User Manual JBL Tune 700BT Wireless Overear Headphones

JBL Tune 700BT Wireless Overear Headphones - Use Manual - Use Guide PDF.
Documents: Go to donwload!
User Manual
  • Owner's manual - (English, French, Spanish, German, Arabic, Chinese, Danish, Dutch - Holland, Finland, Hebrew - Israel, Hungarian, Indonesian, Italian, Japanese, Korean, Norway, Russian, Turkish)
Other Documents
  • Spec Sheet English - (English)
  • Declaration of Conformity - (English)
  • JBL Global Warranty Card - (English)

file thumbnail

Owner 's manual for JBL Tune 700BT

Table of Contents

  • WHAT’S IN THE BOX
  • Power on & connect
  • Manual Pairing
  • BUTTON COMMAND
  • Wired listening
  • Multi-point connection
  • Charging
  • Led behaviors
  • TECH SPEC

Power on & connect

1. POWER ON AND AUTOMATICALLY ENTER PAIRING MODE.

2. Choose "JBL TUNE700BT" to connect.

Manual Pairing

1. POWER OFF

2. Manual pairing mode

3. Choose "JBL TUNE700BT" to connect

Multi-point connection

ENTER PAIRING MODE WITH THE 2nd DEVICE

* (Maximum 2 devices)

1. To switch music source, pause the music on the current device and select play on the 2nd device.

2. Phone call will always take priority.

3. If one device goes out of bluetooth range or powers off, you may need to manually reconnect the remaining device.

4. SELECT “forget this device” on your bluetooth devices to disconnect multi-point.

1st bluetooth device --> Choose "JBL TUNE700BT" to connect --> 2nd bluetooth device

TECH SPEC

  • Driver size: 40 mm Dynamic driver
  • Frequency range: 20 Hz - 20 kHz
  • Sensitivity passive mode: 95 dB SPL/1 mW
  • Sensitivity active mode: 102 dB SPL/1 mW
  • Transducer impedance: 32 ohm
  • Max input power: 40 mW
  • Transmit sensitivity: -15 dBV/Pa
  • Bluetooth transmitted power: <5 dBm
  • Bluetooth transmitted modulation: GFSK, π/4 DQPSK , 8DPSK
  • Bluetooth frequency: 2.402 GHz-2.480 GHz
  • Bluetooth profile version: A2DP 1.2, AVRCP 1.5, HFP 1.6, HSP 1.2
  • Bluetooth version: 4.2
  • Headset battery type: Polymer Li-ion battery (610 mAh / 3.7 V)
  • Power supply: 5 V 1 A
  • Charging time: <2 hrs from empty.
  • Music play time with BT on: up to 27 hrs
  • Weight: 220 g


Newest Added: CLUB 700BT UA TRUE WIRELESS FLASH X - ENGINEERED BY TUNE 225TWS TUNE 125TWS TUNE 215BT

Tags: JBL Audio Use Manual, Jbl 700bt, JBL 125 Tws, Jbl Go 3 Manual, Jbl Logo, How To Pair Jbl Headphones, Jbl Tune 125 Tws

JBL TUNE 700BT | Pages: 20 | Created on: 2019-11-08 | File type: PDF | Filename: 60761804_tune-700bt.pdf | Size: 8.09 MB | Language: English, French, Spanish, German, Arabic, Chinese, Danish, Dutch - Holland, Finland, Hebrew - Israel, Hungarian, Indonesian, Italian, Japanese, Korean, Norway, Russian, Turkish | Other documents: 3 files.
