ENGLISH
MODEL
CD-BH950
MINI COMPONENT SYSTEM
OPERATION MANUAL
CD-BH950 Mini Component System consisting of CD-BH950 (main unit) and CP-BH950 (speaker system).
Accessories
Please conrm that only the following accessories are included.
Special Note
Supply of this product does not convey a license nor imply any right to distribute content created with this product in
revenue-generating broadcast systems (terrestrial, satellite, cable and/or other distribution channels), revenue generating
streaming applications (via Internet, intranets and/or other networks), other revenue-generating content distribution
systems (pay-audio or audio-on-demand applications and the like) or on revenue-generating physical media (compact
discs, digital versatile discs, semiconductor chips, hard drives, memory cards and the like). An independent license for
such use is required. For details, please visit http://mp3licensing.com
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
Remote control x 1
(RRMCGA397AWSA)
AM loop antenna x 1
(QANTLA016AW01)
FM antenna x 1
(92LFANT1535A)
RRMCGA397AWSA
iPhone, iPod, iPod nano, and iPod touch are
trademarks of Apple Inc., registered in the U.S.
and other countries.
Lightning is a trademark of Apple Inc.
PORTABLE MUSIC BOOMBOX GX-BT9
REMOTE
SENSOR
16G R KI 1
Printed in Malaysia
TINSZB995AWZZ
B
arcodesof
t
http://www.barcodesoft.com
Barcode Symbology:
Code 93
; Font Facename:
Code93
M
H
r
Data To Encode:
TINSZB995AWZZ
Point Size 8 :
*TINSZB995AWZZWE*|
Point Size 10 :
*TINSZB995AWZZWE*|
Point Size 12 :
*TINSZB995AWZZWE*|
Point Size 14 :
*TINSZB995AWZZWE*|
● This audio system supports devices with Android 4.1, Jelly Bean and higher.
● For device with a lower Android version, refer the operation manual of the device for recommended app (application).
E-1
Explanation of Graphical Symbols:
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of suf-
cient magnitude to constitute a risk of electric shock
to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instruc-
tions in the literature accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT RE-
MOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
For users in U.S.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
This product is classied as a CLASS 1 LASER PRODUCT
Caution - Use of any controls, adjustments or procedures
other than those specied herein may result in hazardous
radiation exposure.
NOTE
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protec
-
tion against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the in-
structions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and re
-
ceiver.
● Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV technician
for help.
Warning: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC Radiation Exposure Statement
This device complies with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. It must not be co-located
or operating in conjunction with any other antenna or transmitter.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment should be installed and operated with a mini
-
mum distance of 20 cm between the radiator and person’s body.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to Article 820 of the National Electrical Code that
provides guidelines for proper grounding and, in particular,
species that the cable ground shall be connected to the
grounding system of the building, as close to the point of
cable entry as practical.
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss or theft,
please record below the model number and serial number which
are located on the rear of the unit. Please retain this information.
Model number ..............................
Serial number ..............................
Date of purchase ..............................
Place of purchase ..............................
The Bluetooth
®
word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and
any use of such marks by SHARP is under license.
Other trademarks and trade names are those of their
respective owners.
The N-Mark is a trademark or registered trademark
of NFC Forum, Inc. in the United States and in other
countries.
SPECIAL NOTES
Electricity is used to perform many useful functions, but it can also
cause personal injuries and property damage if improperly handled.
This product has been engineered and manufactured with the highest
priority on safety. However, improper use can result in electric shock
and/or re. In order to prevent potential danger, please observe the
following instructions when installing, operating and cleaning the
product. To ensure your safety and prolong the service life of this
product, please read the following precautions carefully before use.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched par
-
ticularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11) Only use attachments/accessories specied by the manufac
-
turer.
12) Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
IMPORTANT SAFETY INSTRUCTIONS
E-2
IMPORTANT SAFETY INSTRUCTIONS (continued)
13) Unplug this apparatus during lightning storms or when unused
for long periods of time.
14) Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate nor
-
mally, or has been dropped.
Additional Safety Information
15) Power Sources - This product should be operated only from the
type of power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your
product dealer or local power company. For product intended to
operate from battery power, or other sources, refer to the operat
-
ing instructions.
16) Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
re or electric shock.
17) Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a re or elec
-
tric shock.
To prevent re or shock hazard, do not expose this appliance
to dripping or splashing. No objects lled with liquids, such as
vases, shall be placed on the apparatus.
18) Damage Requiring Service - Unplug this product from the wall
outlet and refer servicing to qualied service personnel under
the following conditions:
a. When the AC cord or plug is damaged,
b. If liquid has been spilled, or objects have fallen into the prod
-
uct,
c. If the product has been exposed to rain or water,
d. If the product does not operate normally by following the oper
-
ating instructions. Adjust only those controls that are covered
by the operating instructions as an improper adjustment of
other controls may result in damage and will often require ex
-
tensive work by a qualied technician to restore the product
to its normal operation,
e. If the product has been dropped or damaged in any way, and
f. When the product exhibits a distinct change in performance -
this indicates a need for service.
19) Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts speci
-
ed by the manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may result in re,
electric shock, or other hazards.
20) Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
21) Wall or ceiling mounting - When mounting the product on a wall
or ceiling, be sure to install the product according to the method
recommended by the manufacturer.
22) Power Lines - An outside antenna system should not be located
in the vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or cir
-
cuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or cir
-
cuits as contact with them might be fatal.
23) Protective Attachment Plug - The product is equipped with an
attachment plug having overload protection. This is a safety
feature. See Instruction Manual for replacement or resetting of
protective device. If replacement of the plug is required, be sure
the service technician has used a replacement plug specied by
the manufacturer that has the same overload protection as the
original plug.
24) Stand - Do not place the product on an unstable cart, stand,
tripod or table. Placing the product on an unstable base can
cause the product to fall, resulting in serious personal injuries
as well as damage to the product. Use only a cart, stand, tripod,
bracket or table recommended by the manufacturer or sold with
the product. When mounting the product on a wall, be sure to
follow the manufacturer’s instructions. Use only the mounting
hardware recommended by the manufacturer.
■ General
● Please ensure that the equipment is positioned in a
well ventilated area and ensure that there is at least
4" (10 cm) of free space along the sides, top and back
of the equipment.
TIMER
CD
4
3
1
5
4
5
3
2
1
PHONES
RECORD/PLAYBACKPLAYBACK (PLAY & STOP)
2
AUDIO
IN
1
2
3
4
5
4
5
3
2
1
MINI COMPONENT SYSTEM
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
TAPE
TUNER
CD
TIMER
Bluetooth
POWER
ON/ STAND-BY
(BAND)
VOL.
VOL.
REMOTE
SENSOR
CD-BH950
4
"
(10 cm) 4
"
(10 cm)
4" (10 cm)
4" (10 cm)
0" (0 cm)
● The unit will start the tape initialization when plugged in
to the AC outlet. During this process, initializing sound
will be heard and the unit cannot be turned on. Wait
until the process is nished.
● Use the unit on a rm, level surface free from vibration.
● Place the speakers at least 12" (30 cm) away from
any CRT TV to avoid color variations across the TV
screen. If the variations persist, move the speakers
further away from the TV. LCD TV is not prone to such
variation.
● Keep the unit away from direct sunlight, strong
magnetic elds, excessive dust, humidity and
electronic/electrical equipment (home computers,
facsimiles, etc.) which generate electrical noise.
● Do not place anything on top of the unit.
● Do not expose the unit to moisture, to temperatures
higher than 140˚F (60˚C) or to extremely low
temperatures.
● If your system does not work properly, disconnect the
AC power cord from the AC outlet. Plug the AC power
cord back in, and then turn on your system.
● In case of an electrical storm, unplug the unit for safety.
