1
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 - 4 Important Safety Instructions for Proper Use
5 Explanation of Symbols
5 Before the First Time You Use Your Gaming Chair
6 Description of Parts
7 Charging Your Gaming Chair
7 Setting Up Your Gaming Chair
7 A. Bluetooth Pairing the Gaming Chair with Your Device
8 Notes on Bluetooth Pairing
8 B. Using Your Gaming Chair wired with a Games Console
9 C. Using Your Gaming Chair with Second Gaming Chair
9 D. Connecting Your Gaming Chair wired to a TV, Hi Fi, etc.
10 E. Using Your Gaming Chair wired with an Mp3 Player, Handheld Game, etc.
11 F. Using Headphones with Your Gaming Chair
11 Care and Maintenance
11 Technical Specification
12 Recycling Information
13 Customer Support
Back Page Warranty Information
3
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure
the user manual is included when passing the product on to any
third parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
Whilst using electrical appliances, basic safety precautions should
always be followed:
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to property
or persons.
The manufacturer or vendor cannot be held liable for damages or
injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Gaming Chair.
• Always use this appliance on a solid, level, non-
flammable surface.
• Ensure that there is clearance of at least 100mm (4
Inches) minimum around the Gaming Chair for sufficient
ventilation.
• Ensure that any ventilation openings are not covered
with items, such as newspapers, table-cloths, curtains,
etc.
• No naked flame sources, such as lighted candles, should
be placed on the Gaming Chair.
• DO NOT position the Gaming Chair close to sources of
heat such as radiators, heaters, other electronic
equipment, etc.
• The Gaming Chair shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
• DO NOT immerse the Gaming Chair in water or any
other liquids.
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
• DO NOT leave the Gaming Chair unattended during use.
• Close supervision is required when using this Gaming
Chair near children.
• Never leave this Gaming Chair within reach of children.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• Repairs to electrical appliances should only be
performed by qualified personnel. Improper repairs may
place the user at serious risk.
• DO NOT operate this appliance after a malfunction or
after being dropped or damaged in any way.
• DO NOT use any accessories or attachments with this
product other than those supplied or recommended by
supplier.
• DO NOT use this product for anything other than its
intended use.
• DO NOT push objects into any openings as damage to
the product and/or electric shock may occur.
• Indoor use only.
• DO NOT expose to direct sunlight, moisture, or extreme
temperatures. Adult supervision is required for set-up.
• DO NOT use on slippery or uneven flooring.
• DO NOT use this product on polished, laminated or
hardwood floors as the chair may cause scratching.
• Keep hands clear of the Folding Seam (5) whilst opening
and closing the Gaming Chair.
WARNING! Pay attention to your surroundings whilst using
the Gaming Chair. Caution is needed when rocking back and forth,
keep hands and feet clear of the edges of the chair.
5
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This symbol provides useful additional information on the
use of this product.
This symbol identifies voltage and the current rating for
direct current.
This symbol means batteries and rechargeable batteries
may not be disposed of with household waste!
As the end user you are required by law to bring all
batteries and rechargeable batteries to a collection point
run by the Local Authority or to a retailer or visit
www.recycle-more.co.uk, so that they can be disposed of
in an environmentally friendly manner.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not
be disposed of with normal household waste and not sent
to landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk, enter your
postcode to find out your nearest recycling site.
WARNING!
Before the first time you use your Gaming Chair
Remove all packing materials and discard responsibly.
Check that all the parts are present with your Gaming Chair see ‘Description of
Parts’ below.
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
Description of Parts – General
Description of Parts – Control Panel & Accessories
2
1
1. Loudspeakers
2. Chair Back
3. Seat
4. Control Panel
5. Folding Seam
6. Folding Seam Locking Strap (Rear)
7. LED Indicator
8. On/Off/Volume Control
9. Line Input
10. Line Output
11. 3.5mm Jack to Jack Lead
12. Audio Adaptor
13. USB Cable (Behind Zip Inside Folding Seam)
14. Large USB Plug
7
8
11
12
4
3
5
10
1
6
9
13
14
7
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Charging Your Gaming Chair
Before using your Gaming Chair ensure that the internal battery is fully charged
as follows:
1. Remove the USB Cable (13) from the cable storage compartment behind the
Zip Inside the Folding Seam (5) and fully unravel.
