MICROWAVE OVEN
INSTRUCTION MANUAL
Model: FMR17BLK
Read these instructions carefully before using
your microwave oven. If you follow the
instructions, your oven will provide you with
many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
(rev. xx/xx/xx MD)
1
Farberware is a registered trademark of Farberware Licensing Company, LLC
Manufactured and sold pursuant to a license from Farberware Licensing Company, LLC
© 2023 Farberware Licensing Company, LLC. All rights reserved.
2
Table of Contents
PRECAUTIONS ................................................................... 3
SPECIFICATIONS ................................................................ 3
SAFETY ................................................................................ 4
GROUNDING .................................................................... 6
UTENSILS ............................................................................ 7
NAMES OF OVEN PARTS AND ACCESSORIES .................. 10
OPERATION ...................................................................... 11
MAINTENANCE ................................................................. 18
WARRANTY INFORMATION ............................................ 20
3
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
SPECIFICATIONS
a. Do not attempt to operate this oven with the door open since open-door operation
can result in harmful exposure to microwave energy. It is important not to defeat or
tamper with the safety interlocks.
b. Do not place any object between the oven front face and the door or allows soil or
cleaner residue to accumulate on sealing surfaces.
c. Do not operate the oven if it is damaged. It is particularly important that the oven
door close properly and that there is no damage to the:
d. The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
1. DOOR (bent)
2. HINGES AND LATCHES (broken or loosened)
3. DOOR SEALS AND SEALING SURFACES
Model: FMR17WHT
Rated Voltage: 120V~60Hz
Rated Input Power(Microwave): 1550W
Rated Output Power(Microwave): 1000W
Oven Capacity: cubic feet
Turntable Diameter: inches
External Dimensions: (W)x(D)x(H)inches
Net Weight: Approx Lbs
WARNING:
This product can expose you to chemicals
including Phthalates or other chemicals which are known
to the State of California to cause cancer, birth defects and
other reproductive harm.
For more information, visit www.P65Warnings.ca.gov
4
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including
the following:
WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or
exposure to excessive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific: “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY” found on page 4.
3. This appliance must be grounded. Connect only to properly grounded outlet. See
“GROUNDING INSTRUCTIONS” found on page 6.
4. Install or locate this appliance only in accordance with the provided installation
instructions.
5. Some products such as whole eggs and sealed containers - for example, closed glass
jars - are able to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not use
corrosive chemicals or vapors in this appliance. This type of oven is specifically
designed to heat, cook or dry food. It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when us e d by children.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not working
properly, or if it has been damaged or dropped.
9. This appliance should be serviced only by qualified service personnel. Contact nearest
authorized service facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near water - for
example, near a kitchen sink, in a wet basement, near a swimming pool, or similar
location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge o f table or counter.
15. When cleaning surfaces of door and oven that comes together on closing the door,
use only mild, nonabrasive soaps, or detergent applied with a sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the container
is removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN
THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.
1. Do not overcook food. Carefully attend appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
2. Remove wire twist-ties from paper or plastic bag before placing bag in oven.
3. If material inside of the oven ignite, keep oven door closed, turn oven off, and
disconnect the power cord, or shut off power at the fuse or circuit breaker panel.
4. Do not use the cavity for storage purposes. Do not leave paper products, cooking
utensils, or food in the cavity when not in use.
5
18. Do not operate any heating or cooking appliance beneath the appliance.
(Exception: A microwave oven investigated for use above another heating appliance.)
19. Do not mount unit over or near any portion of heating or cooking appliance.
(Exception: A microwave oven investigated for use above another heating appliance.)
20. Do not mount over sink.
21. Do not store anything directly on top of the appliance surface when the appliance is in
operation.
22. Clean Ventilation Hoods Frequently - Grease should not be allowed to accumulate on hood
or filter.
23. When flaming foods under the hood, turn the fan on.
24. Use care when cleaning the vent-hood filter. Corrosive cleaning agents, such aslye-based
oven cleaners, may damage the filter.
25. Suitable for use above both gas and electric cooking equipment.
To reduce the risk of injury to persons:
SAVE THESE INSTRUCTIONS
1. Do not overheat the liquid.Remove wire twist-ties from paper or plastic bag before
placing bag in oven.
2. Stir the liquid both before and halfway through heating it.
3. Do not use straight-sided containers with narrow necks.
4. After heating, allow the container to stand in the microwave oven for a short
timebefore removing the container.
5. Use extreme care when inserting a spoon or other utensil into the container.
6
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape wire for the electric current. This appliance is
equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged
into an outlet that is properly installed and grounded.
