User Manual

This is the main product document for model VR20K9350WK/SA. Series: SR20K9350W* Series
Additionally, the document applies to other Samsung models: SR20K9350W*, VR20K9350WK

The file format is pdf, 36 pages, you can download this manual here .

5
background
POWERbot
User manual
SR20K9350W
Series
• Beforeoperatingthisunit,pleasereadtheinstructionscarefully.
• Forindooruseonly.
SR9300K_EN_DJ68-00743J-00_SA.indd 1 2016-07-15 오후 3:47:49
background
ENGLISH-02
Contents
03
Safety information
08
Installation
Accessories/Installationnote
10
Charging
Automaticcharging/Recharging/Low
battery(Lo)
12
Installing the Virtual guard
PartnameoftheVirtualguard/Inserting
batteries
14
Using POWERbot
Selectingcleaningmode
16
Using the remote control
Power/Recharging/Start/Stop/Suction
power/Additionalfunction/Manualclean
mode&Directioncontrol/Pointcleaning
18
Name of each part
Top/Bottom/Displaypanel
19
Setting time/schedule
Settingthetime/Settingtheschedule
20
Cleaning and maintaining
Cleaningthedustbin/Cleaningthesensorsand
thecamera/CleaningthePetbrush/Cleaningthe
Drivingwheel
22
Samsung Smart Home App
Preparingthenetwork/UsingtheSamsungSmart
Homeapp
30
Notes and cautions
Charging/Inuse/Cleaningandmaintenance/About
battery/AbouttheIrDAsensor
32
Information codes
33
Troubleshooting
35
Open Source Announcement
35
Specifications
SR9300K_EN_DJ68-00743J-00_SA.indd 2 2016-07-15 오후 3:47:49
background
ENGLISH-03
Safety information
SAFETY INFORMATION
WARNING
• Beforeoperatingtheappliance,pleasereadthismanualthoroughlyandretainit
foryourreference.
WARNING
• Becausethesefollowingoperatinginstructionscovervariousmodels,the
characteristicsofyourvacuumcleanermaydifferslightlyfromthosedescribedin
thismanual.
CAUTION/WARNING SYMBOLS USED
WARNING
Indicates that a danger of death or serious injury exists.
CAUTION
Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
NOTE
Indicates that the following text contains additional important
information.
This Smart Robot vacuum supports from Samsung Smart Home.
More detailed information, please visit Samsung.com/Smarthome.
Indicates that a detachable supply unit.
SR9300K_EN_DJ68-00743J-00_SA.indd 3 2016-07-15 오후 3:47:49
background
ENGLISH-04
Safety information
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should be observed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING YOUR POWERbot.
Unplug from outlet when not in use and before conducting maintenance.
WARNING: to reduce the risk of fire, electric shock, or injury:
GENERAL
•Useonlyasdescribedinthismanual.
•DonotoperatePOWERbotorCharger/dockingstationifithasbeendamagedinany
way.
•Ifthevacuumcleanerisnotworkingasitshould,hasbeendropped,damaged,left
outdoors,ordroppedinwater,returnittoacustomercarecenter.
•DonothandletheCharger/dockingstationorPOWERbotwithwethands.
•Useonlyondry,indoorsurfaces.
•Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswith
reducedphysical,sensoryormentalcapabilitiesorlackofexperienceandknowledge
iftheyhavebeengivensupervisionorinstructionconcerninguseoftheapplianceina
safewayandunderstandthehazardsinvolved.
•Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshallnotbe
madebychildrenwithoutsupervision.
BATTERY Charger / docking station
•Donotmodifythepolarizedplugtofitanon-polarizedoutletorextensioncord.
•Donotuseoutdoorsoronwetsurfaces.
•UnplugtheCharger/dockingstationfromtheoutletwhennotinuseandbefore
servicing.
•UseonlytheCharger/dockingstationsuppliedbythemanufacturertorecharge.
•Donotusewithadamagedcordorplugoraloosepoweroutlet.
•Donotpullorcarrybythecord,usethecordasahandle,closethedooronthecord,
orpullthecordaroundsharpedgesorcorners.Keepthecordawayfromheated
surfaces.
•Donotuseextensioncordsoroutletswithinadequatecurrentcarryingcapacity.
•Donotunplugbypullingonthecord.Tounplug,grasptheplug,notthecord.
•Donotmutilateorincineratebatteriesastheywillexplodeathightemperatures.
•DonotattempttoopentheCharger/dockingstation.Repairsshouldonlybecarried
outbyaqualifiedcustomercarecenter.
SR9300K_EN_DJ68-00743J-00_SA.indd 4 2016-07-15 오후 3:47:49
background
ENGLISH-05
•DonotexposetheCharger/dockingstationtohightemperaturesorallowmoistureor
humidityofanykindtocomeintocontactwiththecharger/dockingstation.
POWERbot
•Donotpickuphardorsharpobjectssuchasglass,nails,screws,coins,andetc.
•Donotusewithoutafilterinplace.Whenservicingtheunit,neverputfingersorother
objectsintothefanchamberincasetheunitaccidentallyturnson.
•Donotputanyobjectsintoopenings.Donotusewithanyopeningsblocked;keep
openingsfreeofdust,lint,hair,andanythingthatmayreduceairflow.
•Donotpickuptoxicmaterials(chlorinebleach,ammonia,draincleaner,etc.).
•Donotpickupanythingthatisburningorsmoke,suchascigarettes,matches,orhot
ashes.
•Donotusetopickupflammableorcombustibleliquidssuchasgasoline,noruseon
areaswheretheymaybepresent.
•Locationswithcandlesordesklampsonthefloor.
•Locationswithunattendedfires(fireorembers).
•Locationswithdistilledalcohol,thinner,ashtrayswithburningcigarettes,etc.
•DonotusePOWERbotinanenclosedspacefilledwithvapoursgivenoffbyoilbased
paint,paintthinner,mothproofingsubstances,flammabledust,orotherexplosiveor
toxicvapours.
•Leaksfrombatterycellscanoccurunderextremeusageortemperatureconditions.
Iftheliquidgetsonskin,washquicklywithwater.Iftheliquidgetsintotheeyes,
flushthemimmediatelywithcleanwaterforaminimumof10minutes.Seekmedical
attention.
SR9300K_EN_DJ68-00743J-00_SA.indd 5 2016-07-15 오후 3:47:49
background
ENGLISH-06
WARNING
Power related
f Pleasepreventanyriskofelectricshockor
fire.
– Donotdamagethepowercord.
– Donotpullthepowercordtoohardortouch
thepowerplugwithwethands.
