User Manual RCA RCRPST04BE 4 Device - Universal Remote Cont

Illuminated POWER key serves

as an indicator light to provide

feedback.

Device keys (TV, SAT•CABLE/

STREAM, DVD/BLU RAY,

AUDIO/SOUNDBAR) put the

remote in the right mode to

control your device.

controls Samsung Hub

functionality on TVs. It may also

control similar functionality on

other devices (see your device

manual for information).

The purple keys

(GUIDE•HOME, OPTIONS/

INFO, MENU, GO BACK)

are the most used keys for

streaming player.

GUIDE•HOME puts the

remote in guide mode for

satellite receivers or cable

boxes, and accesses the home

screen for streaming players.

CLEAR exits remote

programming; it also performs

the same functions as on your

original remotes.

Arrow keys act as navigation

keys in device guides and menu

systems.

The INPUT — (dash) key has

three functions: (1) it toggles

through all the video sources

connected to your TV; (2) when

the remote is in VCR mode,

this button toggles between

VCR and the TV input; (3) when

you’re entering digital channel

numbers directly, this button

lets you separate the main

channel number from the sub-

channel number (such as 59.1).

Red, green, yellow, and blue

keys access additional features

on your cable box, satellite

receiver, or Blu-ray disc player

(see your device manual for

details).

Battery Saver

Your universal remote control saves battery power by automatically

turning off if any key is pressed for more than 15 seconds. This saves

your battery life should your remote get stuck in a place where the keys

remain depressed, such as between sofa cushions.

RCRPST04BE

Universal Remote Control

Owner’s Manual

Manual del Propietario (parte posterior)

Actual model may vary from

illustration

Your universal remote requires two AAA alkaline batteries (not

included).

To install the batteries:

1. Remove the battery compartment cover.

2. Insert the batteries, matching the batteries to the (+) and (–) marks

inside the battery compartment.

3. Push the battery cover back into place.

Battery Precautions:

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-

cadmium) batteries.

• Always remove old, weak or worn-out batteries promptly and

recycle or dispose of them in accordance with Local and National

Regulations.

IMPORTANT

Because this remote controls more than one device, you must

rst “tell” the remote which device you wish to operate. That

means, if you wish to operate your TV, you must rst press the

TV key to put the remote in the TV Mode. The remote stays

in that device mode until you press a different device key.

For example, if your remote is in TV Mode and you want to

operate the DVD player, you must press the DVD/BLU RAY key

to change device modes.

Problem: The remote does not operate your device.

• Make sure the remote is in the correct mode by pressing the

corresponding device key (TV, SAT•CABLE/STREAM, DVD/BLU RAY,

AUDIO/SOUNDBAR). This tells the remote which device to operate.

• Remove any obstacles between the remote and the device. Make

sure you’re aiming the remote at the device’s IR sensor.

• Make sure the batteries are fresh and are properly installed. Replace

the batteries with two new AAA batteries, if necessary (see the

Battery Installation section).

Problem: The remote can’t be programmed to operate your

device.

• If you are testing the remote while programming it, you may be too

far away from the device or at a wrong angle. There must be an

unobstructed path between the remote and the IR sensor on the

device. Move closer and make sure you point the remote at the device

you’re trying to control.

• If you’re using the Direct Entry programming method to enter the

codes for your brand and the unit is still not functioning properly, try

one of the auto search methods.

• To control combo units, like TV/VCRs or TV/DVDs, you must

program the individual corresponding device keys to control each

part of the combo unit. Once programmed successfully, the TV key

controls the TV functions, and the DVD/BLU RAY key controls the

VCR or DVD functions.

• Make sure the batteries are fresh and are properly installed.

Problem: The remote doesn’t perform commands properly.

• Make sure the remote is in the correct mode by pressing the

corresponding device key (TV, SAT•CABLE/STREAM, DVD/BLU RAY,

AUDIO/SOUNDBAR). This tells the remote which device to operate.

• Make sure device is ready (for example, the DVD player has a disc

loaded).

• You may have pressed an invalid key for the mode the remote is in.

• If you’re trying to enter a channel number directly, try pressing the

OK key after entering the channel number as this is a requirement of

certain models and brands.

• There is a possibility that a programmed code may only be able

to control some of your device features (for example, only turns a

device on and off). To conrm that the device key is programmed

with the correct code for maximum functionality, test the device.

Attempt to control a variety of the device’s functions with the

remote. If some of the features of your devices don’t work, try

programming the remote with a different code in the list using the

Direct Code Entry Method, until you nd the code that allows the

remote to control the majority of your device’s functions. Different

codes can provide different levels of functionality.

Problem: The POWER key does not light when you press a key.

• You may have pressed an invalid key for the mode the remote is in.

• Make sure the remote is in the correct mode by pressing the

corresponding device key (TV, SAT•CABLE/STREAM, DVD/BLU RAY,

AUDIO/SOUNDBAR). This tells the remote which device to operate.

• Make sure the batteries are fresh and are properly installed. Replace

the batteries with two new AAA batteries, if necessary (see the

Battery Installation section).

Problem: The remote will not change channels on device.

• Make sure the remote is in the correct mode by pressing the

corresponding device key (TV, SAT•CABLE/STREAM, DVD/BLU RAY,

AUDIO/SOUNDBAR). This tells the remote which device to operate.

• Press the OK key after you enter a channel number.

• Remove any obstacles between the remote and the device. Make

sure to aim the remote at the IR sensor on the device.

Problem: The device’s menu does not appear on the TV screen.

• Make sure you have connected the device to your TV properly and

selected the correct input. (See your devices’ Owner’s Manuals for

proper connection procedures.)

• Make sure the remote is in the correct mode by pressing the

corresponding device key (TV, SAT•CABLE/STREAM, DVD/BLU RAY,

AUDIO/SOUNDBAR). This tells the remote which device to operate.

• Menu access isn’t supported for all brands. You may need to use

your original remote control to access menu functions for some

devices.

For more information, including instructional videos, remote

programming codes, and customer support, visit

www.RCACodeSupport.com

Trademark(s) ® Registered

Step 1: Install your batteries

Tour of the Remote

Advanced Functions

Troubleshooting

PLAY

POWER

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

POWER

PLAYREVERSE FORWARD

INPUT

1 2 3

4 5 6

7 8 9

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

DVD/BLU RAY CODE AUDIO/SOUNDBAR CODE

SAT•CABLE/STREAM CODETV CODE

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

RCRPST04BE US 03 R271U1

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

POWER

POWERPOWER

Step 2: Program your remote

To use this universal remote with your home entertainment

system, rst you need to program it to control your devices. There

are three ways you can program the universal remote to operate

your devices. Try them in the order listed.

