SUP AIR PUMP
Specifications
Product name:
Product Model:
Power:
Pressure Range:
Item Dimensions:
AC Direct Charge
12V DC Car Charge
11.8* 7.5*3.5Inch
0-20PSI
120W
YF6609
SUP AIR PUMP
Power Supply:
Product Diagram
How to inflate
1 2
3 4
5 6
7
8
9 10
11
Display screen
Handle
Power mode
“PSI/BAR” button
“+” button
“-” button
AC charging port 12
DC charging port
(DC charging cable storage)
Battery port
(The battery pack is not included)
Run/Stop switch
Air outlet
Air inlet
3
Thank you for purchasing Morpilot SUP AIR PUMP
Please read the User Manual thoroughly before using
the item and keep it properly for reference.
Accessories contents
1
23
4
5
6
7
8
1
9
10
11
12
AC Adapter Carrier BagNozzles
Bag
Air Hose
Car Inflatable
Bed
Inflatable
Tent
Paddle
Board
Inflatable
Sofa
Yoga
Ball
2
DC AC DC AC
How to deflate
4
1. Do not block the air inlet at the bottom of the pump and ensure
that it remains open to maintain the normal operation of the air
pump.
2. Do not pull out the air hose when the pump is in operation to
avoid injury from high-pressure gas.
Step 1: Lift up to open the cover and
select the appropriate power supply
mode;
Step 1: Lift up to open the cover and
select the appropriate power supply
mode;
Step 2: According to the selected power
supply method, press the corresponding
power mode;
Step 3: Insert one of the air hoses into the
deflation port and tighten it, ensuring
that the air hose is tightly connected and
airtight;
Step 4: Select the appropriate nozzle and
connect it to the other end of the air hose.
Make sure the nozzle is tightly connected
to the hose to ensure air tightness;
Step 5: Connect the air hose with the
nozzle to the product to be deflated and
tighten it;
Finally, press the "START" button to start
deflation. After deflating, please re-press
the "START" button to stop.
Step 2: According to the selected power
supply method, press the corresponding
power mode;
Step 7: Press the "+" or "-" button to set
the desired pressure. This will set the
target pressure for the air pump to inflate
the product;
Finally, press the "START" button to start
inflation. The air pump will automatically
stop working when the preset pressure is
reached.
Step 3: Insert one of the air hoses into the
inflation port and tighten it, ensuring that
the air hose is tightly connected and
airtight;
Step 4: Select the appropriate nozzle and
connect it to the other end of the air hose.
Make sure the nozzle is tightly connected
to the hose to ensure air tightness;
Step 5: Connect the air hose with the
nozzle to the product to be inflated and
tighten it. Ensure that there are no air
leaks in the product, otherwise, it will
affect the inflation effect;
Step 6: Press the "PSI/BAR" button to
select the pressure unit;
NOTES
TROUBLESHOOTING
5 6
UP
DOWN
Problem: Inflation slowly or abnormal.
Problem: The unit failed to start.
Possible cause:
a. Overheat cause the motor to stop or break;
b. The cable is broken or not plugged in properly.
Solution:
a. Cool the pump and start again;
b. If the cable is broken, replace it with a new one; If it is not
plugged in, you need to plug it in properly.
Problem: The cover opens automatically and easily.
Possible cause:
a. Check if there is any damage or block of the air hose;
b. The air hose didn't connect the Inflatable product or the main
body tightly;
Solution:
a. Change the air hose if it is broken. Clear the blockage of the
air hose;
b. Reconnect the air hose, please ensure that the air hose
connects the inflatable product or the main body tightly.
Solution:
a. The correct way to open the
cover is to push it up first and
then proceed to open it.
b. When closing the cover,
ensure that it is firmly pressed
down to lock it in place.
Problem: I measured the pressure value myself with my testing
tool, why do I find the tested value is different from the set value?
Possible cause:
a. Air backflow caused by failure to remove the air hose
promptly after stopping inflation;
b. Use of an unprofessional pressure testing instrument;
Solution:
a. Ensure the air hose is promptly removed after stopping
inflation;
b. Use a professional pressure testing instrument to obtain
accurate results.
7
3. If the air pump is used continuously for 40 minutes, let it cool
down for 15-20 minutes to avoid damage to the product due to
overheating of the motor.
4. To prevent danger, ensure that the air inlet is not facing the
body.
5. When using the air pump, do not stay far away from the
inflatable product to ensure safety.
6. Please note that the battery pack is not included. Kindly
purchase the recommended product and feel free to contact us at
[email protected] for further information or assistance.
WARRANTY & CUSTOMER SUPPORT
We offer a one-year limited warranty for the product. If you
need any assistance, please make sure to have your Amazon
Order ID ready when contacting us for service. Please write to
us at [email protected].
For The Period of:
One Year
Starting from the
date of the original
purchase.
Morpilot Covers:
If there is a material or workmanship
defect that causes the SUP AIR PUMP
to fail during the one-year limited
warranty, we will either replace your
product or provide a refund for the
purchase price, at our sole discretion.
The following are not covered under Morpilot's warranty:
1. Improper installation, delivery, or maintenance.
2. Misuse or abuse of the product, which results in failure.
3. Damage to the product due to accidents, fires, floods, or other acts
of God.
4. Damage caused by the user attempting to repair or modify the
product.
5. Damage caused by the use of an improper power supply or
voltage.
6. Damage to the product due to using an unqualified battery pack.