– Donotuseapowersourceotherthan
100-240V~andalsodonotuseamultioutlet
tosupplypowertonumberofdevicesatthe
sametime.(Donotleavethecordcarelesslyon
thefloor.)
– Donotuseadamagedpowerplug,powercord
orloosepoweroutlet.
f Cleandustoranyforeignmattersonthepin
andcontactpartofthepowerplug.
– Thereisariskofelectricshockormalfunction.
WARNING
Before use
f DonotusePOWERbotnearcombustible
materials.
– Placenearcandle,desktoplamps,fireplaceor
nearcombustiblematerialssuchasgasoline,
alcohol,thinnersetc.
f ThePOWERbotisintendedforhousehold
usethereforedonotuseitinanattic,
basement,storage,industrialbuilding,outof
indoorspace,placeswithmoisture(suchas
bathroom,laundry),onthetableorshelves.
– ThePOWERbotcanbedamagedor
malfunction.
f InstalltheVirtualguardinfrontofdangerous
areas(suchasstairsorrailings)toprevent
damagingtheproductorgettinginjured.
– Foryoursafety,alwayskeepthecliffsensor
clean.
f BesurePOWERbotdoesnotpassthroughor
touchanykindofliquids.
– ThePOWERbotcanbeseverelydamagedand
itmaycontaminateotherareasifthewheels
passthroughliquid.
f Donotspillanyliquidsonthedockingstation.
– Thereisariskoffireorelectricshock.
f Donotusethedockingstationforanything
otherthanitsintendedpurpose.
– Thereisariskoffireorseveredamagetothe
dockingstation.
f Alwayskeepthecliffsensorcleanforyour
safety.
WARNING
In use
f Ifanyabnormalsounds,smellsorsmoke
comefromPOWERbot,immediatelyshut
offtheemergencyswitchatthebottomof
POWERbotandcontactaservicecenter.
WARNING
Cleaning and
maintenance
f Whenpowercordisdamaged,contacta
servicecentertogetitreplacedbycertified
repairman.
– Thereisariskoffireorelectricshock.
f PleasecheckwithaSamsungElectronics
servicecenterwhenexchangingbatteries.
– Usingbatteriesfromotherproductscancause
malfunction.
Safety information
SR9300K_EN_DJ68-00743J-00_SA.indd 6 2016-07-15 오후 3:47:49
background
ENGLISH-07
CAUTION
Before use
f InsertthedustbinbeforeusingPOWERbot.
f Openroomdoorsbeforecleaninginorder
tohaveallroomscleanedandinstalla
Virtualguardinfrontofentryway,balconies,
bathrooms,orotherareaswherePOWERbot
mayfall.
f Becarefulwiththefollowingsforproper
automaticrecharging.
– Alwaysturnonthepowerofthedocking
station.
– InstallthedockingstationwherePOWERbot
caneasilyfind.
– Donotleaveanyobjectinfrontofthedocking
station.
f Wheninstallingthedockingstation,donot
leavethecordcarelesslyonthefloorsince
POWERbotmaygettangledbyit.
f DonotusePOWERbotonblackcolored
floors.
– ThePOWERbotmaynotbeabletooperate
normally.
f DonotpickupPOWERbotbythedustbin
holder.
f Donotplaceanyobjectswithin0.5mtoboth
sidesand1mtothefrontofthedocking
station.
f Makesurethedockingstation'scharging
contactisnotdamagedorhaveanyforeign
mattersonit.
f Donotinstallthedockingstationinanarea
withadarkfloor.
– Iftheflooraroundthedockingstationisdark,
rechargingishindered.
f Moveanyobstaclesthatmaydisturb
POWERbot'smovement(suchaschildren's
indoorswingorslides)beforecleaning.
CAUTION
In use
f UsingPOWERbotonthickcarpetmay
damagebothPOWERbotandthecarpet.
– ThePOWERbotcannotpassovercarpetthatis
thickerthan1cm.
f DonotusePOWERbotontablesorother
highsurfaces.
– Thereisariskofdamageifitfalls.
f ThePOWERbotmaybumpintochair,desk
legsthereforemovethemawayforfasterand
efficientcleaning.
f WhenPOWERbotisoperating,donotliftitup
orcarryittoanotherarea.
f DonotholdbydrivingwheelsofPOWERbot
whencarryingittoanotherarea.
f DonotputanyobjectsontopofPOWERbot
sinceitmaycausemalfunction.
f Removeanylargepapersorplasticbags
immediatelywhenusingPOWERbotsince
theymayblocktheintake.
f Donotaimtheredpointerdirectlyatpeople
oranimals.
CAUTION
Cleaning and
maintenance
f PreventanydamagetoPOWERbotby
complyingthefollowings.
– DonotcleanPOWERbotbysprayingwater
directlyontoitorusebenzene,thinner,acetone
oralcoholtocleanit.
f DonotdisassembleorrepairPOWERbot.
Thisshouldonlybedonebyacertified
repairman.
f Alwayskeeptheobstaclesensorandcliff
sensorclean.
– Ifforeignmatteraccumulates,sensorsmay
malfunction.
SR9300K_EN_DJ68-00743J-00_SA.indd 7 2016-07-15 오후 3:47:49
background
ENGLISH-08
1
Connect the
charger jack
to the docking
station
2
Connect the
power cord to
the charger
Whenusingthecharger,
thesidewiththesticker
attachedmustfacedown.
3
Connect the
power plug to
the outlet
Powerlamp(Red)willturn
on.
Installation
Power of the docking station must be on at all times.
DC-IN
DC-IN
Powerlamp(Red)
About1m
About0.5m
About0.5m
Installitinaplacewithoutobstacles
anddangeroffalling.
Do not install the docking station in a narrow
passage or near a door.
SR9300K_EN_DJ68-00743J-00_SA.indd 8 2016-07-15 오후 3:47:50
background
ENGLISH-09
Accessories
Remote control Batteries (AAA
type)
User manual Spare filter Cleaning brush
Docking station
Power cord
Charger Virtual guard
Installation note
Note
f Installthedockingstationinaplacewherethefloorandwallarelevel.
f Itisbesttoinstallthedockingstationalongthegrainofwoodenfloors.
f Iftheemergencyswitchisoff,POWERbotwillnotchargeevenifitisdockedonthedockingstation.
f Alwaysturnonthepowerofthedockingstation.
– Ifpowerisnotsuppliedtothedockingstation,POWERbotcannotfinditandcannotautomatically
recharge.
– IfPOWERbotisleftdetachedfromthedockingstation,thebatterywilldrainnaturally.
f IfPOWERbotisinenergy-savingmode,powerwillnotcomeoneveniftheemergencyswitchis
turnedoffandthenon.Pressandholdthe[Start/Stop]buttononPOWERbot.
