The H5PD Dual Panic Button is an innovative wearable badge designed to deliver instant emergency
response. Its compact design features dual buttons for customizable various clicks (double click, triple
click, etc.), enabling users to trigger precise alerts. Using different forms, these two buttons are
convenient for users to accurately distinguish in emergencies. With firmware-configurable functions for
each button, the H5PD is ideal for personnel safety in various environments like hospitals, schools,
hotels and more.
Dual Panic Button
H5PD
Dual Button
Precise Alert
*Battery lifespan estimates are based on the default settings without accelerometer sensor – 1 active slot, 1000ms ADV interval and
0dBm Tx Power.
Features
Dual programmable
buttons
IP66
waterproof
Replaceable
battery
Supports
RFID
Supports alarm
feedback
Supports silent
alerting
Applications
ConstructionHotel School
www.mokosmart.com
General Specifications
50mm
68mm
6.6mm
Connectivity
Dimensions (mm)
Weight
Color
Material
IP rating
Sensor
LED
Buzzer
RFID/NFC
Battery capacity
Battery lifespan
Operating temperature
Transmission range
Installation
Certification
BLE 5.0
68.0*50.0*6.6
Body - White | Button - Red&Blue
PC
IP65
Accelerometer
Red | Green
Yes
HF | LF/UHF (Customizable)
550mAh | Replaceable battery
3 years*
-20℃/60℃
Up to 150m (Without any obstacles)
Lanyard
FCC | CE | RohS | WEEE
RFID
23g