• The Direct Code Entry lets you enter a code from the

accompanying code list for your brand of device.

• The Auto Code Search: Top Brands searches through the

codes for select brands of devices.

• The Auto Code Search: All Brands goes automatically

through all the codes for the device you’re trying to control.

Direct Code Entry

Direct Code Entry lets you enter a code from the accompanying

code list for your brand of device.

1. Manually turn on the device you want

to control.

3. Press and hold the device key

you want to program for about

2 seconds, until the POWER key

illuminates and stays on. Then

release the key.

2. Find the Code List that came with

the remote. Locate the section for

the type of device you’re trying to

program, and nd your brand in that

section. Circle the codes for your

brand and keep them handy.

NOTES

Test the remote with the device to make sure the device key is

programmed with the correct code for maximum functionality.

If some features don’t work, try a different code in the list.

Remember to enter the code for future reference in the box

provided in the Code Retrieval section of this manual.

If your brand isn’t listed in the code list, use the Auto Code

Search method to program the remote control.

4. Enter the rst ve-digit code for

your brand in the code list (the

POWER key ashes after each

digit).

Did the POWER key turn off?

YES: You’re done! You’ve programmed this device key.

NO, it’s still illuminated: You have either entered a code

number that is not in the code lists or missed a step in the

code entry procedure. Try step 4 again.

5. When you’ve nished entering

the ve-digit code, look at the

POWER key.

Code Lists

Listes de Codes

Lista de Códigos

DURABRAND ...............39213, 55514, 81017, 86718, 88518, 93115

DYNASTY ......................................................................................78613

DYNEX ............06919, 12219, 27311, 27711, 28511, 28911, 39213,

...................................................39512, 45013, 49412, 49813, 61215,

.................................................................79914, 82717, 88518, 89713

ELECTRO..........................................................................54312, 56111

ELECTRON ....................................................................................80517

ELEKTA ..........................................................................................83618

ELEKTRA...........................................................................52814, 65312

ELEMENT .................................01815, 24912, 34211, 34611, 45112,

.................................................................70017, 72015, 79517, 81918

ELEMENT (ROKU TV) ...................................................................44211

EMERSON ................................26618, 29311, 36412, 40411, 46911,

............................................................... 48111, 54711, 71714, 75614,

....................................................79513, 82615, 85913, 88518, 99714

ENVISION ............................................................31612, 33412, 40413

EQD ..................................................................................31612, 33412

ESA ......................................................................25011, 88518, 93115

FAVI ................................................................................................11711

FISHER .................................................................26618, 66011, 72112

FLUID .............................................................................................70013

FUJICOM ......................................................................................76615

FUJITSU ............................................................................54711, 74012

FUNAI ...........................25011, 29311, 40411, 48111, 54711, 88518

FURRION ..........................................................................27911, 47414

FUTURETEC .....................................................................78613, 79513

GATEWAY ........................................................................20111, 59912

GE (GENERAL ELECTRIC) ................................00615, 14951, 42113,

....................................................50115, 55514, 73814, 87215, 90015

GENERAL INSTRUMENT .............................................................39019

GFM ........................................................03419, 25011, 29311, 88518

GIBRALTER ..........................................................53511, 53911, 74916

GLOBALSTAR ...............................................................................49011

GOLDI ...........................................................................................89013

GOLDSTAR .........................................................33411, 40411, 55514

GPX ......................................................................23611, 24611, 46911

GRADIENTE ..............................09215, 43411, 65311, 81214, 92114

GRUNDIG ......................................................................................37911

GUESTVISION ..............................................................................53311

GVISION ........................................................................................88113

HAIER.....................................................11711, 12511, 43912, 54513,

.................................................................55514, 56013, 60914, 77612

HAIER (ROKU TV) .........................................................................44211

HALLMARK ...................................................................................55514

HANNSPREE ....................................................................15811, 26812

HAUPPAUGE.................................................................................65911

HAVERMY ......................................................................................22511

HELLO KITTY.................................................................................78212

HIDEAR ..........................................................................................68211

HISENSE ....................................35611, 44211, 59413, 67614, 78115

HISENSE (ROKU TV)........................................................44211, 55712

HITACHI .....................................13611, 37811, 44913, 49012, 61513

HITACHI (ROKU TV) .....................................................................44211

HKC ................................................................................................47414

HKPRO ...........................................................................................38811

HP (HEWLETT PACKARD) ..............................................38013, 83013

HYUNDAI ............................................................01115, 63811, 66213

IKON ..............................................................................................34112

ILO ......03715, 05816, 28118, 56811, 88518, 89514, 93115, 94215

INFINITY ...........................................................................51011, 56011

INFOCUS..........................................................................35912, 38618

INITIAL .................................................................62213, 74213, 89514

INSIGNIA ...............................................06919, 07216, 12219, 28511,

................................................................28911, 39512, 45013, 49412,

.......................................61312, 69212, 69613, 70017, 82615, 89713

INSIGNIA (ROKU TV) ......................................................12219, 44211

INTEC ............................................................................................38011

INTEQ ..................................................................53511, 53911, 74916

ISYMPHONY .................................................................................11711

JBL .................................................................................................56011

JC PENNEY ...........................................33411, 49219, 55211, 58412,

.................................................................60112, 87215, 90015, 98215

JENSEN .........................................................................................69212

JOCEL ...........................................................................................67211

JVC...................00218, 11719, 48611, 48812, 77213, 87314, 99717

JVC (ROKU TV) .............................................................................44211

KALLEY ..........................................................................................01115

KAWASAKI ....................................................................................47011

KAWASHO ....................................................................................56111

KC ..................................................................................................20611

KDS ...................................................................................40114, 58414

KEC ................................................................................................78613

KLH ................................................................................................42113

KLOSS NOVABEAM .....................................................................68413

KNOLL SYSTEMS (ZENITH) .........................................................74916

KOGI ..............................................................................................88113

KONKA ......................................22218, 32319, 45013, 66213, 96514

KREISEN ........................................................................................97619

KTC ................................................................................................27019

KTV .............................................15311, 54312, 78613, 79513, 88114

KURAZAI........................................................................................65312

KWORLD .......................................................................................72813

LASONIC ..........................................................................54911, 86115

LEADER .........................................................................................96319

LEEGE ............................................................................................10011

LEGEND ...........................................................................68515, 71014

LENOVO........................................................................................90919

LENSON ........................................................................................66116

LETV ..................................................................................56614, 67115

LG .........................................................................31311, 52412, 63913

LIQUIDVIDEO ..................................................................17517, 84315

LODGENET ............................................08415, 65312, 80714, 98215

LOEWE ..........................................................................................56011

LOGIK ............................................................................................98215

LUCE

..............................................................................................70514

