MICROWAVE OVEN
INSTRUCTION MANUAL
Read these instructions carefully before using your
microwave oven, and keep it carefully. If you follow
the instructions, your oven will provide you with
many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
Model:
FMO12AHTBKE
(rev. 08/26/19) MD
Farberware is a registered trademark of Farberware Licensing Company, LLC
Manufactured and sold pursuant to a license from Farberware Licensing Company, LLC
© Farberware Licensing Company, LLC. All rights reserved.
2019
Tables of Contents
PRECAUTIONS....................………………………………………….……….. 4
SPECIFICATIONS……………………………………………………..…........… 4
SAFETY………………………………………………………………………..…. 5
GROUNDING………………………………………………………….……..... 6
UTENSILS………………………................................................................... 8
SETTING UP YOUR OVEN……………...................................................... 10
CONTROL PANEL………………………………......................................... 12
OPERATION……………………………….................................................. 13
MAINTENANCE……………………………………………………………….. 20
WARRANTY INFORMATION.……………………………………………….. 21
3
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a)
result in harmful exposure to microwave energy.
It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allows soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACES
(d) The oven should not be adjusted or repaired by anyone except properly
service personnel
SPECIFICATIONS
Model:
Rated Voltage: 120V~60Hz
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
FMO12AHTBKE
1550W
1100W
1.2 cubic feet
12.4 inches
Approx
sbL 34.6
20.4(W)x15.8(D)x12.8(H) inches
WARNING:
This product can expose you to chemicals
including Phthalates or other chemicals which are know to
the State of California to cause cancer birth defects and
other reproductive harm.
For more information, visit www.P65Warnings.ca.gov
n
,
4
2. Read and follow the “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY” found on page 4.
3. This appliance must be grounded. Connect only to properly grounded outlet. See
“GROUNDING INSTRUCTIONS” found on page .6
4. Install or locate this appliance only in accordance with the provided installation
instructions.
5. Some products such as whole eggs and sealed containers - for example, closed glass
jars - are able to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not
use corrosive chemicals or vapors in this appliance. This type of oven is
designed to heat, cook or dry food. It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not working
properly, or if it has been damaged or dropped.
9. This appliance should be serviced only by
service personnel. Contact
nearest authorized service facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near water - for
example, near a kitchen sink, in a wet basement, near a swimming pool, or similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes together on closing the door,
use only mild, nonabrasive soaps, or detergent applied with a sponge or soft cloth.
16. To reduce the risk of
in the oven cavity:
1). Do not overcook food. Carefully attend appliance when paper, plastic, or
other combustible materials are placed inside the oven to facilitate cooking.
2). Remove wire twist-ties from paper or plastic bag before placing bag in oven.
3). If material inside of the oven ignite, keep oven door closed, turn oven off, and
disconnect the power cord, or shut off power at the fuse or circuit breaker panel.
4). Do not use the cavity for storage purposes. Do not leave paper products,
cooking utensils, or food in the cavity when not in use.
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including
the following:
WARNING – To reduce the risk of burns, electric shock, injury to persons or exposure
to excessive microwave energy:
1. Read all instructions before using the appliance.
5
To reduce the risk of injury to persons:
1) Do not overheat the liquid.
2) Stir the liquid both before and halfway through heating it.
3) Do not use straight-sided containers with narrow necks.
4) After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
5) Use extreme care when inserting a spoon or other utensil into the container.
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape wire for the electric current. This appliance is
equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged
into an outlet that is properly installed and grounded.
WARNING – Improper use of the grounding can result in a risk of electric shock.
Consult a
electrician or serviceman if the grounding instructions are not completely
understood, or if doubt exists as to whether the appliance is properly grounded. If it is necessary
to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounded plug,
and 3-slot receptacle that will accept the plug on the appliance. The marked rating of the
extension cord shall be equal to or greater than the electrical rating of the appliance.
DANGER – Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death. Do not
disassemble this appliance.
WARNING – Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet until
appliance is properly installed and grounded.
1. A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised
in their use.
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.
6
3. If a long cord or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at
least as great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The longer cord should be arranged so that it will not drape over the counter
top or tabletop where it can be pulled on by children or tripped over unintentionally.