WARNING - Improper use of the grounding can result in a risk of electric shock. Consult a
qualified electrician or serviceman if the grounding instructions are not completely understood,
or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an
extension cord, use only a 3-wire extension cord that has a 3-blade grounded plug, and 3-slot
receptacle that will accept the plug on the appliance. The marked rating of the extension cord
shall be equal to or greater than the electrical rating of the appliance.
DANGER - Electric Shock Hazard:
Touching some of the internal components can cause serious personal injury or death.
Do not disassemble this appliance.
WARNING - Electric Shock Hazard:
Improper use of the grounding can result in electric shock. Do not plug into an outlet until
appliance is properly installed and grounded.
1. A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in
their use.
3. If a long cord or extension cord is used:
1. The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance.
2. The extension cord must be a grounding-type 3-wire cord.
3. The longer cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally.
RADIO INTERFERENCE
This device complies with part 18 of the FCC Rules.
GROUNDING INSTRUCTIONS
1. Operation of the microwave oven may cause interference to you r radio, TV or similar
equipment.
2. When there is interference, it may be reduced or eliminated by taking the following
measures:
1. Clean door and sealing surface of the oven.
2. Reorient the receiving antenna of radio or television.
3. Relocate the microwave oven with respect to the receiver.
4. Move the microwave oven away from the receiver.
5. Plug the microwave oven into a different outlet so that microwave oven and receiver
are on different branch circuits.
7
UTENSILS
CAUTION - Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches
should be pierced before cooking.
See the instructions on “Materials you can use in microwave oven.” or “Materials cannot be used
in microwave oven.”
There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt,
you can test the utensil in question by following the procedure below.
Utensil Test:
NOTE - KEEP THE CAVITY CLEAN
1. Fill a microwave-safe container with 1 cup or cold water
(250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm,
do not use it for microwave cooking.
4. Do no exceed 1 minute cooking time.
8
MATERIALS YOU CAN USE IN MICROWAVE OVEN
Utensils Remarks
Browning Dish Follow manufacturer* instructions. The bottom of browning dish must
be at least 3/16 inch (5mm) above the turntable. Incorrect usage may
cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use
cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass
jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic
trim. Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer* instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Paper plates and cups Use for short term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer* instructions. Should
be labeled “Microwave Safe”. Some plastic containers soften, as the
food inside gets hot. “Boiling bags” and tightly closed plastic bags
should be slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax papers Use as a cover to prevent splattering and retain moisture.
9
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe
dish.
Food carton with metal handle May cause arcing. Transfer food into microwave-safe
dish.
Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal
trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside
when exposed to high temperature.
Wood Wood will dry out when used in the microwave oven
and may split or crack.
10
NAMES OF OVEN PARTS AND ACCESSORIES
1. Microwave oven door with see-through
window.
2. Door hinges.
3. Waveguide cover.
DO NOT REMOVE.
4. Turntable motor shaft.
5. Microwave oven light.
It will light when microwave oven is
operating or door is open.
Glass Turntable Turntable Ring Assembly
6. Rack holders.
7. Safety door latches
The microwave oven will not operate
unless the door is securely closed.
8. Handle.
9. Control Panel.
10. Display Screen
11. Ventilation openings.
12. Rating Label.
11
OPERATION
· Before operating your new oven make sure
you read and understand this Use and Care
Guide completely.
· The lock can be disabled when the
microwave is first plugged in and the STOP
key is selected.
To re-enable the clock follow clock
instructions.
· Suppose you want to enter the correct time
of day 10:59
· Suppose you want to cook for 2 minutes at
90% power
· Suppose you want to set for three minutes.
Your microwave oven can be used as a kitchen
timer. You can set up to 99 minutes , 99
seconds. The kitchen timer can be used while
the microwave oven is running.
Your microwave oven can be used as a kitchen
timer. You can set up to 99 minutes , 99
seconds. The kitchen timer can be used while
the microwave oven is running.
There are not any other programs during the
kitchen timer
SETTING THE CLOCK
SETTING THE TIMER
MICROWAVE
Touch:
Touch:
Touch:
1. Clock
2. 1059
3. Clock or Start+30sec.
1. Cook Time
2. 200
3. Power Level x1
4. Power Level x1 or 9
5. Start+30sec.
1. Timer
2. 300
3. Timer
Display Shows:
Display Shows:
Display Shows:
(Current time)
(Time counting down)
NOTE
PRESS POWER LEVEL
POWER CHART
DISPLAY
POWER LEVEL x 1 100%
P-HI
P-90
P-80
P-70
P-60
P-50
P-40
P-30
P-20
P-10
90%
P-0
80%
70%
60%
50%
40%
30%
20%
10%
0%
POWER LEVEL x 2 or 9
POWER LEVEL x 3 or 8
POWER LEVEL x 4 or 7
POWER LEVEL x 5 or 6
POWER LEVEL x 6 or 5
POWER LEVEL x 7 or 4
POWER LEVEL x 8 or 3
POWER LEVEL x 9 or 2
POWER LEVEL x 10 or 1
POWER LEVEL x 11 or 0
12
OPERATION
Using Add 30 Sec.
