Microwave Oven
User manual
ME21D*6500****
2 English
Contents
ContentsContents
Important safety instructions 3
What you need to know about safety instructions 3
Precautions to avoid possible exposure to excessive microwave energy 3
Important safety symbols and precautions 3
California proposition 65 warning 6
Grounding instructions 7
Use of extension cords 7
Critical installation warnings 8
Installation cautions 9
Critical usage warnings 9
Usage cautions 10
Critical cleaning instructions 11
Setting up your new microwave oven 12
Checking the parts 12
Setting up your microwave oven 13
Installing the metal shelf 13
Learning about the control panel 13
Set Time 14
Turn Table (On/Off) 14
Kitchen Timer 14
Child Lock 15
Stop Button 15
Eco Mode 15
+30 sec 15
Cooktop Lamp (High/Low/Off) 15
Vent Fan (4/3/2/1/Off) 15
System Settings 16
Smart control 17
Voice control 17
Auto connectivity 19
Using your microwave oven 20
Microwave 20
Power levels 20
One-stage cooking 20
Multi-stage cooking (maximum of 2 stages) 20
Popcorn 20
Reheat 21
Defrost 21
Sensor Cook 22
Auto Cook 23
Keep Warm 28
Cookware guide 29
Recommended cooking utensils 29
Limited use items 29
Not recommended 29
Testing utensils 29
Cooking guide 30
Cooking techniques 30
General cooking recommendations 31
Guide for cooking eggs in your microwave 31
Guide for cooking vegetables in your microwave 31
Cleaning and maintaining your microwave oven 32
Cleaning the exterior 32
Cleaning under your microwave oven 32
Cleaning the control panel 32
Cleaning the door and door seals 32
Cleaning the interior 32
Cleaning the turntable and roller rings 32
Storing and repairing your microwave oven 33
Replacing the cooktop/night light 33
Replacing the oven light 33
Cleaning the grease lter 34
Replacing the charcoal lter 34
Troubleshooting 35
Check points 35
Information codes 39
Appendix 39
Specications 39
Warranty (USA) 40
Warranty (CANADA) 41
English 3
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions
Congratulations on your new Samsung microwave oven. This manual contains
important information on the installation, use and care of your appliance. Please
take time to read this manual to take full advantage of your microwave oven's
many benets and features.
WHAT YOU NEED TO KNOW
ABOUT SAFETY INSTRUCTIONS
Warnings and Important Safety Instructions in this manual do not cover all
possible conditions and situations that may occur. It is your responsibility to use
common sense, caution, and care when installing, maintaining, and operating your
microwave oven.
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
A. Do not attempt to operate this oven with the door open since open-door
operation can result in harmful exposure to microwave energy. It is important
not to defeat or tamper with the safety interlocks.
B. Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on the sealing surface.
C. Do not operate the oven if it is damaged. It is particularly important that the
oven door close properly and that there is no damage to the:
1. Door (bent),
2. Hinges and latches, (broken or loosened),
3. Door seals and sealing surface.
D. The oven should not be adjusted or repaired by anyone except properly
qualied service personnel.
IMPORTANT SAFETY SYMBOLS
AND PRECAUTIONS
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
CAUTION
To reduce the risk of re, explosion, electric shock, or personal injury when using
your microwave oven, follow these basic safety precautions.
Do NOT attempt.
Unplug the power plug from the wall
socket.
Do NOT disassemble.
Make sure the machine is grounded to
prevent electric shock.
Do NOT touch. Call the service center for help.
Follow directions explicitly. Note
These warning signs are here to prevent injury to you and others. Please follow them explicitly. After
reading this section, keep it in a safe place for future reference.
4 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
1. FCC Notice
FCC STATEMENT:
This equipment generates and uses ISM frequency energy and if not installed and
used properly, that is in strict accordance with the manufacturer's instructions, may
cause interference to radio and television reception. It has been type tested and found
to comply with limits for ISM Equipment pursuant to part 18 of FCC Rules, which are
designed to part 18 of FCC Rules, which are designed to provide residential installation.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following:
• Reorient the receiving antenna of the radio or
television.
• Relocate the Microwave Oven with respect to the
receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so
that the microwave oven and the receiver are on
different branch codes.
The manufacturer is not responsible for any radio of
TV interference caused by unauthorized modication
to this microwave oven. It is the responsibility of the
user to correct such interference.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
English 5
Important safety instructions
SAVE THESE INSTRUCTIONS
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
To satisfy FCC RF exposure requirements, a separation distance of 20 cm or more
should be maintained between the antenna of this device and persons during device
operation. To ensure compliance, operations at closer than this distance is not
recommended.
WARNING : Any changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
2. IC Notice
The term “IC” before the radio certication number only signies that Industry Canada
technical specications were met. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003. For products available
in the US/Canadian markets, only channels 1~11 are available. You cannot select any
other channels.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated so there is at least 8 inches (20 cm)
between the radiator and your body. This device and
its antenna(s) must not be co-located or operated in
conjunction with any other antenna or transmitter.
6 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
10. Do not cover or block any openings on the appliance.
11. Do not tamper with or make any adjustments or repairs to the door.
12. Do not store this appliance outdoors. Do not use this product near water, for
example, near a kitchen sink, in a wet basement, near a swimming pool, or
similar locations.
13. Do not immerse the cord or plug in water.
14. Keep the cord away from heated surfaces. (including the back of the oven).
15. Do not let the cord hang over the edge of a table or counter.
16. When cleaning surfaces of the door and oven that come together when the
door closes, use only mild, nonabrasive soaps, or detergents applied with a
sponge or soft cloth. Unplug the plug before cleaning.
17. To reduce the risk of re in the oven cavity:
a. Do not overcook food. Carefully attend the appliance when paper, plastic,
or other combustible materials are placed inside the oven to facilitate
cooking.
b. Remove wire twist-ties from paper or plastic bags before placing the bags
in the oven.
c. If materials inside the oven ignite, keep the oven door closed, turn the
oven off, and disconnect the power cord, or shut off the power at the fuse
or circuit breaker panel. If the door is opened, the re may spread.
d. Do not use the cavity for storage purposes. Do not leave paper products,
cooking utensils, or food in the cavity when not in use.
18. Liquids, such as water, milk, coffee, or tea can be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not always present. THIS
COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO
THE LIQUID. To reduce the risk of injury:
a. Do not overheat liquid.
b. Stir liquid both before and halfway through heating it.
c. Do not use straight-sided containers with narrow necks.
d. After heating, allow the container to stand in the microwave oven for a
short time before removing the container.
e. Use extreme care when inserting a spoon or other utensil into the
container.
CALIFORNIA PROPOSITION
65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
WARNING
To reduce risk of burns, electric shock, re, personal injury or exposure to
excessive microwave energy:
1. Read all safety instructions before using the appliance.
2. Read and follow the specic Precautions to avoid possible exposure to
excessive microwave energy on page 3.
3. This appliance must be grounded. Connect only to properly grounded outlets.
See Important Grounding instructions on page 7 of this manual.
4. Install or locate this appliance only in accordance with the provided installation
instructions.
