1
Gaming Headphones
Model No. AVS1497
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Gaming Headphones
AVS1497
User Manual
*Please refer to the warranty section for terms of your extended guarantee.
*
2
Gaming Headphones
Model No. AVS1497
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should always
be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating instructions before
using this product.
• Before using your product, visually check that the unit is intact and has
not suffered any transit damage.
• Only connect items as described in this manual, incorrect connections
may cause permanent damage to the product.
• Do not operate this product after a malfunction or after being dropped
or damaged in any way.
• Never allow children to play with the product. Small parts and cables
may be a choking hazard.
• Do not allow cables to hang over sharp edges or come in contact with
hot surfaces.
• This product is intended for household use only and should not be used
for industrial or commercial purposes.
• Do not use this product for anything other than its intended use.
• Do not immerse the product in water or any other liquids.
• Do not expose the product to moisture, rain or humidity, they are not
waterproof.
• Never clean the product with solvents or harsh or abrasive cleaners.
• Do not attempt to dismantle the product, it does not contain any user
serviceable parts.
• Whilst not in use, store the product in a cool dry place free from
extreme temperatures, humidity or dust.
3
Gaming Headphones
Model No. AVS1497
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Your Gaming Headphones
Using Your Gaming Headphones
Connect your headphones in one of the following ways:
Automatically
adjustable headband
Padded
Earpiece(s)
Flexible
Microphone
3.5mm
Headphone plug
PC Headphone
adaptor
Volume Control
PC
1. Plug the 3.5mm
plug on the end of the
Headphone lead into
the pc adaptor as in
the diagram below:
2. Insert the Green 3.5mm Jack into the
Green coloured Headphone socket on your
PC.
Insert the Pink 3.5mm Jack into the Pink
coloured Microphone input socket on your
device as in the diagram below:
4
Gaming Headphones
Model No. AVS1497
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Plug the 3.5mm plug on the end of
the Headphone lead into the
Headphone socket of your Laptop as
shown right:
Plug the 3.5mm plug on the end of
the Headphone lead into the
Headphone socket of your PS4
controller as shown right:
Plug the 3.5mm plug on the end of the
Headphone lead into the Headphone socket
of your Xbox controller as shown right:
Laptop
PS4 Controller
Xbox One/S Controller
2015 model onwards shown. Earlier models will require a Microsoft adaptor.
5
Gaming Headphones
Model No. AVS1497
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Gaming Headphones – Wearing your headphones:
Care and Use of your Gaming Headphones
• Always unplug the headphones before cleaning.
• Clean the outside of the headphones with a clean damp cloth. Never clean with
harsh or abrasive cleaners.
• Do not submerge the headphones in water or any other liquids.
Technical Specification
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Model Number
AVS1497
Impedance
32Ω
Sensitivity
103 ±3dB
Frequency Response
20Hz – 20Khz
Microphone Dimensions
4mm (dia.) x 1.5mm
Operating Current
≤35mA
Connectors
4 pole 3.5mm Jack Plug, USB Plug
Weight (approx.)
340g
1. Insert the USB plug into a USB socket to
illuminate the Headphone logos.
2. Place the Headphones on your Head
until the headband automatically
adjusts and they sit comfortably.
3. Adjust the flexible Microphone so that
it is level with your mouth.
4. Adjust the Volume control as desired
The Headphones are now ready to use.
2
3
1
4
6
Gaming Headphones
Model No. AVS1497
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
7
Gaming Headphones
Model No. AVS1497
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo Audio product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo audio product is guaranteed for 1 year from the date of original purchase, with
proof of purchase or receipt. If any defect should occur due to faulty workmanship or material,
your faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo Electricals is a registered trademark.
Imported by Eurosonic Group Ltd. M3 1JS UK
EU Rep: Euromagppie Ireland Ltd. D05 X006
Produced under licence by ESG Ltd
www.esgltd.com