2. Insert the Large USB Plug (14) into a suitable USB charger rated to at least 1
Amp. (NB most USB chargers are rated 1 Amp or above). The internal battery
will begin to charge.
3. Whilst the chair is on charge, the LED Indicator (3) will light red, once the
internal battery is fully charged the LED Indicator (3) will go out.
Charging time will take approximately 4 hours using a 1A USB charger– remove
the charging cable once the chair is fully charged.
The Gaming Chair can be used normally during charging. Also, once fully
charged, the chair will operate for up to 5 hours on its internal battery.
Setting Up Your Gaming Chair
• Place your chair in a suitable position ensuring that it is stable and level. Do not
place the chair on polished, laminated or wooden floors as scratching may
occur.
• If you are using the Bluetooth mode, ensure that the Gaming Chair is positioned
no more than 30 feet (9 Metres) away from your Bluetooth device.
• Open the chair by lifting the Chair Back (2) up until upright and then secure the
Chair Back (2) in position by pressing the Velcro Folding Seam Locking Strap (6)
on the rear of the chair down.
WARNING! Keep hands clear of the Folding Seam (5) whilst opening the chair.
Using Your Gaming Chair
A. Bluetooth Pairing the Gaming Chair with Your Device
1. Rotate the ON/Off/Volume Control (8) clockwise to power up the chair.
2. After a delay of three seconds, the LED Indicator (7) will flash green and a chime
will sound to show the chair has powered up and is in Bluetooth mode ready to
pair with your device.
3. Enable the Bluetooth mode on your Phone, Tablet or other Bluetooth enabled
device you are using and set it to search.
4. Select ‘AVS1573’ from the search results found by your device. Once the device
has paired with the chair the LED Indicator (7) will light up green continuously.
The chair is now ready for use.
5. Rotate the ON/Off/Volume Control (8) clockwise to increase the volume level
and anticlockwise to decrease the volume.
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
WARNING! Pay attention to your surroundings whilst using the Gaming Chair.
Caution is needed when rocking back and forth, keep hands and feet clear of the
edges of the chair.
Notes on Bluetooth Pairing
• Once you have paired your device with the chair, the chair will ‘remember’
your device and pair automatically the next time they are used, just select
‘AVS1573’ from your paired devices list.
• If another Bluetooth device is to be used with the chair, it is recommended that
the first device is unpaired from the chair by switching the Bluetooth mode off
on the device.
If there is no Bluetooth connection or audio played for approximately 4
minutes the chair will automatically switch off. Switch the ON/Off/Volume
Control (8) off and then back on to power the chair back up.
B. Using Your Gaming Chair wired with a Games Console
Playback the sound of a games console through your Gaming Chair as follows:
1. Rotate the ON/Off/Volume Control (8) clockwise to power up the chair.
2. After a delay of three seconds, the LED Indicator (7) will flash green and a chime
will sound to show the chair has powered up.
3. Insert the 3.5mm Jack to Jack Lead (11) into the Line Input socket (9) on the
Control Panel (4). The LED Indicator (7) will now flash slowly to show the chair
has automatically gone into line input mode.
4. Connect the other end of the 3.5mm Jack to Jack lead (11) to the Audio
Adaptor (12).
5. Connect an RCA/Phono cable (not included) from the Games Console to the red
and white sockets on the Audio Adaptor (12) as below:
4
11
12
9
B
7
9
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
C. Using Your Gaming Chair with a second Gaming Chair
Your Gaming Chair can be connected to a second gaming chair for Multi Player
gameplay so the same sounds come out of both chairs as follows:
1. Rotate the ON/Off/Volume Control (8) clockwise to power up the chair.
2. After a delay of three seconds, the LED Indicator (7) will flash green and a chime
will sound to show the chair has powered up.
3. Insert the 3.5mm Jack to Jack Lead (11) into the Line Output socket (10) on the
Control Panel (4).
4. Connect the other end of the 3.5mm Jack to Jack lead (11) to the line input of
the second Gaming Chair as below:
Note, the internal speakers in the chair will automatically mute when a jack
plug is inserted into the Line Output socket (10).