LXI .......26618, 40411, 53112, 55514, 56011, 58012, 60112, 98215

MAG..................................................................................40114, 58414

MAGNASONIC .............................................................................54711

MAGNAVOX .........................................25011, 42513, 42812, 48111,

....................................................51011, 63011, 82615, 88518, 95017

MAGNAVOX (ROKU TV) ..............................................................44211

MAJESTIC .....................................................................................98215

MARANTZ ...........................................................33412, 53811, 56011

MASTER-G ....................................................................................01115

MATSUSHITA ................................................................................39011

MAXENT ...........................................................................27117, 59912

MEDION ..............................................................28118, 69112, 95515

MEGATRON .....................................................................37219, 55514

MEI .................................................................................................54312

MELODY ........................................................................................36711

MEMOREX ...............................12219, 20212, 26618, 53014, 54711,

.......................................55514, 57812, 65813, 74414, 85915, 98215

MGA..............................33411, 54711, 55514, 56511, 67012, 75413

MI ...................................................................................................21012

MIDLAND ..............................................53112, 53511, 53911, 58012,

.................................................................64511, 74916, 87215, 98215

MINOKA ........................................................................................36913

MINTEK .........................................................................................60916

MINUTZ .........................................................................................90015

MISAKAI ........................................................................................93115

MITSUBISHI .....21711, 33411, 36311, 54711, 70215, 78112, 97415

MITSUI .........................17711, 18311, 18711, 19311, 21711, 29312,

..........................30813, 36311, 41314, 52215, 70215, 78112, 89713

MONIVISION ................................................................................48011

MONTGOMERY WARD ..................................................65312, 98215

MOTEVA ...........................................................................26618, 92114

MOTOROLA .................................................................................63712

MTC ........................................................33411, 54312, 58412, 60112

MYRON & DAVIS ..........................................................................91615

NAD .....................................................................55514, 60112, 64911

NAXA .........................................11711, 25811, 29419, 41011, 82318

NEC ............................................29811, 31912, 33411, 47811, 53811

NET TV ..............................................................................46511, 59912

NEXUS ..............................................................................36412, 82717

NEXXTECH ......................................................................62313, 62912

NIKAI..............................................................................................84218

NIKKEI............................................................................................78613

NIKKO ...............................................................................55514, 63511

NIKO ..............................................................................................47719

NOBEL ...........................................................................................80313

NORCENT ........................................................................40413, 68912

NTC ................................................................................................63511

NUVISION .....................................................................................02315

OBONI .................................................................17711, 85818, 94219

ÖLEVIA ................................................................17211, 80118, 85114

ONCOMMAND ...............................................................53311, 65711

ONN .......................................................00717, 32011, 43612, 57513

ONN (ROKU TV) ...........................................................................44211

ONWA ..............................................................................78613, 79513

OPTIMUS ..........................................................................39011, 64812

OPTOMA .......................................................................................81614

OPTONICA ......................................................................47811, 55411

ORION ....................................................21311, 53511, 53911, 81017

PALSONIC .....................................................................................73717

PANASONIC .............................39011, 39811, 51913, 60513, 79515

PANDA .............................................................................18411, 18911

PARK ..............................................................................................25811

PEERLESS ......................................................................................18918

PENNEY .........................................................................................55514

PHILCO ..................................................01115, 25011, 33411, 41212,

.................................................................52814, 63214, 76813, 92815

PHILIPS ...........06918, 17419, 21319, 33412, 43911, 44211, 48111,

.......................................62414, 73915, 82615, 84416, 88518, 95017

PHILIPS (ROKU TV) .......................................................................44211

PHILIPS-MAGNAVOX ..............51011, 56011, 69411, 73915, 86815

PIONEER ................................................53714, 53811, 69913, 73513

PIVA ...............................................................................................86914

PIXEL ..............................................................................................99119

PLANAR ............................................................................40413, 75812

POLAROID .....07015, 16611, 20011, 24912, 33211, 40114, 42113,

43319, 58414, 65014, 67211, 68515, 89013, 94016

PORTLAND ......................................................................33411, 63511

PRECISION ....................................................................................64713

PRIMA ..................................................................27311, 66213, 71014

PRINCETON GRAPHICS .................................................55411, 59611

PRISM ............................................................................................01117

PROMAC .......................................................................................26711

PROSCAN ......01815, 07017, 07819, 11711, 20011, 34211, 35611,

47414, 69416, 79712, 93218

PROTON ........................................................................................55514

PROTRON ........................................................................32818, 63111

PROVIEW ......................................................................................24912

PULSAR ...............................................................53511, 53911, 74916

PYLE ...............................................................................................68016

PYLE HOME ..................................................................................68016

QFX ................................................................................................41811

QUASAR ....................................39011, 51913, 56011, 64812, 87215

RADIO SHACK ............00615, 26618, 40411, 47811, 54311, 55514,

..............................................................................56511, 79513, 98215

RCA .................04719, 11711, 22511, 26411, 32111, 33012, 36412,

.........................43912, 44613, 44712, 54113, 55213, 58915, 61513,

.......................................65714, 66114, 67013, 69416, 79712, 90214

RCA (ROKU TV) ............................................................................44211

REALISTIC ................................26618, 40411, 47811, 55514, 57512,

.................................................................78613, 79513, 79515, 98215

