LW006-E Datasheet
MOKO TECHNOLOGY LTD.
www.mokosmart.com
Version 1.0
LW006-E Datasheet
Introduction
LW006-E is the smart badge that combines LoRaWAN network transmission with BLE, and GPS positioning
technologies.
This combination allows for reliable indoor and outdoor positioning, making it ideal for ensuring staff
safety, emergency alarm capabilities, and effective personnel management.
Key Features
Long-range & Low-power communication
Multi-mode positioning fusion
Flexible alarm trigger
Built-in accelerometer
Multiple working mode
IP67 water proof
Mechanical Size Description
General Specifications
Categories
Parameter
Value
LW006-E Datasheet
2 www.mokosmart.com
LoRa
Wireless
Specification
LoRa Protocol
LoRaWAN V1.0.3
Lora Frequency
EU868/AU915/US915/AS923/IN865/KR920/RU
864/AS923-1/AS923-2/AS923-3/AS923-4
LoRa Communication Distance
Up to 5 km (in urban open space)
BLE Wireless
Specification
Bluetooth® (BLE)
V5.3
BLE Broadcast Distance
Up to 50m in free space
BLE Scan Distance (1M PHY)
Up to 150m in free space
Power Supply
Power Supply
1500 mAh rechargeable battery
Physical
Specification
Protection level
IP67
Dimension
96.5*61.6*10.0mm
Weight
70g
Application
Specification
Power Switch
power button
Operation Temperature/
Storage Temperature
-20℃ ~ 60℃
Operation Humidity
10%~90%
Certification
CE/FCC/Reach/RoHS pending approval
Ordering Information
Product Type
Description
Notes
LW006-E US915
LW006-E EU868
Smart badge
Subnet except US915 and EU868
also supported, please consult
with moko before ordering
Warning Message
>Unless specifically indicated that it is safe to do so in the user guide or instruction manual do not use this
device in an environment that exceeds the recommended low or high temperature
>Unless specifically indicated that it is safe to do so in the user guide or instruction manual, avoid exposing
your device to direct sunshine or excessively wet environments.
>The recommended temperature range for devices and accessories is -20°C to 60°C(Charging
temperature is 0'C to 45°)
>When Charging, please place the device in an environment that has a normal room temperature and good
ventilation
>Do not use the product in any way other than described herein in order to avoid personal injury or
property damage.
>User should comply with the laws and regulations of the corresponding countries and regions where the
equipment is used, abide by professional ethics, pay attention to safety obligations, and strictly prohibit
the use of our product or equipment for any illegal purposes.Our company will not be responsible for any
LW006-E Datasheet
3 www.mokosmart.com
violators'legal liability under any circumstances.
>Replacing a battery with an incorrect type may bypass safeguards and create danger;
>Disposal of a battery in a fire or other source of significant heat, or by crushing, or cutting, may result in
an explosion as well as leakage of flammable liquids and gases;
>Leaving a battery in an extremely hot environment may result in an explosion as well as leakage of
flammable liquids and gases;
>A battery subjected to extremely low air pressure may result in an explosion as well as leakage of
flammable liquids and gases.
FCC Radio Frequency Exposure Statement
>This device complies with the FCC RF exposure requirements for an uncontrolled environment.
The output power of this device is so low that a Specific Absorption Rate (SAR) evaluation is not
required.
FCC Statement:
This device complies with part 15 of the FCC Rules.Operation is subject to the following two
conditions:
(1)This device may not cause harmful interference,and
(2)this device must accept any interference received,including interference that may cause
undesired operation
This equipment generates uses and can radiate radio frequency energy and,if not installed and
used in accordance with the instructions,may cause harmful interference to radio
communications.However,there is no guarantee that interference will not occur in a particular
installation.If this equipment does cause harmful interference to radio or television reception,which
can be determined by turning the equipment off and on,the user is encouraged to try to correct
the interference by one or more of the following measures:
(1)Reorient or relocate the receiving antenna
(2)Increase the separation between the equipment and receiver.
(3)Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
(4)Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
FCC warning statements:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
