1
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety
instructions. Failure to do so may result in personal injury or
damage to the product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Microwave Oven.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Close supervision is required when using this appliance
near children.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children unless they are older than 8 and
supervised.
• Keep the appliance and its cord out of reach of children
less than 8 years.
3
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT touch hot surfaces. The outer surfaces are
liable to get hot during use. Always use the handles
and knobs.
• DO NOT immerse the appliance or its cord in water or
any other liquids.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst
connected to the mains supply.
• Always use this appliance on a solid, level, non-
flammable surface.
• DO NOT use this appliance outdoors.
• DO NOT use this Microwave Oven with a programmer,
timer, separate remote-control system or any other
device that switches the appliance on automatically.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user
at serious risk.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the power cable is damaged, it should only be replaced
by suitable qualified personnel in order to avoid a hazard.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• DO NOT run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
• This appliance is intended for household use only and
4
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come in contact with Cupboards, Curtains, wall
coverings, clothing or other flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• CAUTION Do not overcook food.
• Metallic containers for food and beverages are not
allowed during microwave cooking.
• When heating food in plastic containers or paper
containers, keep an eye on the oven due to the possibility
of ignition.
• The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
• This appliance shall not be cleaned with a steam cleaner.
• The microwave oven is intended to be used free-
standing.
• DO NOT place this microwave into a cabinet.
• CAUTION Remove wire twists from paper and plastic
bags before placing in the oven.
• DO NOT heat oil or fat for deep frying in the oven as the
temperature of the fat can’t be controlled.
• After use wipe the waveguide cover with a damp cloth,
followed by a dry cloth to remove any food splashes and
grease. Built up grease may overheat and smoke or ignite.
• If materials inside the oven smoke or ignite, keep the
door closed, turn oven off and disconnect the power
supply in order to stifle any flames.
5
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• WARNING! Liquids and other foods must not be
heated in sealed containers since they are liable to
explode; Baby bottles fitted with a screw cap or teat are
considered sealed containers.
• Liquids should be heated in a wide mouthed container
and left for a short period after the heating cycle to avoid
possible hazards such as delayed eruptive boiling of the
liquid. Therefore, care must be taken when handling the
container.
• Potatoes, sausage and other skinned foods should be
pierced before heating.
• Eggs in their shell and whole hard-boiled eggs should not
be heated in microwave ovens since they may explode,
even after microwave heating has ended.
• Only use utensils suitable for use in a microwave oven.
• DO NOT store food or other items in the oven.
• DO NOT operate the oven without any food or liquid
inside, this may damage the oven.
• WARNING! If the door or door seals are damaged or
if the oven has malfunctioned, the oven must not be
operated until it has been repaired by a competent
person. It is hazardous for anybody other than a suitably
qualified person to carry out any service or repair that
involves the removal of a cover which gives protection
against exposure to microwave energy.
• This microwave oven is intended for the heating of food
and beverages. The drying of clothes, heating of warming
pads slippers, sponges and cloths may lead to risk of
injury, ignition and fire.
• The oven should be cleaned regularly and any food
deposit removed.
• Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
6
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Group 2 Class B appliance
• Group 2 ISM equipment: group 2 contains all ISM
equipment in which radio-frequency energy is
intentionally generated and/or used in the form of
electromagnetic radiation for the treatment of material,
and EDM and arc welding equipment.
• Class B equipment is equipment suitable for use in
domestic establishments and in establishments directly
connected to a low voltage power supply network which
supplies buildings used for domestic purposes.
• This product internal light source LED light on < 60lm.
Installation
• Select a level surface no less than 85cm (33 inches) from the floor,
that provides enough space for the outlet vents.
• A minimum clearance of 5cm (2 inches) is required between the oven
and any adjacent wall, with a minimum clearance of 10cm (4 inches)
between the rear of the microwave and the wall.
• Leave a minimum clearance of 20cm (8 inches) above the oven
7
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating
current mains supply.
