Builders Series
Continuous Flow Hot Water
Discover our range of cost effective 6-star
models designed specifically for builders
and projects.
Accessories
Designed for the Builder
Y
E
A
R
W
A
R
R
A
N
T
Y
STANDARD EXTENDED
+
10 YEAR 5 YEAR
*
HEAT EXCHANGER
WARRANTY
6 Star
Builders Series
Rinnai Continuous Flow hot
water systems are the most
technologically advanced hot
water system available today.
These units are designed to be
energy efficient, by heating water
as it passes through the unit,
therefore reducing running costs
and greenhouse gas emissions,
add to this its compact size
which allows it to be installed
almost anywhere.
The range is available in
16L (6.1 star), 20L (6.0 star) or
26L (6.0 star) variants and
supplied in a neutral Dune colour.
Recess Box
(SBOX)
Manufactured
from a tough ABS
plastic, the SBOX is
light weight, easy to
handle, durable and
easy to install.
Metal
Recess Box
(RBOX04L)
Designed to
house and hide
the pipe work
but also create
a smooth and
clean finish to the
installation.
Pipe Cover
(PC11D)
Colour matched
to enhance the
installation by hiding
unsightly pipe work
and complement its
existing surroundings.
Security
Bracket
(SECBKT)
Secure your
investment with
a quick and easy
to install security
bracket.
Flue Diverter
Directing the flue
gases sideways
means your
Rinnai Builders
Series Continuous
Flow unit may be
installed into areas
with restricted
ventilation like
balconies.
We’re at
your service
The National Customer Care
Centre provides first class service
and maintenance of your system,
ensuring it’s running at its highest
efficiency - so you can enjoy the
Rinnai experience for many years
to come.
Operating 5 days a week
(Monday to Friday)
13 43 73
Features and Benefits
* Sizing assumes AAA or 3 star outlets. For more sizing information, consult with your hot water specialist.
** 50oC appliances can be adjusted up to 53°C. For 60°C plus installations a tempering valve in accordance with AS3500.4 is required.
# Made from premium materials and built to last, Rinnai provides a standard 3 year (10 Year Heat Exchanger) parts and labour warranty on all Builders series Continuous Flow
hot water systems plus an optional 5 years extended Heat Exchanger warranty. Visit rinnai.com.au for full terms and conditions
.
Model B16 B20 B26
Bathrooms (Cool Climate / Warm Climate)* 1 1 / 1-2 1-2 / 1-3
Installation External External External
Gas Energy Rating 6.1 6.0 6.0
Heating Capacity L/Min (raised at 25ºC) 16 20 26
Height 531 531 531
Width 351 351 351
Depth 195 195 195
Weight 13kg 14kg 15kg
Gas Input (High) 124MJ/h 156MJ/h 199MJ/h
Cold Water Connection (mm) 15 (1/2”) 20 (3/4”) 20 (3/4”)
Hot Water Connection (mm) 15 (1/2”) 20 (3/4”) 20 (3/4”)
Gas Connection (mm) 20 (3/4”) 20 (3/4”) 20 (3/4”)
Minimum Operating Flow (L/Min) 1.5 1.5 1.5
Factory Pre-set Temperature (°C)** 50/60 50/60 50/60
Colour Dune Dune Dune
Ignition Direct electronic ignition with automatic flame sensing
Gas Type NG / LPG
Electrical Supply AC 240V 50 Hz (10 amp weatherproof power point)
Water Controllers Up to 4 Water Controllers can be installed
Heat Exchanger Warranty 15 Years
#
Parts and Labour Warranty 3 Years (5 Years if two or more Water Controllers are installed in domestic applications)
Design
Sleek, compact, quality Japanese design and
manufactured in Rinnai’s own high tech facility.
Quality
High quality componentry, engineered to last.
Water Conservation
Low flow shower head (WELS) compatible.
Stability Temperature
Puretemp
™
temperature stability technology
provides PCB controlled and perfectly stable
outlet water temperature.
Star Rating
Superior 6+ star efficiency across the range of
16 – 26 litre units.
Warranty
15 years Heat Exchanger warranty
#
.
Flow rate
1.5L/minute minimum operating flow rate.
Connectability
50oC compliant models available with quick
connect systems for water controllers.
Technical Information
With our policy of continuous improvement, we reserve the right to change, or discontinue at any time, specifications or designs without notice.
Note: All images contained within this brochure are for illustrative purposes only, the colours and finishes of the products featured are as close to the
respective product range as photographic lighting and printing processes allow.
TOTAL HOME COMFORT
HOT WATER HEATING COOLING
Rinnai Australia Pty Ltd
ABN 74 005 138 769
100 Atlantic Drive,
Keysborough, Victoria 3173
For further information
call 1300 555 545 or visit
rinnai.com.au
RA37.02.20 Brochure Rinnai Builders Series CF