REVOLUTION HD .........................................................................93819

RIVIERA .............................................................................50613, 90614

ROKU TV .......................................................................................44211

ROWA ............................................................................................53815

RUNCO

...................................................53511, 53811, 53911, 74916

SAMPO ..........................................................................................59912

SAMSUNG ......16616, 21818, 36218, 66611, 77114, 79113, 97817

SAMTRON .....................................................................................58412

SANSUI ......................................20011, 39213, 54411, 57812, 88518

SANYO ............03818, 10811, 33711, 77715, 88513, 98718, 99014

SANYO (ROKU TV) .......................................................................44211

SCEPTRE .........05115, 19711, 20611, 30211, 37313, 65815, 83515

SCOTCH ........................................................................................55514

SCOTT .......................................54711, 55514, 78613, 79513, 94215

SEARS .............48111, 54711, 55514, 56011, 57812, 58412, 59211,

.......................................60112, 68612, 72112, 82615, 93115, 98215

SEIKI .................01815, 11218, 22719, 55514, 64814, 79517, 96416

SELECTRON .......................................................74313, 78112, 85814

SEMP .............................................................................................70712

SÉURA ..............................................................................05517, 13019

SHARP .............02118, 13019, 31713, 35611, 37311, 50912, 91517

SHARP (ROKU TV) ...........................................................13019, 55712

SHENG-CHIA ................................................................................22511

SIGMAC .........................................................................................02019

SIGNATURE ..................................................................................98215

SIGNET ................................................................50911, 83414, 96715

SILO DIGITAL ................................................................................20611

SIMPLY ...........................................................................................76716

SIRAGON ......................................................................................26211

SKYVUE .........................................................................................37712

SKYWORTH...............................14319, 56112, 59315, 62415, 67211

SOAIY ............................................................................................89117

SOLE ..............................................................................................93819

SONIC ...........................................................................................54312

SONY ...................................................................31912, 41112, 89616

SOULACA .....................................................................................16118

SOUNDESIGN .......................................54711, 55514, 78613, 79513

SOVA ................................................................................81213, 85613

SOYO .............................................................................................69613

SPECTRA .......................................................................................54911

SPECTRAVISION ..........................................................................58611

SPECTRONIQ ...............................................................................48814

SPELER ..........................................................................................41313

SQUAREVIEW ..................................................................88518, 93115

STAR SAT .......................................................................................50913

STARLITE .......................................................................................79513

SUMEC ..........................................................................................10818

SUNBRITETV .............................19711, 20611, 65815, 80118, 92918

SUPER GENERAL..........................................................................84218

SUPERSCAN ....................................................................48111, 82615

SUPERSONIC ...............01117, 25811, 41811, 44711, 46911, 88715

SUPRA..................................................................43411, 72117, 78913

SVA.................................................................................................25011

SYLVANIA ....................25011, 29311, 40411, 48111, 56011, 63614,

....................................................74115, 75315, 81017, 82615, 88518

SYMPHONIC ................40411, 48111, 79513, 82615, 88518, 93115

SYNTAX .........................................................................................64716

TATUNG ..............................................................20111, 28118, 31919

TCL ...............................15919, 36711, 37511, 44211, 44411, 57513,

..............................................................................61513, 68014, 80313

TCL (ROKU TV) .............................................................................44211

TECHNICOLOR ............................................................................65714

TECHNICS ........................................................................39011, 87215

TECHWOOD ...................................................................73513, 87215

TEKNIKA ...................................33411, 54711, 58412, 60112, 63511,

.................................................................68413, 78613, 79515, 98215

TELERENT ........................................................................65312, 98215

TERA ..............................................................................................43411

TEVION .........................................................................................28118

THOMSON....................................................................................80313

THTF .................................................................................21412, 32913

TMK ................................................................................................55514

TNCI ...............................................................................................74916

TOSHIBA .....................08318, 24919, 36411, 36911, 48512, 57812,

..........................65014, 67611, 70017, 70416, 72014, 78614, 90616

TRUTECH ............................................................24912, 76312, 88518

TVA ................................................................................................38511

TVS .................................................................................................81017

UNIVERSAL ......................................................................42611, 90015

UPSTAR.............................................................................27411, 51914

VENTURER .......................................................................51611, 65911

VESTEL ..........................................................................................71415

R271U1

4-Device Codes 00

VICTOR .............................................................................64811, 77213

VIDEOCON ...................................................................................97914

VIDTECH ..........................................................................33411, 55514

VIEWSONIC .............................10111, 10511, 12311, 12911, 23512,

...................................................23812, 31612, 33412, 34413, 45914,

....................................................47312, 56415, 59912, 67412, 92419

VIMAX ............................................................................................54015

VIORE .....................................................11711, 25811, 47913, 94915

VISION QUEST ................................................................24912, 68411

VIVITEK .............................................................................44384, 80213

VIZIO .......................................................20111, 35011, 40412, 80016

WARDS .....................................33411, 47811, 54711, 55514, 56011,

....................................................71013, 74916, 81015, 90015, 98215

WAYCON ......................................................................................70416

WBOX ..................................................................12618, 23219, 45211

WESTINGHOUSE .......01815, 11711, 30611, 31912, 43711, 48213,

.................................................................58813, 68515, 69314, 70713

WESTINGHOUSE (ROKU TV) ......................................................44211

WHITE-WESTINGHOUSE .....................40411, 53212, 81017, 90214

WINDSOR .....................................................................................37811

WYSE .............................................................................................34413

XIAOMI ..........................................................................................21012

XOCECO .............................................................14011, 14811, 16611

YAMAHA ..........................................................................33411, 79515

ZENITH ...........15117, 40411, 43311, 51011, 51712, 53014, 54411,

..........................

57011, 63511, 64311, 64512, 66611, 85913, 95216

ZUTEST ..........................................................................................49611

TV / Téléviseur

ABEX .................................................................................64911, 69913

ACCURIAN ....................................................................................91814

ACER ....................................................................16317, 42919, 59114

ADC ..................................................................................33719, 65312

ADVENT .................................................50411, 71014, 91019, 99715

AFFINITY .......................................................................................07819

AFTRON ........................................................................................01219

AIKO ..............................................................................................63511

AIWA.................................................................................40411, 66111

AKAI ...........................................09619, 43514, 90117, 94219, 97817

ALLERON ......................................................................................54711

AMTRON .......................................................................................79513

AMW .................................................................................64013, 75214

ANAM NATIONAL....................49219, 57611, 58211, 78613, 79513

AOC ....19819, 31612, 31811, 33411, 33412, 40413, 52713, 53313

APEX .........................................06016, 39019, 42113, 47111, 54214,

.................................................................60113, 75217, 76314, 84715