5. Some products such as whole eggs and sealed containers (for example, closed
glass jars) can explode if heated rapidly. Never heat them in a microwave oven.
6. Use this appliance only for its intended use as described in the manual.
Do not put corrosive chemicals or vapors in or on this appliance. This type of
oven is specically designed to heat, cook, or dry food. It is not designed for
industrial or laboratory use.
7. As with any appliance, close supervision is necessary when it is used by
children. Keep children away from the door when opening or closing it as they
may bump themselves on the door or catch their ngers in the door.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not
working properly, or if it has been damaged or dropped.
9. This appliance should be repaired or serviced only by qualied service
personnel. Contact the nearest authorized service facility for examination,
repair, or adjustment.
English 7
Important safety instructions
SAVE THESE INSTRUCTIONS
WARNING
Improper use of the grounding plug can result in a risk of electric shock.
• Plug into a grounded, 3 pronged outlet. Do not remove the third (grounding)
prong. Do not use an adaptor or otherwise thwart the safety function of the
grounding plug.
• Consult a qualied electrician or service person if you do not understand
the grounding instructions or if you are not sure if the appliance is properly
grounded.
• We do not recommend using an extension cord with this appliance. If the
power-supply cord is too short, have a qualied electrician or serviceman install
an outlet near the appliance. However, if it is necessary to use an extension
cord, read and follow the 'Use of Extension Cords' section below.
USE OF EXTENSION CORDS
A short power-supply cord is provided to reduce the risk of your becoming
entangled in or tripping over a longer cord. Longer cord sets or extension cords
are available and you can use them if you exercise care. If you use a long cord or
an extension cord:
1. The marked electrical rating of the cord set or extension cord should be at least
as great as the electrical rating of the appliance.
2. The extension cord must be a grounding-type 3-wire cord and it must be
plugged into a 3-slot outlet.
3. The longer cord should be arranged so that it will not drape over the
counter top or tabletop where it can be pulled on by children or tripped over
accidentally. If you use an extension cord, the interior light may icker and the
speed of the blower may vary when the microwave oven is on. Cooking times
may be longer too.
19. Oversized foods or oversized metal utensils should not inserted into the
microwave oven as they may cause a re or risk of electric shock.
20. Do not clean the microwave with a metal scouring pad. A piece of metal could
come off the pad, contact electrical parts, and cause an electric shock.
21. Do not put paper products into the oven when you are operating it in the
toaster mode.
22. Do not store any materials, other than manufacturer's recommended
accessories, in this oven when not in use.
23. Do not cover the racks or any other part of the oven with metal foil.
This will cause the oven to overheat.
CAUTION
1. Clean Ventilating Hoods Frequently - Grease should not be allowed to
accumulate on the hood of the lter.
2. When aming foods under the hood, turn the fan on.
3. Use care when cleaning the vent-hood lter. Corrosive cleaning agents, such as
lye-based oven cleaner, may damage the lter.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for the
electrical current. This appliance is equipped with a cord that includes a grounding
wire and a grounding plug. The plug must be plugged into an outlet that is
properly installed and grounded.
8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
This appliance must be properly grounded. Read and follow the specic
Grounding instructions found in the beginning of this section. Do not ground
the appliance to a gas pipe, plastic water pipe, or telephone line.
• This may result in electric shock, re, an explosion, or problems with the
product.
• Never plug the power cord into a socket that is not grounded correctly
and make sure that it is grounded in accordance with local and national
codes.
Do not cut or remove the third (ground) prong from the power cord under
any circumstances.
The microwave requires a separate branch circuit single grounded outlet of
at least 15 A and max of 20 A.
Do not install this appliance in a humid, oily, or dusty location, or in a
location exposed to direct sunlight or water (rain drops).
• This may result in electric shock or re.
Plug the power plug into the wall socket rmly. Do not use a damaged
power plug, damaged power cord, or loose wall socket.
• This may result in electric shock or re.
Do not mount over a sink.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the
power cord, insert the power cord between objects, or push the power cord
into the space behind the appliance.
• This may result in electric shock or re.
Do not pull the power cord when you unplug the oven.
• Unplug the oven by pulling the plug only.
• Failing to do so may result in electric shock or re.
If the power plug or power cord is damaged, contact your nearest service
center for a replacement or repair.
CRITICAL INSTALLATION
WARNINGS
This appliance must be installed by a qualied technician or service
company.
• Failing to have a qualied technician install the oven may result in
electric shock, re, an explosion, problems with the product, or injury.
Unpack the oven, remove all packaging material and examine the oven for
any damage such as dents on the interior or exterior of the oven, broken
door latches, cracks in the door, or a door that is not lined up correctly.
If there is any damage, do not operate the oven and notify your dealer
immediately.
Make sure to install your oven in a location with adequate space.
Remove all foreign substances such as dust or water from the power plug
terminals and contact points using a dry cloth on a regular basis.
• Unplug the power plug and clean it with a dry cloth.
• Failing to do so may result in electric shock or re.
Plug the power cord into a properly grounded 3 pronged outlet. Your oven
should be the only appliance connected to this circuit.
• Sharing a wall socket with other appliances, using a power strip, or
extending the power cord may result in electric shock or re.
• Do not use an electric transformer. It may result in electric shock or re.
• Ensure that the voltage, frequency and current provided match the
product's specications. Failing to do so may result in electric shock or
re.
Keep all packaging materials out of the reach of children. Children may use
them for play.
English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
In the event of a grease re on the surface units below the microwave oven,
smother the aming pan on the surface unit by covering the pan completely
with a lid, a cookie sheet, or a at tray.
Never leave surface units beneath your microwave oven unattended at high
heat settings. Boil overs cause smoking and greasy spillovers that may ignite
and spread if the vent fan is operating. To minimize automatic fan operation,
use adequate sized cookware and use high heat on surface units only when
necessary.
If materials inside the microwave oven should ignite, keep the oven door
closed, turn the oven off and disconnect the power cord, or shut off power at
the fuse or circuit breaker panel. If the door is opened, the re may spread.
Use of inadequately sized cookware on top of the stove may result in
melting of microwave door or other damage.
• Always observe safety precautions when using your microwave oven.
Never try to repair the oven on your own. There is dangerous voltage
inside. If the oven needs to be repaired, contact an authorized service
center near you.
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Because a high voltage current enters the product chassis during
operation, opening the chassis can result in electric shock or re.
• You may be exposed to electromagnetic waves.
• If your microwave oven requires repair, contact your nearest Samsung
service center.
If any foreign substance such as water enters the microwave, unplug it, and
then contact your nearest service center.
• Failing to do so may result in electric shock or re.
INSTALLATION CAUTIONS
Position the oven so that the plug is easily accessible.
• Failing to do so may result in electric shock or re due to electric leakage.
Unplug the oven when it is not being used for long periods of time or during
a thunder/lightning storm.
• Failing to do so may result in electric shock or re.
CRITICAL USAGE WARNINGS
If the microwave appliance is ooded, please contact your nearest Samsung
service center. Failing to do so may result in electric shock or re.
