1
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Air Buds & QI Wireless Charging Case
AVS1444 & AVS1445
User Manual
Available in Black or White colours
*
*Please refer to the warranty section for terms of your extended guarantee.
CERTIFIED
#
2
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
Whilst using electrical appliances, basic safety precautions should
always be followed:
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using your TWS Earbuds.
• Before using your TWS Earbuds, visually check that the
product is intact and has not suffered any transit damage.
• Only charge the earbud Charging Case from a suitable USB
outlet using the USB cable or the Wireless Charging Pad,
any other power source may cause permanent damage to
the earphones.
• The earbuds must be fully charged before use.
• Do not operate these Earbuds, Charging Case or Wireless
Charging Pad after a malfunction or after being dropped
or damaged in any way.
• Never allow children to play with the products. Small parts
may be a choking hazard.
• Do not allow the USB charging cable to hang over sharp
edges or come in contact with hot surfaces.
• This product is intended for household use only and
should not be used for industrial purposes.
• Do not use this product for anything other than its
intended use.
• Do not immerse the product in water or any other liquids.
3
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Do not expose the product to moisture, rain or humidity,
they are not waterproof.
• Before cleaning, ensure the Charging Case or Wireless
Charging Pad are not connected to the USB supply.
• Never clean the product with solvents or harsh or abrasive
cleaners.
• Do not attempt to dismantle the product, it does not
contain any user serviceable parts.
• Whilst not in use, store the product in a cool dry place free
from extreme temperatures, humidity or dust.
4
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This symbol provides useful additional information on the
use of this product.
This symbol identifies voltage and the current rating for direct
current.
This symbol means batteries and rechargeable batteries may
not be disposed of with household waste!
As the end user you are required by law to bring all batteries
and rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk enter your postcode to find out your nearest
recycling site.
Before the first time you use your Air Buds with QI Wireless Charging
Remove all packing materials and discard responsibly.
Check that all the parts are present with your product see ‘Description of Parts’
below.
5
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
8
7
2
5
4
3
18
9
10
11
12
1. Charging Case
2. Air Bud Docking Stations
3. Charging Case Lid
4. Air Bud Control Buttons
5. Right Air Bud
6. Air Bud LEDs
7. Charging Pins
8. Left Air Bud
9. Micro USB Charging Port
10. Charging Case LED
11. Charge Button
Charging Case – Over view
Charging Case – Rear view
Charging Case – Bottom view
6
4
16
14
1
13
QI Charging Pad
USB Charging Cable
12. Base Unit QI Charging Area
13. Charging Pad USB Port
14. QI Wireless Charging Pad
15. Pad LED Indicator
16. USB Charging Cable
17. Micro USB Plug
18. Large USB Plug
17
15
6
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
About your Air Buds with QI Wireless Charging Case
Your Air Buds automatically pair together in stereo and in turn pair with your
Bluetooth device. They are supplied with a Charging Case which is used to store the
Air Buds and will also charge the Air Buds whilst on the move.
The Charging Case can be recharged either via the QI charging pad or by
connecting the USB cable directly to a USB charger using the USB Charging Socket
on the rear of the Charging Case.
Charging the Air Buds
Before use, please ensure that the Air Buds internal rechargeable batteries are fully
charged as follows:
1. Simply place the Air Buds into the Docking Stations
(2) in the Charging Case (1) as shown arrowed right.
2. The Air Bud LEDs (6) on the back of each Air Bud
(arrowed) will illuminate red to show that they are
charging.
3. The Charging Case LED (10) will also light blue to
show the unit is charging the Air Buds.
4. Once the Air Buds are fully charged the Air Bud
LEDs (6) will go out.
5. Press the Charge Button (11) on the Charging Case
(1) to start and stop charging the Air Buds.
If during use, a tone is heard every 10 seconds, this indicates that the
batteries are going flat and Air Buds will require replacing in the Docking Stations
(2) for recharging.
Charging the Charging Case (1)
In order to charge your Air Buds, the built-in battery in the Charging Case (1) will
need to be charged, this can be done in one of two ways:
1. QI
#
Wireless Charging
a. First insert the Micro USB Plug (17) of the USB
Charging Cable (16) into the Charging Pad USB Port
(13) on the rear of the pad.
b. Insert the Large USB Plug (18) on the other end of the
USB Charging Cable (16) into a suitable USB outlet
such as a computer or USB Charger.
c. Place the Charging Case (1) centrally onto the QI
Wireless Charging Pad (14) as shown above right, the
Pad LED Indicator (15) will light green to show it is
charging the Charging Case (1).
The Charging Case LED (10 – arrowed right) will flash to
show that the Charging Case (1) battery is being charged.
7
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
d. Once the Charging Case (1) is fully charged, the Charging Case LED (10) will go
out to show the Charging Case (1) is fully charged and can now be removed and
used.
Pad LED Indicator (3) Information
1. Pad LED Indicator is off – The pad is in standby and no item is on the pad.
2. Pad LED Indicator is illuminated green – the device is being charged and the
Charging Pad is working normally.
3. Pad LED Indicator is flashing – this indicates that a metallic item or non-
compatible device has been placed on the QI Wireless Charging Pad (14).
2. USB Cable Charging
a. Insert the Micro USB Plug (17) of the USB Charging
Cable (16) into the Micro USB DC Charging Port (9) on
the rear of the charging case to charge the internal
battery.
b. Insert the Large USB Plug (18) on the other end of the
USB Charging Cable (16) into a suitable USB charger.
c. The Charging Case LED (10 – arrowed right) will flash to
show the internal battery is charging. Once the battery
is fully charged, the Charging Case LED (10) will go out
showing that the internal battery is fully charged and
the USB Charging Cable (16) can be removed.