APEX DIGITAL...............................................................................39019

ARIO ..............................................................................................68515

ATVIO .....................................................21711, 38111, 63315, 64615

ATYME ...........................................................................................52013

AUDIOVOX .........................................................75512, 79513, 86413

AURIA ...............................................................................31612, 33412

AURORA ........................................................................................46014

AUVIO...............................................................................46513, 57014

AVENTURA....................................................................................88518

AVERA ...........................................................................................68515

AVOL ................................................................................87217, 89115

AXESS ............................................................................................41811

AXION ...........................................................................................84315

BANG & OLUFSEN ......................................................................24011

BELL & HOWELL.................................................26618, 65312, 98215

BENQ ......................................................31919, 80014, 87813, 95719

BLUE SKY .........................................................................95017, 98314

BOE ...................................................................................19819, 89013

BOLVA ...........................................................................................72015

BROCKWOOD .............................................................................43411

BROKSONIC ................54411, 55711, 57812, 65813, 75614, 81017

CCE ................................................................................................95017

CELERA ............................................................................42113, 86718

CENTRIOS .....................................................................................82614

CETOMER ........................................................................40412, 83314

CETRONIC ....................................................................................78613

CHANGHONG ................................................................01618, 72117

CHARTER COMMUNICATIONS .................................................80415

CHIMEI ..........................................................................................24912

CIELO ............................................................................................30812

CINERAL ...........................................................................63511, 95017

CITIZEN ........................58412, 60112, 63511, 78613, 79513, 93115

CLASSIC ..............................................................04616, 46311, 78613

CLP .................................................................................................43311

CLP CLASSIC ...................................................................43411, 79914

COBY ...............13011, 52211, 52411, 61611, 77617, 77912, 96315

COLORTYME ................................................................................33719

COMWAVE ...................................................................................32611

CONTEC ................................................54312, 56511, 78613, 79513

CONTEX ........................................................................................20011

CORNEA .......................................................................................66712

CRAIG ........................................19311, 23211, 24912, 78613, 79513

CROSLEY .............................................................19711, 56011, 79914

CROWN............................................................................78613, 79513

CRYSTAL ........................................................................................72117

CTX ................................................................................................55411

CURTIS ............11711, 20011, 47913, 64615, 68515, 79016, 80517

CURTIS INTERNATIONAL ................................07819, 47913, 68515,

..............................................................................79016, 80517, 91118

CURTIS MATHES ...............................................17411, 26618, 58012,

.................................................................58412, 66611, 90614, 98215

CYBERVISION ...............................................................................95017

DAEWOO..............................................33411, 42211, 63511, 68912,

....................................................74412, 78613, 84014, 85817, 90214

DAYTRON .....................................................................................43411

DELL...........................................40211, 61211, 65411, 92815, 95017

DÉVANT ..............................................................05319, 27911, 94818

DIAMOND VISION ................................54911, 57111, 59612, 86115

DIGIHOME .......................................................................37811, 71415

DIGIMATE .....................................................................................63111

DIGISTAR ................................................42214, 65411, 71014, 78112

DIGITAL .........................................................................................83618

DIGITOR ........................................................................................33113

DISNEY ..........................................................................................81017

DISTAR ...........................................................................................84218

DSE ................................................................................................22612

DUKANE ...........................................................................37219, 67412

Video - VCR /

Vidéo — magnétoscope / Video - VCR

AIWA ...............................................................22222, 25922, 57125

BROKSONIC ........................................10621, 12121, 58525, 91229

CURTIS MATHES .................................22222, 29522, 41924, 71027

DAEWOO ................................16221, 29522, 32123, 57125, 91229

DENON ...................................................................................19821

EMERSON .......................................................13621, 16221, 22222

FISHER .........................10121, 18921, 49124, 69026, 70527, 71027

FUNAI ..............................................................22222, 57125, 60426

GE (GENERAL ELECTRIC) ...................30423, 38223, 56025, 72727

GO VIDEO ...........................................26422, 45524, 54625, 59925

GOLDSTAR ..................................................................11721, 22222

HITACHI ...................................15021, 22222, 24122, 47024, 50725

INFINITY ..................................................................................81128

INSIGNIA .................................................................................37923

JVC ..........................................14021, 15821, 23422, 50725, 70527

KENWOOD .........................................15821, 48424, 50725, 70527

LG ................................................................................22222, 37923

LITEON ....................................................................................12821

LXI ............................................................................................22222

MAGNAVOX ...........................12521, 22222, 60426, 75827, 79127

MEMOREX ..................................................................22222, 93429

MITSUBISHI .................................................................92029, 97829

NEC .........................................................................................27722

NEXXTECH ......................................................34923, 68626, 82928

ONKYO ...................................................................................17321

OPTIMUS .................................................................................12021

ORION .............................................................10621, 12121, 35023

PANASONIC ................................................................11321, 88728

PHILIPS ........................17421, 19321, 51225, 53325, 71027, 75827

PHILIPS-MAGNAVOX ..................................................71027, 81128

PIONEER .....................15821, 19821, 21622, 47024, 48424, 84828

PROSCAN ...............................................................................14621

QUASAR ..............................................12021, 12521, 17921, 94729

RADIO SHACK ............................................................22222, 30423

RCA .........................................13221, 18821, 43724, 47024, 56025

REALISTIC ...............................................................................22222

SAMSUNG ..........................................20822, 32123, 34623, 41924,

.............................................................47024, 52425, 80628, 93429

SANSUI ........................10621, 12121, 15821, 48424, 50725, 58525

SANYO ...................................10121, 16421, 18921, 28322, 39823,

.............................................................40324, 42824, 64926, 70527

SHARP .....................................22222, 33723, 46624, 83228, 99629

SONY ...................................................16721, 18321, 23022, 32123

SUPERSCAN ............................................................................60426

SYLVANIA ........................................................13621, 17721, 22222

SYMPHONIC ...........................17721, 22222, 29822, 57125, 60426

TOSHIBA ....................13621, 18521, 22222, 33723, 41924, 44224,

.........................47024, 55825, 66726, 71027, 77227, 86328, 96929

VECTOR ..................................................................................32123

WHITE-WESTINGHOUSE ............................................22222, 36523

YAMAHA .........................................................15821, 48424, 50725

ZENITH ................................................12121, 22222, 54625, 95329

ZUTEST ....................................................................................31323

Projector / Proyector / Projecteur

3M .......30483, 43784, 45584, 46284, 51985, 60985, 65186, 78487

AAXA .............................................................................................47084

ACER .............................14081, 21981, 29581, 32582, 32882, 45283

ADJ ................................................................................................21381

AEHR..............................................................................................35182

ASUS ..............................................................................................12181

AVERMEDIA ..................................................................................36583

AVIO ..............................................................................................46684

BARCO ..........................................................................................65186

BENQ ...........................12581, 16481, 33883, 37683, 48584, 53485,

....................................................55285, 59384, 65485, 67385, 85488

BOMAKER .....................................................................................56884

BOXLIGHT .....................................................................................35083

CANON ..................................................19381, 20582, 29181, 30082

CASIO ...............................................................................25982, 34683

CHRISTIE ........24681, 25081, 25681, 32183, 35282, 36982, 47583,

.................................................................58084, 58784, 69685, 78286