Read and follow the specic 'Precautions to Avoid Possible Exposure
to Excessive Microwave Energy', found in the beginning of this Safety
Information Section.
If the microwave generates a strange noise, a burning smell or smoke,
unplug it immediately and contact your nearest Samsung service center.
• Failing to do so may result in electric shock or re.
In the event of a gas leak (propane gas, LP gas, etc.), ventilate the room
immediately. Do not touch the microwave, power cord, or plug.
• Do not use a ventilating fan.
• A spark may result in an explosion or re.
Take care that the door or any of the other parts do not come into contact
with your body while the microwave is cooking or just after cooking.
• Failing to do so may result in burns.
10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
USAGE CAUTIONS
If the surface of the microwave is cracked, turn it off.
• Failing to do so may result in electric shock.
Dishes and containers can become hot. Handle with care.
Hot foods and steam can cause burns. Carefully remove container coverings,
directing steam away from your hands and face.
Remove lids from baby food before heating. After heating baby food, stir
well to distribute the heat evenly. Always test the temperature by tasting
before feeding the baby. The glass jar or surface of the food may appear to
be cooler than the food in the interior, which can be so hot that it will burn
the infant's mouth.
Make sure all cookware used in your microwave oven is suitable for
microwaving.
Use microwavable cookware in strict compliance with such manufacturer's
recommendations.
Do not stand on top of the microwave or place objects (such as laundry, oven
covers, lighted candles, lighted cigarettes, dishes, chemicals, metal objects,
etc.) on the appliance.
• Items, such as a cloth, may get caught in the door.
• This may result in electric shock, re, problems with the product, or
injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the
appliance.
• As well as being harmful to humans, it may also result in electric shock,
re or problems with the product.
Do not place the appliance over a fragile object such as a sink or glass
object.
• This may result in damage to the sink or glass object.
Do not touch the power plug with wet hands.
• This may result in electric shock.
Do not turn the appliance off by unplugging the power plug while the
appliance is in operation.
• Plugging the power plug into the wall socket again may cause a spark and
result in electric shock or re.
Keep all packaging materials well out of the reach of children. Packaging
materials can be dangerous to children.
• If a child places a bag over its head, the child can suffocate.
Do not let children or any person with reduced physical, sensory or mental
capabilities use this appliance unsupervised. Make sure that the appliance is
out of the reach of children.
• Failing to do so may result in electric shock, burns, or injury.
Do not touch the inside of the appliance immediately after cooking. The
inside of the appliance will be hot.
• The heat on the inside of your microwave oven can cause burns.
Do not put aluminum foil (except as specically directed in this manual),
metal objects (such as containers, forks, etc.), or containers with golden or
silver rims into the microwave.
• These objects can cause sparks or a re.
Do not use or place ammable sprays or objects near the microwave oven.
• Heat from the microwave can cause ammable sprays to explode or burn.
• Failing to do so may result in electric shock or injury.
Do not tamper with or make any adjustments or repairs to the door. Under
no circumstances should you remove the outer cabinet.
Do not store or use your microwave oven outdoors.
English 11
Important safety instructions
SAVE THESE INSTRUCTIONS
CRITICAL CLEANING
INSTRUCTIONS
Do not clean the appliance by spraying water directly onto it.
Do not use benzene, thinner, or alcohol to clean the appliance.
• This may result in discoloration, deformation, damage, electric shock, or re.
Before cleaning or performing maintenance, unplug the appliance from the wall
socket. Then, remove food waste from the door and cooking compartment.
• Failing to do so may result in electric shock or re.
Take care not to hurt yourself when cleaning the appliance.
(external/internal)
• You may hurt yourself on the sharp edges of the appliance.
Do not clean the appliance with a steam cleaner.
• This may result in corrosion.
Keep the inside of your microwave oven clean. Food particles or spattered oils
stuck to the oven walls or oor can cause paint damage and reduce the efciency
of the oven.
Do not put your face or body close to the appliance while it is cooking or
when opening the door just after cooking.
• Take care that children do not come too close to the appliance.
• Failing to do so may result in children burning themselves.
Do not place food or heavy objects over the door.
• When you open the door, the food or object may fall and this may result
in burns or injury.
Do not abruptly cool the door, the inside of the appliance, or the dish by
pouring water over it during or just after cooking.
• This may result in damage to the appliance. The steam or water spray
may result in burns or injury.
Do not cook without the glass tray in place on the oven oor. Food will not
cook properly without the tray.
Do not defrost frozen beverages in narrow-necked bottles. The containers
can break.
Do not scratch the glass of your microwave oven door with a sharp object.
• This may result in the glass being damaged or broken.
Do not store anything directly on top of the appliance when it is in
operation.
Do not use sealed containers. Remove seals and lids before use. Sealed
containers can explode due to buildup of pressure even after the oven has
been turned off.
12 English
Setting up your new microwave oven
Manuals
(User & Installation)
Templates
(Top & Wall)
NOTE
If you need an accessory marked with an * (asterisk), please contact the Samsung Call Center
using the phone number listed on the last page of this manual or visit our on-line parts web site at
www.samsungparts.com.
Be sure to follow these instructions closely so that your new microwave oven works properly.
Checking the parts
Carefully unpack your microwave oven, and make sure you've received all the parts shown below. If
your microwave oven was damaged during shipping, or if you do not have all the parts, contact the
Samsung Call Center.
(Refer to the WARRANTY AND SERVICE INFORMATION on page 39.)
Microwave oven
* Glass tray * Roller guide ring * Charcoal lter
* Exhaust adaptor * Grease lters (2 ea) * Hardware kit
(Screws & Brackets)
Setting up your new microwave oven
English 13
Setting up your new microwave oven
Learning about the control panel
01 03 05 07 10 12 14 16
02 04 06 08 11 13 15 17
09
01 Cooktop Lamp Button (High/Low/Off)
02 Vent Fan Button (4 Speed & On/Off)
03 Popcorn Button
04 Sensor Cook Button
05 Reheat Button
06 Auto Cook Button
07 Defrost Button
08 Keep Warm Button
09 Number Pad
10 Turntable Button
11 Settings Button
12 OK Button
13 Kitchen Timer
/Clock Setting Button
14 Child Lock Button
15 +30 sec Button
16 Start Button
17 Stop Eco Button
Setting up your microwave oven
damp clothdamp cloth
1. Open the door by pulling the handle on the right
side of the door.
2. Wipe the inside of your microwave oven with a
damp cloth.
indentationindentation
pre-assembled roller ringpre-assembled roller ring
3. Install the pre-assembled ring into the indentation
at the center of the microwave oven.
glass trayglass tray
4. Place the glass tray securely in the center of the
pre-assembled roller ring.
Installing the metal shelf
When you need to use the Metal Shelf, place it on the plastic hooks inside your oven and make sure it
is positioned properly to avoid electrical arcing that can damage your oven.
CAUTION
Make sure the shelf is positioned properly inside the microwave to prevent damage to the oven from
arcing.
14 English
Setting up your new microwave oven
Setting up your new microwave oven
Set Time
Your microwave oven is equipped with a built-in clock. Set the clock when rst installing your
microwave oven or after a power failure. The time is displayed whenever the microwave oven is not
being used.