● Hold the AC power plug by the head when removing
it from the AC outlet, as pulling the cord can damage
internal wires.
● The AC power plug is used as a disconnect device and
shall always remain readily operable.
● Do not remove the outer cover, as this may result
in electric shock. Refer internal service to your
local SHARP service facility.
● This unit should only be used within the range of
41˚F - 95˚F (5˚C - 35˚C).
Precautions
E-3
For U.S. customer only
CONSUMER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the
"Product"), when ship in its original container, will be free from defective workmanship and materials, and agrees that it will,
at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent
at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below
nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or
other misuse, abnormal service or handling, or which has been altered or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide
proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law.
ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE
LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those
described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and
exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described
herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise.
In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused
by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any
way responsible for any incidental or consequential economic or property damage. Some states do not allow the exclusion
of incidental or consequential damages, so the above exclusion may not apply to you.
THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND
PUERTO RICO.
Model Specific Section
Your Product Model Number & Description:
Warranty Period for this Product:
Additional Item(s) Excluded from Warranty Coverage
(if any):
Where to Obtain Service:
What to do to Obtain Service:
CD-BH950
Mini Component System
(Be sure to have this information available when you need
service for your Product.)
One (1) year parts and labor from the date of purchase.
Non-functional accessories, supplies, and consumable
items.
At a Sharp Authorized Servicer located in the United States.
To find a location of the nearest Sharp Authorized Servicer,
call Sharp toll free at 1-800-BE-SHARP.
Ship prepaid or carry in your Product to a Sharp Authorized
Servicer. Be sure to have Proof of Purchase available. If
you ship the Product, be sure it is insured and packaged
securely.
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP
SHARP ELECTRONICS CORPORATION
1 Sharp Plaza, Suite 1, Mahwah, NJ 07495-1123
Warning:
The voltage used must be the same as that specied on
this unit. Using this product with a higher voltage other than
that which is specied is dangerous and may result in a re
or other type of accident causing damage. SHARP will not
be held responsible for any damage resulting from use of
this unit with a voltage other than that which is specied.
■ Volume control
The sound level at a given volume setting depends on
speaker efciency, location and various other factors. It is
advisable to avoid exposure to high volume levels, which
occurs while turning the unit on with the volume control
setting up high, or while continually listening at high
volumes. Excessive sound pressure from earphones and
headphones can cause hearing loss.
Precautions (continued)
E-4
Controls and indicators
■ Front Panel
1. Disc Trays
2. Timer Indicator
3. CD / USB, Tape Stop Button
4. On/Standby Button
5. Bluetooth Button
6. CD Button
7. Tuner (Band) / Tape Button
8. Audio In / USB Button
9. Track Down or Fast Reverse, Tape Rewind, Tuning
Up Button
10. Tuning Down Button
11. Headphone Jack
12. Audio In Jack
13. USB Terminal
14. Volume Control
15. Remote Sensor
16. Play or Pause Button
17. Disc Tray Open / Close Button
18. Disc Number Select Buttons
19. Track Up or Fast Forward, Tape Fast Forward,
Preset Up Button
20. Preset Down Button
21. Cassette Compartment
22. NFC detection area
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
AUDIO IN
USB
PHONES
TAPE
TUNER
CD
TIMER
ON/ STANDBY
(BAND)
VOL.
VOL.
REMOTE
SENSOR
2
3
9
10
4
5
6
7
8
11
12
13
14
22
15
16
17
18
21
20
19
1
■ Rear Panel
1. AM Loop Antenna Terminal
2. FM 75 Ohms Antenna Jack
3. Speaker Terminals
4. AC Power Cord
■ Display
1. Disc Number Indicators
2. Folder Indicator
3. Title Indicator
4. Artist Indicator
5. Album Indicator
6. MP3 Indicator
7. WMA Indicator
8. FM Stereo Mode Indicator
9. FM Stereo Receiving Indicator
10. Sleep Indicator
11. Timer Play Indicator
12. Total Indicator
13. Tuning FM/Bluetooth pairing indicator
14. Daily Timer Indicator
15. Memory Indicator
16. Extra Bass Indicator
17. Repeat Play Indicator
18. Pause Indicator
19. Play Indicator
1234 567 89
16 17
18
19
14
12
10 11
13
15
1
2
3
4
E-5
■ Remote Control
1. Remote Control Transmitter
2. On / Standby Button
3. Disc Number Select Buttons
4. USB Button
5. CD Button
6. Audio In Button
7. Preset Up Button
8. Stop Button
9. Disc Track Down or Fast Reverse, Tape Rewind
Button
10. Folder Button
11. Preset Down Button
12. Tuning Up Button
13. Tuning Down Button
14. Treble Button
15. Demo Button
16. Eco Button
17. Clock Button
18. Timer Button
19. Mute Button
20. Memory Button
21. Tape Button
22. Bluetooth/Pairing Button
23. Tuner [Band] Button
24. Play/Pause Button
25. Enter Button
26. Disc Track Up or Fast Forward, Tape Fast Forward
Button
27. Play Mode Button
28. X-Bass Button
29. Volume Up Button
30. Volume Down Button
31. Bass Button
32. Display Button
33. Dimmer Button
34. Clear Button
35. Sleep Button
Controls and indicators (continued)
RRMCGA397AWSA
2
4
5
3
6
8
7
9
10
11
12
13
15
17
18
19
20
21
22
24
23
25
27
26
29
28
30
14
31
32
16
33
34
35
1
■ Speaker System
1. Tweeter
2. Woofer
3. Bass Reex Duct
4. Speaker Wire
1
2
3
4
E-6
System connection
Make sure to unplug the AC power cord before making any connections.
AC outlet (AC 120 V ~ 60 Hz)
FM antenna
External FM
antenna for
better reception
(not supplied)
AM loop antenna
Red
Black
To left
speaker
To right
speaker
CAUTION:
TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT,
FULLY INSERT.
■ Speaker connection
+ speaker terminal red wire
- speaker terminal black wire
● Use speakers with an impedance of 6 ohms or more,
as lower impedance speakers can damage the unit.
● Do not mistake the right and the left channels. The
right speaker is the one on the right side when you
face the unit.
● Do not let the bare speaker
wires touch each other.
● Do not allow any objects to fall
into or to be placed in the bass
reex ducts.
● Do not stand or sit on the
speakers. You may be injured.
Incorrect
■ Antenna connection
Supplied FM antenna:
Connect to the FM 75 ohms jack and position it where
reception is best.
External FM antenna:
Use an external FM antenna (75 ohms coaxial cable) for
better reception. Disconnect the supplied FM antenna wire
before use.
Supplied AM loop antenna:
Connect to the AM terminal and position it where reception
is best. Place it on a shelf, etc., or attach it to a stand or a
wall with screws (not supplied).
Installing the AM loop antenna
< Attaching to the wall >< Assembling >
wall
Screws (not
supplied)
Note:
Keep the antenna away from the unit or AC power cord to
avoid noise pickup.
■ Demonstration mode
● The rst time the unit is plugged in, the unit will enter
the demonstration mode. You will see words scroll.
● To cancel the demonstration mode, press the DEMO
button (remote control) once. The unit will enter the
Bluetooth standby mode.
● To cancel the Bluetooth standby mode, press the ECO
button (remote control). The unit will enter the low
power consumption mode.
● To return to the demonstration or Bluetooth standy
mode, press the DEMO button again.
● During demonstration or Bluetooth standby mode,
NFC function is activated once your device touches
the NFC detection area.
■ AC power connection
After all connections have been made correctly, plug the
AC power cord into the AC outlet.
Note:
Unplug the AC power cord from the AC outlet if the unit will
not be in use for a prolonged period of time.
E-7
■ Battery installation
Use 2 “AAA” size batteries (UM/SUM-4, R3, HP-16 or
similar). Batteries are not included.