SR9300K_EN_DJ68-00743J-00_SA.indd 9 2016-07-15 오후 3:47:51
background
ENGLISH-10
Charginglampduringcharging(green)
It takes approximately 240 minutes to
completely charge when charging for the
first time after purchase and can be used for
approximately 30 minutes in Max mode.
Charging
1
Turn on the
emergency switch
on the bottom
Youmustturnonthe
emergencyswitchtoturnon
POWERbot.
2
Manually charge
POWERbot by
placing it on the
docking station
Makesurechargepinsof
POWERbotandthedocking
stationisaligned.
3
Check the
charging status
“ ”willturnon
accordingtocharging
progressand"FULL"will
turnonwhenchargingis
complete.
WARNING
• Ratedinputvoltageofthisproduct
is100-240V~.
SR9300K_EN_DJ68-00743J-00_SA.indd 10 2016-07-15 오후 3:47:51
background
ENGLISH-11
When the battery indicator blinks
during cleaning, POWERbot will
return to the docking station to
charge itself automatically.
Automatic charging
You may command POWERbot to
recharge at the docking station
while it is in cleaning process.
Recharging
Manually charge POWERbot by
placing it on the docking station.
Low battery (Lo)
Steps to take if recharging is not being executed
Check the installation status of the
docking station when:
fdockingstationislocatedinaplacewhere
POWERbotcannoteasilyaccess
fdistanceofthedockingstationandPOWERbotis
over5mapart
– ItmaytakealongtimeforPOWERbottoreturnto
thedockingstationforrecharging
Manually charge POWERbot when:
fdockingstationislocatedinacorner
fbatteryisfullyexhausted
fPOWERbotisstuckbyobstacles(furnitureetc.)
fPOWERbotcan'tclimbthresholdneardocking
station(HeightofthethresholdthatPOWERbotcan
climb:about2.0cmandbelow)
fBatteryindicatorblinksand"Lo"isdisplayed
fPOWERbotissetonSpotcleanorManualclean
mode
SR9300K_EN_DJ68-00743J-00_SA.indd 11 2016-07-15 오후 3:47:51
background
ENGLISH-12
Installing the Virtual guard
Infrared ray from the Virtual guard will restrict POWERbot from approaching certain
area.
Virtualguard
1
Press the Power
button to turn it on
Powerlamp(Red)willblink.
2
Install the Virtual guard
where you want to restrict
POWERbot's entrance
Makesurethatdistancesensorisfacing
atthedesireddirectionyouwantto
createainvisiblebarrier(whichwillrestrict
POWERbot'sapproach).
The distance of virtual wall is 2.5 m at minimum and may differ
depending on surroundings and movement status of POWERbot.
Minimum 2.5 m
SR9300K_EN_DJ68-00743J-00_SA.indd 12 2016-07-15 오후 3:47:52
background
ENGLISH-13
Part name of the Virtual guard
Power button
Distance detection sensor
(Infrared ray sensor)
Power lamp
Poweron:Redlampblinks
Poweroff:Lampisoff
POWERbot detection sensor
Battery cover
Inserting batteries
BatteriesforVirtualguardmustbepurchasedseparately.
1
Open the battery cover
of the Virtual guard by
pressing the locking
tab and lift it up.
2
Insert the alkaline
batteries (D type)
as shown in the
illustration (check the
+, - polarity).
3
Insert the tip of the
cover into the slot and
push the other end to
close the battery cover.
Specification:typeD(LR20)batteries
SR9300K_EN_DJ68-00743J-00_SA.indd 13 2016-07-15 오후 3:47:52
background
ENGLISH-14
Using POWERbot
You must turn on the emergency switch before using POWERbot.
Turning the power on/off
Press the button for more than
3 second
Using Auto clean mode
ThePOWERbotmovesandcleansautomatically
untilitcleansentirespaceonce.
Stopcleaning:Pressthe button
Recharging
YoumaycommandPOWERbottorechargeatthe
dockingstationautomaticallywhileitisincleaning
process.
Using Spot clean mode
ThePOWERbotcleansalocalizedareaintensely.
WARNING
• WhenPOWERbotisnotusedfor
30minutes,itwillreturntothedocking
stationtochargeitselfautomatically.
Location recognizing function
fIfturningoffthePOWERbotandturningitback
on,thePOWERbotwillsearchthelocationthatit
stoppedpreviouslyandthencleantheareawhere
wasnotcleanedbefore.
– Whenthelocationrecognizingfunctionoperates,
thePOWERbotsearchesthecurrentlocation.
– Ifthesearchingisfailedmorethan3times,the
POWERbotwillstarttocleanfromthebeginning.
Note
f Startthecleaningagainattheareawithin1m
aroundwherethePOWERbotstopped.
– Ifyoustartthecleaningattheareamorethan
1mfromwherethePOWERbotstopped,
itisdifficulttosearchthelocationandthe
POWERbotmaycleantheareawhereitalready
cleaned.
SR9300K_EN_DJ68-00743J-00_SA.indd 14 2016-07-15 오후 3:47:53
background
ENGLISH-15
Cleaning mode How to select Displayed icon
Auto clean
Spot clean
Spotcleanmodecanbeselectedonly
bypressingthisbuttononthemain
bodyofthePOWERbot.
Manual clean
Manualcleanmodecanbeselected
bythedirectioncontrolbuttonsofthe
remotecontrol.
Whencleaningisdonewithin15minutesinAutocleanmode,thePOWERbotwillrepeatcleaning
onemoretime.
WhendustintakeisdetectedinSpot/Manualcleanmode,suctionofthePOWERbotwillbecome
stronger.
IfthePOWERbotfailstoreturntothedockingstation,itwillbeturnedintotheenergy-savingmode.
Thenthedisplaypanelofthemainbodywillbeturnedoff.Press[Start/Stop]or[Power]buttonto
canceltheenergy-savingmode.
Chargingandcleaningtimescandifferaccordingtoconditionsofuse.
Cleaning method for each modes
About1.5m
About1.5m
Auto clean
Cleansautomaticallyuntilentire
spaceiscleanedonce.
Spot clean
Cleansalocalizedarea
intensely.Itcanbeusedto
cleanbreadorcookiecrumbs.
Manual clean
YoucanmovePOWERbotwith
theremotecontroltocleanthe
desiredspot.