RADIO INTERFERENCE
1. Operation of the microwave oven may cause interference to your radio, TV or
similar equipment.
2. When there is interference, it may be reduced or eliminated by taking the
following measures:
1) Clean door and sealing surface of the oven
2) Reorient the receiving antenna of radio or television.
3) Relocate the microwave oven with respect to the receiver.
4) Move the microwave oven away from the receiver.
5) Plug the microwave oven into a different outlet so that microwave oven and
receiver are on different branch circuits.
SAFETY
1. The oven must be on a leveled surface.
2. The turntable and turntable roller rest must be in the oven during cooking. Place the
c
ookware gently on the turntable and handle it carefully to avoid possible breakage.
3. Incorrect use of browning dish may cause the turntable to break.
4. Use only the
bag size when using Direct Access Popcorn.
5. The oven has several built-in safety switches to ensure that the power remains off when
the door is open. Do not tamper with these switches.
6. Do not operate the microwave oven empty. Operating the oven with no food or food that
is extremely low in moisture can cause
charring or sparking.
7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable
may cause the turntable to break.
8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating
may occur and could cause physical injury.
7
9. Do not heat narrow-necked containers, such as syrup bottles.
10. Do not attempt to deep-fry in your microwave oven.
11. Do not attempt home canning in this microwave oven, as it is impossible to be sure
all contents of the jar have reached boiling temperature.
12. Do not use this microwave oven for commercial purpose. This microwave oven is made
for household use only.
13. To prevent delayed eruptive boiling of hot liquids and beverages or scalding yourself, stir
liquid before placing the container in the oven and again halfway through cooking time. Let
stand in the oven for a short time and stir again before removing the container.
14. Use carefully when cooking food in the microwave oven to avoid burning due to
excessive cooking.
15. When the appliance is operated in the combination mode, children should only use the
oven under adult supervision due to the temperatures generated.
16. Failure to maintain the oven in a clean condition could lead to deterioration that could
adversely affect the life of the appliance and possibly result in a hazardous situation.
UTENSILS
!
CAUTION – Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches
should be pierced before cooking.
See the instructions on “Materials you can use in microwave oven or to be avoided in
microwave oven.”
There may be certain non-metallic utensils that are not safe to use for microwaving. If in
doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
8
MATERIALS YOU CAN USE IN MICROWAVE OVEN
Utensils Remarks
Browning dish Follow manufacturer* instructions. The bottom of browning dish must
be at least 3/16 inch (5mm) above the turntable. Incorrect usage may
cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use
cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass
jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer* instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Paper plates and cups Use for short term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer* instructions. Should
be labeled “Microwave Safe”. Some plastic containers soften, as the
food inside gets hot. “Boiling bags” and tightly closed plastic bags
should be slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
9
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal
trim may cause arcing.
Metal twist ties May cause arcing and could cause a in the oven.
Paper bags May cause a in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside
when exposed to high temperature.
Wood Wood will dry out when used in the microwave oven
and may split or crack.
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity. Your oven comes with the
following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
F
G
C B
E
D
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
A
Smart Sensor Cook
Potato
Reheat
Popcorn
Kitchen
Timer
Power
Level
Cook
Time
1 lb
Defrost
Express Cook
Auto
Defrost
Memory Clock
Auto
Cook
Soften/
Melt
Vegetable
Frozen
Pizza
Rice
Frozen
Entrée
10
Turntable Installation
Counter-top Installation
Hub (underside)
Glass tray
Tu
rntable ring assembly
Turntable shaft
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly
must always be used during cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Cabinet: Remove any protective
found
on the microwave oven cabinet surface. Do
not remove the light brown Mica cover that
is attached to the oven cavity to protect the
magnetron.
1. Select a level surface that provide enough
open space for the intake and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is
required between the oven and any adjacent
walls. One side must be open.
(1) Leave a minimum clearance of 12 inches
(30cm) above the oven.
2) Do not remove the legs from the
bottom of the oven.
(3) Blocking the intake and/or outlet openings
can damage the oven.
(4) Place the oven as far away from radios
and TV as possible. Operation of
microwave oven may cause interference
to your radio or TV reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the frequency
is the same as the voltage and the frequency
on the rating label.