CIBEST ...........................................................................................57684

COCAR ..........................................................................................35182

COOAU .........................................................................................45383

COOLUX .......................................................................................26482

DELL...........................................13281, 23481, 42984, 47183, 57185

EIKI ....................................................................................20582, 78286

EPSON ......................................11381, 34782, 49884, 52485, 63386,

..............................................................................74987, 97989, 99389

GOODEE.......................................................................................57284

HITACHI ..................................................51985, 60985, 76687, 98189

HP(HEWLETT PACKARD) ............................................................26082

INFOCUS.......................................................................................31483

JVC.............................................11981, 18581, 26981, 54984, 89088

LENOVO........................................................................................44384

LG ..................................19981, 40384, 51285, 52585, 62886, 73387

MITSUBISHI ...............................15081, 17481, 17981, 26481, 28382

NEC .........................................................19381, 25181, 41983, 48883

OPTOMA .....................14181, 14681, 15881, 22382, 25682, 36183,

......................................37983, 38283, 39883, 40484, 47784, 49184,

.................................................................50785, 56085, 58685, 61286

PANASONIC ...11781, 21682, 27782, 37382, 59085, 59484, 67785

PHILIPS ................................................................18981, 29081, 65186

PIONEER .......................................................................................38383

PROXIMA .........................................................................46284, 57885

PYLE ..................................................................................46783, 57284

RAGU .............................................................................................68185

RICOH............................................................................................20882

RUNCO ...................................................29881, 35783, 54685, 67586

SAMSUNG .......................................................................11481, 15581

SANYO ............20582, 26481, 32183, 41984, 43483, 52584, 78286

SHARP ......................................09989, 10181, 10781, 15181, 21581,

.................................................................63085, 87588, 88888, 90589

SMART ...........................................................................................30482

SONY .............................................................................................67385

TOSHIBA ......................19581, 23281, 29582, 31483, 41683, 50385

TOUMEI .........................................................................................35182

VANKYO ..............................................................24281, 35182, 68885

VIEWSONIC .................16281, 19881, 21881, 23082, 24282, 56184

VIVITEK ..........................................................................................44384

WALLIS UNIVERSAL .....................................................................88888

WOWOTO ....................................................................................46083

YAMAHA ..........................................................................13681, 24182

YAUFEY .........................................................................................35182

ZUTEST ..........................................................................................36682

Digital TV Tuner / Syntoniseur de Télévision

Numérique / Sintonizador de TV Digital

ACCESS HD ........................................................11841, 45244, 97049

ADB......................................................................16841, 44042, 81747

AIRLINK 101 .....................................................................29942, 81248

ALPHA DIGITAL ...............................................................45244, 97049

AMINO ..........................................................................................55643

AMTC ................................................................................45244, 97049

APEX

..............................................................................................15641

APEX DIGITAL...............................................................................15641

APPLE ............................................................................................25742

ARRIS .............................................................................................27141

ARTEC ..............................................................................34743, 70747

AT&T ..............................................................................................27542

CADENCE .....................................................................................23242

CASIO ............................................................................................35342

CASTI .............................................................................................31543

CHANNEL MASTER ...........................................39441, 41044, 80848

CINCINNATI BELL ........................................................................40742

CISCO ........................................16341, 24342, 27542, 35342, 61844

COBY ................................................................................

36243, 77047

CONFLUENT.................................................................................51243

COSHIP ............................................................................23242, 37043

DAEWOO......................................................................................42044

DAYTEK .........................................................................................31543

DGTEC ...........................................................................................55945

DIGITAL STREAM ...............................................20942, 30543, 39741

DISH NETWORK ...........................................................................78445

ECHOSTAR ...................................................................................78445

EMATIC ............................................................................17041, 40544

EPSON ...........................................................................................75547

EVOLUTION ........................................................11041, 17841, 54345

GE (GENERAL ELECTRIC) ...........................................................15241

GOODMIND .................................................................................15241

GRIDLINK .........................................................................52645, 71147

HOME2US .....................................................................................27141

HOMECAST ..................................................................................17749

ICONQ ..........................................................................................18141

INET ACCESS ................................................................................45244

INSIGNIA .............................................................28442, 52644, 58745

KINGBOX ......................................................................................34743

KOOLCONNECT ..........................................................................55643

LASONIC ..........................................................................52645, 71147

LG ...................................................................................................58745

MAGNAVOX .................................................................................75547

MEMOREX ....................................................................................26142

MICROGEM .....................................................................18641, 59145

MICROSOFT .................................................................................86148

MINERVA .......................................................................................46344

MOTOROLA .......................................................38443, 65642, 95747

NBOX.............................................................................................57245

NEGRAVISION ..............................................................................16541

NOW TV ........................................................................................50445

PACE ..............................................................................................95747

PCT ................................................................................................53545

PHILCO ..........................................................................................75547

RCA .........................................................28042, 64046, 66442, 91349

ROKU .............................................................................................82648

SAMSUNG ....................................................................................14441

SANSONIC .......................................................................52645, 71147

SCIENTIFIC ATLANTA.....................................................27542, 35342

SKARDIN .......................................................................................29942

SLING MEDIA ...............................................................................14241

SUDDEN LINK ..............................................................................17141

SUNKEY ............................................................................41744, 47144

SUREWEST ....................................................................................55643

SYLVANIA ......................................................................................75547

TECHNICOLOR ............................................................................62144

THOMPSON .................................................................................62144

TIVAX ...................................................................11841, 45244, 97049

TRANSPARENT VIDEO SYSTEM .................................................39241

VENTURA ......................................................................................91349

VENTURER .......................................................................18041, 91349

VERIZON .......................................................................................65642

VUDU .............................................................................................19041

WD (WESTERN DIGITAL) ............................................................92749

WEGENER .....................................................................................16941

WINEGARD ......................................................................18041, 91349

XBOX .............................................................................................86148

ZENITH ..........................................................................................58745

ZENTECH .........................................................................29942, 81248

ZINWELL ...........................................................................30143, 48644

Auto Code Search: Top Brands

This search goes automatically through all device codes for the

select brands listed below. If your brand of device is listed, this

search can be quick and easy.

3. Manually turn on the device you

want to control.

5. Point the remote directly at the

front panel of the device you want

to control. Press POWER on the

remote.

The remote starts sending the on/

off command for a new code every

2 seconds.

1. Press and hold the device key

you want to program for about

2 seconds, until the POWER key

illuminates and stays on. Then

release the key.

2. Enter the ve-digit device code for

your device you want to operate.