Selecting cleaning mode
SR9300K_EN_DJ68-00743J-00_SA.indd 15 2016-07-15 오후 3:47:53
background
ENGLISH-16
Using the remote control
1 Power / Recharging / Start/Stop
Power
TurnPOWERbot'spoweron/off
Recharging
SelecttorechargePOWERbotatthedockingstation
automatically
Start/Stop
Selecttostartorstopcleaningprocess
2 Suction power
Max mode
Selecttocleanwiththestrongestsuctionpower
Normal mode
Selecttocleanwithmoderatesuctionpower
Quiet mode
Selecttocleanwithloweroperationnoise
3 Additional function
Sound
Eachtimeyoupressthisbutton,SoundEffectsMuteis
selectedinthissequence.
Smart control
Selecttoturnonoroffthesmartcontrol
Press[Sound]buttonfor3seconds..
Wi-Ficonnectionshouldbedonetocontrolthe
POWERbotusingSamsungSmartHomeapp.
Thepreviouslyselectedsettingwillnotchangeeveniftheemergencyswitchisturnedoffandthenon.
Inserting batteries
Openthebatterycoverbyliftingitup
whilepressingthelockingtaband
insertthebatteriesasshowninthe
illustration.Then,closethecoveruntil
itclicksintoplace.
SR9300K_EN_DJ68-00743J-00_SA.indd 16 2016-07-15 오후 3:47:54
background
ENGLISH-17
You can use the remote control to point and clean
the desired spot while the POWERbot is in cleaning
process.
Point the red light on the floor within 1 m around POWERbot's
location.
PressandholdthePointcleaningbuttontomovetheredlightto
thedesiredspot.ThePOWERbotwillfollowthelightwhilecleaning.
1 m
Operating distance of the remote control
Heightoftheremote
control
Operatingdistance
Height of the remote
control
1m 1.5m
Operating distance About2m About2.5m
5 Point cleaning
4 Manual clean mode & Direction
control
Selecttomoveforward
Selecttoturnleft
Selecttoturnright
Movingbackwardisnotavailable.
Referto
page19
1
1
2
4
3
5
SR9300K_EN_DJ68-00743J-00_SA.indd 17 2016-07-15 오후 3:47:55
background
ENGLISH-18
Name of each part
1
5
2
3
4
6
3
3
4
7
8
9
Top
1. Displaypanel
2. Dustbinholder
3. Remotecontrolsignalreceiver
4. Virtualguardsensor
5. Obstaclesensor
6. Dustbin
7. Camera
8. Dustbinhandle
9. Bumpersensor
1
4
2
6
5
5
4
7
4
8
9
3
Bottom
1. Chargepins
2. Petbrush
3. Petbrushcover
4. Cliffsensor
5. Roller
6. Batterycover
7. Petbrushcoverbutton
8. Drivingwheel
9. Emergencyswitch
13 149 121110
6
17
16
3
4
5
8
1
7
2
15
Display panel
1. Mute
2. InformationIndicator
3. Filterinspection
4. SmartControlOff/Onindicator
5. Wi-Fi
6. Batteryindicator
7. One-time/Dailyschedule
8. Numberdisplay
9. Spotcleanmode
10. Manualcleanmode
11. Quietmode
12. Normalmode
13. Maxmode
14. Dustsensor
15. Spotcleaningbutton
16. Start/Stopbutton
17. Rechargingbutton
SR9300K_EN_DJ68-00743J-00_SA.indd 18 2016-07-15 오후 3:47:56
background
ENGLISH-19
Setting time/schedule
Only Auto clean mode can be scheduled.
Setting the time
YoumustsetthecurrenttimebeforeusingtheOne-time/dailyschedule.
Start setting Select "Hour" Select "Minute"
Select "AM/PM"Setting complete
Skip to previous, next setting
Setting the schedule
Setting/cancellingtheschedulecanonlybedonewhilePOWERbotisdockedonthedockingstation.
Start setting Select "One-time" or
"Daily" schedule
Select "Hour"
Select "Minute"Select "AM/PM"Setting complete
Skip to previous, next setting
Cancelling during setup
fSettingwillbecanceledautomaticallywhenthere'snoinput
for7seconds
Cancelling One-time/Daily schedule
When both One-time/
Daily schedule is set
or or
Pressfor3sec. Selecttheschedule Cancelcomplete
When either one of
One-time or Daily
schedule is set
Pressfor3sec.
SR9300K_EN_DJ68-00743J-00_SA.indd 19 2016-07-15 오후 3:47:57
background
ENGLISH-20
Cleaning and maintaining
You must turn off the emergency switch before cleaning POWERbot.
Cleaning the dustbin
Cleanthedustbinwhenfilterinspectionindicator( )turnsonorifthere'stoomuchdustinthedustbin.
1
Remove the dustbin
2
Remove the dustbin
cover
3
Remove dust in the
dustbin and cyclone
unit
"Click"
4
Detach the cyclone unit
from the dustbin cover
then wash the dustbin
and the filter
5
Reassemble the
dustbin
6
Reinsert the dustbin
into the main body until
it clicks
Cleaning the sensors and the camera
Lightly wipe with soft cloth. Do not use water or cleaning solutions.
Camera
Frontsensor
window
Rearsensor
window
Cliffsensors
SR9300K_EN_DJ68-00743J-00_SA.indd 20 2016-07-15 오후 3:47:58
background
ENGLISH-21
Cleaning the Pet brush
1
Remove the Pet brush
cover
2
Remove the Pet brush
3
Clean the Pet brush
ON
OFF
ON
OFF
4
Reassemble the Pet
brush
5
Reassemble the Pet
brush cover
Cleaning the Driving wheel
1
Putasoftclothonthefloorandplace
POWERbotupside-down.
2
Useabluntrodortweezerstoremovethe
foreignmatters.
SR9300K_EN_DJ68-00743J-00_SA.indd 21 2016-07-15 오후 3:48:00
background
ENGLISH-22
Samsung Smart Home App
Preparing the network
Setting up the wireless router
fThisproductsupportsonlyDHCP(DynamicHostConfigurationProtocol).PleasecheckiftheDHCPserver
optionfunctionofawirelessrouterisactivated.
fThesupportedtypesofauthorization/encryptionofthewirelessrouterareWEP-OPEN,WPA-PSK/TKIPand
WPA2-PSK/AES801.11n.