This symbol indicates that the surface gets hot and care must be
taken.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
8
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Door Viewing Mirror window 6. Waveguide Cover
2. Door catches 7. Control Panel
3. Turntable 8. Grill Heating Element
4. Motor Spindle 9. Grill Rack
5. Turntable Support Ring
Description of Parts
The door must be fully closed in order for the Microwave to operate. The
door operates a safety interlock mechanism which prevents the unit from
operating whilst the door is open.
WARNING! The waveguide cover (6) should never be removed.
1
2
3
4
5
6
7
8
2
9
9
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
LED Display
Displays cooking time, power, mode indicators
and clock time.
Microw.
Press to select in 5 power levels, from 100P,
80P, 50P, 30P and 10P.
Defrost/Clock
Press to use the defrost function or set the clock.
Menu
Press to select pre-set program.
Grill
Press to use the Grill function.
Reheat
Press to use the Reheat function.
STOP/lock
Press this button to stop or cancel the setting.
Hold for 3 seconds to set the Child Lock
function.
START/+30sec
Press to start cooking instantly.
Time/Weight
Rotate the control to set cooking time or
weight.
Description of Parts – Control Panel
The door of the microwave oven must be fully closed in
order for it to operate, this is due to a safety interlock between the locking
mechanism and the control panel.
Place the turntable ring in first, fit the turntable onto the rotating turntable
support and make sure it is geared in properly
Never remove the waveguide cover
Make sure the turntable support is correctly located
10
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
10. Microwave Icon
11. Defrost Icon
12. Grill Icon
13. No Function
14. No Function
15. Countdown
16. Child Lock
17. MENU auto function
18. Reheat Icon
19. Weight
Description of Parts – LED Display
Using Your Microwave Oven
1. Place the Microwave Oven on a solid level, heat resistant surface, ensure that
the ventilation outlets are not obstructed.
2. Before first use, open the door and place the Turntable Support Ring (5) on the
base of the oven as shown in the diagram above.
3. Place the glass Turntable (3) onto the Motor Spindle (4).
Rotate the Turntable a little until the notches in the turntable drop onto the
Motor Spindle (4).
4. Insert the mains plug into the nearest socket.
5. The display will light up and show 1.00.
Setting the Clock
1. Press the Defrost/Clock button for 3 seconds to set the clock.
2. Rotate the Time/Weight control to set the hour.
3. Press the START/+30sec button to confirm the hour.
4. Rotate the Time/Weight control to set the minutes.
5. Press the START/+30sec button to confirm the minutes.
If the microwave is unplugged from the mains supply, the clock will have to
be reset.
10
11
12
13
14
15
16
17
18
19
11
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Microwave Cooking
Place the food onto a suitable microwavable plate or container and place onto
the Turntable (3).
1. In standby mode, press the Microw. button repeatedly to set the power level.
2. Rotate the Time/Weight control to set the cooking time. The time range can be
set between 10 seconds and 60 minutes.
3. Press the START/+30sec button to start cooking.
Number of Power Level button presses
Power Level
LED Display
Once
100%
100P
Twice
80%
80P
3 times
50%
50P
4 times
30%
30P
5 times
10%
10P
When cooking has finished, 3 beeps will be heard and the display will show
End and beep every 2 minutes until the oven door is opened or START/+30sec
button is pressed.
The cooking time can be adjusted in the following increments:
0-5 minutes: in 10 second increments
5-10 minutes: in 30 second increments
10-60 minutes: in 1 minute increments
Express Cooking
Use this feature to program the oven to microwave food at 100% power
conveniently. In standby mode, press the START/+30sec button repeatedly to set
cooking time (each press to increase 30 seconds). The oven starts working
automatically at full power.
Defrost
There are 2 defrost settings: dEF1 and dEF2.
• dEF1 defrosts food by weight, from 100g to 1500g.
• dEF2 defrosts food by time, from 10 seconds to 60 minutes.
