1
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Contents
Page No.
2
Contents
3
3
6
Reading and Storing the User Manual
Important Safety Instructions for Proper Use
Additional Safety Information
7 Explanation of symbols
8 Description of Parts
8 Preparing for Use
9 Charging Your Food Processor
9 Assembling Your Food Processor
10 Using Your Food Processor
10 Grating/slicing tool
1
1
Using the
C
hopping
B
lade
12 Indicator lights
12 Battery life during use
12 Charging Indicators
12
Overload
I
ndicat
ion
12
Care and
M
aintenance
13 Cleaning tips
13 To store
13 Technical specification
13
Customer support
14 Recycling information
Back Page Warranty information
3
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Read and familiarise yourself with all operating
instructions before using this Food Processor.
Before plugging your unit into the power supply, visually
check that it is intact and has not suffered any transit
damage.
Do not immerse this appliance in water or any other
liquids.
Close supervision is required when using this appliance
near children.
Never leave this appliance within reach of children.
This appliance shall not be used by children.
Keep the appliance and its cable out of the reach of
children.
Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children.
Do not leave the appliance unattended during use.
Do not leave the appliance unattended whilst connected
to the mains supply.
Always use this appliance on a solid, level, non-flammable
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
surface.
Protect the unit from moisture whilst using this appliance
outdoors.
It is imperative to unplug the mains cable after the
appliance has been used, before it is cleaned and whilst
being repaired.
Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
If the mains cable is damaged, it should only be replaced
by the manufacturer or a suitable qualified after sales-
service in order to avoid a hazard.
Do not operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
Do not allow the mains cable to hang over sharp edges or
come in contact with hot surfaces.
Do not use this appliance for anything other than its
intended use.
Do not push objects into any openings as damage to the
appliance and/or electric shock may occur.
CAUTION: The blade is very sharp, handle the motor unit
with care.
DO NOT ATTEMPT TO SHARPEN THE BLADES
DO NOT use the appliance if the blade assembly is bent or
damaged.
DO NOT overfill the bowl.
DO NOT operate the appliance whilst it is empty.
DO NOT attempt to override the safety interlock device as
injury may occur.
This appliance is intended for household use only and
should not be used for industrial or commercial purposes.
Switch off the appliance and disconnect from the supply
before changing accessories or approaching parts that
move in use.
5
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Do not use the Food Processor for crushing or chopping
hot or boiling foods.
Do not use the Food Processor to crush or chop bones or
frozen foods (with the exception of ice cubes and frozen
berries), coffee beans, grains or nutmeg.
Non food substances should also not be processed.
CAUTION: DO NOT PROCESS HOT FOODS OR LIQUIDS.
If the appliance overheats a thermal switch will activate
and shut off the motor. To reset, unplug the appliance
and allow it to cool for 30 minutes before using again.
This product is intended for household use only. Do not
use this appliance for anything other than its intended
use.
WARNING: Exercise caution when attaching or removing
attachments from the Food Processor and ensure the
appliance is turned off and unplugged whilst fitting
attachments.
NOTE: The Food Processor should not be used for more
than 1 minute intervals. Make sure you allow a 5 minute
rest period offer every 1 minute cycle.
CAUTION: Always remove the USB cable from the Hand
Blender before use.
DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
the supplier.
DO NOT use this appliance for anything other than its
intended use.
DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
Switch off the appliance and disconnect from the supply
before changing accessories or approaching parts that
move in use.
Grasp the plug, not the cord.
DO NOT touch the blades whilst the Food Processor is
connected to the mains.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Wash the blades in warm soapy water, rinse and dry
thoroughly.
CAUTION: the blades on this Food Processor are very
sharp; extreme caution should be taken when cleaning.
Do not insert other tools than the pusher (9) into the
filling tube (1) during processing.
The bowl (4) is not microwave-proof.
Must let hot ingredients cool down before you chop them
or pour them into the chopping bowl (max. temperature
30⁰C).
Cut large ingredients into pieces of 2cm before you
process them.
Additional Safety Information
PLEASE NOTE: Before use, ensure that the Food Processor is
used in an open, well ventilated area well away from other
appliances and other obstructions.
Do not use the Food Processor in front of, near or below
combustible materials such as plastics, curtains or cupboards,
etc.
Leave at least 10cm minimum free space between the
appliance and any other surfaces.
Do not place anything on top of the appliance.
7
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk to find your nearest recycling point.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
1
1
2
4
3
5
13
14
Description of Parts
Preparing For Use
Carefully unpack the motor housing unit and all parts. Remove any tape, labels
or packaging materials.
Wash all product attachments carefully except for the motor housing unit with
warm, soapy water. Rinse and dry thoroughly.