Using Your Air Buds with QI Wireless Charging Case
1. Ensure the Air Buds are fully charged as described above.
2. Remove the Air Buds from the Charging Case (1).
3. As they are removed from the base, the Air Bud LEDs (6) will start to flash
alternately red and blue to show they have automatically gone into Bluetooth
pairing mode.
4. Enable the Bluetooth mode on your Phone, Tablet or other Bluetooth
compatible device you are using and set it to search.
5. Select ‘AVS1445’ from the search results found by your device which will now
pair automatically with both the Air Buds.
6. The Air Bud LEDs (6) will flash blue only to show the Air Buds are Bluetooth
connected with your device.
7. Enable the music player on your Bluetooth connected device.
The Earbud Control Buttons (4)
1. To power up the Air Buds, press both the Air Bud Control Buttons (4) for 3
seconds until a chime is heard to show the earbuds have now powered up.
2. To start the music playing, briefly press the Air Bud Control Button (4) on either
Air Bud.
3. To stop the music playing, briefly press the Air Bud Control Button (4) on either
8
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Air Bud.
4. To skip to the next track, press the Air Bud Control Button (4) twice on the Right
Air Bud only.
5. To skip to the previous track, press the Air Bud Control Button (4) twice on the
Left Air Bud only.
6. To power down the Air Buds, press and hold the Air Bud Control Button (4) on
either Air Bud for 3 seconds.
7. Press the Right Air Bud Control Button (4) for two seconds to wake up the Voice
Assistant (if applicable) on the connected device.
If your device is still paired with the Air Buds then they will automatically re-
pair on powering up.
Manual Bluetooth Pairing
1. Power up the Air Buds by pressing and holding the Air Bud Control Buttons (4)
on both Earbuds for 3 seconds. Both Air Bud LEDs (6) will flash alternately red
and blue.
2. Press the Air Bud Control Button (4) twice on either Air Bud, the Air Buds will
now pair with each other. After pairing, one of the Air Bud LEDs (6) will flash red
and blue the other LED will be off.
3. Enable the Bluetooth mode on your Phone, Tablet or other Bluetooth
compatible device you are using and set it to search.
4. Select ‘AVS1445’ from the search results found by your device which will now
pair with the Air Buds.
Unpairing Your Device
1. On your device, unpair with ‘AVS1445’.
2. Replacing both the Air Buds into the Charging Case (1) will also enable them to
unpair with your Bluetooth device.
3. Your device is now completely unpaired with the Air Buds.
Handling Telephone Calls
Answering a Call
1. A call coming in will mute (cut) the music you are listening to.
2. Briefly press either Air Bud Control Button (4) to answer the call.
3. At the end of the telephone call, briefly press either Air Bud Control Button (4)
to end the call and return to the music originally being played.
The callers voice will be heard through the Air Buds and your voice will be
picked up by the built in Microphone.
Rejecting a Call
1. A call coming in will mute (cut) the music you are listening to.
2. Press either Air Bud Control Button (4) for 2 seconds to reject the call.
3. The Air Buds will then return to the music originally being played.
9
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Redialling the Last Call Made
1. Press the left Air Bud Control Button (4) button for 2 seconds to redial the last
number you called.
2. Briefly press either Air Bud Control Button (4) button once to end the call.
Care and Use of your Air Buds with QI Wireless Charging Case
1. Always disconnect the Charging Case (1) from the USB charging supply before
cleaning.
2. Clean the Air Buds and Charging Case (1) with a clean damp cloth. Never clean
with harsh or abrasive cleaners.
3. Do not submerge the Air Buds or the Charging Case (1) in water or any other
liquids.
Technical Specification
Model Numbers
AVS1444 (White) & AVS1445 (Black)
Base Unit Charger Input
DC 5V 500mA
Base Unit Weight
62g
Base Unit Dimensions
57mm (l) 57mm (w) x 30mm (h) Approx.
Drive Unit Size
10mm (dia.)
Drive Unit Impedance
16 ohms
Driver Sensitivity
95dB/W Approx.
Frequency Response
50hz – 20khz
Built in Battery type (Earbuds)
Lithium 35mAh 3.7V
Built in Battery type (Base Unit)
Lithium 400mAh 3.7V
Playing Time
2 – 2.5 hours
Charge Time (Earbuds)
1.5 Hours
Bluetooth Version
5.0
Bluetooth Range
10 metres
Bluetooth Transmission power
≦-3.325dBm
QI Charging Pad Interface
Micro USB
QI Charging Pad Input
5V/2A or 9V/1.67A
QI Charging Pad Output
10W maximum
QI Charging Pad Conversion
≥ 72%
QI Charging Pad Weight
52g Approx.
QI Charging Pad Dimensions
99mm (diameter) x 7mm (h) Approx.
This product conforms to Radio Equipment Directive 2014/53/EU
10
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
11
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-
cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk enter
your postcode to find out your nearest recycling site.
This symbol means batteries and rechargeable batteries may not
be disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
#
Qi and the Qi symbol are trademarks of the Wireless Power Consortium.
#
12
Air Buds with QI Wireless Charging Case
Model No’s. AVS1444 & AVS1445
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Daewoo Electricals is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
WARRANTY
Thank you for purchasing your Daewoo Audio product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo audio product is guaranteed for 1 year from the date of original purchase, with
proof of purchase or receipt. If any defect should occur due to faulty workmanship or material,
your faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