2 3
2
1 3
1. Touch and hold the Clock button for 3 seconds.
2. Use the numeric buttons to enter the time and then touch the OK button.
3. For 12 hour display mode, touch Clock button to set AM or PM and then touch OK button.
Turn Table (On/Off)
1
1. Touch the Turntable button to turn it on or off.
NOTE
You can use this feature only on manual cooking mode.
If the turntable does not rotate for an extended period of time, food may burn.
For best cooking results, leave the turntable feature on.
CAUTION
The turntable may become too hot to touch.
Use pot holders to handle the turntable during and after cooking.
Kitchen Timer
Your microwave has a built-in timer function - the Kitchen Timer. Use the Kitchen Timer for timing up
to 99 minutes, 99 seconds.
2
1 5
3
1. Touch the Kitchen Timer button.
2. Use numeric buttons to set the time.
3. Touch the OK button.
4. The display counts down, and then beeps when the time has elapsed.
5. To cancel the timer setting, touch the Stop button.
English 15
Setting up your new microwave oven
Child Lock
The Child Lock function allows you to lock all buttons so that the microwave oven cannot be operated
by children accidentally.
1
Activating / Deactivating
1. If you want to activate or deactivate the child lock function, touch the Child Lock button for 3
seconds. The display will show
when the oven is locked.
Stop Button
The Stop button allows you to clear instructions you have entered. It also allows you to pause your
microwave oven’s cooking cycle, so that you can check the food.
• To pause the oven during cooking, touch the Stop button once.
To restart, touch the Start button.
• To stop cooking, erase instructions, and return the oven display to the time of day, touch the
Stop button twice.
• To clear instructions you have just entered, touch the Stop button once, and then re-enter the
instructions.
• To cancel a timer setting, touch the Stop button once.
Eco Mode
Eco Mode reduces standby power usage. When you touch the Stop Eco button once, the display will
go out and the microwave shifts to a mode which minimizes power usage. To cancel the Eco mode,
touch any button.
+30 sec
This feature offers a convenient way to increase cooking time in manual cooking mode.
1. In standby mode, touching +30 sec button will add 30 seconds of microwave mode.
2. If the oven is in manual cooking mode, touching +30 sec button will add cooking time by
30 seconds.
Cooktop Lamp (High/Low/Off)
Touch the Cooktop Lamp button to turn the cooktop lamp on or off. Touch the button once for high,
twice for low and three times to turn the cooktop lamp off.
Vent Fan (4/3/2/1/Off)
The vent fan removes steam and other vapors that result from cooking on the cooktop below.
Touch the Vent Fan button once for boost fan, twice for high fan, three times for medium fan and four
times for low fan speed. Touch the button ve times to turn the fan off.
NOTE
• The exhaust fan’s speed may decrease when the oven’s cooking function is activated.
• The Vent Fan protects the microwave from excess heat. It automatically turns on if it senses too
much heat. If you have turned the fan on, you may nd that you cannot turn it off. The fan will
automatically turn off when the internal parts are cooled down. It may stay on for 30 minutes or
more after the cooktop and microwave controls are turned off.
16 English
Setting up your new microwave oven
Setting up your new microwave oven
System Settings
You can customize your new microwave oven to suit your preferences.
To customize :
1
2 3 2 3
1. Touch the Settings button.
2. Touch the numeric buttons (1 - 6) to select a function you want to customize and then touch
OK button.
3. Touch number 1 or 2 to change the options and then touch OK button.
Function Description Options
1 Filter Remind
The lter remind function can be turned On
and Off.
1 On
2 Off
2 Weight Unit
Weight option can display in either pounds
or grams.
1 lb
2 g
3 Sounds You can turn the sound On and Off.
1 On
2 Off
4 Remind End Signal
The remind end signal can be turned On and
Off.
1 On
2 Off
5 Use 24-hour format
The clock can display in either the 12 hr or 24
hr time mode.
1 12hr
2 24hr
6 Wi-Fi The Wi-Fi function can be turned On and Off.
1 On
2 Off
NOTE
• If you change your mind while adjusting a setting, touch the Stop button to go back, and then
adjust the setting again.
• If there is a power interruption, you will need to reset these options.
• If the Filter Remind function is On, the microwave will remind you to clean or replace the grease
lter every four months. When it is time to clean or replace the grease lter, the microwave
displays the 'Filter' message to remind you to clean or replace the grease lter. To remove the
message, touch the number 0 when the microwave is in standby mode. If you don`t want to
receive this message, set the Filter Remind function Off in System Settings.
Smart control
To use the microwave oven’s Smart Control, you must download the SmartThings app to a mobile
device.
English 17
Setting up your new microwave oven
Functions operated by the SmartThings app may not work smoothly if communication conditions are
poor or the microwave oven is installed in a place with a weak Wi-Fi signal.
How to connect the microwave oven
1. Download and open the SmartThings app on your smart device.
2. Follow the app’s on-screen instructions to connect your microwave oven.
3. To operate smart control function from the microwave oven, touch and hold OK button for
3 seconds.
4. Once the process is complete, the
icon appears on your microwave oven display and the app
will conrm you are connected.
5. If the connection icon does not turn on, follow the instruction on the app to reconnect.
Microwave Oven remote control using the SmartThings app
Microwave Oven Monitoring Check the status of the microwave oven
Microwave Oven Remote Control Remotely control vent fan speed/cooktop lamp
NOTE
• For safety reasons, you cannot turn on the microwave oven remotely and you must specify the
cooking time to enable remote control.
• Smart Control will not work properly if the Wi-Fi Connection is unstable.
Voice control
To use the microwave oven’s Voice Control function, you need Bixby / Amazon Alexa App /Google
Assistant App on your mobile device.
Bixby
Start conversation with Bixby on SAMSUNG mobile by saying “Hi Bixby” or by pressing the side key.
Function OTR Bixby Command
Turn Off/Stop
• Cancel the microwave
• Turn off the microwave
Check Time
• Check the remaining time of the microwave
• How much time is left on the microwave timer?
Check Status
• Check the microwave status
• Check the status of the microwave
MW Hood Control
• Turn On/Off the microwave hood light
• Trun On/Off hood power of microwave
• Turn On/Off hood fan of microwave
• Set the microwave hood fan speed to boost/high/mid/low
Send Auto Cook
Recipe
• Cook pizza • Cook pizza for 2 • Cook 2 slices of pizza
• Heat pizza • Heat pizza for 2 • Heat 2 slices of pizza
• I want to cook
pizza
• I want to cook pizza
for 2
• I want to cook 2 slices
of pizza
• Can you cook
pizza?
• Can you cook pizza
for 2?
• Can you cook 2 slices
of pizza?
18 English
Setting up your new microwave oven
Setting up your new microwave oven
Amazon Alexa & Google Assistant
Samsung smart home appliances are supported by SmartThings skill in Alexa & action in Google
Assistant.
Installation Guide
Here’s how to link SmartThings account into Amazon Alexa or Google Assistant. SmartThings App and
Alexa App (or Google Assistant App) Should be installed on your phone.