Wipe exterior surfaces of the motor housing with a soft, moist cloth to remove
dust particles collected during packing and handling.
NEVER IMMERSE THE MOTOR HOUSING, USB CHARGING CABLE IN WATER
OR ANY OTHER LIQUID.
Ensure all parts are properly assembled and in place before use.
12
8
7
1. Pusher
2. Funnel
3. Processor Bowl Lid
4. Processor Bowl
5. Chopper Blade
6. Motor Housing Unit
7. Power Indicator Lights
8. USB Charging Port
9. Puree Button
10. Chop Button
11. Non-Slip Feet
12. USB Charging Cable
13. Disc Pivot
14. Grating/Slicing Disc
6
10
9
11
9
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Charging Your Food Processor
1. Open the USB Charging Port (8) on the Motor Housing Unit (6). Attach micro
end of USB Charging Cable (12) to the motor housing.
2. Attach the USB connector (larger end) into a suitable USB charger rated to at
least 1 Amp. (NB most USB chargers are rated 1 Amp or above). The internal
battery will begin to charge.
3. The Power Indicator Lights (7) will flash while charging. The lights will stop
flashing once the unit is fully charged. See indicator Light section for details.
NB: The unit is shipped with approximately 30% charge in the batteries. One or
two lights will be illuminated during use. It is recommended to fully charge before
first use for best performance.
4. It will approximately 2.5 hours to fully charge the unit.
WARNING! The Blades are sharp great care should
be taken.
Assembl
ing
Y
our Food Processor
Safety Lock System
This appliance is equipped with a safety lock system
which will prevent the motor starting without correct
installation of the bowl and it’s lid.
1. Place the Motor Housing Unit (6) on a solid, level, non-
flammable surface.
2. Place the Processor Bowl (4) onto the Motor Housing
Unit (6), and turn clockwise until it clicks into place.
3. Place the Chopper Blade (5) over the centre piece in
the Processor Bowl (4), push down gently until it clicks
into place.
4. Fit the Processor Bowl Lid (3) onto the Processor Bowl
(4). To lock the lid, turn clockwise until it clicks into
place.
The lid has an activator to trigger the safety lock
system and must be fitted and locked into place onto
the Processor Bowl (4), before placing onto the
Housing Unit (6).
5. Place the Pusher (1) into the Funnel (2).
1
2
3
5
4
6
Fig 1
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Using Your Food Processor
All in one Food Chopper
Chopping, slicing, shredding and making puree.
2 Speed Settings
Your Food Processor will do all the hard work for you. One machine to chop,
mix, grate, shred, slice in one. This compact chopper offers a small and
speedy solution to laborious food prep tasks.
Dual Lock Protection
To protect your safety while working, the food processor has a double lock
protection that will only work if the bowl is locked to the base and the top lid
is locked to the bowl. If you want to add food during work, add it from the
Filling tube.
Grating/Slicing tool
Use the Slicing tool to slice cucumbers, onions, mushrooms, apples, carrots,
radishes, raw potatoes, courgettes, cabbage.
Use the grating tool to grate apples, carrots, radishes, raw potatoes, beetroot,
cabbage, cheese (soft to medium).
1. Place the Processor Bowl (4) onto the Motor Housing Unit (6) and turn
clockwise until it clicks into place.
2. Place the Grating/Slicing Disc (14) onto the Disc Pivot (13) and snap into
position.
WARNING! The Blades are sharp great care should be taken.
3. Place the Grating/Slicing Disc (14) and Disc Pivot (13) onto centre pin of the
bowl (with the desired tool facing up) and give a turn to lock into place.
4. Fit the Processor Bowl Lid (3) onto the Processor Bowl (4). To lock the lid,
turn clockwise until it clicks into place.
5. Put the food to be processed into the Funnel (2). Never reach into the filling
tube when the appliance is switched on. Always use the pusher to feed in
food.
6. Press and hold either the Puree Button (9) or the Chop button (10) to operate
your food processor. After use, wait until all the parts have stopped before
disassembling.
7. Remove the Processor Bowl Lid (3) by turning anti-clockwise and lifting.
8. Remove the Grating/Slicing Disc (14) before removing the processed food.
9. Carefully remove the Disc Pivot (13) from the Grating/Slicing Disc (14) by
pushing it up at the protruding end.
DO NOT insert any tools other than the Pusher (1) provided into the Funnel (2).
IMPORTANT: Always use the pusher when feeding food into the funnel, never
push with your fingers.
11
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Using the Chopping Blade
Divide large amounts of food into small portions for processing. This chopper has
two speeds, Puree and chop. When you release the button, the chopper will stop.