– WPA2-PSK/AESisrecommendedtobeused.
fThequalityofconnectionofthewirelessnetworkmaybeinfluencedbythesurroundingwirelessenvironment.
fWhenyourInternetserviceproviderhaspermanentlyregisteredanMACaddress(auniqueidentification
number)ofyourPCormodem,yourPOWERbotmaybeunavailabletobeconnectedtotheInternet.Askyour
InternetserviceproviderabouttheproceduretoconnectanapparatusotherthanaPCtotheInternet.
fIfyourinternetserviceproviderrequiresyourIDorpasswordtoconnecttotheinternet,yourPOWERbotmay
notbeabletoconnecttotheinternet.Inthiscase,youmustenteryourIDorpasswordwhenconnectingto
theinternet.
fTheconnectiontotheInternetmaybeimpossiblebecauseofissuesoffirewall.AskyourInternetservice
providerforresolvingtheissue.
fSomewirelessroutersmayconveyanabnormalDomainNameServer(DNS)addresseveniftheInternetisnot
connected.Inthiscase,inquiretheproviderofthepertinentwirelessrouterandyourInternetserviceprovider.
fIfyoustillcannotconnecttotheInternetevenaftertryingtheprocedureinformedbyyourInternetservice
provider,pleaseaskanagencyorservicecenterofSamsungElectronics.
Note
f Pleaserefertotheusermanualofthepertinentwirelessrouterwithoutaccessproblems.
f SamsungPOWERbotssupportonlyWi-Fi2.4Ghz.
f SamsungPOWERbotssupportthecommunicationprotocolofthemethodsofIEEE802.11b/g/n
andWi-FiDirect.(SamsungElectronicsrecommendstouseIEEE802.11n.)
f AwirelessrouterwithnoauthorizationofWi-Fimaybeunavailabletobeconnectedtothe
POWERbot.
f WhenthepowerissuppliedandthePOWERbotisdockedonthedockingstation,thePOWERbot
willbeconnectedtotheserverandthencheckifthereissoftwareupdates.Ifthereisthelatest
software,itwillbeautomaticallydownloadedandupdated.
f If“UP”isdisplayedonthedisplaypanelwhilethePOWERbotischarging,itmeansthattheupdate
isinprogress.Pleasewaitforcompletingtherebooting.
f Iftheproductregistrationisnotdone,pleasefollowthefollowinginstructions:
– Refertothepopupmessageandretrytheregistraionprocedure.
– CheckiftheUPnPoptionofthewirelessrouterisavailableandretrytheregistrationprocedure.
– Checkiftheoperatingmodeofthewirelessrouterisaroutermodeandretrytheregistrationprocedure.
– IfyouhavemorethantwoPOWERbot,turnofftheotherstoregistertheone.Theconnectionmustbeone
toone.
– IfthereisawirelessrouterwhichhasthesameSSIDaroundyourrouter,anormalregistrationcannotbe
guaranteed.
– SetauniqueSSIDandpasswordforthewirelessrouterandthenregistertheproduct.
SR9300K_EN_DJ68-00743J-00_SA.indd 22 2016-07-15 오후 3:48:00
background
ENGLISH-23
Using the Samsung Smart Home app
Creating your Samsung account
IfyouwanttousetheSamsungSmartHomeapp,pleaseregisteryour
SamsungaccountinSamsungaccountapp.
Note
f Ifyoudonotsetauto-logintotheSamsungSmartHomeappandrun
theapp,thescreenofSamsungaccountappearsonetimeatfirst.
f IfyouareauserofaSamsungsmartphone,registeryourSamsung
accountinthesettingsofthesmartphone,andthentheautomatic
logingetssetwithoutanyotherloginprocesses,andyoucanusethe
Samsungsmarthomeappimmediately.
Downloading Samsung Smart Home app
YoucandownloadtheSamsungSmartHomeappbysearchingfor“SamsungSmartHomeApp”attheGoogle
PlayStore,SamsungGalaxyAppsandAppleAppstore.
Note
f SamsungSmartHomeappsarecompatiblewithselectedSamsungGalaxySandSamsungNote
seriesdevices.
– supportAndroid™(2)4.0(sinceGalaxyS2)orhigherandiOS7orhigher
– Applicationmustbedownloaded.Internetconnectionrequired.Datachangesmayapply.
– AndroidisatrademarkofGoogleInc
– TheUIofSamsungSmartHomeAppmaychangewithoutadvancenoticeforimprovementofproductuse
andperformance.
f SamsungSmartHomeServicedoesnotguaranteeanormaloperationunderfirewallenvironment.
f IfthePOWERbotandsmartphonearenotconnectedtothesamewirelessrouter,responsedelay
mayoccuraccordingtonetworkenvironment.
f SmartcontrolandWi-Fiindicator
– On:Smartcontrolislocked.(Onlytheremotecontrolisavailable.)
–
Off:Smartcontrolisallowed.
–
Off:ThePOWERbotisconnectingtothewirelessrouter.
–
On:ThePOWERbotisconnectedtothewirelessrouter.
f IfSmartcontrolislocked,youcannotuseSamsungSmartHomeApp.
SR9300K_EN_DJ68-00743J-00_SA.indd 23 2016-07-15 오후 3:48:01
background
ENGLISH-24
Samsung Smart Home App
Registering the product (Easy-Setup)
RegistertheproducttotheSamsungSmartHomeServicebeforeusingtheSamsungSmartHomeapp.
Android
1.PresstheAddnewicononthedevicelistscreenoftheSamsungSmartHomeapptostarttheregistrationof
theproduct.
2.SelecttheRobotvacuumicon.
3.Entertheinformationofthewirelessroutertobeconnected.
4.SetthePOWERbotaccordingtotheguidanceonthescreen.
– ToturnontheAPmodeimmediately,press[Clock]buttonformorethan5seconds.
5.Then,theregistrationwillproceedautomatically.
6.Themessagewillappearwhentheregistrationcomplete.
7.Whentheproductregistrationiscomplete,themainscreenoftheSamsungSmartHomeappwillappear.
Iftheproductregistrationisfailed,refertopage22.
SR9300K_EN_DJ68-00743J-00_SA.indd 24 2016-07-15 오후 3:48:02
background
ENGLISH-25
iOS
1.RunSamsungSmartHomeapp..
2.MovetotheleftscreenandthenpresstheAddnewicononthedevicelistscreentostarttheregistrationof
theproduct.
3.Enterthesamsungaccountandthenpress[Signin]button.
– ForiPhone,yourIDandpasswordisnotsavedsothatyouneedtosignineverytimeyouuseSamsung
SmartHomeapp.
4.Select[Robotvacuum]icon.
5.Presstheclockbuttonoftheremotecontrollerformorethan5seconds.
– APwillappearonthedisplaypanel.
SR9300K_EN_DJ68-00743J-00_SA.indd 25 2016-07-15 오후 3:48:03
background
ENGLISH-26
Samsung Smart Home App
6.RuntheSettingsappofyouriPhoneandthenconnectto[RobotVacuum]Samsungonthelist.
7.EnterIDandpasswordofthewirelessrouterwhichwillbeconnectedandthenpress[Next]button.
8.Theconnectionbetweenthesmartphoneandtherobotvacuumisinprogress.