1. Setup the supported devices to SmartThings.
2. After device setup, tap + button on the screen.
3. Tap Voice assistant and link your Samsung account to Amazon Alexa. (or Google Assistant)
Check the devices are visible on Amazon Alexa app. Then account linking is complete. (Check the
devices are visible and set the location(home&room) of devices in Google home app. Then account
linking is complete.)
Function ‘Alexa’ ‘OK Google’
Turn Off/Stop
• Turn off the microwave
• Stop the microwave
• Turn off the microwave
• Stop the microwave
Check Status
• Is the microwave running?
• Is the microwave on?
• Is the microwave running?
• Is the microwave on?
Function ‘Alexa’ ‘OK Google’
MW Hood Control
• Turn On/Off the (hood light, hood
lamp, lamp,light) on microwave
• Turn On/Off the (hood light, hood
lamp)
• Set the microwave (brightness,
light level, lamp level) to [low,
high]
• Turn On/Off the (hood, fan, hood
fan) on microwave[device name]
• Turn On/Off the (hood, hood fan)
• Set the microwave (hood, fan,
hood fan) speed to [low, medium,
high, boost]
• Turn On/Off the microwave (light,
lamp)
• Turn On/Off the (hood light, hood
lamp)
• Set the microwave (brightness,
light level, lamp level) to [low,
high]
• Turn On/Off the (hood, fan, hood
fan) on microwave
• Turn On/Off the (hood, hood fan)
• Set the microwave (hood, fan,
hood fan) speed to [low, medium,
high, boost]
Send Auto Cook
Recipe
• Cook pizza • Cook pizza for 2 • Cook 2 slices of pizza
• Heat pizza • Heat pizza for 2 • Heat 2 slices of pizza
• I want to cook pizza • I want to cook pizza
for 2
• I want to cook
2 slices of pizza
• Can you cook pizza? • Can you cook pizza
for 2?
• Can you cook 2 slices
of pizza?
NOTE
• For safety reasons, you cannot turn on the microwave oven remotely.
• Below table is available menu for Send Auto Cook Recipe function.
English 19
Setting up your new microwave oven
Food Amount Instructions
Popcorn
3.0 oz
Cook only one microwave popcorn bag at a time. Be careful when
removing the heated bag from the oven and opening it.
3.5 oz
Potatoes
2 potatoes
Pierce each potato several times with a fork. Place on the
turntable in a spoke-like fashion. After cooking, let the potatoes
stand for 3 - 5 minutes.
4 potatoes
Pizza
2 slices
Place pizza slices on a microwave-safe plate with the wide ends
of the slices towards the outside edge of the plate. Do not let the
slices overlap. Do not cover.
4 slices
Spinach
2 servings
Wash and clean the spinach. Place the spinach in a microwave
safe bowl. Add 1 - 4 tablespoons of water (1 Tbsp per serving).
Cover during cooking and stir afterwards.
4 servings
Brown Rice
1 serving
Place 0.5 cups brown rice + 1 cup water for 2 servings or 1 cup
brown rice + 2 cups water for 4 servings in a microwave safe
bowl. Stir well before and uff with a fork afterwards. Let stand 5
minutes before serving.
2 servings
Fish Fillets
1 serving
Put the fresh llets (cod, pollack, etc.) in a dish, and then cover
with plastic wrap. Place the dish on the center of the turntable.
2 servings
Chicken
Nuggets
1 serving
Place a paper towel on a plate and arrange the frozen nuggets in
a spoke-like fashion on the paper towel. Do not cover. Let stand
for a minute after heating.
NOTE
Refer to the package directions for the serving size and the
amount of food.
2 servings
Food Amount Instructions
French Fries
1 serving
Place two paper towels on a microwave-safe plate and
arrange the frozen french fries on the towels without letting
them overlap. Blot the fries with additional paper towels after
removing from the oven. Let stand for a minute.
NOTE
Refer to the directions on the packaging for the serving size and
the amount of food.
2 servings
Melt Butter
1 stick
Remove the wrapping and cut the butter in half vertically. Place
the butter in a dish and cover with wax paper. Stir well after
nishing and let stand for 1 - 2 minutes.
2 sticks
Soften
Cream
Cheese
1 package
Unwrap the cream cheese and place on a microwave-safe
container. Cut in half vertically. Let stand for 2 minutes.
Auto connectivity
Auto Connectivity function lets you quickly connect the hood via Wi-Fi with a compatible Samsung
cooktop after the hood and cooktop have been paired.
To turn the function on, press the Auto Connectivity button in SmartThings App.
To disconnect the hood and cooktop, press the Auto Connectivity button again. While the hood and
cooktop are connected, the hood fan will automatically turn on when you turn on the cooktop. The
hood fan will also turn off automatically when you turn off the cooktop.
NOTE
Auto connectivity function may not work normally when the temperature is set high.
20 English
Using your microwave oven
Using your microwave ovenUsing your microwave oven
Microwave
Your microwave oven allows you to set two different cooking stages, each with its own time length
and power level. The power level lets you control the heating intensity from Warm (1) to High (10).
Power levels
The 10 power levels allow you to choose the optimal power level for your cooking needs.
Power Level Description Power Level Description
1 10 Warm 6 60 Simmer
2 20 Low 7 70 Medium high
3 30 Defrost 8 80 Reheat
4 40 Medium low 9 90 Sauté
5 50 Medium 10 100 High
One-stage cooking
412
4
1 3
1. In standby mode, touch the numeric buttons to set a cooking time. You can enter a time from
one second to 99 minutes and 99 seconds.
To select a time greater than 1 minute, enter the seconds too. (For example, to set a cooking
time of 20 minutes, enter 2, 0, 0, 0.) If you do not need to set the power level, just touch the
Start button. The microwave will automatically operate at the High power level.
2. If you want to set the power level to a level other than High, touch the OK button.
3. Touch the numeric buttons that correspond to the power level you want to use.
4. Touch the Start button. If you want to add the cooking time, touch +30 sec button. You can
adjust the cooking time while the microwave oven is operating.
Multi-stage cooking (maximum of 2 stages)
Your oven allows you to set two different cooking stages, each with its own time length and power
level. The power level lets you control the heating intensity from Warm to High.
1. Follow steps 1, 2, and 3 from the One-stage cooking section.
2. Touch the OK button to move to the second stage.
3. Follow steps 1, 2, 3, and 4 from the One-stage cooking section.
Popcorn
You can easily cook popcorn using the Popcorn button. You do not need to set either the cooking time
or the power level.
2 3
1. Put a bag of unpopped popcorn on the tray.
2. Touch the Popcorn button.
3. Touch Start button. The microwave oven will automatically operate by sensing the popcorn
inside. (3 - 3.5 OZ)
English 21
Using your microwave oven
Defrost
To thaw frozen foods, enter the weight of the food, and the microwave automatically sets the
defrosting time, power level, and standing time.