11111 TV

22222 VCR

33333 Streaming Player

44444 Satellite Receiver, Cable Box,

Digital TV Converter

55555 DVD / Blu Ray Player

88888 Projector

66666 Audio/Amplier

66664 Soundbar

The POWER key ashes after the rst four digits and turns off

after the fth.

4. Press and hold the device key you

want to program for 2 seconds, until

the POWER key illuminates and

stays on. Then release the key.

When your device turns off:

Press the STOP key to store the code. You’re done! You’ve

programmed this device key.

If your device turns off but you waited more than 2

seconds: Press the PLAY key to go backwards through the

last few codes. When your device turns back on again, press

STOP to store that code.

Testing the Code for Maximum Functionality

1. Try a variety of the device’s functions with the remote. If

some device features don’t work, go to the next step to try

a different code.

2. Repeat the Brand Code Search from step 3.

3. Test the key’s functionality again by attempting to control

a variety of the device’s functions. If the code that has

been stored controls the majority of the device’s functions,

programming is complete. If the code stored does not give

maximum functionality, try another code.

NOTES

Throughout the programming of each key, be sure to keep the

remote pointed at the IR sensor of the device you are currently

programming the remote to control.

Test the remote with the device to make sure the device key is

programmed with the correct code for maximum functionality.

If some features don’t work, try a different code. See the

“Testing the Code for Maximum Functionality” section below

for more information.

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

POWER

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

POWER

Auto Code Search: All Brands

This search goes automatically through all the codes for the

device you’re trying to control. When you nd the one that

operates your device, you can stop the search and store that

code.

5. Point the remote directly at the front

panel of the device you want to

control. Press PLAY on the remote.

The remote starts sending the on/

off command for a new code every

2 seconds.

When your device turns off:

Press the STOP key to store the code. You’re done! You’ve

programmed this device key.

If your device turns off but you waited more than 2 seconds:

Press the PLAY key to go backwards through the last few

codes. When your device turns back on again, press STOP to

store that code.

3. Manually turn on the device you

want to control.

1. Press and hold the device key

you want to program fofr about

2 seconds, until the POWER key

illuminates and stays on. Then

release the key.

2. Enter the ve-digit device code for

your device you want to operate.

11111 TV

22222 VCR

33333 Streaming Player

44444 Satellite Receiver, Cable Box,

Digital TV Converter

55555 DVD / Blu Ray Player

88888 Projector

66666 Audio/Amplier

66664 Soundbar

The POWER key ashes after the rst four digits and turns off

after the fth.

4. Press and hold the device key

you want to program for about

2 seconds, until the POWER key

illuminates. Then release the key.

Testing the Code for Maximum Functionality

1. Try a variety of the device’s functions with the remote. If

some device features don’t work, go to the next step to try

a different code.

2. Repeat the search from step 3.

3. Test the key’s functionality again by attempting to control

a variety of the device’s functions. If the code that has

been stored controls the majority of the device’s functions,

programming is complete. If the code stored does not give

maximum functionality, try another code.

NOTES

Throughout the programming of each key, be sure to keep

the remote pointed at the IR sensor of the device you are

currently programming the remote to control.

Test the remote with the device to make sure the device key is

programmed with the correct code for maximum functionality.

If some features don’t work, try a different code. See the

“Testing the Code for Maximum Functionality” section below

for more information.

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

POWER

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

PLAYREVERSE FORWARD

INPUT

123

456

789

SAT•CABLE

STREAM

AUDIO

SOUNDBARTV

DVD

BLURAY

POWER

PAUSERECORD

STOP

GUIDE•HOME

MUTE GO BACK

CLEAR

OPTIONS

INFO

VOL CH

POWER

In most cases, the keys on this remote perform the same functions

as the keys on your original remotes once you’ve programmed this

remote to operate your components. Many keys on this remote

have other functions as well.

TV Volume Lock and Advanced Volume Lock

TV Volume Lock allows the VOL and MUTE keys, when pressed in

SAT•CABLE/STREAM or DVD/BLU RAY modes, to go directly to

your TV. TV Volume Lock occurs automatically and allows you to

control the TV volume without exiting the current mode.

Note: TV Volume Lock does not occur in cases where the

component code has its own volume/mute controls, such as some

satellite receivers.

Advanced Volume Lock lets you lock volume controls to a

different component, like a soundbar or audio receiver.

To use Advanced Volume Lock:

1. Press and hold the device key you want to use to control

volume for about 2s until the POWER key illuminates and

stays on. Then release the device key.

2. Press VOL+ once. The POWER key ashes once and remains

illumintated.

3. Press OK once to lock volume commands to this device. The

POWER key ashes twice and turns off.

Volume commands will now go to the device you specied.

To turn Advanced Volume Lock off:

1. Press and hold the device key that currently controls volume

for about 2s until the POWER key illuminates and stays on.

Then release the device key.

2. Press VOL- once. The POWER key ashes once and remains

illumintated.

3. Press OK once to unlock Volume commands. The POWER key

ashes twice and then turns off.

Volume commands will now go to your TV.

Channel Lock

Channel lock automatically sends channel commands, like the

CH, GO BACK, and 0–9 number keys, to your satellite receiver,

cable box, or digital TV converter when you’re in TV mode. This

can save you keypresses if you use a device other than your TV to

change channels.

To turn channel lock on:

1. Press and hold the device key you want to use to change

channels for about 2 seconds until the POWER key

illuminates. Then release the device key.

2. Press the CH + key once. The POWER key ashes once and

remains ON.

3. Press OK to lock channel commands to this device. The

POWER key ashes twice and turns off.

To turn channel lock off:

1. Press any device key for about 2 seconds until the POWER

key illuminates. Then release device key.

2. Press the CH + key once. The POWER key ashes once and

remains ON.

3. Press OK to unlock channel commands. The POWER key

ashes twice and turns off.

Code Retrieval

Once you’ve programmed the remote to control your devices,

you may want to record the codes for future reference. If you used

the Direct Code Entry method, this is easy. Just nd the codes you

entered and make a note of them in the boxes below. If you used

one of the Code Search methods to program your remote or if

you used the Direct Entry method but don’t remember the code,

you will need to retrieve each device’s ve-digit code. Retrieving

the actual code and writing it down will save you time if you ever

need to program the remote again. If the codes are recorded,

you can use the Direct Entry method to reprogram your remote to

control your devices, which is quick and easy.