1 Open the battery cover.
2 Insert the batteries according to the terminal indicated
in the battery compartment.
When inserting or removing the batteries, push it
toward the (–) battery terminals.
3 Close the cover.
Caution:
● Replace all old batteries with new ones at the same
time.
● Do not mix old and new batteries.
● Remove the batteries if the unit will not be used for a
long period of time. This will prevent potential damage
due to battery leakage.
● Do not use rechargeable batteries (nickel-cadmium
battery, etc.).
● Installing the batteries incorrectly may cause the unit
to malfunction.
● Batteries (battery pack or batteries installed) shall not
be exposed to excessive heat such as sunshine, re
or the like.
Notes concerning use:
● Replace the batteries if the operating distance is
reduced or if the operation becomes erratic. Purchase
2 “AAA” size batteries. (UM/SUM-4, R3, HP-16 or
similar)
● Periodically clean the transmitter on the remote control
and the sensor on the unit with a soft cloth.
● Exposing the sensor on the unit to strong light may
interfere with operation. Change the lighting or the
direction of the unit if this occurs.
● Keep the remote control away from moisture, heat,
shock, and vibrations.
■ Test of the remote control
Check the remote control after checking all the connections.
Point the remote control directly at the remote sensor on the
unit. The remote control can be used within the range shown
below:
Remote sensor
REMOTE
SENSOR
8” - 20’
(0.2 m
- 6 m)
Note:
Exposing the infrared remote control to direct sunlight may
cause the remote control to be inoperable.
Remote control
E-8
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
AUDIO IN
USB
PHONES
TAPE
TUNER
CD
TIMER
ON/ STANDBY
(BAND)
VOL.
VOL.
REMOTE
SENSOR
CD
Bluetooth
USB
AUDIO IN
TAPE
TUNER
(BAND)
ON/ STANDBY
VOL.
VOL.
RRMCGA397AWSA
■ To turn the power on
The rst time the unit is plugged in, the unit will enter the
demonstration mode.
Function Main unit
Remote
control
Operation
Power on/
off
POWER
ON/STANDBY
Press to turn the
power on or to
go to standby
mode.
Demo /
Bluetooth
Standby
____
Press to enter
demonstration
or Bluetooth
standby mode.
Eco mode
____
Press to enter
low power
consumption
mode.
Note:
During demonstration or Bluetooth standby mode, NFC
function is activated once your device touches the NFC
detection area.
■ Display brightness control
To dim the display brightness, press the DIMMER button
on the remote control.
DIMMER 1
DIMMER 2
DIMMER OF
F
(Display is dim).
(Display is bright).
(Display gets dimmer).
■ Volume auto fade-in
If you turn off and on the main unit with the volume set to
27 or higher, the volume starts at 16 and fades in to the
last set level.
■ Volume control
Turn the volume knob toward VOL. +/– (on main unit) or
press VOL +/– (on remote control) to increase or decrease
the volume.
■ Muting
To mute the volume, press the MUTE ( ) button (remote
control).
Press again to restore the volume.
■ Bass control (X-BASS)
When the power is rst turned on, the unit will enter the
extra bass mode which emphasizes the bass frequencies,
and “X-BASS” will appear. To cancel the extra bass mode,
press the X-BASS button.
■ Bass control
1 Press the BASS button to select “BASS”.
2 Within 3 seconds, press the VOL (+ or -) button to
adjust the bass.
■ Treble control
1 Press the TREBLE button to select “TREBLE”.
2 Within 3 seconds, press the VOL (+ or -) button to
adjust the treble.
■ Auto power on function
When you press any of the following buttons, the unit turns
on.
● Bluetooth, CD, USB, AUDIO IN, TUNER (BAND),
TAPE button (main unit/remote control): Selected
function is activated.
●
button (main unit): The unit turns on and playback
of the last function will start (Bluetooth, CD, USB,
AUDIO IN, TUNER, TAPE).
■ Auto power off function
The main unit will enter the standby mode after 15 minutes
of inactivity during:
AUDIO IN: No detection of input signal or very low sound
audibility.
CD / USB / TAPE: In the stop mode.
Bluetooth: In the pause or stop mode and no incoming
signal from a source device.
General control
E-9
■ About NFC technology
Near Field Communication (NFC) is a set of standards for
devices (smartphones/tablets) to establish radio communi-
cation with each other by touching/tapping them together or
bringing them into close proximity.
Using NFC in this product simplies the pairing method of
Bluetooth connectivity.
Notes for Android Device.
● This audio system supports NFC-enabled device with
Android 4.1, Jelly Bean and higher.
● For device with a lower Android version, refer the
operation manual of the device for recommended app
(application).
Unlike other wireless technology, NFC requires no
discovery or pairing.
Simply tap the source device to the NFC detection area
to instantly enjoy seamless connectivity between your
smart device and the audio system.
■ NFC detection area
NFC detection area location may vary depending on the
device (smartphone/tablet). Refer operation manual of the
device for detail.
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
AUDIO IN
USB
PHONES
TAPE
TUNER
CD
TIMER
ON/ STANDBY
(BAND)
VOL.
VOL.
REMOTE
SENSOR
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
AUDIO IN
USB
PHONES
TAPE
TUNER
CD
TIMER
(BAND)
VOL.
VOL.
REMOTE
SENSOR
ON/ STANDBY
NFC detection area on
the main unit
M
a
n
u
a
l
B
l
u
e
t
o
o
t
h
s
e
t
t
i
n
g
Switch ‘ON’
Bluetooth
Search/scan
A Bluetooth audio source
device (smartphone/
tablet).
Pairing
Connect
■ NFC connection for audio playback
Check that:
● Your device (smartphone/tablet) has an NFC function.
● NFC function on your device is enabled.
● Screen lock function of the device is off.
● This unit is not in low power consumption (ECO) mode.
● Your device must be within 10 meters from the unit.
1 Touch your device to the NFC detection area on the
main unit.
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
AUDIO IN
USB
PHONES
TAPE
TUNER
CD
TIMER
(BAND)
VOL.
VOL.
REMOTE
SENSOR
ON/ STANDBY
NFC detection area
on the main unit
2 A pop-up window asking whether to proceed with the
Bluetooth connection appears on the device. Select
<YES>.
● The ‘connected’ message appears when the connection is
complete.
3 Press play (on remote control or source device).
● Sound will be heard from the speakers of this unit via audio
streaming.
● Your device must be within 10 meters from the unit.
Various Bluetooth operation buttons (remote control only)
Press the button to play or pause.
Press the button to track up.
Press and hold to fast forward.
Press the button to track down.
Press and hold to fast reverse.
Notes:
● To disconnect, simply touch your device to the NFC
detection area on the main unit again.
● This product switches to Bluetooth function automati-
cally when NFC tagging is done by your device.
● If your device does not support NFC, or if you wish to
listen to audio via Bluetooth connectivity without NFC;
refer “Pairing with other Bluetooth source devices”
on the next page.
● Some Bluetooth devices will connect to this product
automatically when the device or its Bluetooth mode
was turned on. In such case, it will also change the
function selection of this product. If you do not want it
to connect automatically, please disable Bluetooth on
your device.
● It takes about 6-8 seconds for a Bluetooth enabled de-
vice (eg. smartphone) to establish Bluetooth connec-
tion with this unit via NFC or manual connection.
● If “Empty tag” or similar message appears on your de-
vice, touch the device again to the NFC detection area
on the main unit.
Bluetooth one touch connection via NFC
E-10
■ Bluetooth
Bluetooth wireless technology is a short-range radio
technology that enables wireless communication between
various types of digital devices, such as mobile phone or
computer. It operates within a range of about 32 feet (10
meters) without the hassle of having to use cables to con-
nect these devices.