1 32 3
1. Touch the Defrost button.
2. Touch the numeric buttons to directly enter the weight of the food. (0.1 - 6.0 lbs, 100 - 2700 gr.
See below table)
3. Touch OK or Start button.
4. The oven will beep during the defrosting process. Open the oven door, and turn the food over.
If you do not turn the food over when the oven beeps, the microwave will continue until the
end of cooking time.
Food Amount Instructions
1
Roast Beef,
Pork
2.5 - 6.0 lbs.
Start with the food placed fat side down. After each stage,
turn the food over and shield any warm portions with narrow
strips of aluminum foil.
Let stand, covered for 10 - 20 minutes.
2
Steaks,
Chops, Fish
0.5 - 3.0 lbs.
After each stage, rearrange the food. If there are any warm or
thawed portions of food, shield them with narrow, at pieces
of aluminum foil. Remove any pieces of food that are nearly
defrosted. Let stand, covered for 5 - 10 minutes.
3
Ground
Meat
0.5 - 3.0 lbs.
After each stage, remove any pieces of food that are nearly
defrosted. Let stand, covered with foil for 5 - 10 minutes.
Reheat
You can reheat foods easily using the Reheat button. You do not need to set either the cooking time or
the power level.
2 43 4
1. Put the food on the tray.
2. Touch the Reheat button.
3. Select food item by touching numeric buttons (1 - 3).
4. Touch OK or Start button. The microwave oven will automatically operate by sensing the food
inside.
Food Amount Directions
1 Casserole
1 - 4
servings
Cover the plate with a lid or vented plastic wrap.
If the food is not as hot as you would like after using the Sensor Cooking
Reheat function, continue heating using additional time and power. Stir
the food once before serving.
Contents: Casserole, refrigerated foods.
2 Dinner Plate
1 - 4
servings
Use only precooked, refrigerated foods.
Cover the plate with vented plastic wrap or waxed paper tucked under the
plate. If the food is not
as hot as you would like after using the Sensor Cooking Reheat function,
continue heating using
additional time and power.
Contents: 3 - 4 oz. meat, poultry or sh (up to 6 oz. with bone), ½ cup
starch (potatoes, pasta, rice, etc.), ½ cup vegetables (about 3 - 4 oz).
3 Pasta
1 - 4
servings
Cover the plate with a lid or vented plastic wrap.
If the food is not as hot as you would like after using the Sensor Cooking
Reheat function, continue heating using additional time and power. Stir
the food once before serving.
Contents: Pasta - canned spaghetti and ravioli.
22 English
Using your microwave oven
Using your microwave oven
Sensor Cook
The Sensor Cook buttons lets you cook favorite foods using preset power levels and times. If the food
is not thoroughly cooked after using Sensor Cook feature, complete the cooking process by cooking
the food for an additional amount of time.
2
53 4 3 5
1. Put the food on the tray.
2. Touch the Sensor Cook button.
3. Select category of food by touching numeric buttons (1 - 4) and then touch OK button.
4. Select food item by touching numeric buttons if needed.
5. Touch OK or Start button. The microwave oven will automatically operate by sensing the food
inside.
Category Food Amount Instructions
1 Potato -
1 - 6
potatoes.
Pierce each potato several times with a fork. Place on the
turntable in a spoke-like fashion. After cooking, let the
potatoes stand for 3 - 5 minutes. Let the microwave oven
cool for at least 5 minutes before using it again.
2 Pizza -
1 - 4 slices
Place 1 - 4 pizza slices on a microwave-safe plate with
the wide ends of the slices towards the outside edge of
the plate.
Do not let the slices overlap. Do not cover. Let the
microwave oven cool for at least 5 minutes before using
it again.
Food Amount Instructions
4
Whole
Chicken
2.5 - 6.0 lbs.
Before freezing the poultry, remove the giblets. When you
defrost the poultry, start defrosting with the breast side down.
After the rst stage, turn the chicken over and shield any warm
portions with narrow strips of aluminum foil. After the second
stage, again shield any warm portions with narrow strips of
aluminum foil. Let stand, covered for 30 - 60 minutes in the
refrigerator.
5
Chicken
Pieces
0.5 - 3.0 lbs.
After each stage, rearrange or remove any pieces of food that are
nearly defrosted. Let stand for 10 - 20 minutes.
NOTE
Check the food when you hear the oven signal. After the nal stage, small sections may still be icy;
let them stand to continue the thawing process. The food is not defrosted until all ice crystals have
melted. Shielding roasts and pieces of steak using small pieces of foil prevents the edges from being
cooked before the center of the food has defrosted. Use narrow, at, smooth strips of aluminum foil to
cover edges and thinner sections of the food.
English 23
Using your microwave oven
Auto Cook
The Auto Cook button lets you cook favorite foods using preset power levels and times. If the food is
not thoroughly cooked after using Auto Cook feature, complete the cooking process by cooking the
food for an additional amount of time.
2
3 4 6 63 4 5
1. Put the food on the tray.
2. Touch the Auto Cook button.
3. Select the category of food by touching numeric buttons (1 - 5) and then touch OK button.
4. Select food item by touching numeric buttons and then touch OK button.
5. Select the amount of food by touching numeric buttons if needed.
6. Touch OK or Start button to start cooking. The microwave oven will automatically operate by
preprogrammed time.
NOTE
You can operate some of Auto Cook items by voice control also. Check Voice control on page 17 of
this manual.
Category Food Amount Instructions
3 Cook
1 Beverage
1 cup
Use a measuring cup or mug and do not cover. Place the
beverage in the microwave oven. After heating, stir well.
Let the oven cool for at least 5 minutes before using it
again.
2
Chicken
Breasts
8 - 24 oz.
Pierce the chicken breasts 3 times with a knife. Place
the chicken breasts on a microwave safe plate and
cover with vented plastic wrap. Cook to an internal
temperature of 165 °F. Let stand for 5 minutes.
3
Frozen
Breakfast
4 - 8 oz.
Follow the package instructions for covering and letting
stand. Use this button for frozen sandwiches, breakfast
entrees, pancakes, wafes, etc. Let the microwave oven
cool for at least 5 minutes before using it again.
4
Frozen
Dinner
12 - 16 oz.
Remove the food from its wrapping and follow the
instructions on the box for covering and letting stand. Let
the microwave oven cool for at least 5 minutes before
using it again.
4 Veggies
1
Fresh
Vegetables
1 - 4 cups
Place the fresh vegetables in a microwave-safe ceramic,
glass, or plastic dish and add 2 - 4 tbs. of water. Cover
with a lid or vented plastic wrap. Stir before letting stand.
Let the microwave oven cool for at least 5 minutes before
using it again.
2
Frozen
Vegetables
1 - 4
servings
Place the frozen vegetables in a microwave-safe
ceramic, glass, or plastic dish and add 2 - 4 tbs. of water.
Cover with a lid or vented plastic wrap to cook. Stir before
letting stand for 3 - 5 minutes. Let the microwave oven
cool for at least 5 minutes before using it again.