WARNING – Do not install oven over
a range cook-top or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and the
warranty would be void.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
11
Smart Sensor Cook
Potato
Reheat
Popcorn
Kitchen
Timer
Power
Level
Cook
Time
1 lb
Defrost
Express Cook
Auto
Defrost
Memory Clock
Auto
Cook
Soften/
Melt
Vegetable
Frozen
Pizza
Rice
Frozen
Entrée
(3)
(4)
(1)(1)
(14)
(2)
(8)
(9)
(10)
(5)
(12)
(13)
(6)
(7)
(11)
(1) Sensor Menu (Frozen Pizza, Potato,
Vegetable, Rice, Frozen Entree, Reheat)
(2) Presets Menu (Auto Cook, Soften/Melt,
Popcorn)
(3) Kitchen Timer
(4) 1lb Defrost
(5) Number Buttons
(6) Power Level
(7) START/+30SEC.
(8) Memory
(9) Clock
(10) Auto Defrost
(11) One Touch Start button(1-6)
(12) Cook time
(13) STOP Cancel : Before cooking starts, press
to clear all previous settings.
During cooking, press once to stop oven;
press twice to stop oven and clear all
settings.
(14) Display Window
12
OPERATION
Level
Power
10
100%
9
90%
8
80%
7
70%
6
60%
5
50%
4
40%
3
30%
2
20%
1
10%
PL10 PL9 PL8 PL7 PL6 PL5 PL4
PL3
PL2
PL1
0 9 8 7 6 5 4 3 1
2
Display
numer button
1. Power Level
Ten power levels are available.
In microwave setting or cooking, press POWER LEVEL and "PL10" flash. Now you can
press the number button to adjust the power level.
2. Clock Setting
When the microwave oven is plugged into a outlet, the oven will display " 0:00 ".
(1) Press CLOCK, LED will display 00:00, will be lighted. The first figure
will flash; ":" and other "0" will be lighted.
(2) Press the number pads and enter the correct time. For example, time is 10:12 now,
please press "1, 0, 1, 2" in turn.
(3) Press CLOCK to finish clock setting, will go out. ":" will flash
and the clock will be lighted.
Note:
1. lf the numbers input are not within the range of 1:00--12:59, the setting will be
invalid until valid numbers are input.
2. In the process of clock setting, if the STOP/Cancel is pressed or if there is no
operation within 1 minute, the oven will go back to the former state automatically.
3. Kitchen Timer
(1) Press KITCHEN TIMER, LED will display 00:00, will be lighted.
(2) Press the number pads and enter the correct timer.(The maximum time is 99 minutes
and 99 seconds). will flash.
(3) Press START/+30SEC. to confirm setting, will flash and will go out.
Timer counts down.
(4) When the time elapses, will go out, the oven will beep 5 times.
If the clock has been set (12-hour system), LED will display the current time.
Note:
1. The kitchen timer setting is different from the clock setting. Kitchen Timer is a timer.
2. During the Kitchen Timer function, any program cannot be set. Time cannot be
increased by pressing START/+30SEC.
3. Press STOP/Cancel can cancel the timer.
Clock
Clock
Timer
Timer
Timer
Start
Start
13
4. Microwave cook
(1) Press COOK TIME, LED will display "00:00", will be lighted.
(2) Press number keys to enter the cooking time; the maximum cooking time is 99
minutes and 99 seconds, will flash.
(3) Press POWER LEVEL, LED will display "PL10". The default power is 100%
power. Now you can press number keys to adjust the power level.
(4) Press START/+30SEC. to start cooking. will flash and will go out.
Example: to cook the food with 50% microwave power for 15 minutes.
a. Press COOK TIME ,"00:00" displays.
b. Press "1","5","0","0" in order to enter the cooking time.
c. Press POWER LEVEL, then press "5" to select 50% microwave power.
d. Press START/+30SEC. to start cooking.
Note:
During the microwave setting, if the STOP/Cancel button is pressed or no operation
within 1 minute, the oven will go out to the setting state.