This unit supports the following:
Communication System: Bluetooth Specication version
2.1 Bluetooth + Enhanced Data Rate (EDR).
Support Prole : A2DP (Advanced Audio Distribution Prole)
and AVRCP (Audio/Video Remote Control Prole)
Notes when using unit with a mobile phone
● This unit cannot be used to talk over the telephone even
when there is a Bluetooth connection made to a mobile
phone.
● Please refer to the operating manual supplied with the
mobile phone for details on operation of your mobile
phone while transmitting the sound using a Bluetooth
connection.
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
AUDIO IN
USB
PHONES
TAPE
TUNER
CD
TIMER
(BAND)
VOL.
VOL.
REMOTE
SENSOR
ON/ ST
ANDBY
RRMCGA397AWSA
ON/ STANDBY
■ Pairing Bluetooth devices
Bluetooth devices need to be initially paired rst before they
can exchange data. Once paired, it is not necessary to pair
them again unless:
● pairing is made with more than 99 devices.
Pairing can only be made one device at a time. This
unit can be paired to a maximum of 99 devices. If sub-
sequent device is paired, the oldest device paired, will
be deleted and replaced with the new one.
● this unit is reset. All pairing information is deleted when
unit is reset.
● pairing information is deleted while repairing, etc.
Indicators:
Indicator Condition Bluetooth status
Lights up
Connected
No indication Unconnected
However, the indicator status is not displayed during Blue-
tooth standby mode.
■ Pairing with other Bluetooth source devices
1 Press the ON/STANDBY button to turn the power on.
2 Press the
BLUETOOTH
button on the main unit or
BLUETOOTH (PAIRING) on the remote control to se-
lect Bluetooth function. “BLUETOOTH” appears on the
display.
3 Perform pairing procedure on the source device to de-
tect this unit. “CD-BH950 SHARP” will appear in the
detected devices list (if available) in the source device.
(Refer the source device operating manual for details).
Notes:
● Place the devices to be paired within 3 feet (1 me-
ter) of each other when pairing.
● Some source devices are unable to display lists of
detected devices. To pair this unit with the source
device, refer to the source device operating manual
for details.
4 Select “CD-BH950 SHARP” from the source list. If
Passcode* is required, enter “0000”.
* Passcode may be called PIN Code, Passkey, PIN
number or Password.
5 Pairing indicator light up once the unit is successfully
paired with the source device. (Pairing information is
now memorized in the unit.)
Some audio source devices may connect with the unit
automatically after pairing is completed, otherwise
follow the instructions in the source device operating
manual to start connection.
6 Press play (on remote control or source device) to start
Bluetooth streaming playback.
Notes:
● If a device such as microwave oven, wireless LAN card,
Bluetooth device or any other device that uses the same 2.4
GHz frequency near the system some sound interruption
may be heard.
● The transmission distance of the wireless signal between the
device and the main unit is about 32 feet (10 m), but may vary
depending on your operating environment. If a steel concrete
or metallic wall is between the device and the main unit, the
system may not operate at all, because the wireless signal
cannot penetrate metal.
● If this unit or the source device is turned off before Bluetooth
connection is completed, pairing will not be completed and
the pairing information will not be memorized. Repeat step 1
onward to start pairing again.
● To pair with other devices, repeat steps 1 - 4 for each de-
vice. This unit can be paired to a maximum of 99 devices. If
subsequent device is paired, the oldest device paired, will be
deleted and replaced with the new one.
● Once a device is ousted or deleted from the pairing list, the
pairing information for the device is also deleted. To listen to
the sound from the device again, it needs to be re-paired.
Perform steps 1 - 4 to pair the device again.
● CD-BH950 supports Bluetooth prole AVRCP 1.4. If your de-
vice supports the same prole (refer to device manufacturer’s
specication), CD-BH950 is able to control the volume of the
device.
Note:
Some music applications do not support this feature, hence
there will be no volume synchronisation between your de
-
vice and the unit even if your Bluetooth device supports such
prole.
Listening to Bluetooth enabled devices
E-11
■ Listening to the sound
Check that:
● The source device Bluetooth functionality is ON.
● Pairing of this unit and the source device is completed.
● Unit is in connected mode.
1 Press the ON/STANDBY button to turn the power on.
2 Press the BLUETOOTH button on the main unit or
BLUETOOTH (PAIRING) button on the remote control
to select Bluetooth function.
3 Start the Bluetooth connection from the Bluetooth audio
source device.
4 Press play (on remote control or source device).
Notes:
● For various Bluetooth operations, refer “NFC connec-
tion for audio playback” on page 9.
● If the source device has an extra bass function or
equalizer function, set them to off. If these functions
are on, sound may be distorted.
Notes:
● Make the Bluetooth connection again if the source device
is not turned on, or its Bluetooth functionality is off or is in
sleep mode.
● The volume of this unit may not be controlled as intend-
ed depending on the device.
■ To disconnect the Bluetooth device
Perform any of the followings.
- Disconnect the Bluetooth connection on the audio source
device.
Refer the operating manual supplied with the device.
- Turn off the Bluetooth audio source device.
- Turn off this unit.
- Press and hold the BLUETOOTH (PAIRING) button on the
remote control.
■ Auto power on
During Bluetooth standby mode, the unit will automatically
power on when the Bluetooth connection has been set up
between the main unit and your device.
Note:
This function is not applicable during low power consump-
tion (ECO) mode.
Listening to Bluetooth enabled devices (continued)
E-12
■ Introduction : Open Accessory
Open Accessory support allows external USB hardware
(an Android USB accessory) to interact with an Android-
powered device in a special accessory mode. When an
Android-powered device is in accessory mode, the con-
nected accessory acts as the USB host (powers the bus
and enumerates devices) and the Android-powered device
acts in the USB accessory role. Android USB accessories
are specically designed to attach to Android-powered
devices and adhere to the Open Accessory Protocol, that
allows them to detect Android-powered devices that support
accessory mode.
■ Android device connection (USB)
1 Insert the connector to the Android device.
Connector
(not supplied)
Android device
2 Connect the Android device to the unit via USB
connector.
AUDIO IN
USB
PHONES
■ Android device playback
1 Press the ON/STANDBY button to turn the power on.
2 Press the AUDIO IN (USB) button repeatedly on the
main unit or USB button on the remote control to select
USB function.
3 Connect the device to the unit. “USB MEDIA” will be
displayed.
4 Press play (on remote control or source device).
Notes:
● If the source device has an extra bass or equalizer
function, set them to off. If these functions are on,
sound may be distorted.
● Incoming calls will pause the playback/application.
● Once the calls are answered, the conversation can only
be heard through the built-in speaker of the cellular
device. Turn on the device speaker or disconnect the
device to start conversation.
■ To disconnect the Android device
1 Pause the playback or quit the application (app).
2 Disconnect the device from the USB terminal.
■ Various functions
Function
Remote control Operation
Track
up/down
Press in the playback or
stop mode.
If you press the button
in the stop mode, press
the / button to start the
desired track.
Fast
forward/
reverse
Press and hold down in
the playback mode.
Release the button to
resume playback.
Notes:
● If non-compatible device is detected “NO SUPPORT”
will be displayed.
● Controls (play/pause/track up/track down/fast forward /
fast reverse) will function based on actual application
(app) controls used on Android devices.
● Stop button ( ) is invalid during Android device
playback.
Android is a trademark of Google Inc.
Listening on Android™ devices
E-13
■ Disc playback
1 Press the ON/STANDBY button to turn the power on.
2 Press the CD button.
3 Press the 1 button and within 5 seconds, press the OPEN/
CLOSE button to open the disc tray 1.
4 Place the disc on the disc tray 1, label side up.
5 Press OPEN/CLOSE button to close the disc tray 1.
6 You can place discs on the trays 2 - 5 by following steps 3 - 5.
7 Press the button to start playback.
To stop playback completely:
● Press the
button twice.