9.RuntheSettingsappofyouriPhoneandthenconnecttothewirelessrouterwhichwillbeconnectedonthe
Wi-Filist.
10. Theconnectionbetweenthewirelessrouterandtherobotvacuumisinprogress.
11. Whentheproductregistrationiscompleted,themessagewillappear.
12. Whentheproductregistrationiscompleted,Robotvacuumiconisaddedonthedevicelist.
SR9300K_EN_DJ68-00743J-00_SA.indd 26 2016-07-15 오후 3:48:04
background
ENGLISH-27
Main screen
fSelecttheRobotvacuumicononthemainscreen,andyoucanmovetothe
POWERbotcontrolscreen.
fYoucancontrolyoursmarthomeappliancesmadebySamsungElectronics
byGoingout,Cominghome,Goodnight,andGoodmorningicons.
fHomeviewfunctionisnotsupportedforaPOWERbot.
User menu screen
fYoucancontrolthesmarthomeappliancesmadebySamsungElectronics
withChatcontrolandMasterkeyfunctions.
Chat control
fYoucancontrolthesmarthomeappliancesorcheckaboutthe
statusofthemconveniently.
Master key
fYoucancontrolseveralhomeappliancesatonceusingthe
masterkeys(Goingout,Cominghome,Goodnight,Good
morning).
Customer service
fYoucanseethemanualoftheproduct.
fWhenaproductisoutoforder,youcanconsultwithour
customercenterandrequestforanafter-salesservice.
SR9300K_EN_DJ68-00743J-00_SA.indd 27 2016-07-15 오후 3:48:04
background
ENGLISH-28
Samsung Smart Home App
Controlling POWERbot
WhenaccessingtheSamsungSmartRobotvacuumapp,thecontrolscreenwillappear.
1. Poweron/off
2. ManualcleanmodeandDirectioncontrol(forwardmovement,leftturn,
rightturn)
3. Autocleanmodestart/stop
4. Spotcleanmode
5. Currentstatusindicator
6. Batterystatus
7. Suctionpower
8. Schedule(Youcansetthedesiredtimeforeachdate.)
▶ ThePOWERbotoperatesbysynchronizingthesettimeinthenetwork.
9. Cleaninghistorycheck
10. Energymonitor(DisplaysthepowercunsumptionofthePOWERbot.)
11. Options(Settings,CustomerService)
12. Deviceinformaation
Note
f AscheduledcleaningrunsonlywhenthePOWERbotisdockedon
thedockingstation.
SR9300K_EN_DJ68-00743J-00_SA.indd 28 2016-07-15 오후 3:48:05
background
ENGLISH-29
Using Select & Go
AfeaturethatallowstheusertoselectandcleanspecificareasusingtheSamsungSmartHomeapp.
1.CleaningMapandCleaningFloorplan
fCleaningMaprepresentstheareasthePOWERbotmovedwhilecleaning.
fCleaningFloorplanisanartificiallydelineatedrepresentationofCleaning
Map.
2.AreaCleaning
fIncludesconfigurablelabelsforeachoftheareas.
fSelectareastocleanandtapStarttoclean.
fEacharea’sstatusisindicatedonthemap.
Completed
Progressing
Canceled,Erroroccurred
Selected
Notselected
Note
f PrecautionsforSettingCleaningFloorplan
– Placethechargingstationflushtoawallinanopenarea.
– Removeobstaclesfromthefloor(rugs,towels,chairs,mats,toys,etc.).
– Removeobstaclesalongthepathstotheareastobeincludedinthefloorplan.
– Ifpossible,closealldoorswithhighsills(veranda,balcony,etc.).
– Ensuretheareastobeincludedinthefloorplanarewellilluminated.
f CautionsforUsingAreaCleaning
– AreaCleaningcancommenceonlywhenPowerbotisbeingcharged.
– AreaCleaningwillnotfunctionproperlyiftheactualstation’slocationandorientationdonotmatchthe
locationandorientationinthefloorplanselected.
– AreaCleaningfeaturemaynotfunctionproperlydependingonthestateofthefloorand/orplacementor
obstaclesintheconcernedarea.
– AreasonafloorplanareareasartificiallydelineatedbyPowerbotandmaynotincludealltherooms.
– MapgenerationandSelect&Gomaynotbeavailableonareascoveredinsomecarpets.
– TheremaybethedifferencebetweenfloorplansaccordingtostatusofPowerboteventheenvironmentis
same.
– TheusercanselectandusethedesiredfloorplanbyFloorplanmenu.
SR9300K_EN_DJ68-00743J-00_SA.indd 29 2016-07-15 오후 3:48:06
background
ENGLISH-30
Notes and cautions
Charging
Note
f Ifthebatteryoverheatsduringcharging,it
maytakelongertocharge.
f Whenautomaticchargingisnotworking,
pleasecheckthefollowings.
– Turntheemergencyswitch(onthebottomof
POWERbot)offandonagain.
– Unplugthedockingstation'spowerplugand
thenplugitbackon.
– Checkwhetherthereisanyforeignmatterin
thechargepinsandcleanPOWERbotandthe
chargepinsofthedockingstationwithadry
clothorrag.
– Checkforanyobstaclessuchasreflective
objects,chairs,etc.nearthedockingstation.
f IfPOWERbotisleftdetachedfromthe
dockingstation,thebatterywilldrainnaturally.
– TrytokeepPOWERbotbeingchargedonthe
dockingstation.(Turnofftheemergencyswitch
andleavethedockingstationunpluggedwhen
planningtoleavethehouseforlongperiodsof
timebygoingonabusinesstriporvacation,
etc.,)
In use
Note
f ThePOWERbotmaygetcaughton
thresholds,etc.duringcleaning.
– Torestartoperation,shutofftheemergency
switch,movePOWERbottoanareawhereit
canmoveeasilyandthenturnonthepower
again.
f ThePOWERbotcannotcompletelyclean
areasitcannotenter,suchascorners,
betweenthewallandsofa,etc.
– Pleaseuseanothercleaningtooltocleanthem
regularly.
f ThePOWERbotcannotvacuumclumpsof
dirt,sosomemayremainonthefloorafter
cleaning.
– Pleaseuseanothercleaningtooltocleanthem
regularly.
f IfthebatterybecomeslowduringAutoclean
mode,POWERbotwillrechargeandfinish
cleaningtheremainingareaafterrecharging.
(Repeatcleaningfrequency:1time)
f YoucannotselectandexecuteSpotclean
modewhilecharging.
f IfyoupressManualclean/Pointcleaning
buttonwhilecharging,thePOWERbotwillbe
detachedfromthedockingstationandthen
turnintothestandbymode.
f DonotliedownaroundthePOWERBOTthat
isrunning.
