W6 is a Bluetooth wristband beacon designed to offer personnel monitoring, access control and
indoor location-based services. Equipped with replaceable battery, the device will last up to 4
years due to the ultra-low power consumption. When facing emergencies, users could press
the button to trigger SOS help. Available now in both soft rubber button and regular button
options.
Application
Wristband Beacon
W6 Series
Stay Connected
Keep Safety
Shopping Mall Healthcare
General Specs
Connectivity:
Transmission Range:
Dimension(main body):
Color:
Material:
IP rating:
Installation:
Button:
LED:
Sensor:
Battery lifespan:
RFID/NFC:
BLE 5.0
Up to 150 meters
(without any obstacles)
38.6mm*38.6mm*10.5mm (W6)
38.6mm*38.6mm*10.8mm (W6B)
W6: Black
W6B: Black (body), Red (button)
ABS+PC & TPU
IP67
Wristband | Keychain
Mechanical button
Red
3-axis accelerometer sensor
1.5 years*
Supported
Battery capacity:
Operating temperature:
Certification:
CR2032 220mAh | Replaceable battery
-20°C/60°C
FCC | CE | REACH |WEEE
38.6 mm
10.8 mm
38.6 mm
10.5 mm
*Lifespan estimated based on standard scenario under 25℃ conditions. (0dBm Tx Power | 1000ms ADV interval)
Multiple Wearing Methods
Multiple wearing methods IP67 Waterproof Replaceable battery
Wristband
Keychain Neck chain
W6B (soft rubber button) W6 (regular button)
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
