● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
6
7
8
9
6 10 9
8 3
11
2
3
4
5
1. Switch
2. Handle
3. Power cord hook
4. Power cord
5. Clean water tank
6.Small brush
7. Dirty water tank
8. Hook for brush
9. Hose
10. Big brush
11. Hose hook
COMPONENTS LIST：
- 3 -
HOW TO USE
Plug the power cord and press
ON/OFF button.
2
Press the water-spray button to
spray water.
3
Select the desired wash tool
suitable for the flooring/surface
and attach this to the hose
handle.
1
Brush the unit back and forth to
clean stains.
4
Suction inlet
Press the brush in the stains
position to suck all dirty water.
6
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid
unpleasant smell
7
IMPORTANT: Over or under tilting the hand tool may result in poor water pick up.
Suction inlet
x
For spills always pick up the
excess liquid before using water
or solution.
5
- 5 -
HOW TO CLEAN STUBBORN STAINS
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 6 -
CLEANING CARE AND MAINTENANCE
Remove the dirty water tank
from the main cleaner.
6
Remove the clean water tank
from the main cleaner.
2
Pour water out of the tank.
3
Re-install the empty clean
water tank and ower on, press
the water-spray button to
remove any excess water from
the tank.
4
Press the wash tool release
button and pull to remove
the tool from the hose.
1
Remove the wash tool brush
cover to clean by rinsing under
the tap. To replace; place cover
into position on the wash tool
until it clicks into place.
5
To prolong the life of your spot & stain cleaner and prevent blockages or problems occurring follow this
guide.
Always carry out cleaning when the product has been switched off for a short period of time.
CAUTION! never clean the cleaner or any parts of it whilst the plug is switched on at the mains.
This appliance can be cleaned by wiping a damp soft cloth to keep the outside free of dirt including
dust. Use a dry cloth to clean the power cord.
To avoid unpleasant damp smells clean both tanks and ensure they are fully air dried before storing
and after every use.
- 7 -
Empty the dirty water tank after
every use or when the water level
reaches the max fill line. The float
inside will prevent suction if the
tank is full.
7
Open the dirty water tank and
take out the cover and filter.
8
Clean all parts with warm water
only. Do not use washing up
liquids or other chemicals.
10
Reinstall the dirty water tank
into place on the cleaner.
11
Remove small foam filter to
clean by rinsing under the tap.
Ensure this is fully dry before
replacing and using in the
appliance. TIP! Place on or near
a radiator to dry.
9
- 8 -
SPECIFICATIONS
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W07-1/W07-2
220-240V~ 50/60Hz
450W/600W
≥11 kPa
1500ML /
700ML
IPX4
120V~ 60Hz
3.7A / 5A
≥11 kPa
1500ML /
700ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 9 - - 10 -
Name
IP rating
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
C5
PROTABLE CARPET CLEANER
USER’S MANUAL
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
svstems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
This appliance may be normal used under 60Hz the frequency need not to be adjustted.
Insert the house into the
machine and make sure
the lock tap is well fixed.
PREPARATIONS BEFORE USE
Open the clean water tank by
turning the cover in anticlockwise
direction and take.
1
Insert the handle and cable
hook into the machine.
2
Put the hose hook in the correct
position to push it from right to
left, and it is fixed well when you
hear a lock tone.
3
Wrap the hose around the base
and insert the hook.
8
Insert the hose into the
machine. make sure the lock
tap is well fixed.
4
Put suitable amount of water
into the clean water tank.
WARNING: Donot exceed the
max water level line.
5
Align the solid circle of the tank
cover with the hollow circle of
the tank, with a clockwise
rotation to close the cover until
you hear a lock tone and insert
it into the machine.
6
Assemble the brush as you may
want.
7
- 4 -
Insert the house into the
machine and make sure
the lock tap is well fixed.
Item number
Portable carpet cleaner
C5
120V ~ 60Hz
500W
≥11 kPa
1500ML/700ML
IPX4
Voltage/Frequency
Rated power(Current)
Max vacuity
Capacity of clean water tank/
Dirty water tank
Email:Ailltopd-aftersale@outlook.com
Adress:Block A,Galaxy WORLD Building,Bantian Street,
Longgang District,Shenzhen
210 mm
142 mm
黑白说明书 105G铜版纸 12P