This is a time-saving pad. It is a simplified
feature that lets you quickly set and start
microwave cooking at 100% power.
Using Number Pads For “1-6”
Press number pads “1-6” to start cooking with
corresponding time for 100% power level
directly.
For example, cooking with 3 minutes for 100%
power level.
The oven should be opend and closed in 5
minutes before the speed cooking,otherwise,
operating as below.
The buzzer will sound to remind you of turning
over the food when half of the time has passed
on.
“Food” will be displayed if a quick start cooking
cycle or +30 sec key is not selected within 5
minutes of placing f o od in the microwave. You
must open then close the door again to clear
‘’Food” from the display.
WEIGHT DEFROST
TIME DEFROST
SPEED COOKING
Touch:
Touch:
Touch:
Touch:
Touch:
1. Defrost x1
2. 12
3. Clock or Start+30sec.
1. Start+30sec.
1. 3
2. After 2 seconds
1. 2
2. Open the door
3. START Enter/+30Sec
1. Defrost x2
2. 1200
3. Start+30sec.
Display Shows:
Display Shows:
Display Shows:
Display Shows:
Display Shows:
NOTE
NOTE
Time counting down
SEE MENU LABEL
(Time counting down)
SEE MENU LABEL
COOK
DEFR
COOK
Time counting down
(Close the door)
13
OPERATION
Press “Popcorn” key and LED displays 3.3
oz. Press “Popcorn” repeatedly to choose the
desired weight.
· Suppose you want to cook 3.0 oz. popcorn.
VEGGIES POTATO
POPCORN
Touch:
Touch:
Press popcorn pad
Press potato pad or number keys
Touch:
1. VeggiesX1
VeggiesX2
2. 1
3. Start+30sec. Time counting down
Time counting down
Time counting down
1. Potato
2. PotatoX1 or 2
3. Start+30sec.
1. Popcorn
2. PopcornX1
3. Start+30sec.
X1
X2
X3
X1
X2
X3
X4
3.3 oz
3.0 oz
1.75 oz
1
2
3
4
Display Shows:
Display Shows:
Amount
Amount
Display Shows:
SEE MENU LABEL
SEE MENU LABEL
SEE MENU LABEL
SEE MENU LABE
L
SEE MENU LABEL
SEE MENU LABE
L
14
1. Snack MenusX1
2. 1
3. Start+30sec.
1. Auto cookX1
2. 2
3. Start+30sec.
1. Snack MenusX2
2. Start+30sec.
Time counting down
Time counting down
Time counting down
X1
X2
X3
X4
X1
X2
X3
X4
X5
Hot Dogs
Frozen Kids Meal
Meal in a cup
Soup
Bacon
Dinner Plate
Rice
Frozen Breakfast
Frozen Pizza
1-6 Pieces
8.8 Oz
2.39 Oz
1-2 Cups
1-3 Slices
1-2 Plates
1-2 Cups
8/12 Oz
6/8/12 Oz
OPERATION
There are 5 options (Bacon,Dinner Plate, Rice,
Frozen breakfast, Frozen Pizza) under the auto
cook.
There are 4 options ( Hot dogs,Frozen Kids
Meal Meal In A Cup,Soup)under the snack
menu.
· (Hot dogs, soup)
· (Frozen Kid’s Meal, Meal In A Cup)
SNACK MENU AUTO COOK
Touch:
Touch:
Touch:
Press snack menu pad
Press auto cook
Display Shows:
Display Shows:
Display Shows:
Amount
Amount
Food
Food
SEE MENU LABEL
SEE MENU LABEL
SEE MENU LABEL
15
The oven uses low power to melt and soften
items. See the following table.
At most two stages of microwave can be set.
Defrost can’t be one of the multi-stage.
· Suppose you want to melt 2 sticks of Butter.
MELT/SOFTEN
CHILD LOCK
Touch:
Touch:
1. Melt/Soften X1
2. 2
3. Start+30sec.
1. 1 2 0
2. Power Level
3. Power Level x8 or 2
4. Cook Time
5. 1 0 5 9
6. Power Level
7. Power Leve x7 or 3
8. Start+30sec.
1. STOP/CANCEL
(for 3 seconds)
2. STOP/CANCEL
(for 3 seconds)
Display Shows:
Display Shows:
OPERATION
SEE MENU LABEL
Time counting down
Time counting down
X1
X2
X3
X4
Melt Butter
Melt Chocolate
Soften Ice Cream
Soften Cream Cheese
1/2 Stick
2/4/8 Oz
Pint/1.5 Qt
3/8 Oz
Press Melt Soften Pad AmountFood
(if clock is set)
(if clock is set)
LOCK
LOCK
or
POTATO
Touch: Display Shows:
16
The pad controls the 2-speed vent fan. If the
vent fan is OFF, the first touch of the Vent pad
will turn the fan on HIGH, second touch LOW
and third touch OFF.
