PLASTERBOARD TROLLEY LARGE SHEET
HANDLING 800KG
MODEL NO: DWC01
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
1. SAFETY
9 Inspect the product before use. DO NOT use if damaged or with missing parts.
8 DO NOT use the product for anything other than its intended use.
8 DO NOT exceed the maximum load capacity.
9 Always distribute the weight evenly on the cart.
9 Use this product on solid at surface.
8 DO NOT use this product if you are feeling tired or are under the inuence of alcohol or drugs.
8 DO NOT wear loose clothing or jewellery whilst using this product.
9 Keep long hair or any loose item away from moving parts.
2. INTRODUCTION
Heavy-duty plasterboard trolley offers a practical solution for transporting a wide range of boards, doors, fences and other large sheet
panels. Open deck makes loading and unloading easy. Heavy-duty wheels with two castors for easy turning and brakes to hold in place
while loading/unloading. 800kg capacity.
3. SPECIFICATION
MODEL NO: DWC01
Capacity: 800kg
Length: 1200mm
Nett Weight: 18.38kg
4. ASSEMBLY
4.1. Place the cart bed upside down on the ground.
4.2. Attach two rigid casters and two swivel casters on the cart bed and tighten using M8x16 bolt,
washer, and lock nut.
4.3. Turn the cart bed over to its normal position.
4.4. Insert the frame on the cart bed and tighten using M8x35 bolt, washer, and lock nut.
Refer to
instructions
DWC01 Issue 1 10/12/2024
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