1. Press the Defrost/Clock button to select either dEF1 or dEF2.
2. Rotate the Time/Weight control to select the weight or the time.
3. After selecting the weight or time for defrosting, press the START/+30sec
button to start defrosting.
4. Once defrosting has finished, 3 beeps will be heard and the display will show
End.
If you have chosen option dEF1 (defrosting by weight), during the defrosting
cycle the oven will beep to prompt you to turn food over.
12
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Defrosting Tips
Microwaves penetrate approximately 4cm into most foods, to maximise the
defrosting effect the following is advised:
• For thick and chunky foods, turn the food regularly during defrosting in order
to obtain uniform thawing.
• If food is over 2kg, it is advised to turn it a minimum of two times.
• DO NOT refreeze food once defrosted.
• Ensure that food is thoroughly defrosted before cooking.
Grill Function
• The Grill Function allows food to be cooked and grilled for browning at the same
time without microwave.
• Grill cooking is particularly useful for thin slices of meat, steaks, chops, kebabs,
sausages or piece of chicken.
• It is also suitable for hot sandwiches and au gratin dishes.
• The longest cooking time you can set is 60 minutes.
• Open the door, place the grill stand on the turntable and place the food on the
stand, then close the door.
There are 3 grill functions, G -Grill, C1 – Combination1 and C2 – Combination2 as
per the table below:
Press the Grill button
Function
G
Grill – Only the grill will operate
C-1
Combination of grill and microwave cooking,
30% microwave and 70% grill
C-2
Combination of grill and microwave cooking,
55% microwave and 45% grill
The cooking time can be set between 10 seconds and 60 minutes.
1. Press the Grill button continuously to select the required cooking mode.
2. Rotate the Time/Weight control to select the cooking time.
3. Press the START/+30sec button to start cooking.
Once the cooking has finished, 3 beeps will be heard and the display will show End.
13
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Menu Auto Functions
This auto function has eight pre-set cooking programs where there is no need to
set either cooking times or power levels. The following table shows details of the
pre-set programs:
Auto Cooking
Food Type
Portion
A.1
Potato
250g
500g
750g
A.2
Pasta
50g
100g
150g
A.3
Pizza
200g
400g
A.4
Popcorn
100g
A.5
Vegetable
200g
400g
600g
A.6
Beverage
1 cup
2 cups
3 cups
(250ml for each cup)
A.7
Meat
200g
400g
600g
A.8
Fish
200g
400g
600g
1. Press the Menu button to select the desired program from A1 to A8.
2. Rotate the Time/Weight control to select the portion size.
3. Press the START/+30sec button to start cooking.
The result of auto cooking depends on factors such as fluctuation of voltage,
the shape and size of food, your personnel preference as to how well cooked
certain foods are and even how well you place food in the oven.
If it is found that the result is not quite satisfactory, adjust the cooking time
accordingly.
14
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Reheat
• Reheat function is mainly to facilitate users to heat food according to the
weight of food.
1. Press the Reheat button to select the desired weight of food from 200g,
400g, 600g, 800g and 1000g.
2. Press the START/+30sec button to start cooking.
Once the cooking has finished, 3 beeps will be heard and the display will show
End.
Child Lock
This function is used to lock the Control Panel (7), once the child lock is set all
the buttons on the control panel will be disabled.
• To set the child lock, press and hold the STOP/lock button for 3 seconds.
• To cancel the child lock, press and hold the STOP/lock button for 3 seconds.
Utensils Guideline
It is recommended that only utensils and containers marked safe for microwave
use should be used in this microwave oven. As a general rule a container made
from heat resistant ceramic, glass or plastic are suitable for microwave cooking.
Never use metal containers for microwave cooking.
Material
Microwave
only
Grill only
Combination*
Notes
Heat–Resistant
Ceramics
Yes
Yes
Yes
Never use the ceramics
which are decorated
with metal rim or glazed.