24 English
Using your microwave oven
Using your microwave oven
Category
Food
Amount
Instructions
1
Home
Dessert
4
Brownie
1 serving
Ingredients
Flour 90 g, Butter(Melted) ½ cup,
Sugar 230 g, Egg 2 pcs., Cocoa power 40 g
1. Combine butter, beaten eggs, sugar in bowl.
2. Add a our, cocoa powder and keep stirring.
3. Pour a mixture in greased glass or plastic bowl.
4. Put the bowl in the microwave oven and select the Brownie under
Home Dessert.
5. After cooking, stand for 20 - 30 minutes.
5
Egg Pudding
1 serving
(3 pcs.)
Ingredients
Milk 250 g, Sugar 40 g, Egg 2 pcs.
1. Crack the two eggs into a bowl. Lightly beat the egg with a balloon
whisk. Don’t let the tip of the whisk leave the bottom of the bowl to
avoid creating too much foam.
2. Combine milk, sugar in other bowl.
3. Add the milk to the beaten egg while whisking the mixture.
4. Sieve the egg mixture with a ne mesh strainer. Scrape off the
bottom of the strainer with a spatula. Remove any foam on the
surface with a spoon.
5. Pour the mixture into custard cups.
6. Put the cups in the microwave oven and select the Egg Pudding
under Home Dessert.
7. After cooking, refrigerate and serve.
Category
Food
Amount
Instructions
1
Home
Dessert
1
Walnut Pound
Cake
1 serving
Ingredients
Flour 120 g, Butter 150 g, Black sugar 100 g, Egg
2 pcs., Walnut (Chopped) 50 g,
Baking powder 4 g
1. Combine butter and black sugar in bowl.
2. Add egg and mix well.
3. Add a our, baking powder and keep stirring.
4. Add a walnut and mix well.
5. Pour a mixture in greased glass or plastic bowl.
6. Put the bowl in the microwave oven and select the Walnut Pound
Cake under Home Dessert.
7. After cooking, stand for 2 - 3 minutes.
2
Banana Bread
1 serving
(6 pcs.)
Ingredients
Banana 3 pcs., Pancake mix 120 g, Milk 120 g,
Egg 1 pc., Malt syrup 2 tbsp.
1. Chop the banana.
2. Combine pancake mix, milk, egg, malt syrup in bowl.
3. Add banana and mix well.
4. Pour a mixture in 6 paper cups.
5. Put paper cups in the microwave oven and select the Banana Bread
under Home Dessert.
6. After cooking, stand for 2 - 3 minutes.
3
Sponge Cake
1 serving
Ingredients
Flour 170 g, Butter 50 g, Sugar 150 g,
Egg 3 pcs., Baking powder 10 g
1. Combine butter and sugar in bowl.
2. Add egg and mix well.
3. Add a our, baking powder and keep stirring.
4. Pour a mixture in greased glass or plastic bowl.
5. Put the bowl in the microwave oven and select the Sponge Cake
under Home Dessert.
6. After cooking, stand for 2 - 3 minutes.
English 25
Using your microwave oven
Category
Food
Amount
Instructions
1
Home
Dessert
9
Green Tea
Latte
1 serving
Ingredients
Green tea powder 6 g, Sugar 15 g, Milk 250 g
1. Mix all ingredients in mug.
2. Put the mug in the microwave oven and select the Green Tea Latte
under Home Dessert.
3. After cooking, mix well and serve.
10
Milk Tea
1 serving
Ingredients
Black tea bag 2 pcs., Water 60 g, Milk 125 g
1. Mix the black tea bag and water in mug.
2. Pour milk in other mug.
3. Put the tea mixture in the microwave oven and select the Milk Tea
under Home Dessert.
4. When the beeps, take mug out.
5. Put the milk in the microwave oven and press the Start button.
6. After cooking, mix all well and serve.
Category
Food
Amount
Instructions
1
Home
Dessert
6
Chocolate
Mug Cake
1 serving
Ingredients
Butter 30 g, Sugar 60 g, Egg 1 pc.,
Heavy cream 40 g, Flour 25 g,
Cocoa powder 15 g, Vanilla 1.5 g,
Semi-sweet chocolate chips 50 g
1. Combine the butter, egg and cream together in a mug until well
combined.
2. Add the our, sugar and keep stirring.
3. Add the cocoa, vanilla and stir until just combined.
4. Stir in the chocolate chips.
5. Put the mug in the microwave oven and select the Chocolate Mug
Cake under Home Dessert.
6. After cooking, stand for 2 - 3 minutes.
7
Mug Cake
1 serving
Ingredients
Butter 30 g, Sugar 60 g, Egg 1 pc.,
Flour 50 g, Milk 30 g, Vanilla 6 g,
Almond powder 3 g, Baking powder 1.5 g
1. Combine butter, egg, and milk together in a mug until well combined.
2. Add our, sugar, baking powder, and keep stirring.
3. Add almond powder, vanilla, milk, and stir until just combined.
4. Put the mug in the microwave oven and select the Mug Cake under
Home Dessert.
5. After cooking, stand for 2 - 3 minute
8
Caffe Latte
1 serving
Ingredients
Instant coffee powder 2 g, Water 50 g,
Milk 125 g
1. Mix the coffee powder and water in mug.
2. Pour milk in other mug.
3. Put the coffee mixture in the microwave oven and select the Caffe
Latte under Home Dessert.
4. When the beeps, take mug out.
5. Put the milk in the microwave oven and press the Start button.
6. After cooking, mix all well and serve.
26 English
Using your microwave oven
Using your microwave oven
Category
Food
Amount
Instructions
2 Fit Choice
6
Bone-in
Chicken
Pieces
1 2 servings
Brush the chicken pieces with oil and
seasonings. Arrange chicken pieces in dish with
meatiest portions toward the outside edge of
dish, and then cover with wax paper. Place the
dish on the center of the turntable.
2 4 servings
7
Fresh Fish
Fillets
1 1 serving
Put the llets (cod, pollack, etc.) in a dish, and
then cover with plastic wrap. Place the dish on
the center of the turntable.
2 2 servings
8
Fresh Salmon
Fillets
1 1 serving
Put the salmon llets in a dish, and then cover
with plastic wrap. Place the dish on the center of
the turntable.
2 2 servings
9
Fresh Prawns
1 2 servings
Put the prawns in a dish, and then cover with
plastic wrap. Place the dish on the center of the
turntable.
2 4 servings
3 Kids Meal 1
Chicken
nuggets
(frozen)
1 1 serving
Place a paper towel on a plate and arrange the
nuggets in a spokelike fashion on the paper
towel. Do not cover. Let stand for 1 minute after
heating.
NOTE
Refer to the package directions for the serving
size and the amount of food.
2 2 servings
Category
Food
Amount
Instructions
2 Fit Choice
1
Spinach
1 1 serving
Wash and clean the spinach. Place the spinach in
a microwave safe bowl. Add 1 - 4 tablespoons of
water (1 Tbsp per serving). Cover during cooking
and stir afterwards.
2 2 servings
3 3 servings
4 4 servings
2
Squash
1 1 - 2 lbs.
Slice the squash in half and remove the seeds.
Place the squash cut side down in a microwave
safe dish and cover with the plastic wrap. If
needed, add a ¼ cup of water.
2 2 - 3 lbs.