Caution:
● Do not place two discs in one-disc-tray.
● Do not play discs of special shapes (heart, octagon,
etc). It may cause malfunctions.
● Do not push the disc tray while it is moving.
● If the power fails wait until the power is restored.
● If TV or radio interference occurs during CD operation,
move the unit away from the TV or radio.
● Be sure to place 8 cm (3”) disc in the middle of the
disc tray.
● Due to the structure of the disc information, it takes
longer to read an MP3/WMA disc than a normal CD
(approximately 20 to 90 seconds).
Notes for CD or MP3/WMA discs:
●
Rewritable multi-session discs with unnished writing, can
still be played.
■ To resume playback after stopping (resume
play)
You can resume playback from the point playback is stopped.
1 While a disc is playing, press the button once. The
system stores the point you stopped.
2 To resume play, press the
/
button. Playback re-
sumes from the point you stopped.
To cancel the resume playback:
Press the button twice.
Note:
Depending on the disc, playback may resume from slightly
before the stopped position.
■ Various disc functions
Function
Main
unit
Remote
control
Operation
Pause
Press in the playback
mode. Press the
button to resume playback
from the paused point.
Track up/
Track
down
Press in the playback or
stop mode. If you press the
button in the stop mode,
press the
button to
start the desired track.
Fast
forward/
Fast
reverse
Press and hold down in the
playback mode. Release
the button to resume
playback.
■ To specify a disc to play
You can play a disc by specifying the disc number.
1 Press one of the 1 - 5
buttons to select the desired
disc.
Selected disc number
2 Within 5 seconds, press the button.
● After the last track on the last disc is played, the unit stops
automatically.
Note:
If a disc tray with no disc is selected, playback will not start
and the disc indicator will disappear.
■ Repeat play
Repeat play can play all 5 discs, all tracks on a chosen
disc, single track on a chosen disc, or a programmed
sequence continuously.
To repeat one track:
Press the PLAY MODE button repeatedly until “I-REPEAT”
appears.
To repeat one disc:
Press the PLAY MODE button repeatedly until “DISC
REPEAT” appears.
To repeat all tracks on up to 5 discs:
Press the PLAY MODE button repeatedly until “ ALL
REPEAT”appears.
To repeat desired tracks:
Perform steps 1 - 5 in “Programmed play” section on page
14 and then press the PLAY MODE button repeatedly until
“ALL REPEAT” appears.
To repeat one folder:
While in folder mode in MP3/WMA, press the PLAY MODE
button repeatedly until “REPEAT FOL” appears.
To cancel repeat play:
Press the PLAY MODE button repeatedly until “NORMAL”
appears.
■ Random play
The tracks on the disc(s) can be played in random order
automatically.
To random play all tracks on up to 5 discs:
Press the PLAY MODE button repeatedly until “RANDOM”
appears.
To cancel random play:
Press the PLAY MODE button repeatedly until “NORMAL”
appears.
Notes:
● If you press the button during random play, you
can move to the next track by the random operation. On
the other hand, the button does not allow you to
move to the previous track. The beginning of the track
being played will be located.
● In random play, the unit will select and play tracks
automatically. (You cannot select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press
the button. Otherwise, the disc(s) will play continuously.
Listening to a CD or MP3/WMA disc
E-14
■ Programmed play (CD)
You can choose up to 32 selections for playback in the
order you like.
1 While in the stop mode,
press the MEMORY button
to enter the programming
save mode.
2 Press or button to select the desired
track.
3 Press the MEMORY button to save the track number.
4 Repeat steps 2 - 3 for other tracks. Up to 32 tracks
can be programmed.
5 Press the button to start playback.
To check the programmed track, during stop mode,
press the MEMORY button repeatedly. The desired
programmed tracks can be cleared by pressing the
CLEAR button
■ Programmed play (MP3/WMA)
1 While in the stop mode,
press the MEMORY
button to enter the
programing save mode.
2 Press the PRESET ( or ) button on the remote
control to select the desired folder.
Then press the
or button on the
remote control to select the desired tracks.
3 Press the MEMORY button to save the folder and
track number.
4 Repeat steps 2 - 3 for other folder/tracks. Up to 32
tracks can be programmed.
5 Press the button to start playback.
To cancel the programmed play mode:
During programmed stop mode, press the button. The
display will show “MEM CLEAR” and all the programmed
contents will be cleared.
Adding tracks to the program:
If a program has been previously stored, the “MEMORY”
indicator will be displayed. During stop mode, press the
MEMORY button once. Within 10 seconds, press and hold
the MEMORY button again. Then follow steps 2 - 3 to add
tracks.
Notes:
● When a disc is ejected, the program is automatically
canceled.
● If you press the ON/STANDBY button to enter the
standby mode or change the function from CD to
another, the programmed selections will be cleared.
● During the program operation, random play is not
possible.
■ Procedure to playback MP3/WMA disc
with folder mode on
To play back CD-R/RW.
1 In CD function, load an MP3/WMA disc. Press the
FOLDER button and disc info will be displayed.
TOTAL indicator
WMA indicator
MP3 indicator
Total number of les
2 Press the PRESET ( or ) button to select desired
playback folder. (Folder mode on)
First track number in
the folder
FOLDER
indicator
3 Select desired le to be played back by pressing the
or button.
4 Press the / button. Playback will start and le name
will be displayed.
● Title, Artist and Album name are displayed if they
are recorded on the disc.
● In case of playback with the folder mode on, press
the PRESET (
or ) button, and the folder can
be selected even though it is in playback/pause
mode. It will continue playback/pause mode in the
1st track of the selected folder.
● Display content can be changed by pressing the
DISPLAY button.
Title displayCounter display
Album display
Folder displayFile name display
Artist display
Note:
If “NO SUPPORT” is displayed, it means “Copyright protect-
ed WMA le” or “Not supported playback le” is selected.
Listening to a CD or MP3/WMA disc (continued)
E-15
TUNING
USB
AUDIO IN
TAPE
TUNER
CD
(BAND)
USB
AUDIO IN
USB
RRMCGA397AWSA
Note:
This product is not compatible with MTP and AAC le systems
from USB mass storage device or MP3 player.
■ To play back USB/MP3 player with folder
mode on / off
1 Press the AUDIO IN (USB) button (main unit) repeat-
edly to select USB function. Connect the USB memory
device that has MP3/WMA format files on the unit.
When the USB memory is connected to the main unit,
the device information will be displayed.
To playback with folder mode on, follow step 2 below.
To playback with folder mode off, skip to step 3 below.
2 Press the FOLDER button, and press the PRESET ( or
) button to select desired playback folder. To start play-
back, go to step 4. To change the playback folder, press
the PRESET ( or ) button to select another folder.
3 Select desired le to be played back by pressing the
or button.
4 Press the / button. Playback will start and the le
name will be displayed.
● Title, Artist and Album name are displayed if they
are recorded in the USB memory device.
● Display content can be changed by pressing the
DISPLAY button.
Note:
To pause playback:
Press the
/ button.
■ To remove USB memory device
1 Press the button to stop playback.
2 Disconnect USB memory device from the USB terminal.
Notes:
●
SHARP will not be held liable for the loss of data while the
USB memory device is connected to the audio system.
●
Files compressed in MP3 and/or WMA format can be played
back when connected to the USB terminal.
●
This USB memory’s format supports FAT 16 or FAT 32.
●
SHARP cannot guarantee that all USB memory devices will
work on this audio system.
●
USB cable is not recommended for use in this audio system
to connect to USB memory device. Use of the USB cable will
affect the performance of this audio system.
Advanced USB playback
The following functions are the same as CD operations:
Page
Various disc functions ...........................................................13
Repeat play ............................................................................13
Random play ..........................................................................13
Programmed play (MP3/WMA) .............................................14
Notes:
●
If USB memory device is not connected, “NO MEDIA” will be
shown on the display.
