The M7 is a small foam asset tag engineered for real-time security monitoring and disassembly
alarms. It features a physical mechanical button on the back, serving as an indicator to show
whether the label has detached. Moreover, the built-in acceleration sensor is supplemented to detect
any movement of the label when attached to stationary objects. M7 is able to submit maintenance or
repair requests via pressing the front blue button. With the compact size, the M7 is easily attached
on valuable assets in warehouses, hospitals, and more.Available in CR2450 and CR2032 built-in
battery version to satisfy various needs.
Real-time Guard
Disassembly Alarmed
Application scenarios
Anti-Tamper Tag
M7
Warehouse
Hospital
*Battery lifespan estimates are based on the default settings without accelerometer sensor – 1 active slot, 1000ms ADV interval and
0dBm Tx Power.
Features
Buzzer
notification
IP67
waterproof
Physical tamper-proof
button
Prominent maintenance
button
www.mokosmart.com
General specifications
57.3mm
37.3mm
6.8mm
Connectivity
Dimensions (mm)
Color
Material
IP rating
Sensor
LED
Buzzer
Battery capacity
Battery lifespan*
Operating temperature
Transmission range
Installation
Certification
BLE 5.0
57.3*37.3*6.8 (CR2450 battery version)
53.3*33.3*5.0 (CR2032 battery version)
Body - White | Button - Blue
PVC
IP67
Accelerometer
Red | Green
Supported
600mAh (CR2450 battery version)
220mAh (CR2032 battery version)
3 years(CR2450) | 1.5 years(CR2032)
-20℃/60℃
Up to 150m (Without any obstacles)
Sticker
FCC | CE | RohS | WEEE
CR2450 battery version
53.3mm
33.3mm
5mm
CR2032 battery version
