1
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, safety precautions should always be
followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Wet & Dry Multi-Grinder.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• Do not use this product with a programmer, timer,
separate remote-control system or any other device.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• Do not immerse this appliance in water or any other
liquids.
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• This appliance shall not be used by children.
• Keep the appliance and its cable out of the reach of
children.
• Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
3
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by
children.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• Protect the unit from moisture whilst using this appliance
outdoors.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user at
serious risk.
• It is imperative to unplug the mains cable after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• Do not operate this appliance with a damaged plug or
mains cable, after a malfunction or after being dropped or
damaged in any way.
• Do not allow the mains cable to hang over sharp edges or
come in contact with hot surfaces.
• Do not use this appliance for anything other than its
intended use.
• Do not push objects into any openings as damage to the
appliance and/or electric shock may occur.
• This appliance is intended for household use only and
should not be used for industrial or commercial purposes.
• Switch off the appliance and disconnect from the mains
supply before changing accessories or approaching parts
4
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
that move in use.
• Allow the unit to cool before storage.
• Do not touch the blades whilst the grinder is connected to
the mains.
• Wash the blades in warm soapy water, rinse and dry
thoroughly.
WARNING! The blades on this grinder are very sharp; extreme
caution should be taken whilst cleaning.
5
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This Class 2 symbol indicates that the product is electrically
double insulated and does not require an earth connection.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to land
fill. Please ensure it is taken to a suitable facility for disposal.
Check with your Local Authority or retailer for recycling advice
or visit www.recycle-more.co.uk, enter your postcode to find
out your nearest recycling site.
This symbol provides useful additional information on the use of
this product.
WARNING!
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.
6
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before First Use of Your Wet & Dry Multi Grinder
• Remove all packing materials and discard responsibly.
• Before use, Rinse the grinding chamber with warm water and wipe with a soft
cloth.
• Wipe the outside of the unit with a soft damp cloth.
• Do not use harsh or abrasive cleaners.
• Do not clean any part of your Wet & Dry Multi Grinder in a dishwasher.
• Do not immerse the appliance in water or any other liquid.
WARNING! Extreme caution should be taken whilst cleaning the blades to
avoid injury.
2
3
4
1
1. Lid
2. Grinder
3. Safety Interlock Cover
4. Power Button
5. Motor Body
5
7
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using Your Wet & Dry Multi Grinder
1. Place the grinder on a solid level, non-flammable surface.
2. Right: Remove the Safety Interlock Cover (3) by
rotating it anti-clockwise.
3. Left: Lift the Lid (1) off the Grinder (2).
4. Right: Remove the Grinder (2) from the
Motor Body (5)
5. Left: Place coffee beans or chosen
spices into the Grinder (2), ensure
that the ‘MAX’ mark on the inside
of the grinder is not exceeded.
The grinder can hold up to 85g of
coffee beans or spices at a time.
8
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6. Replace the Grinder (2) onto the Motor Body (5) by rotating clockwise and
replace the Lid (1) onto the grinder.
7. Before use replace the Safety Interlock Cover (3) by rotating clockwise until it
locks into place.
The Wet & Dry Multi Grinder will not operate until the Safety Interlock Cover
(3) is properly replaced.
8. Plug the grinder into the nearest socket outlet.
9. Press the Power Button (4) to grind the chosen contents, look through the clear
Lid (1) to check the consistency of contents.
Press and hold the Power Button (4) for a finer consistency.
10. Once the desired consistency has been reached release the Power Button (4)
and allow the blades to stop spinning before opening the Lid (1).
11. Remove the mains plug from the socket.
The Grinder can also be used to chop herbs and spices such as pepper,
cinnamon, dried chilli and coriander seeds. The Grinder (2) should be thoroughly
cleaned after chopping herbs and spices to avoid odours and taste affecting the
next usage.
The Grinder can also be used to chop moist foods such as Hummus, Pesto, etc.
Ensure that the Grinder is not filled above the ‘MAX’ mark.
WARNING! Do not run the appliance continuously for more than 1 minute,
allow the appliance to cool down for 3 minutes between two continuous cycles.
Care and Maintenance
• Always disconnect the grinder from the mains supply and allow to fully cool
before cleaning.
• Rinse the Grinder (1) with warm water and wipe with a soft cloth after each use.
Extreme care should be exercised whilst cleaning the grinder as the blades are
sharp.
• Wipe the outside of the grinder with a soft damp cloth.
• Never clean with harsh or abrasive cleaners.
• Do not submerge the unit in water or any other liquids.
• Do not clean any part of your grinder in a dishwasher.
• Store the grinder in a cool, dry place out of direct sunshine.
Technical Specification
Model Number
SDA2697
Rated Voltage
220-240V ~ 50-60Hz
Rated Power
200W
Grinding Chamber Capacity
85g (Max)
Protection Class
II
9
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting
Symptom
Possible Cause
Possible Solution
The Grinder is
not grinding
The Safety Interlock is not
positioned correctly.
Ensure that the Grinder is
mounted correctly on the
Motor Body and the Safety
Interlock cover is in place to
operate the Safety Interlock.
Consistency of
coffee beans,
herbs and spices
is too coarse
The contents have not been
ground sufficiently
Press and Hold the Power
Button, ensuring that
consistency is monitored
through the clear Lid.
There is no
power to the
unit
The fuse in the plug has failed
Check the fuse by
substitution
The grinder is not connected to
the mains supply
Check that the appliance is
connected to the mains
supply.
Ensure the mains socket is
switched on (if applicable)
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk enter
your postcode to find out your nearest recycling site.
10
Wet & Dry Multi Grinder
Model No. SDA2697
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
