En
g
lish
WHAT’S
IN THE
BOX
quick
START
GUIDE
Connections
Radio Preset
TUNERXL
Radio Tuning
Radio Auto Scanning
BUTTONS
1m
30 mins
0 m
IPX7
WATERPROOF
IPX7
Bluetooth
Settings Bluetooth
Bluetooth
DEVICES
JBL Tuner XL
Now Discoverable
Connected
ON
Language setting
BBC Radio 1
DAB
P1 Saved
DAB
P1
37%
DAB
BBC Radio 1
DAB
Connected
BT
BBC Radio 1
DAB
Tune Down
Radio Preset
Auto Scan
Bluetooth
DAB/FM Selection
Power On/Off
Set default language for the first time or after factory reset
(press + >10 seconds).
1
1
2
2
>2S
1
3
2
When DAB mode is activated for the first time, a full scan will
automatically start.
• In FM mode, JBL Tuner XL will automatically search for and
tune to an available radio station.
• In DAB mode, JBL Tuner XL scans all available DAB radio
stations and play the first available radio station.
You can save a maximum of 5 preset radio stations.
Tune Up
DAB
FM
1
3
2
TECH SPEC
Transducer: 1 x 2.75”
Rated output power: 10W RMS
Frequency response: 70 Hz - 20 kHz (-6 dB)
Signal-to-noise ratio: >80 dB
Battery type: Lithium-ion polymer 11.7 Wh
Battery charge time: 4 hours (5 V / 0.9 A)
Charging input: 5 V, 1.2 A
Music playing time: up to 15 hours for radio listening
(dependent on volume level and audio
content)
Bluetooth® version: 4.2
Bluetooth® profile: A2DP V1.2, AVRCP V1.5
Bluetooth® transmitter frequency range: 2.402 - 2.480 GHz
Bluetooth® transmitter power: 0 - 9 dBm (EIRP)
Bluetooth® transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
DAB Tuning range: 174.928 MHz - 239.200 MHz (Band-III)
FM Tuning range: 76 MHz - 108 MHz (varies by countries)
Dimensions (W x H x D): 145 x 167 x 103 (mm) / 5.7” x 6.6” x 4.1”
Weight: 1.15 kg (2.54 lb)
