3 Tier Heated Airer
Model No. HEA1872
User Manual
1
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 Tier Heated Airer
Model No. HEA1872
User Manual
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Heated Airer.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage
• DO NOT install the appliance directly below an electrical
socket.
• DO NOT use this Heated Airer with a programmer, timer,
separate remote-control system or any other device that
switches the heater on automatically, since a fire risk
exists if the Heated Airer is positioned incorrectly.
• DO NOT use this Heated Airer with an extension cable.
• WARNING! This appliance is intended only for drying
textiles washed in water.
• CAUTION — Some parts of this product can become very
hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Close supervision is required when using this appliance
3 Tier Heated Airer
Model No. HEA1872
User Manual
3
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children of less than 3 years should be kept away unless
continuously supervised.
• Children aged from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has been
placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children aged from
3 years and less than 8 years shall not plug in, regulate
and clean the appliance or perform user maintenance.
• DO NOT use this Heated Airer in the immediate
surroundings of a bath, a shower or a swimming pool.
• DO NOT immerse the appliance or its cord in water or any
other liquids.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by a qualified electrician. Improper repairs may place user
at serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
3 Tier Heated Airer
Model No. HEA1872
User Manual
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
If the power cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified after-sales-
service in order to avoid a hazard
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
• Never place the appliance near to flammable material or
high pressure containers. (e.g., Paper, wood, petrol,
solvents, spray canisters etc.)
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area.
• The appliance should not be installed in areas which have
a fire-risk, such as garages, stables or wooden sheds; this
is applicable also for rooms in which highly inflammable
gasses or dust can develop. Danger of fire!!
• Unplug after each use. Grasp the plug, not the cord.
THIS APPLIANCE MUST BE EARTHED
3 Tier Heated Airer
Model No. HEA1872
User Manual
5
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
During the first few minutes of initial use, you may notice a slight odour and
a little smoke. This is normal and will quickly disappear, it is the coating
applied to the heating elements to prevent any corrosion during transit.
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
This symbol provides useful additional information on the use of
this product.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
This symbol indicates that the supply uses an alternating current
mains supply.
3 Tier Heated Airer
Model No. HEA1872
User Manual
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
1. Frame
2. Top Heated Tier
3. Middle Heated Tier
4. Lower Heated Tier
5. On/Off Switch
6. Mains Cable
Before the first time you use your Heated Airer
Remove all packing materials and discard responsibly.
Ensure all parts are present - see Description of parts above.
Check that there is no damage to the mains cable or product.
WARNING! Ensure that the Mains Cable (6) does not get trapped in the airer whilst
unfolding or folding it closed for storage.
1
2
3
5
4
6
3 Tier Heated Airer
Model No. HEA1872
User Manual
7
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Preparing your Heated Airer
1. Place the Heated Airer on solid level surface in a suitable area,
allowing enough space for access around it.
Open the airer Frame (1) by swinging out
the two support legs as shown right:
2. Fold down each half of the Top Heated Tier
(2) until it is locked in the hook and horizontal
as shown below right:
4. Repeat the above process for the
Middle Heated Tier (3) and the Lower
Heated Tier (4) until the Heated Airer
looks as shown right:
3 Tier Heated Airer
Model No. HEA1872
User Manual
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using Your Heated Airer
1. After preparing your Heated Airer, insert the mains plug
into the nearest socket outlet and switch the socket on (if
applicable).
2. Press the On/Off Switch (5) to the
ON ‘I’ position to operate the Heated
Airer, the switch will illuminate and
the rails of the heated tiers will begin
to warm up. Press the switch to OFF
‘O’ position to switch off the airer.
3. After a short time (approximately 5 minutes) the Heated Airer will reach its
operating temperature and is ready for use.
4. After use switch off the Heated Airer by pressing the On/Off Switch (5) to the ‘O’
position, and unplug from the mains.
5. Before storage, allow the unit to cool.
6. Fold up the Heated Airer following the reverse procedure as above and store in a
cool dry place.
Do not overload the Heated Airer, the maximum load per tier is 10kg.
Care and Use of your Heated Airer
• Always disconnect the Airer from the mains power supply and allow to cool
before cleaning.
• Clean outside of the Airer with a clean damp cloth. Never clean with harsh or
abrasive cleaners.
• Do not submerge any part of Airer in water or any other liquids.
Technical Specification
Model Number
HEA1872
Rated Voltage
220-240V ~ 50/60Hz
Rated Power
300W
IP Rating
IP44
Maximum Load
30Kg (10kg per tier)
On/Off Switch
(5) located near
the base of the
Airer
3 Tier Heated Airer
Model No. HEA1872
User Manual
9
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician. Never use a plug with the fuse cover missing.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk or enter your postcode to find out your
nearest recycling site.
3 Tier Heated Airer
Model No. HEA1872
User Manual
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the discretion
of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