5. One Touch Start
(1) In waiting state, instant cooking at 100% power level can be started by select a cooking
time from 1 to 6 minutes by pressing number pads 1 to 6. Press START/+30SEC. to
increase the cooking time up to 99 minutes and 99 seconds.
(2) In waiting state, instant cooking at 100% power level with 30 seconds' cooking time can
be started by pressing START/+30SEC. . Each press on the same button will increase
cooking time by 30 seconds. The maximum cooking time is 99 minutes and 99 seconds.
Note:
1. During microwave cooking, press START/+30SEC. button to increase cooking time by
30 seconds.
2. In the cooking of kitchen timer and weight defrost, time cannot be added.
6. Auto Defrost Function
(1) Press Auto DEFROST , LED will display "dEF1", will be lighted.
Press the same button repeatly, "dEF2", "dEF3", "dEF1" will display in order.
(2) Press number buttons to enter the weight to be defrosted. will be lighted and
will flash. The weight range should be between 0.1-6.0 Lbs.
If the weight input is not within 0.1-6.0 Lbs, the input will be invalid.
(3) Press START/+30SEC. to start defrosting, will flash. and will go out.
And the remaining cooking time will display.
Note:
When half of the defrosting time passes, the oven will beep once to remind you to turn over
the food. Open the door to pause operation. Turn over food, close the door and press
START/+30SEC. to resume defrost cycle. If you do not open door to pause operation, the
oven will continue the defrost cycle without interruption.
dEF1
dEF2
dEF3LED display
Food
Meat Poultry
Fish
Clock
Clock
Start
Start
Start
Start
DEF.
DEF.
Lbs
Lbs
14
7. 1lb Defrost
(1) Press 1lb DEFROST, LED will display "1.0", and will be lighted.
will flash.
(2) Press START/+30SEC. to start defrosting, and go out, will flash.
And the remaining cooking time will display.
8.POPCORN
(1) Press POPCORN repeatedly until the desired weight appears in the display,
and light. will flash.
For example, press " POPCORN " twice, "3.0" displays.
(2) Press START/+30SEC. to cook, and disappear, flashes.
9.Sensor Menu (Frozen Pizza, Potato, Vegetable, Rice, Frozen Entree,
Reheat)
(1) In waiting state, press the sensor menu button, "SC-X" displays, and
light. will flash.
Example 1: if "Rice" is pressed, " SC-5" will display.
(2) Press START/+30SEC. to sensor time, "SC-X" flashes. will go out, When the
cooking start, the remaining time count down, and flash.
Note:
1. When cooking food with sensor menu, you should note below for better effect.
a.The room temperature cannot be over 35 degrees.
b.The weight of food must be more than 110g (4 Oz).
c.The oven cavity, glass tray and utensils must keep dry.
2. During cooking, you should note below.
a. The food can be covered with the lid. But the lid must has vent hole in order to
emanate the steam.
b. If the cooking time does not start to count down, do not open the ovendoor or press
STOP/Cancel. Otherwise, the sensor will make mistakes.
c. When the time will count down, you can open the door to mix the food or replace
the food.
Example 2 : to use the menu of potato.
1)Press POTATO key once, "SC-4" displays.
The max. amount is 4pc and about 6~8 Oz/pc.
2) Press START/+30SEC. to cook, After the cooking time display, food can be turn over.
Once
2 Times
3 Times
1.75 Oz
3.0 Oz
3.5 Oz
1.75
3.0
3.5
Times( Press
POPCORN
)
Weight
Display
Clock
Start
Start
Start
Start
Start
Start
DEF.
DEF.
Lbs
Lbs
Auto
Auto
Auto
Auto
Oz
Oz
SENS.
SENS.
15
Note:
a.Each potato is stabbed 6 finestra with the fork on surface.
b.Place the potato on the edge of glass tray, if more potatoes, please keep them deteched
and the interval of each one is 2.5mm.
Example 3 : Sensor Reheat
1) In waiting states, after putting the food into the oven, press REHEAT and "SC-1"
will display.
2) Press START/+30SEC. to cook.
Note:
1. Food to be avoided in sensor reheating.
a.Bread and other dry food, such as biscuit, cake.
b,Raw or uncooked food.
c.Beverage and frozen food.