Heat–Resistant
Plastic
Yes
No
No
Cannot be used for long
periods of microwave
cooking.
Heat–Resistant
Glass
Yes
Yes
Yes
Plastic film
Yes
No
No
Shall not be used when
cooking meat or chops as
the high temperature
may damage to the film.
Metal
containers
No
No
No
Metal items shall not be
used in this product.
Grill rack
No
Yes
No
Grill rack can only be
used in Grill only mode.
*Combination: applicable for "Microwave+Grill"
15
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cooking tips
• Place thicker pieces towards outside of food container, the thinner pieces
towards the centre and spread evenly. Do not overlap if possible.
• Start cooking with a shorter time setting, evaluate it after the time finishes and
extend the cooking time if needed. Over cooking can result in smoke and burnt
food.
• Food such as chicken, burgers or steak should be turned once during cooking.
• Depending on the food type, if applicable stir from the outside inwards to the
centre of the dish once or twice during cooking.
• Make sure meat is cooked thoroughly there should be no signs of pink in the
meat or in the meat juices.
Cleaning and Maintenance
Remove the plug from the wall socket before cleaning.
DO NOT immerse the appliance in water or any other liquids whilst cleaning.
• Wipe the exterior with clean soft damp cloth and dry thoroughly.
• Using a clean soft damp cloth, wipe clean the interior of the door and door
seals, interior cavity to remove any spills or spatter and dry thoroughly.
• Do not remove the waveguide cover. Wipe clean the wave guide cover making
sure it is free from food residue, this is located on the cavity wall on the right
hand side.
• Wash the glass turntable, the turntable ring support in warm soapy water and
dry thoroughly.
Some foods, for example fish can leave an odour which may linger, to refresh the
cavity follow one of the 3 methods below:
Method 1 - Distilled Vinegar
1. Add 1 cup of water and 1/2 cup of distilled vinegar to a microwave proof bowl
or plastic container and place in the centre of the oven.
2. Heat on high for 2 minutes 30 seconds or until the solution boils or gives off
steam.
3. Leave to cool for 15 minutes before opening the door.
4. Open the door, remove the bowl and glass turntable, then wipe the microwave
with a clean damp cloth.
5. Wipe the glass turntable before replacing.
Method 2 - Lemon
1. Cut a lemon in two and squeeze the lemon into a microwave proof bowl or
plastic container, add 1 cup of water and place in the centre of the oven.
2. Heat on high for 2 minutes 30 seconds or until the solution boils or gives off
steam.
3. Leave to cool for 15 minutes before opening the door.
4. Open the door, remove the bowl and glass turntable, then wipe the microwave
with a clean, damp cloth.
16
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
5. Wipe the glass turntable before replacing.
Method 3 - Bicarbonate of soda
1. Add 1 cup of water and 2 tbsp bicarbonate soda to a microwave proof bowl or
plastic container and place in the centre of the oven.
2. Heat on high for 2 minutes 30 seconds or until the solution boils or gives off
steam.
3. Leave to cool for 15 minutes before opening the door.
4. Open the door, remove the bowl and glass turntable, then wipe the microwave
with a clean, damp cloth.
5. Wipe the glass turntable before replacing.
Servicing
Servicing and repairs should only be carried out by qualified service personnel.
WARNING!
Some components still retain a high voltage charge even when the microwave
oven is disconnected from the mains supply, never remove Covers or Guards.
Covers and Guards should only be removed by qualified personnel.
If any part of the oven or cord becomes damaged stop using it immediately and
seek advice from qualified service personnel.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut
it off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Specification
Model Number
SDA2088
Rated Voltage
220-240V~ 50Hz
Rated power (Input)
1100W
Microwave Rated power (Output)
700W
Microwave frequency
2450MHz
Grill Rated Power
800W
Protection Class
I (This Appliance Must Be Earthed)
17
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
18
20L Microwave with Grill
Model No. SDA2088
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the discretion
of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
