Jump start port
USB output port
Air outlet
LED light
Type-C charging port
Digital display
Control keys
Don’t touch
Press once to turn on. Long press 3 seconds to enter inflate
mode. Long press 3 seconds again to turn off.
Press once to switch between different inflation modes.
Long press 3 seconds to switch between pressure units.
Increase/decrease inflation pressure.
After power on, long press 3 seconds to turn on the LED light,
press once to switch between LED modes.
Control keys
/
Jump start port
Note: After using the jump starter function, This area will be very
hot, please don't touch it.
PRODUCT DIAGRAM
Insert jumper cables
into the Jump Start port
1
JUMP STARTER INSTRUCTION
Locate your car battery. First
connect the red clamp to "+",
then connect the black clamp
to the "-". (DO NOT REVERSE!)
Start your car right aw
ay,
within 3 seconds.
Remov
e black clamp first,
then remove the red clamp
Pack aw
ay and charge
your unit
Long press " " 3 seconds to
enter the inflation mode, press
"R" to swith different inflation mode,
and "-" "+" to adjust the pressure
AIR COMPRESSOR INFLATION INSTRUCTION
Pull out the inflation hose,
and connect it to your tire
Press once the " "
button to start inflating
The inflation will automatically
stop after the inflation pressure
reaches the preset value
After inflation, remo
ve the
air pump hose immediately,
and charge your unit
2
3 4
5
1
2
3 4
5
ON/OFF
Click
When switching between inflation modes, be
aware that there might be air pressure coming
out, do not point the air pump hose towards any
individual, with special emphasis on avoiding the
eyes or ears. Before starting inflation, ensure the
inflation hose is securely connected.
ATTENTION!
During inflation mode, be aware that the device's tube may generate
high temperatures. For safety, the device is designed to automatically
turn off if continuously running for 3 minutes to prevent overheating.
After the automatic shutdown, allow the device to cool down before
storing or using it again. This precaution is essential to ensure safe
operation and extend the device's lifespan.
HOT SURFACE CAUTION
TECHNICAL SPECIFICATIONS
1 x Car Jump Starter with Air Compressor
1 x Jumper Cable
1 x Charging Cable
3 x Air Nozzle
1 x Cloth Bag
1 x User Manual
1 x Warranty Card
Battery type: Lithium ion
Charge cycles: 2000 times
Charging time: 3~5H
Starting current: 400A/500A/600A/800A
Peak current: 800A/1000A/2000A/3000A
Operating temperature: -4°F~140°F
LED Lumens:100LM
Applicable Models: 12V Car
Charging port: 5V 2A / 9V 2A / 12V 1.5A
Output USB port: 5V 2A
Max current consumption: 10A
Maximum pressure of the compressor: 150PSI
Continuous operation time: 5 minutes
Air flow rate: 22L/min
4 Inflation mode: Car/Motorcycle/Bicycle/Ball mode
Preset tire pressure range: Car/2.5Bar, Motorcycles/2.4Bar,
Bicycles/2.5Bar, Balls/7.5PSI
Measurements: 182*115*59mm / 7.2*4.5*2.3in
PACKAGE INCLUDE
1. Auto-Cooldown Safety Feature:
After 5 minutes of continuous use as an air compressor or jump
starter, the unit will automatically pause for a 3-minute cooldown.
Please wait for this period to elapse before resuming operation
for safety and optimal performance.
2. Jump Starter Precaution:
Before using the jump starter function, ensure that the unit's
power level is no less than 60% to guarantee effective performance.
ATTENTION!
LED LIGHTS OPERATION
Long press 3 seconds
Short press
Short press
Short press
Light OFF
Strong Light
Flash
SOS
Light OFF
Charge Operations
Safety Advisory:
When charging, ensure to use a regular charger that matches the
specified charging port parameters provided in page 3.
Do not connect incompatible devices while the device is in the
output mode. Improper use may lead to safety hazards and
potential damage.
5V/9V/12V
Type-C Charging port
Input
Output
USB Output port
LCD DIGITAL DISPLAY
4 Inflation mode
Car mode: Default 2.5bar
Motorcycle mode: Default 2.4bar
Bicycle mode: Default 2.5bar
Ball mode: Default 7.5PSI
Unit of measure
Battery
level display
Pressure
indicator
USAGE GUIDELINES
1. This product can be operated by individuals aged 8 years and
older. It is important that user read instruction carefully before
use. Understanding the potential risks associated with its use
is essential for ensuring a safe and secure experience.
2. Within the designated working area, users are solely responsible
for any damage or injury that may result from improper use of
the device. Exercise caution and adhere to safety guidelines.
3. While in operation, never direct the device towards yourself or
others, and ensure a safe distance from ears and eyes. There is
a risk of injury, and strict adherence to this precautionary
measure is advised.
4. Do not leave the device unsupervised during operation.
5. Caution: The inflatable article could burst, follow the
compressor instructions carefully.
6. Switch off the compressor before reaching the maximum
permissible pressure to ensure safe operation.
7. Store the device in a dry location and out of reach of children
to ensure safety and prevent unauthorized use.
For any support or comments concerning our products,
please send an email to: [email protected] or
toll free number in the USA: 800-473-5156
SUPPORT
*All products brands and trademarks are property of their respective
owners.