The pad controls the 2-states light. If the light is
OFF the first touch of the light pad will turn the
light on ON , second touch OFF
In waiting state.
· Suppose you want to set the vent fan speed
to LOW from the OFF position.
· Suppose you want to set the vent fan speed
to LOW from the OFF position.
VENT FAN
LIGHT
Touch:
Touch:
Display Shows:
Display Shows:
OPERATION
USER PREFERENCES
VOLUME LOW/NOR/HI/OFF
Touch: Display Shows:
1.
2.
x1
x2
3.
x3
x1
x2
2.
1.
USER PREFx1
Key Setting
Volume Hi / Med
/Low/Off
Weight lb/kg
Clock Display Off/On
Demo Mode
USER PREFx2
USER PREFx3
USER PREFx4
SEE MENU LABEL
(Lo,nor,HI,oFF will
display in order)
1. USER PREF X1
2. Start+30sec.
3. Start+30sec.
17
In waiting state.
In waiting state.
WEIGHT (LBS/KG)
CLOCK DISPLAY
Touch:
Touch:
1. Melt/Soften X1
2. 2
3. Start+30sec.
1. USER PREF x4
2. Start+30sec.
3. Start+30sec.
1. USER PREF x3
2. Start+30sec.
3. Start+30sec.
Display Shows:
Display Shows:
OPERATION
SEE MENU LABEL
lb
kg
or
or
SEE MENU LABEL
Time counting down
Time counting down
In waiting state.
DEMO SETTING
Touch: Display Shows:
or
SEE MENU LABEL
18
MAINTENANCE
Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
Trouble Possible Cause Possible Remedy
Oven will not start a. Electrical cord for oven is not
plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try again.
c. Check instructions.
Arcing or sparking a. Materials to be avoided in
microwave oven were used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe cookware
only.
b. Do not operate with oven
empty.
c. Clean cavity with wet towel.
Unevenly cooked foods a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Cooking time, power level is
not suitable.
d. Food is not turned or stirred.
a. Use microwave-safe cookware
only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Overcooked foods Cooking time, power level is not
suitable.
Use correct cooking time, power
level.
Undercooked foods a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe cookware
only.
b. Completely defrost food.
c. Check to see that oven
ventilation ports are not
restricted.
d. Use correct cooking time,
power level.
Improper defrosting a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe cookware
only.
b. Use correct cooking time,
power level.
c. Turn or stir food.
19
20
ONE YEAR LIMITED WARRANTY
This warranty applies to products purchased and used in the U.S. and Canada.
This is the only express warranty for this product and is in lieu of any other warranty or
condition.
This product is warranted to be free from defects in material and workmanship for a period
of one (1) year from the date of original purchase. This warranty is valid for the original retail
purchaser or gift recipient from the date of initial retail purchase and is not transferable.
Keep your original sales receipt as proof of purchase is required to make a warranty claim.
IMPORTANT: This warranty does not cover damages resulting from use not in conformity with
the printed directions, accident, misuse or abuse, alternation, the axing of any attachments
not provided with the product, loss of parts, or subjecting the appliance to any but the specied
voltage. (Read directions carefully.) This warranty is void if the product is used for other than
single-family household use or subjected to any voltage and waveform other than as specied
on the rating label (e.g., 120V ~ 60 Hz).
Englewood Marketing LLC excludes all claims for special, incidental, and consequential
damages caused by breach of express or implied warranty. All liability is limited to the amount
of the purchase price. Every implied warranty, including any statutory warranty or
condition of merchantability or tness for a particular purpose, is disclaimed except
to the extent prohibited by law, in which case such warranty or condition is limited to
the duration of this written warranty. This warranty gives you specic legal rights. You may
have other legal rights that vary depending on where you live. Some states or provinces do not
allow limitations on implied warranties or special, incidental, or consequential damages, so the
foregoing limitations may not apply to you.
To make a warranty claim or if service is required, please call our CUSTOMER SERVICE
NUMBER.
Product registration is not mandatory. Failure to complete and return the card or form does not
diminish the consumer’s warranty rights.
For faster service, please have the model, type, and series numbers ready for the operator to
assist you.
Customer Service Number
Englewood Marketing LLC
In the US 844-918-0509
Email: Customer [email protected]