●
Fast forward/reverse is invalid when playing back a variable
bitrate le.
Notes:
●
This unit only supports “MPEG-1 Audio Layer-3” format.
(Sampling Frequency is 32, 44.1, 48kHz)
●
Playback order for MP3 les may differ depending on the
writing software used during le download.
●
Bitrate which is supported by MP3 is 32~320 kbps, WMA is
64~160 kbps.
●
For MP3/WMA les, please put “.MP3” “.WMA” extension.
Files cannot be played back if there is no MP3/WMA
extension.
●
Playlists are not supported on this unit.
●
This unit can display Folder Name or File Name up to 32
characters.
●
Maximum total number of MP3/WMA les is 65025.
●
Total number of folders read is 999 including folder with non
player les. However, the display shows only folder with MP3
les.
●
The display playback time may not be displayed correctly
when playing back a variable bitrate le.
●
The ID3TAG information supported are TITLE, ARTIST and
ALBUM only. Title name, artist name and album name can
be displayed by pressing the DISPLAY button during le
playback or pause mode.
●
WMA meta tag also supports title, artist and album name
which are recorded in WMA les. Copyright protected WMA
les cannot be played back.
●
This USB memory cannot be operated via USB hub.
●
The USB terminal in this unit is not intended for a PC
connection but is used for music streaming with a USB
memory device.
●
External HDD-storage cannot be played back via USB
terminal.
●
If the data inside the USB memory is large, it may take longer
time for the data to be read.
●
This product can play WMA and MP3 les. It will automatically
detect the le type being played. If unplayable le is played
on this product, “NO SUPPORT” is indicated and the le
will be automatically skipped. This will take a few seconds.
If abnormal indications appear on the display due to the
unspecied le, turn off the unit and then turn it on again.
●
This product relates to USB mass storage devices and MP3
players. It may however face some irregularities due to
various unforeseen reasons from some devices. Should this
happen, turn off the unit and then turn it on again.
●
The USB port is only intended for direct connection to a USB
memory device without any cable.
● MP3 player will not be charging in other than USB
function. However, charging ability depends on type of
MP3 player used.
Listening to USB mass storage device/MP3 player
E-16
Listening to the radio
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
AUDIO IN
USB
PHONES
TAPE
TUNER
CD
TIMER
ON/ STANDBY
(BAND)
VOL.
VOL.
REMOTE
SENSOR
OPEN / CLOSE
T
APE
TUNER
(BAND)
PRESET
TUNING
RRMCGA397AWSA
■ Tuning
1 Press the ON/STANDBY button to turn the power on.
2 Press the TUNER (BAND) (TAPE) button repeatedly
on the main unit or TUNER (BAND) button repeatedly
on the remote control to select the desired frequency
band (FM or AM).
3 Press the TUNING ( or ) button to tune in to the
desired station.
Manual tuning:
Press the TUNING (
or ) button as many times as
required to tune in to the desired station.
Auto tuning:
When the TUNING (
or ) button is pressed for more
than 0.5 seconds, scanning will start automatically
and the tuner will stop at the rst receivable broadcast
station.
Notes:
● When radio interference occurs, auto scan tuning may
stop automatically at that point.
● Auto scan tuning will skip weak signal stations.
● To stop the auto tuning, press the TUNING (
or )
button again.
To receive an FM stereo transmission:
● Press the TUNER (BAND) button to display the “ST”
indicator.
● “
” will appear when an FM broadcast is in stereo.
● If the FM reception is weak, press the TUNER (BAND)
button to extinguish the “ST” indicator. The reception
changes to monaural, and the sound becomes clearer.
■ Memorizing a station
You can store 40 AM and FM stations in memory and
recall them at the push of a button. (Preset tuning)
1 Perform steps 1 - 3 in “Tuning”.
2 Press the MEMORY
button to enter the
preset tuning saving
mode.
3 Within 30 seconds, press the PRESET ( or ) button
to select the preset channel number. Store the stations
in memory, in order, starting with preset channel 1.
4 Within 30 seconds, press the MEMORY button to
store that station in memory. If the “MEMORY” and
preset number indicators disappear before the station
is memorized, repeat the operation from step 2.
5 Repeat steps 1 - 4 to set other stations, or to change
a preset station. When a new station is stored in the
memory, the station previously memorized for that
preset channel number will be erased.
Note:
The backup function protects the memorized stations for
a few hours should there be a power failure or the AC
power cord become disconnected.
■ To recall a memorized station
Press the PRESET ( or ) button for less than 0.5
seconds to select the desired station.
■ To scan the preset stations
The stations saved in the memory can be scanned
automatically. (Preset memory scan)
1 Press the PRESET ( or ) button for more than
0.5 seconds. The preset number will ash and the
programmed stations will be tuned in sequentially, for
5 seconds each.
2 Press the PRESET ( or ) button again when the
desired station is located.
■ To erase entire preset memory (In TUNER
function)
Press and hold CLEAR button until ‘TUNER CLEAR’
appears.
E-17
Listening to a cassette tape
Before playback:
● For playback, use normal or low-
noise tapes for the best sound. (Metal
or CrO
2
tapes are not recommended.)
● Do not use C-120 tapes or poor-quality
tapes, as they may cause malfunctions.
● Before loading a tape into the cassette compartment,
tighten the slack with a pen or a pencil.
■ Tape playback
1 Press the ON/STANDBY button to turn the power on.
2 Open the cassette compartment
by pushing the area marked “
”.
3 Load a cassette into the
TAPE compartment with
the side to be played facing
toward you.
4 Press the TUNER (BAND)
TAPE button repeatedly on
the main unit to select TAPE.
4
5
3
2
1
OPEN / CLOSE
TUN
ING
PRE
SET
USB
AUD
IO
IN
T
A
P
E
T
U
N
E
R
CD
iPo
d/i
Pho
ne
ON/
ST
(B
A
N
D
)
VOL
.
VOL
.
5 Press the button to start playback.
■ Various tape functions
Function
Main
unit
Remote
control
Operation
Stop
Press in the
playback, fast
forward or fast
rewind mode.
Fast
forward/
rewind
Press in the
playback or stop
mode.
Caution:
● Before remove the cassette or changing from one tape
operation to another, press the
button.
● If a power failure occurs during tape operation, the
tape head will remain engaged with the tape and the
cassette door will not open. In this case, wait until the
power is restored.
■ Cleaning the tape-handling parts
● Dirty heads, capstans or pinch rollers can cause poor
sound and tape jams. Clean these parts with a cotton
swab moistened with commercial head/pinch roller
cleaner or isopropyl alcohol.
● When cleaning the heads, pinch rollers, etc., unplug
the unit which contains high voltages.
A Playback head
B Capstan
C Pinch roller
A
C
B
● After long use, the deck’s heads and capstans
may become magnetized, causing poor sound.
Demagnetize these parts once every 30 hours
of playing/recording time by using a commercial
tape head demagnetizer. Read the demagnetizer’s
instructions carefully before use.
RRMCGA397AWSA
In this example, the clock is set for the 12-hour (AM 12:00)
display.
1 Press the ON/STANDBY button to turn the power on.
2 Press the CLOCK button.
3 Within 10 seconds, press the ENTER button. To adjust
the day, press the or button and then
press the ENTER button.
4 Press the or button to select 24-hour or
12-hour display and then press the ENTER button.
The 12-hour display will appear.
(AM 12:00 - PM 11:59)
The 12-hour display will appear.
(AM 0:00 - PM 11:59)
The 24-hour display will appear.
(0:00 - 23:59)
5 To adjust the hour, press the or button
and then press the ENTER button. Press the or
button once to advance the time by 1 hour. Hold
it down to advance continuously.