– YourhairmaybecaughtinthePetbrush,
resultinginphysicalinjury
Cleaning and maintenance
Note
f Ifyouwashedthedustbinandfilterwithwater
– Dustbin:Completelywipeoutthewater.
– Filter:Completelydryitinashadebeforeuse.
Caution
f Watchyourfingerwhenattachingor
detachingthefilter,sincetheymaygetstuck
inthedustbin'sintake.
f Toavoidblockagesbyforeignmatter,donot
lettoothpicks,cottonswabsetc.frombeing
vacuumedbyPOWERbot.
f Ifitisdifficulttoremoveforeignmattersfrom
thePetbrush,contactaservicecenter.
SR9300K_EN_DJ68-00743J-00_SA.indd 30 2016-07-15 오후 3:48:06
background
ENGLISH-31
f SincethePetbrushremovesdirtfromthe
floorduringcleaning,foreignmatterssuchas
thread,longhair,etc.maygetcaughtinit.
Thereforecheckandcleanitregularly.
About battery
Note
f PurchasebatteriesatauthorizedSamsung
centersandcheckforthesymbol( )
whichisstuckonthebatteryandthemodel
namebeforepurchasing.
f ThisbatteryisexclusiveforSamsung
ElectronicsPOWERbot;donotuseitforany
otherproduct.
f Donotdisassembleormodifyit.
f Donotthrowthebatteryoutinfireorheatit
up.
f Donotconnectanymetallicobjecttothe
chargingcontacts(+,-).
f Storeitinindoor(at0°C~40°C).
f Ifthebatterymalfunctions,donot
disassembleityourself;contactyournearest
servicecenter.
f Batterychargingtimeandusagetimemay
decreasethemorethebatteryisused.Ifthe
battery’slifespanhasbeenexceeded,haveit
replacedataservicecenter.
f Thebatterywarrantyperiodis6monthsfrom
thedateofpurchase.
About the IrDA sensor
Caution
f Theinfraredsignaltransmissionmaynot
besmoothinlocationsexposedtohalogen
lampsorinoutdoorlocations.
f ThePOWERbotuses3typesofinfrared
devicesandadevicemaynotworkinfrontof
anotherdevicewithahigherpriority.
– InfraredsignalPriority:Remotecontrol>Virtual
guard>Dockingstation
f WhencontrollingPOWERbotwiththeremote
control,POWERbotmaycrosstheinvisible
barriersetbytheVirtualguardandenterthe
areayoudon'twantittoenter,sinceremote
control'ssignalhasahigherpriority.
f Differentinfraredsignalsmayinterferewith
oneanotherandcausemalfunctiontothe
devicesiftheyareusedtogetherinasmall
spaceorinaclosedistance.
f InstalltheVirtualguardawayfromthedocking
stationasautochargingmaybeinterruptedif
theVirtualguardisnearthedockingstation.
f IfmorethanonePOWERbotsareused
simultaneously,theymaymalfunctiondueto
interferenceoftheinfraredsignals.
SR9300K_EN_DJ68-00743J-00_SA.indd 31 2016-07-15 오후 3:48:06
background
ENGLISH-32
Information codes
1
Below information
codes appear on
the display panel
2
Turn off the
emergency switch
and check the below
instructions and take
appropriate action
3
Information code
will disappear
when you turn on
the emergency
switch
Information codes Checklist
The POWERbot is caught, stuck or trapped while
moving around.
fTurnofftheemergencyswitchandmovethePOWERbottoanother
area.
Foreign matter caught in the Pet brush.
fTurnofftheemergencyswitchandremovetheforeignmatterfromthe
Petbrush.
Foreign matter caught in the left Driving wheel.
fTurnofftheemergencyswitchandremovetheforeignmatterfromthe
Drivingwheel.
Foreign matter caught in the right Driving wheel.
fTurnofftheemergencyswitchandremovetheforeignmatterfromthe
Drivingwheel.
Bumper sensor needs to be checked.
fTurnofftheemergencyswitchandturnitbackon.
fWheninformationcodedoesnotdisappear,checkifthere'sanysmall
foreignmatterbetweenthebumperandthemainbody.Ifthereis,pull
thebumperslightlyandremovetheforeignmatter.
Foreign matter accumulated on the obstacle sensor.
fTurnofftheemergencyswitchandcleanthefrontandrearsensor
withasoftcloth.
Foreign matter accumulated on the cliff sensor.
fTurnofftheemergencyswitchandcleanthecliffsensorwithasoft
cloth.
SR9300K_EN_DJ68-00743J-00_SA.indd 32 2016-07-15 오후 3:48:07
background
ENGLISH-33
Troubleshooting
Symptom Checklist
The POWERbot is not working at
all.
fCheckiftheemergencyswitchison.
fCheckifalltheiconsaredisplayedondisplaypanel.
fCheckifthebatteryofPOWERbotisdepleted.
– When"Lo"isdisplayed,carryPOWERbottothedockingstationto
chargeit.
fReplacethebatteries(AAAtype)whentheremotecontrollerisnot
working.
The POWERbot is stopped during
cleaning process.
fWhen"Lo"isdisplayedonthedisplaypanel,carryPOWERbottothe
dockingstationtochargeit.
fWhenPOWERbotisstuckbytheobstaclessuchascord,threshold
etc,pickituptoremoveitfromtheobstacle.
– Ifanyfabricsorstringsarecaughtinthedrivewheel,turnoffthe
emergencyswitchandremovethefabricsorstringsbeforeusingit
again.
Suction power is weak.
fIfthe"Filterinspectionindicator"ison,turnofftheemergencyswitch
andcleanthedustbin.
fWhenthere'stoomuchdustinthedustbin,suctionpowermayget
weakened.Turnofftheemergencyswitchandemptythedustbin.
fIftheintake(onbottomofPOWERbot)isblockedbyforeignmatters,
turnofftheemergencyswitchandremoveforeignmatterfromthe
intake.
fWhennoisesuddenlyincrease,turnofftheemergencyswitchand
emptythedustbin.
The POWERbot cannot find the
docking station.
fCheckifthere'spowerfailureorwhetherthepowerplugis
unplugged.
fRemoveanyobstaclesaroundthedockingstationthatmaydisturb
POWERbotfromreturningtothedockingstation.
fWhenthere'sforeignmattersonthechargepinsthataffects
charging,cleantheforeignmatter.
The POWERbot passes through
the Virtual guard.
fIfthebatteriesaredepleted,replacethem.(2typeD(LR20)
batteries)
fIfthelampisoff,checkiftheVirtualguardisturnedoffandturnit
on.
