User manual Heater for Dimplex 403TSFTIE7

Using the Heater

  • The product can be used as an installed or portable unit. Once the desired application has been decided upon and the requirements below have been met, the product is ready to be used. Simply plug in and switch on at the wall socket.
  • There are various control options available with various combinations via the membrane buttons and segmented display. Please note - the element has been coated with a protective film which will burn off during the first few minutes of use and may cause a small amount of fuming. This is quite normal - the fumes are non-toxic and will quickly disappear. We recommend that you open a window to ventilate the room when using the heater for the first time.

Free Standing Use

  • Lay the heater on its back and remove the wall mounting brackets - see ‘Wall Mounting’. Locate the footfixing screw (see ‘a’ in Fig. 3) and remove the screw using an X-head screwdriver, then align foot over slots and holes in base (see ‘b’ in Fig. 3) and push into the slots. Finally take the foot fixing screw, insert and tighten using a screwdriver to secure the foot.
  • NOTE: The wall mounting brackets must be removed before the foot can be fitted. The brackets should be retained for wall mounting the product in the future if required.

Setting the Time and Week Day

The time and day are set with the following steps:

  • Press and hold the PROG key for three seconds. The clock symbol appears. The hours and display flashes.
  • Use the +/- keys to set the hours. Press the ENTER key. The minutes diplay flashes
  • Use the +/- keys to set the minutes. Press the ENTER key. The weekday flashes.
  • Use the +/- keys to set the day of the week. Press the ENTER key. The CLOCK symbol disappears. Setting is complete.

Setting time block ON

  • Press the ENTER key. P1 (period 1) and ON apprears. The hours display flashes
  • Use the +/- keys to set the hours. Press the ENTER key. The minutes display flahses.
  • Use the +/- to s