6 To adjust the minutes, press the or but-
ton and then press the ENTER button. Press the
or button once to advance the time by 1 minute.
Hold it down to advance the time by 5 minutes interval.
To conrm the time display:
Press the CLOCK button. The time display will appear for
about 5 seconds.
Note:
When power supply is restored after unit is plugged in again
or after a power failure, reset the clock.
To readjust the clock:
Perform “Setting the clock” from step 1.
To change the 24-hour or 12-hour display:
1 Clear all the programmed contents. [Refer to “Factory
reset, clearing all memory” on page 20 for details.]
2 Perform “Setting the clock” from step 1 onward.
Setting the clock (Remote control
only)
E-18
Timer and sleep operation (Remote control only) (continued)
Timer playback:
The unit turns on and plays the desired source (CD,
TUNER, USB, AUDIO IN, TAPE) at a preset time.
This unit has 2 types of timer: ONCE TIMER and DAILY
TIMER.
Once timer (“
” indicator):
Once timer play works for one time only at a preset time.
Daily timer (“DAILY” indicator):
Daily timer play works at the same preset time every day
that we set. For example, set the timer as a wake-up call
every morning.
Using the once timer and daily timer in combination:
For example, use the once timer to listen to a radio
program, and use the daily timer to wake up.
1 Set the daily and once timer (pages 18).
1 minute or more
Daily timer Once timer
Stop StartStart Stop
■ Timer playback
Before setting timer:
● Check that the clock is set to the correct time. If it is not
set, you cannot use the timer function.
● For timer playback: Plug in USB, load disc or tape to
be played.
1 Press the ON/STANDBY button to turn the power on.
2 Press the TIMER button.
3 Within 10 seconds, press the or button
to select “ONCE” or “DAILY”, and press the ENTER
button.
4 Within 10 seconds, press the or button
to select “TIMER SET”, and press the ENTER button.
5 To select the timer playback source (CD, TUNER,
USB, AUDIO IN, TAPE), press the or
button. Press the ENTER button.
When you select the tuner, select a station by press-
ing the
or button, and then press the
ENTER button. If a station has not been programmed,
“NO PRESET” will be displayed and timer setting will
be canceled.
6 To adjust the day, press the or button
and then press the ENTER button.
7 Press the or button to adjust the hour,
and then press the ENTER button.
8 To adjust the minutes, press the or
button and then press the ENTER button.
9 Set the time to nish as in steps 7 and 8 above.
10 Adjust the volume using the VOLUME control, and then
press the ENTER button.
11 Press the ON/STANDBY button to enter the power
standby mode. “TIMER” indicator lights up.
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
TAPE
TUNER
CD
TIMER
ON/ STANDBY
(BAND)
VOL.
VOL.
REMOTE
SENSOR
12 When the preset time is reached, playback will start. The
volume will increase gradually until it reaches the preset
volume. The timer indicator will blink during timer playback.
13 When the timer end time is reached, the system will
enter the power standby mode automatically.
Once timer:
The timer will be canceled.
Daily timer:
The timer operates at the same time every selected
day. Cancel the daily timer when it is not in use.
Notes:
● When performing timer playback using another unit
connected to the USB terminal or AUDIO IN jack, se-
lect “USB” or “AUDIO IN” in step 5. This unit will turn on
or enter the power standby mode automatically. How-
ever, the connected unit will not turn on or off.
● To stop the timer playback, follow step “Cancelling
the timer setting” of this page.
Checking the timer setting:
1 Turn the power on. Press the TIMER button.
2 Within 10 seconds, press the or button
to select “ONCE” or “DAILY”, and press the ENTER
button.
3 Within 10 seconds, press the or button
to select “TIMER CALL”, and press the ENTER button.
Cancelling the timer setting:
1 Turn the power on. Press the TIMER button.
2 Within 10 seconds, press the or but-
ton to select “ONCE” or “DAILY”, and press the ENTER
button.
3 Within 10 seconds, press the or button
to select “TIMER OFF”, and press the ENTER button.
Timer will be canceled (the setting will not be canceled).
Reusing the memorized timer setting:
The timer setting will be memorized once it is entered. To
reuse the same setting, perform the following operations.
1 Turn the power on. Press the TIMER button.
2 Within 10 seconds, press the or button
to select “ONCE” or “DAILY”, and press the ENTER
button.
3 Within 10 seconds, press the or button
to select “TIMER ON” , and press the ENTER button.
4 Press the ON/STANDBY button to enter the power
standby mode.
■ Sleep operation
The radio, disc, USB and Audio In can all be turned off
automatically.
1 Play back the desired sound source.
2 Press the SLEEP button.
3 Within 5 seconds, press the SLEEP button repeatedly
to select the time.
“SLEEP 90”
“SLEEP 80” ... “SLEEP 10”
“SLEEP OFF”
4 “SLEEP” indicator will appear.
5 The unit will enter the power standby mode
automatically after the preset time has elapsed. The
volume will be turned down 1 minute before the sleep
operation nishes.
To conrm the remaining sleep time:
1 While “SLEEP” is indicated, press the SLEEP button.
To cancel the sleep operation:
Press the ON/STANDBY button while “SLEEP” is indicated.
To cancel the sleep operation without setting the unit to the
standby mode, proceed as follows.
1 While “SLEEP” is indicated, press the SLEEP button.
2 Within 5 seconds, press the SLEEP button repeatedly
until “SLEEP OFF” appears.
E-19
Timer and sleep operation (Remote
control only) (continued)
■ To use timer and sleep operation together
Sleep and timer playback:
For example, you can fall asleep listening to the radio and
wake up to CD in the next morning.
1 Set the sleep time (see above, steps 1 - 5).
2 While the sleep timer is set, set the timer playback
(steps 2 - 10, page 18).
Sleep timer
setting
Timer playback
setting
End time
Timer playback
start time
Sleep operation will
automatically stop
Desired time10 - 90 minutes
Enhancing your system
The connection cord is not included. Purchase a
commercially available cord as shown below.
1
2
3
4
5
4
5
3
2
1
OPEN / CLOSE
TUNING
PRESET
USB
AUDIO IN
AUDIO IN
USB
PHONES
TAPE
TUNER
CD
TIMER
ON/ STANDBY
(BAND)
VOL.
VOL.
REMOTE
SENSOR
AUDIO IN
PHONES
Portable audio
player, etc.
Audio cable (not supplied)
■ Listening to the playback sounds of
portable audio player, etc.
1 Connect a portable audio player etc. to the front
AUDIO IN jack.
2 Press the ON/STANDBY button to turn the power on.
3 Press the AUDIO IN/USB button repeatedly to select
AUDIO IN.
4 Play the connected equipment.
If volume level of the connected device is too high,
sound distortion may occur. Should this happen, lower
the volume of the connected device.
If volume level is too low, increase the volume of the
connected device.
Note:
To prevent noise interference, place the unit away from
the television.
■ Headphones
● Before plugging in or unplugging the headphones,
reduce the volume.
● Be sure your headphones have a 1/8" (3.5 mm)
diameter plug and impedance between 16 and 50
ohms. The recommended impedance is 32 ohms.
● Plugging in the headphones disconnects the speakers
automatically. Adjust the volume using the VOLUME
control.
Troubleshooting chart
Many potential problems can be resolved by the owner
without calling a service technician. If something is wrong
with this product, check the following before calling your
authorized SHARP dealer or service center.
■ General
Symptom Possible cause
● The clock is not set
to the correct time.
● Did a power failure occur?
Reset the clock. (Refer page
17)
● When a button is
pressed, the unit
does not respond.
● Set the unit to the power
standby mode and then turn
it back on.
● If the unit still malfunctions,
reset it. (Refer page 20)
● No sound is heard. ● Is the volume level set to “0”?