The POWERbot suddenly cleans
diagonally.
fCheckifthedockingstationisinstalledalongthegrainofwooden
floorsortiles.
fItmaycleanindiagonaldirectionformovingtoanotherareain
shortestroute,oritmadecontactwithanyobstaclesinthatangle,
orifitwaschargedatthechargedatanangle,orgrainofthe
wooden/tilefloorisinthatdirection.
Point cleaning is not working.
fIfyoupointtheredlightdirectlyonPOWERbot,itmaynotmoveto
desireddirection.
– Pointtheredlightonthefloorwithin39in(1m)aroundPOWERbot.
Donotusethepointcleaningunderdirectsunlight,brightlightoron
darkfloors.
SR9300K_EN_DJ68-00743J-00_SA.indd 33 2016-07-15 오후 3:48:07
background
ENGLISH-34
Symptom Checklist
"Filter inspection indicator" is on
even after the dustbin has been
emptied.
fUsePOWERbotafterturningofftheemergencyswitchandthen
turningitbackon.
fEmptythedustbinagainandre-cleanthefilterthoroughly.
POWERbot moves around at the
same place.
fDustsensormodeison.
– Thedustsensormodeisonbydefault.WhenthePOWERbot
passesthroughadustyarea,itmovesaroundthatareatofocuson
cleaning.
fPOWERbotmovesaroundanareaandthe"DUST"isonthedisplay
paneleventhoughthere'snodustatthesurroundingarea.
– CheckifforeignmattersarecaughtbetweenthedustbinandPet
brushandthenremovethem.
POWERbot does not clean a
certain area.
fCheckifthedockingstationisinstallednearanarrowpassageor
door,andreinstallitintheotherareas.
– Ifthedockingstationisinstallednearanarrowpassageordoor,the
POWERbotcannotpassthroughthepassageordoorsill.
The battery usage time of the
Virtual guard is too short.
fCheckifyou'reusingmanganesedrycellbatteriesandreplacethe
batterieswithnewones.(2typeD(LR20)batteries)
I have installed the Samsung
Smart Home app, but, the
POWERbot fails to be connected.
fYoucanusetheproductafterconnectingthewirelessrouterandthe
POWERbotthroughEasy-Setupaccordingtotheprocedure.
I fail to log into the Samsung
account.
fCheckyourIDandpasswordonthescreenoftheSamsung
account.
There appears a message saying
there is a failure during Easy-
Setup.
fYoumayhavefailedtemporarilyduetothedistancefromthe
wirelessrouterorotherobstacles.Pleasetryagainafterawhile.
The products do not work
even though the smart phone
is normally connected to the
POWERbot.
fTurnofftheSamsungSmartHomeappandthenrunitagain,or
disconnectthesmartphonefromthewirelessrouterandthen
connectitagain.OrturnoffthepowersupplyofthePOWERbot,
turniton,waitforaminuteorlonger,andthenruntheSmartHome
appagain.
The functions of the Samsung
Smart Home App do not work.
fCheckiftheSmartcontrolblockingfunctionofthePOWERbotis
set.(WhentheSmartcontrolislocked,theWi-Fiindicatoristurned
off.)
The Samsung Smart Robot
Vacuum App fails to get started.
fCheckifthePOWERbotisconnectedtothewirelessrouter.
POWERbot is not connected to
Wi-Fi.
fCheckthesettingstatusofthewirelessrouter.
Location recognizing function
does not operate.
fOperatethePOWERbotagainneartheareawhereitstopped
previously.
fIfthePOWERbotdoesnotrecognizethesurroundingenvironment
orstartsthecleaningattheareamorethan1maroundwhereit
stopped,thesearchingmaybedifficult.
Troubleshooting
SR9300K_EN_DJ68-00743J-00_SA.indd 34 2016-07-15 오후 3:48:07
background
ENGLISH-35
Open Source Announcement
Thesoftwareincludedinthisproductcontainsopensourcesoftware.Youmayobtainthecomplete
correspondingsourcecodeforaperiodofthreeyearsafterthelastshipmentofthisproductbysendinganemail
tomailto:[email protected].
ItisalsopossibletoobtainthecompletecorrespondingsourcecodeinaphysicalmediumsuchasaCD-ROM;
aminimalchargewillberequired.
ThefollowingURLhttp://opensource.samsung.com/opensource/VR_TZ_01/seq/1leadstothedownloadpage
ofthesourcecodemadeavailableandopensourcelicenseinformationasrelatedtothisproduct.Thisofferis
validtoanyoneinreceiptofthisinformation.
Specifications
Classification Item Detail information
Mechanical
specifications
(POWERbot)
Size(DepthxHeightxLength) 378mmx135mmx362mm
Weight 4.9kg
Sensor Ceilingshaperecognition(VisionarymappingplusTM)
ButtontypeofPOWERbot Touchtype
Power
specifications
Powervoltage 100-240V~,50Hz/60Hz
Powerconsumption 250W(Maxmode)
Batteryspecifications Lithiumion21.6V/97.2Wh
Cleaning
Chargingtype Automaticcharging/Manualcharging
Cleaningmode Auto,Spot,Manual
Schedulingfunction One-timeschedule,Dailyschedule
Chargingtime Approximately240minutes
Cleaningtime
(Onthebasisofhardfloor)
Maxmode Approximately30minutes
Normalmode Approximately60minutes
Quietmode Approximately90minutes
Forproductimprovementpurposes,designandspecificationsoftheproductaresubjecttochangewithout
priornotice.
Chargingandcleaningtimesmaydifferaccordingtoconditionsofuse.
SR9300K_EN_DJ68-00743J-00_SA.indd 35 2016-07-15 오후 3:48:07
background
DJ68-00743J-00
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care center.
Country Customer Care Center Web Site
AUSTRALIA 1300362603 www.samsung.com/au/support
SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com/sg/support
HONKKONG (852)36984698
www.samsung.com/hk/support(Chinese)
www.samsung.com/hk_en/support(English)
MALAYSIA
1800-88-9999
603-77137477(Overseascontact)
www.samsung.com/my/support
INDIA
180030008282-TollFree
18002668282-TollFree
www.samsung.com/in/support
This product is RoHS compliant
SR9300K_EN_DJ68-00743J-00_SA.indd 36 2016-07-15 오후 3:48:07

Specifications

Indexed Terms: Robot Vacuum, Samsung Powerbot, Samsung Powerbot Series

Samsung VR20K9350WK/SA Questions and Answers

Find answers or ask new question.
See other models: GQ65Q60RGTXZG QA65Q90RAWXXY GQ49Q6FNGTXZG GQ75Q85RGTXZG QA55Q900RBWXXY
Questions and Answers