2. The oven cannot cook automatically when the temperature of the oven cavity is high
3. The reheat food can be covered with the lid. But the lid must has vent hole in order to
emanate the steam, Sealed utensil is forbidden.
4. The food temperature must be at least 40
o
F (5
o
C), when placing it into the oven for
sensor heat to work correctly.
5. The sensor reheat has different request for different food,
Casseroles- Add 2 to 3 tablespoons of liquid, cover with lid or vented plastic wrap.
Stir when time appears in the display window.
Canned foods-Empty contents into casserole dish or serving bowl, cover dish with lid
or vented plastic wrap. After reheating, let stand for a few minutes.
Plate of food- Arranged food on plate; top with butter, gravy, etc. Cover with lid or
vented plastic wrap. After reheating, let stand for a few minutes.
Example 4 : to use the menu of Vegetable
1) Press Vegetable once, "SC-6" will display, to cook fresh vegetable.
Press Vegetable 2 times, "SC-7" will display, to cook frozen vegetable.
2) Press START/+30SEC. to cook. After the cooking time display, food can be turn over.
Sensor menu chart:
Rice
Frozen En tree
Rehea t
Frozen Pizza
Potato
Vegetable
Rice
Frozen En tree
Frozen Pizza
Potato
Fresh/Froz en
Vegetable
Menu button
Food
Food Code
SC- 2
SC- 4
SC-6/SC- 7
SC- 5
SC- 3
SC- 1
Rehea t
16
10.Auto Cook
a) Press Auto Cook, "CC-1" will display, lights. Keep pressing the same key,
CC-2, CC-3, CC-4, CC-5, CC-1 will display in order.
b) Press numer button to select the different weight or portion. will flash.
c) Press START/+30SEC. to cook, flashes. will go out.
11.Soften/Melt
a) Press Soften/Melt, "S-1" will display. Keep pressing the same key, S-2, S-3...S-7, S-1
will display in order.
b) Press numer button to select the different weight or portion. will flash.
c) Press START/+30SEC. to cook, flash. will go out.
Auto Menu Chart:
MENU BUTTON
FOOD
Weight/portion
Soften/Melt
1*Melt-Butter/Margarine
2*Melt-Chocolate
3*Melt-Cheese
4*Melt-Marshmallows
5*Soften-Butter
6*Soften-Ice cream/Frozen juice
7*Soften-Cream cheese
Auto Cook
1*Auto Cook-Bacon
2*Auto Cook-Frozen roll/Mu ffin-reheat
3*Auto Cook-Beverage
4*Auto Cook-Chicken Pieces
5*Auto Cook-Oatmeal(with milk)
2-6 SLICES
1-6 PIECES
1-2 CUPS
20/40Oz
1-3 STICHS
4/8Oz
8/16Oz
5/10Oz
1-3 S TICH
6/12/16Oz
3/8Oz
0.5-2.0 Lbs
S
Start
Start
Start
Start
Auto
Auto
Auto
17
12. MEMORY FUNCTION
Press MEMORY to choose Memory 1-3 procedure. 1,2,3 will display.
If the memory programme has been set, press START/+30SEC. to start cooking.
Set the memory function:
(1) Single or two stages cooking function can be set.
(2) After finishing the setting, press MEMORY to save the Memory 1-3 and the oven turn
back to the waiting state. If not pressing MEMORY but START/+30SEC., the favorit can
be saved and operated at once.
Example: to set a Memory 2 of cooking food with 80% microwave power for 3 minutes and
20 seconds, follow the steps below:
1) In waiting states, press MEMORY twice, "2" displays.
2) Set the programme:
a. Press COOK TIME, then press the number buttons ,"3","2","0". will be lighted.
b. Press POWER LEVEL, "PL10" flashes.And press "8" to select 80% power, "PL8" displays.
3) Press MEMORY once to save Memory 2 and the oven turn back to the waiting state.
4) To run Memory 2, press MEMORY twice, "2" displays. And press START/+30SEC. to
run the program.
Note:
Auto menu cannot be set as memory cooking.
13. Multi-section cooking
At most 2 sections cooking can be set. In multi-section cooking, if one section is defrosting,
defrosting will be placed in the first section. When the first stage finishes, the buzzer will
sound once and the next stage will begin.
Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave
power for 10 minutes. The cooking steps are as following.
(1) Press COOK TIME, then press, "5","0","0" to enter 5 minutes.
(2) Press POWER LEVEL, "PL10" flashes.
(3) Press number button "8" to set 80% microwave power.
(4) Press COOK TIME , then press "1","0","0","0" to enter 10 minutes.
(5) Press POWER LEVEL, "PL10" flashes.
(6) Then press number button "6" to set 60% microwave power.
(7) Press START/+30SEC. to start cooking.
Note:
Auto menu cannot be set as one of the multi-section.
Clock
18
14. INQUIRING FUNCTION
(1) In cooking state, press CLOCK, the clock will be displayed. After three seconds,
the oven will turn back to the cooking state.
(2) When timer counts down, press CLOCK, the clock will be displayed. After three
seconds, the oven will turn back to the timer state.
(3) In the microwave cooking state, press POWER LEVEL, the current microwave power
will be displayed. After three seconds, the oven will turn back to the cooking state.
15. LOCK FUNCTION FOR CHILDREN
Lock: In waiting state, press STOP/Cancel for 3 seconds, there will be a long "beep"
denoting the entering into the children-lock state, will display .
Unlock: In locked state, press STOP/Cancel for 3 seconds, there will be a long
"beep" denoting that lock is released, the current time or "0:00" will display.
16. COOKING END REMINDING FUNCTION
When the cooking is over, End will display. Press STOP/Cancel or open/close the oven
door to turn back to the waiting state.
Lock
19
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Oven will not start
a. Electrical cord for oven is
not plugged in.
b. Door is open.
c. Wrong operation is set or
not confirmed.
a. Plug into the outlet.
b.Close the door and try again.
c.Press"Start/+30Sec./Confirm"
or check instructions.
Arcing or sparking
a. Materials to be avoided in
microwave oven were used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe
cookware only.
b.Do not operate with oven empty.
c. Clean cavity with wet towel.
Unevenly cooke d
foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Cooking time, power level
is not suitable.
d. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Overcooked foods
Cooking time, power level is
not suitable.
Use correct cooking time,
power level.
Undercooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c.Check to see that
oven ventilation ports are
not restricted.
d. Use correct cooking time,
power level.
Improper defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Use correct cooking time,
power level.
c. Turn or stir food.
MAINTENANCE
20
ONE YEAR LIMITED WARRANTY
This warranty applies to products purchased and used in the U.S and Canada
This is the only express warranty for this product and is in lieu of any other warranty or
condion.
This product is warranted to be free from defects in material and workmanship for a period
of one (1) year from the date of original purchase. This warranty is valid for the original
retail purchaser or gi recipient from the date of inial retail purchase and is not
transferable.
Keep your original sales receipt as proof of purchase is required to make a warranty claim.
IMPORTANT: This warranty does
not cover damages resulng from use not in conformity
with the printed direcons, accident, misuse or abuse, alternaon, the affixing of any
aachments not provided with the product, loss of parts, or subjecng the appliance to any
but the specified voltage. (Read direcons carefully.) This warranty is void if the product is
used for other than single-family household use or subjected to any voltage and waveform
other than as specified on the rang label (e.g., 120V ~ 60 Hz).
damages caused by breach of express or implied warranty. All liability is limited to the
amount of the purchase price. Every implied wa
rranty, including any statutory warranty or
condion of merchantability or fitness for a parcular purpose, is disclaimed except to
the extent prohibited by law, in which case such warranty or condion is limited to the
duraon of this wrien warranty. This warranty gives you specific legal rights. You may
have other legal rights that vary depending on where you live. Some states or provinces do
not allow limitaons on implied warranes or special, incidental, or consequenal damages,
so the foregoing limitaons may not apply to you.
To make a warranty claim or if service is required, please call our CUSTOMER SERVI
CE
NUMBER.
For faster service, please have the model, type, and series numbers ready for the operator
to assist you.
Customer Service Number
In the US
844-918-0509
.
Englewood Markeng LLC excludes all claims for special, incidental, and consequenal
Email: [email protected]
Englewood Marketing LLC
PN:
21