● Are the headphones
connected?
● Are the speaker wires
disconnected?
■ CD player
Symptom Possible cause
● Playback does not
start.
● Playback stops in
the middle or is not
performed properly.
● Is the disc loaded upside
down?
● Does the disc satisfy the
standards?
● Is the disc distorted or
scratched?
● Playback sounds
are skipped, or
stopped in the
middle of a track.
● Is the unit located near
excessive vibrations?
● Is the disc very dirty?
● Has condensation formed
inside the unit?
● “ER-CD21”
appears on the
display.
● Is the disc tray stopped with
force? Set the unit to the
power standby mode and
then turn it back on.
■ Cassette deck
Symptom Possible cause
● Sound skipping.
● Cannot hear treble.
● Sound uctuation.
● Is there any slack?
● Is the tape stretched?
● Are the capstans, pinch
rollers, or heads dirty?
● Cannot remove the
tape.
● If a power failure occurs
during playback, the heads
remain engaged with the
tape. Do not open the
compartment with great
force.
■ Remote control
Symptom Possible cause
● The remote control
does not operate.
● Is the AC power cord of the
unit plugged in?
● Is the battery polarity
correct?
● Is the battery dead?
● Is the distance or angle
incorrect?
● Does the remote control
sensor receive strong light?
E-20
Troubleshooting chart (continued)
Maintenance
■ Cleaning the cabinet
Periodically wipe the cabinet with a soft cloth and a diluted
soap solution, then with a dry cloth.
Caution:
● Do not use chemicals for cleaning (gasoline, paint thinner,
etc.). It may damage the cabinet.
● Do not apply oil to the inside of the unit. It may cause
malfunctions.
■ Cleaning the CD pickup lens
In order to ensure proper operation of the CD player,
preventative maintenance (cleaning of the laser pickup
lens) should be performed periodically. Lens cleaners are
commercially available. Contact your local CD software
dealer for options.
■ Tuner
Symptom Possible cause
● The radio makes
unusual noises
continuously.
● Is the unit placed near the TV
or computer?
● Is the FM antenna or AM loop
antenna placed properly?
Move the antenna away from
the AC power cord if it is
located nearby.
■ Bluetooth
Symptom Possible cause
● No sound is heard. ● The unit is too far from the
Bluetooth audio source
device.
● The unit is not paired with
the Bluetooth audio source
device.
● Bluetooth sound
is interrupted or
distorted.
● The unit is too near to
a device that generates
electromagnetic radiation.
● There is an obstacle between
the unit and the Bluetooth
audio source device.
■ NFC
Symptom Possible cause
● NFC-enabled
device cannot
connect to
Bluetooth when
tapping on N-Mark.
● The unit is in Eco mode.
● NFC mode is disabled on your
device.
● Your device is in sleep mode.
■ Open Accessory
Symptom Possible cause
● No sound is pro-
duced.
● The device is not playing.
● The device is not properly
connected to the unit.
● The AC power cord of the unit
is not plugged in.
● Device is not
charging.
● The device is not making full
contact with the USB terminal.
■ USB
Symptom Possible cause
● Device cannot be
detected.
● Playback does not
start.
● There is no MP3/WMA le
inside the device.
● The device is not properly
connected.
● A MTP device is connected.
● The device contains AAC
le only.
● A copyright-protected WMA
or false MP3 le is being
played back.
● Wrong time
display.
● Wrong le name
display.
● A Variable Bitrate les are
being played back.
● The File Name was written in
other than English characters.
■ If problem occurs
When this product is subjected to strong external
interference (mechanical shock, excessive static
electricity, abnormal supply voltage due to lightning, etc.)
or if it is operated incorrectly, it may malfunction.
If such a problem occurs, do the following:
1 Set the unit to the standby mode and turn the power
on again.
2 If the unit is not restored in the previous operation,
unplug and plug in the unit again, and then turn the
power on.
Note:
If neither operation above restores the unit, clear all the
memory by resetting it.
■ Factory reset, clearing all memory
1 Press the ON/STANDBY button to turn the power on.
2 Press AUDIO IN (USB) button (main unit) repeatedly or
AUDIO IN button (remote control) to enter Audio In mode.
3 Press button (main unit) once.
4 Press and hold button (main unit) until “RESET” appears.
5 Unplug and plug in the main unit again.
Caution:
This operation will erase all data stored in memory including
clock, timer settings, tuner preset, and CD program.
■ Condensation
Sudden temperature changes, storage or operation in an
extremely humid environment may cause condensation
inside the cabinet (CD pickup, tape heads, etc.) or on the
transmitter on the remote control. Condensation can cause
the unit to malfunction. If this happens, leave the power on
with no disc (or cassette) in the unit until normal playback
is possible (about 1 hour). Wipe off any condensation on
the transmitter with a soft cloth before operating the unit.
■ Before transporting the unit
Remove the USB memory device and disc from the unit.
Then, set the unit to the power standby mode. Carrying the
unit with USB memory device left connected or discs left
inside might damage the unit.
E-21
Specications
As part of our policy of continuous improvement, SHARP
reserves the right to make design and specication changes
for product improvement without prior notice. The performance
specication gures indicated are nominal values of production
units. There may be some deviations from these values in
individual units.
■ General
Power source AC 120 V ~ 60 Hz
Power consumption 60 W
Dimensions Width: 10 - 1/4" (260 mm)
Height: 13 - 1/16" (332 mm)
Depth: 13 - 8/16" (345 mm)
Weight 9.9 lbs. (4.5 kg)
■ Amplier
Output power RMS: Total 240 W (120 W per
channel into 6 ohms at
1 kHz, 10% Total harmonic
distortion.)
FTC: 110 W minimum RMS per
channel into 6 ohms from
20 Hz to 20 kHz, 10% Total
harmonic distortion.
Output terminals Front Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Input terminals Audio In (audio signal):
500 mV/47 k ohms
■ Bluetooth interface
Bluetooth Frequency
band
2.400GHz - 2.480GHz
Compatible Bluetooth
Prole
A2DP (Advanced Audio
Distribution Profile), AVRCP
(Audio/Video Remote Control
Profile)
Bluetooth 2.1 + EDR
■ Tuner
Frequency range FM: 87.5 - 108.0 MHz
AM: 530 - 1,710 kHz
Preset 40 (FM and AM station)
■ CD player
Type 5-disc multi-play compact disc
player
Signal readout Non-contact, 3-beam
semiconductor laser pickup
D/A converter Multi bit D/A converter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
■ Cassette deck
Frequency response 50 - 14,000 Hz (normal tape)
Signal/noise ratio
50 dB (playback)
Wow and utter 0.3% (WRMS)
Tape speed 4.76 cm/sec. (1 - 7/8” ips)
Heads Playback
■ USB (MP3/WMA)
USB host interface Complies with USB 1.1 (Full
Speed)/2.0 Mass Storage Class.
Support Bulk only and CBI
protocol.
Support le MPEG 1 Layer 3
WMA (Non DRM)
Bitrate support MP3 (32 ~ 320 kbps)
WMA (64 ~ 160 kbps)
Other Maximum total number of MP3/
WMA les is 65025.
Maximum total number of folders is
999 INCLUSIVE of root directory.
The ID3TAG information supported
are TITLE, ARTIST and ALBUM
only.
Supports ID3TAG version 1 and
version 2.
File system support Support USB devices with FAT 16/
FAT 32.
■ Speaker
Type 2-way type speaker system
2” (5 cm) tweeter
5 - 1/8” (13 cm) woofer
Maximum input
power
240 W
Rated input power 120 W
Impedance 6 ohms
Dimensions Width: 8 - 11/16" (220 mm)
Height: 13 - 1/16" (332 mm)
Depth: 8 - 3/4" (222 mm)
Weight 6.6 lbs. (3.0 kg)