1. Press and hold the device key (TV, SAT•CABLE/STREAM,

DVD/BLU RAY, AUDIO/SOUNDBAR) whose code you wish to

retrieve for about 2 seconds until the POWER key illuminates

and stays on. Then release device key.

2. Press the MENU key. The POWER key ashes once and

remains illuminated.

3. To retrieve the rst number in the code, press the 1 key on

the remote. The POWER key blinks to show the number that

is the rst digit in the code. For example, if the POWER key

blinks 3 times when you press the 1 key, the rst number in

the code is 3. Write this number in the corresponding box

below.

Repeat for each number in the code—press 2 to see the

second number in the code, 3 for the third, and so on until

you have all 5.

4. Press MENU to exit code retrieval.

TIP: To exit the Code Retrieval Mode at any time, press the

MENU key.

Voxx Accessories Corporation (the “Company”) warrants to you the original retail

purchaser of this product that should it, under normal use and conditions, be

proven defective in material or workmanship during its lifetime while you own

it, such defect(s) will be repaired or replaced (at the Company’s option) without

charge for parts and repair labor.

To obtain repair or replacement within the terms of the warranty, the product

is to be delivered with proof of warranty coverage (e.g. dated bill of sale),

specication of defect(s), transportation prepaid, to an approved warranty station.

For the location of the nearest warranty station to you, call toll-free to our control

ofce: 1-800-645-4994.

This Warranty does not cover product purchased, serviced or used outside

the United States or Canada. This Warranty is not transferable and does not

extend to costs incurred for installation, removal or reinstallation of the product.

This Warranty does not apply if in the Company’s opinion, the product has

been damaged through alteration, improper installation, mishandling, misuse,

neglect, accident, or the simultaneous use of different battery types (e.g. alkaline,

standard or rechargeable).

THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS

LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO

EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID

BY PURCHASER FOR THE PRODUCT.

This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED

WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE SHALL BE LIMITED TO DURATION

OF THIS WARRANTY. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY

CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER. No person or

representative is authorized to assume for the Company any liability other than

expressed herein in connection with the sale of this product.

Some states/provinces do not allow limitations on how long an implied warranty

lasts or the exclusion or limitation of incidental or consequential damage so the

above limitations or exclusions may not apply to you. This Warranty gives you

specic legal rights and you may also have other rights, which vary from state/

province to state/province.

Limited Lifetime Warranty

FCC Statement:

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution: Any Changes or modications not expressly approved by the

party responsible for compliance could void the user’s authority to operate

this equipment.

Industry Canada Regulatory Information CAN ICES-3 (B)/NMB-3 (B)

Avis d’Industrie Canada CAN ICES-3 (B)/NMB-3 (B)

Care and Maintenance

• Keep the remote dry. If it gets wet, wipe it dry immediately.

• Use and store the remote only in normal temperature environments.

• Handle the remote gently and carefully. Don’t drop it.

• Keep the remote away from dust and dirt.

• Wipe the remote with a damp cloth occasionally to keep it looking new.

• Modifying or tampering with the remote’s internal devices can cause

malfunction and invalidate its warranty.

ELEMENT, EMERSON, HISENSE, HITACHI, INSIGNIA, JVC,

LG, MAGNAVOX, PANASONIC, PHILIPS, PROSCAN, RCA,

ROKU TV, SAMSUNG, SANSUI, SANYO, SCEPTRE, SHARP,

SONY, SUNBRITETV, SYLVANIA, TCL, TOSHIBA, VIZIO,

WESTINGHOUSE

STREAM

APPLE TV, AT&T, DIGITAL STREAM, D-LINK, LG,

MICROSOFT, NETGEAR, NVIDIA, PHILIPS, QNAP, ROKU,

SAMSUNG, SEAGATE, SHARP, SONY, TIVO, UNBLOCK

TECH, VIZIO, WD (WESTERN DIGITAL), XBOX, XIAOMI,

XTREAMER

SAT-CBL

ADELPHIA, ARRIS, AT&T, CABLEVISION, CHARTER

COMMUNICATIONS, CISCO, COMCAST, COX, DIRECTV,

DISH NETWORK, MOTOROLA, PACE, SAMSUNG, SHARP,

SHAW, SHAW DIRECT, SPECTRUM, TIVO, VERIZON,

XFINITY

DVD-BLURAY

BOSE, FUNAI, INSIGNIA, LG, MAGNAVOX, MEMOREX,

ONN, PANASONIC, PHILIPS, PIONEER, RCA, SAMSUNG,

SANYO, SHARP, SONY, SYLVANIA, TOSHIBA, VIZIO

PROJECTOR

3M, BENQ, EPSON, LG, MITSUBISHI, NEC, OPTOMA,

PANASONIC, SONY, VANKYO, VIEWSONIC

VCR

HITACHI, JVC, MAGNAVOX, PHILIPS, RCA, SAMSUNG,

SANSUI, SANYO, SHARP, SONY, YAMAHA

AUDIO

BOSE, DENON, HARMAN/KARDON , INSIGNIA, JVC,

KENWOOD, LG, MARANTZ, ONKYO, PANASONIC, PHILIPS,

PIONEER, RCA, SAMSUNG, SANYO, SONY, TECHNICS,

VIZIO, YAMAHA

SOUNDBAR

BOSE, CRAIG, ILIVE, INSIGNIA, JBL, KLIPSCH, LG,

MAGNAVOX, ONN, PHILIPS, POLK AUDIO, PROSCAN,

RCA, SAMSUNG, SANYO, SONOS, SONY, VIZIO, YAMAHA

CD PLAYER

AIWA, HARMAN/KARDON, JVC, PANASONIC, PHILIPS,

RCA, SANSUI, SANYO, SHARP, SONY, YAMAHA

SAVE THIS MANUAL AND THE CODE LISTS!

Remote controls can sometimes lose their programming when you

change the batteries. Make sure you keep the manual and code lists

in a safe place so that you can reprogram the remote if you need to.

Tip: This remote is already programmed to operate most Samsung

TVs, DVD and Blu Ray players, Comcast cable boxes, and JBL audio

products. Just press the corresponding key—DVD/BLU RAY for a

DVD or Blu Ray player, TV for a television, SAT•CABLE/STREAM for

a satellite receiver, or AUDIO/SOUNDBAR for an audio device or

soundbar.

Loading ...

User Manual RCA RCRPST04BE 4 Device - Universal Remote Control - Streaming Player and Soundbar Compatible

Documents for RCA RCRPST04BE

Owner’s Manual

Specifications

RCA RCRPST04BE Questions and Answers

#1 How to get code list for RCA Remote Universal?

Photos
