model
24V* IONMAX
TM
2.5 Ah Lithium-Ion Battery 24VBAT-LT
24V* IONMAX
TM
4.0 Ah Lithium-Ion Battery 24VBAT
24V* IONMAX
TM
5.0 Ah Lithium-Ion Battery 24VBAT-XR
24V* IONMAX
TM
Lithium-Ion Battery Quick Charger 24VCHRG-QC
24V* IONMAX
TM
Lithium-Ion Battery Dual Port Charger 24VCHRG-DPC
Universal Wall Bracket With Mounting Hardware
SJWB
(Fits most Snow Joe
®
+
Sun Joe
®
tools)
1
2
3
4
5
6
14
R5_05112023
SNOW JOE
®
+ SUN JOE
®
CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used for
ordinary household use for a period of two years from the date of delivery of the Product to the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specific part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no charge,
or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or by calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty rights. However,
registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not affect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased at
snowjoe.com/support or by calling 1-866-SNOWJOE (1-866-766-9563).
Keep your warranty intact. Only use CERTIFIED AUTHENTIC Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
+ Auto Joe
®
replacement parts +
accessories. Use of any other parts + accessories will void the warranty. Genuine parts + accessories can be found and purchased online at
snowjoe.com/support by entering the model number of your product.
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
, or Auto Joe
®
product (“Product”) does not work or breaks
under normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited
Warranty (“Warranty”) for our Products.
TM
TM
15
sunjoe.com
TM