Watch carefully to avoid over processing, as most food chopping takes less than 6
seconds. Again, when you release the button, the chopper will stop. If the
chopper fails to operate, check to ensure that the container and lid are properly
locked into place. Wait for the blade to stop before removing the lid. Lift the
blade out before emptying the contents of the container.
1. Assemble the Food Processor as in Fig 1.
2. Remove the Processor Lid (3).
3. Place the ingredients into the Processor Bowl (4).
4. Place the Processor Lid (3) on to the Processing Bowl (5) and insert the Pusher
(1), turn clockwise until its locks into place.
5. Press either the Puree Button (9) or the Chop button (10) to operate your food
processor. For a coarser finish, press and hold the Chop button (10) for the
desired time. For a smoother, more processed finish, press and hold the Puree
Button (9) for the desired time.
6. Further ingredients can be added whilst processing by removing the Pusher (8)
and feeding down the Funnel (7).
IMPORTANT: Always use the pusher when feeding food into the funnel, never
push with your fingers.
7. When processing is complete, hold the Motor Housing Unit (6) and grasp the
bowl handle, turn anti-clockwise and lift to release it.
8. Remove the lid by turning anti-clockwise and carefully remove the Chopper
Blade (5) before removing the ingredients.
The lights will extinguish as the battery life reduces. A fully charged unit will show
all three lights. When only the lowest light is illuminated and flashing, this
indicates that the unit needs to be charged.
CAUTION: Do not use the blender for longer than 1 minute continuously. After 1
minute of continuous use, the unit may become over-heated. Allow the unit to
rest for at least 5 min. before resuming use.
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Indicator Lights
The motor housing indicator lights provide feedback for different situation.
Battery Life During Use:
As the motor housing is used and the battery begins to drain during performance,
the Power Indicator Lights (7) will extinguish in sequence from the top to the
bottom to indicate how much battery capacity is left.
66% to 100% of capacity: Lights 1, 2 and 3 will illuminate.
33% to 65% of capacity: Light 1 & 2 will illuminate.
20% to 30% of capacity: Light 1 will illuminate.
If less than 20% of capacity: Light 1 flashes and the unit needs to be charged.
Charging Indicators:
Indicator lights will also provide feedback during the charging process:
If battery capacity is less than 33%, Lights 1, 2 and 3 will flash while charging.
If battery capacity is within 33%-65%, Light 1 will illuminate and Lights 2 and
3 will flash.
If battery capacity is within 66%-99%, Lights 1 and 2 will illuminate and only
Light 3 will flash.
If battery capacity is greater than 99%, Lights 1, 2 and 3 will illuminate.
Overloading Indication:
Note: The motor housing has an automatic protection system that will not allow
overloading. If the load is too large, the unit will automatically shut off. If the unit
senses an overload situation, the Power Indicator Lights (7) will flash 5 times and
the unit will turn Off. Release the Puree Button (9) or the Chop button (10) and
the Power Indicator Lights (7) will turn off. Reduce the load on the Food
Processor, allow it to rest for more than 15 minutes and then resume use.
Do not expose a battery pack or appliance to fire or excessive heat.
Exposure to fire or temperatures above 130⁰C may cause an explosion.
Care and Maintenance
CAUTION:
Unplug
the USB Charging Cable (12) from the Food Processor before
cleaning.
Wash the attachments in warm soapy water and dry thoroughly.
Clean the outside of the motor housing with a clean damp cloth. Never clean
with harsh or abrasive cleaners.
Do not submerge the Motor Housing Unit in water or any other liquids.
WARNING! DO NOT CLEAN ANY PART OF YOUR FOOD PROCESSOR IN A
DISHWASHER. WASH IN WARM SOAPY WATER AND DRY THOROUGHLY.
13
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Cleaning Tips
To ease washing it is advised to rinse parts immediately after mixing.
Use a small brush (not supplied) to remove particles lodged in the
attachments.
To Store:
Be sure all parts are clean and dry before storing. Never store it while it is wet.
The unit can be stored for up to 3 months with a fully charged state. If storing for
longer than 3 months the unit should be charged before next use.
Store in a dry area in an ambient temperature of 5⁰C - 35⁰C.
Technical Specification
Model no.
SDA
26
51
Battery
2
0
00mAh Li
-
Ion
Rated Power
200W
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling
advice visit www.recycle-more.co.uk enter your postcode to find your
nearest recycling site.
This symbol means batteries and rechargeable batteries may not
be disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
15
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Food Processor
Model no: SDA2651
User Manual
WARRANTY
Thank you for purchasing your Cordless Pro Food Processor
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition
to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your faulty
vacuum should be returned to the place of purchase, replacement or refund is at the discretion of the
retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
