1
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
4 Explanation of Symbols
4 Before the First Time You Use Your Gaming Headset Stand
5 Description of Parts
6 Assembling Your Gaming Headset Stand
6 Connecting the USB Cable to the Stand
6 Connecting Your Gaming Headset Stand when…
6 …Using a PC
7 …Using a Laptop
7 RGB Light Control Button Functions
7 Using the USB Outlets
7 Care and Use of Your Gaming Headset Stand
8 Technical Specification
8 Recycling Information
9 Customer Support
Back Page Warranty Information
3
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should always
be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating instructions before
using this Gaming Headset Stand.
• Before using your Gaming Headset Stand, visually check that the
unit is intact and has not suffered any transit damage.
• Only connect items as described in this manual, incorrect
connections may cause permanent damage to the product.
• DO NOT operate this product after a malfunction or after being
dropped or damaged in any way.
• Never allow children to play with the product. Small parts and
cables may be a choking hazard.
• DO NOT allow cables to hang over sharp edges or come in contact
with hot surfaces.
• This product is intended for household use only and should not be
used for industrial or commercial purposes.
• DO NOT use this product for anything other than its intended use.
• DO NOT immerse the product in water or any other liquids.
• DO NOT expose the product to moisture, rain or humidity, they are
not waterproof.
• Never clean the product with solvents or harsh or abrasive cleaners.
• DO NOT attempt to dismantle the product, it does not contain any
user serviceable parts.
• Whilst not in use, store the product in a cool dry place free from
extreme temperatures, humidity or dust.
4
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
This symbol provides useful additional information on the use of
this product.
This symbol identifies voltage and the current rating for direct
current.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with your
Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
Before the first time you use your Gaming Headset Stand
Remove all packing materials and discard responsibly.
Check that all the parts are present with your Gaming Headset Stand see
‘Description of Parts’ below.
5
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
1
2
3
8
1. Top Section
2. Upright Section
3. Illuminated Base
4. RGB Illuminated Window
5. RGB Light Control Button
6. USB 1 Outlet
7. USB 2 Outlet
8. C-Type USB Socket (rear)
9. USB Power Cable
10. Large USB Plug
11. C-Type USB Plug
7
4
6
5
9
10
11
6
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Assembling your Gaming Headset Stand
Connecting the USB Cable to the Stand
Connecting up your Gaming Headset Stand when…
…Using a PC
Insert the Large USB Plug (10) of the USB Power Cable (9) into any spare
USB socket on your PC:
Step 1:
Attach the Top Section (1) onto
the Upright Section (2) by sliding
the top section in the direction of
the arrow shown right:
Step 1
Step 2
Step 2:
Push the Upright Section (2) into
the slot in the base (3) as shown
right:
Insert the USB C-Type Plug (11) of the
USB Power Cable (9) into the C-Type
USB Socket (8) on the rear of the unit
as shown left:
7
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Only connect the Headset Stand to a normal USB outlet and not to a fast
charge outlet or charger.
RGB Light Control Button (5) Functions
Press
Function
Press and hold
Switches the RGB LED Effect on
Brief Press
RGB Colour Changing
Brief Press
Red
Brief Press
Green
Brief Press
Blue
Brief Press
Yellow
Brief Press
Violet
Brief Press
Cyan
Press and hold
Switches the RGB LED Effect off
Using the USB Outlets - USB 1 (6) & USB 2 (7)
Use the two USB Outlets (6) & (7) – arrowed
right, to connect your keyboard, mouse, etc.
Care and Use of your Gaming Headset Stand
• Always unplug the Headset Stand before cleaning.
• Clean the outside of the Headset Stand with a clean damp cloth. Never clean
with harsh or abrasive cleaners.
• Do not submerge the Headset Stand in water or any other liquids.
…Using a Laptop
Insert the Large USB Plug (10) of the USB Power Cable (9) into any spare
USB socket on your Laptop:
8
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
Model Number
AVS1570
Supply Current (with RGB)
<180mA
Supply Current (no RGB)
<60mA
Supply Voltage
5V (4.75 – 5.25V) DC
USB Input Connection
C-Type
USB Cable Length
1400mm
USB Outlet Port Current Rating
500mA max. each port
USB Support Protocol
USB1.1, USB2.0
Weight (approx.)
238g
Dimensions (approx.)
280mm (h) x 105mm (w) x 137mm (d)
9
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
10
Gaming Headset Stand with RGB
Model No. AVS1570
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo Audio product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo audio product is guaranteed for 1 year from the date of original purchase, with
proof of purchase or receipt. If any defect should occur due to faulty workmanship or material,
your faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo Electricals is a registered trademark.
Imported by Eurosonic Group Ltd. M3 1JS UK
EU Rep: Euromagppie Ireland Ltd. D05 X006
Produced under licence by ESG Ltd
www.esgltd.com