D. Connecting Your Gaming Chair wired to TV, Hi Fi, etc.
Your Gaming Chair can be connected to a Hi Fi, TV or other audio device equipped
with RCA/Phone Socket outlets so the sound maybe reproduced through the chair
as follows:
1. Rotate the ON/Off/Volume Control (8) clockwise to power up the chair.
2. After a delay of three seconds, the LED Indicator (7) will flash green and a chime
will sound to show the chair has powered up.
3. Insert the 3.5mm Jack to Jack Lead (11) into the Line Input socket (9) on the
Control Panel (4). The LED Indicator (7) will now flash slowly to show the chair is
in line input mode.
4. Connect the other end of the 3.5mm Jack to Jack lead (11) to the Audio
Adaptor (12).
5. Connect an RCA/Phono cable* (not included) to the red and white sockets on
the Audio Adaptor (12).
6. Connect the other end of the RCA/Phone cable* to the audio output on the Hi
Fi, TV or other audio device that you are using as below:
4
10
11
C
7
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
*Another cable maybe required if the RCA/Phono cable (not supplied) shown
in the diagram above, is not compatible with the external audio device.
E. Using Your Gaming Chair wired with an Mp3 Player, Handheld Game, etc.
Your Gaming Chair can be connected to a Smart Phone, Mp3 Player or Handheld
Game equipped with a 3.5mm jack socket so that the sound maybe reproduced
through the chair as follows:
1. Rotate the ON/Off/Volume Control (8) clockwise to power up the chair.
2. After a delay of three seconds, the LED Indicator (7) will flash green and a chime
will sound to show the chair has powered up.
3. Insert the 3.5mm Jack to Jack Lead (11) into the Line Input socket (9) on the
Control Panel (4). The LED Indicator (7) will now flash slowly to show the chair is
in line input mode.
4. Connect the other end of the 3.5mm Jack to Jack lead (11) to the 3.5mm Jack
Socket of the Smart Phone, Mp3 Player, Handheld Game or other audio device
that you are using as below:
*
4
9
12
11
External
Audio
Device
11
4
9
D
E
7
7
11
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
F. Using Headphones with Your Gaming Chair
1. Rotate the ON/Off/Volume Control (8) clockwise to power up the chair.
2. After a delay of three seconds, the LED Indicator (7) will flash green and a chime
will sound to show the chair has powered up.
3. Insert the 3.5mm Jack to Jack Lead (11) into the Line Output socket (10) on the
Control Panel (4).
4. Insert the plug at the other end of the lead into the jack socket on the
Headphones as below:
Note, the internal speakers in the chair will automatically mute when a jack
plug is inserted into the Line Output socket (10).
Care and Maintenance
• Clean outside of the Gaming Chair with a clean damp cloth. Never clean with
harsh or abrasive cleaners.
• Do not submerge the Gaming Chair in water or any other liquids.
Technical Specification
Model Number
AVS1573
Power Supply/Charger Requirement
DC 5V @1.0A
Audio output power
2x 2W RMS
Speaker Units
2x 3” Full Range Drivers
Speaker Impedance
4 Ohm
Unpacked Weight
7 Kgs Approx.
Maximum User Weight
120kgs
Dimensions (Approx.)
76.5cm (h) x 43.5cm (w) x 83cm (d) Approx.
Operation temperature
0°C to + 40°C
Built in Battery Type
7.4V Li-ion 2000mAh
Charging Time
4 Hours (approx.)
Playback Time
Up to 5 Hours
Bluetooth Frequency Range
2402 - 2480MHz
Bluetooth Transmission power
≦-3.325dBm
This product conforms to Radio Equipment Directive 2014/53/EU
11
10
F
4
7
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products at
the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling advice
or visit www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site
This symbol means batteries and rechargeable batteries may not be
disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local Authority
or to a retailer or visit www.recycle-more.co.uk, so that they can be
disposed of in an environmentally friendly manner.
13
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Rechargeable Rocker Gaming Chair with Speakers
Model No. AVS1573
User Manual
WARRANTY
Thank you for purchasing your Daewoo Audio product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo audio product is guaranteed for 1 year from the date of original purchase, with
proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty product should be returned to the place of purchase, replacement or refund
is at the discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to
the conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