3
Brown Rice
1 1 serving
Place 0.5 cups brown rice + 1 cup water for
2 servings or 1 cup brown rice + 2 cups water for
4 servings in a microwave safe bowl. Stir well
before and uff with a fork afterwards. Let stand
5 minutes before serving.
2 2 servings
4
Oatmeal
1 1 package
Follow the package directions for the
recommended amount of water needed. Stir well
before and afterwards.
2 2 packages
5
Quinoa
1 1 serving
Follow the package directions for the recom-
mended amount of water needed. When the
microwave beeps, stir well, and then restart the
microwave.
2 2 servings
English 27
Using your microwave oven
Category
Food
Amount
Instructions
4 Snacks
1
Cheese sticks
(frozen)
1
5 - 6 pcs
(1 Srv.)
Place the cheese sticks on a plate in a spoke-like
fashion. Do not cover. Let stand for 1 to 2 minutes
after heating.
2
7 - 10 pcs
(2 Srvs.)
2
Chicken
Wings
1
5 - 6 oz.
(2 Srvs.)
Use precooked, refrigerated chicken wings.
Place the chicken wings around the plate in a
spoke-like fashion and cover with wax paper.
Let stand for 1 to 2 minutes.
2
7 - 8 oz.
(4 Srvs.)
3
Nachos
1 1 serving
Place the nachos on a plate without letting them
overlap. Sprinkle cheese evenly over them.
Contents:
2 cups tortilla chips
⅓ cup grated cheese
4
Potato Skins
1 1 cooked potato
Cut the cooked potato into 4 even wedges. Scoop
or cut out the potato esh, leaving about a ¼
in. of skin. Place the skins in a spokelike fashion
around the plate. Sprinkle with bacon, onions
and cheese. Do not cover.
Let stand 1 to 2 minutes.
2
2 cooked
potatoes
Category
Food
Amount
Instructions
3 Kids Meal
2
French fries
(frozen)
1 1 serving
Place two paper towels on a microwave-safe
plate and arrange the French fries on the towels
without letting them overlap. Blot the fries with
additional paper towels after removing from the
oven. Let stand for 1 minute.
NOTE
Refer to the directions on the packaging for the
serving size and the amount of food.
2 2 servings
3
Frozen
sandwiches
(in crisping
sleeve)
9-oz package
size
1 1 sandwich
Place the frozen sandwich in a susceptor crisping
sleeve (which is in the package) and place on a
microwave-safe plate.
Remove from the crisping sleeve. Let stand for 2
minutes after heating.
2 2 sandwiches
4
Hot dogs
1 2 hot dogs
Pierce the hot dogs and place them on a plate.
When the oven beeps, add the buns and restart
the oven.
Let stand for 1 minute after heating.
NOTE
For the best texture, the buns should be added to
the hot dogs when the oven beeps.
2 4 hot dogs
28 English
Using your microwave oven
Using your microwave oven
Category
Food
Amount
Instructions
5
Soften/
Melt
1
Melt Butter
1 1 stick
Remove the wrapping and cut the butter in half
vertically.
Place the butter in a dish and cover with wax
paper.
Stir well after nishing and let stand for
1 - 2 minutes.
2 2 sticks
2
Melt
Chocolate
1
1 cup chips or
1 square
Place the chocolate chips or squares in a
microwave-safe container.
When the oven beeps, stir the chocolate and
restart the oven.
Stir and let stand for 1 minute.
3
Soften Butter
1
1 stick
(¼ lbs.)
Remove wrapping and cut butter in half
vertically.
Place butter in dish, cover with wax paper.
4
Soften Cream
Cheese
1
1 package
(8 oz.)
Unwrap the cream cheese and place on a
microwave-safe container.
Cut in half vertically. Let stand for 2 minutes.
Keep Warm
You can keep cooked food warm in your microwave oven for up to 99 minutes and 99 seconds.
32
1
1. Touch the Keep Warm button.
2. Enter the warm hold time by touching the numeric buttons. If you don`t set the time, your
oven will maintain the Warm Hold function for 99 minutes and 99 seconds.
3. Touch the Start button.
NOTE
• Keep Warm operates for up to 99 minutes and 99 seconds.
• The Vent Fan protects the microwave from excess heat.
It automatically turns on if it senses the overheating. If you have turned the
fan on, you may nd that you cannot turn it off. The fan will automatically
turn off when the internal parts are cool.
• Food that is cooked covered should also be covered during Keep Warm.
• Pastry items (pies, turnovers, etc.) should be uncovered during Keep Warm.
• Complete meals kept warm on a dinner plate can be covered during Keep Warm.
Below are the amounts of food we recommend you apply the Keep Warm function to by Food Type.
Food Type Recommended Quantity
Liquid 1 - 2 cups
Dry 5 - 10 oz.
English 29
Cookware guide
Cookware guide
To cook food in your microwave oven, microwaves must be able to penetrate the food without being
reected or absorbed by the cookware holding the food.
Consequently, it is important to choose cookware that both allows microwaves to penetrate food and
is microwave-safe.
The following lists contain various types of cookware and indicate if and how the cookware should be
used in a microwave oven.
Recommended cooking utensils
• Glass and glass-ceramic bowls and dishes — Use for heating or cooking.
• Microwavable plastic wrap — Use to cover. Leave a small opening for steam to escape and avoid
placing it directly on the food.
• Wax paper — Use as a cover to prevent spattering.
• Paper towels and napkins — Use for short-term heating and covering. They absorb excess
moisture and prevent spattering. Do not use recycled paper towels, which may contain metal and
can catch re.
• Paper plates and cups — Use for short-term heating at low temperatures. Do not use recycled
paper, which may contain metal and can catch re.
• Thermometers — Use only those labeled 'Microwave Safe' and follow all directions. Check the
food in several places. Conventional thermometers may be used once the food has been removed
from the oven.
Limited use items
• Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas. Using too
much foil can damage your oven, so be careful.
• Ceramic, porcelain, and stoneware — Use these if they are labeled 'Microwave Safe'. If they are
not labeled, test them to make sure they can be used safely. Never use dishes with metallic trim.
• Plastic — Use only if labeled 'Microwave Safe'. Other plastics can melt.
• Straw, wicker, and wood — Use only for short-term heating, as they are ammable.
Not recommended
• Glass jars and bottles — Regular glass is too thin to be used in a microwave and can shatter.
• Paper bags — These are a re hazard, except for popcorn bags that are designed for microwave
use.
• Styrofoam plates and cups — These can melt and leave an unhealthy residue on food.
• Plastic storage and food containers — Containers such as margarine tubs can melt in the
microwave.
Testing utensils
If you are not sure whether a dish is microwave-safe or not, you can perform this test:
1. Fill a 1 cup glass measuring cup with water and
put it inside your oven, next to the dish you want
to test.
2. Set the microwave to 1 minute using the numeric
buttons, and then press the Start button. This will
heat the glass and dish for one minute at High
power.
When the microwave stops, the water should be warm
and the dish you are testing should be cool.
If the dish is warm, then it is absorbing microwave
energy and is not acceptable for use in the microwave.
30 English
Cooking guide
Microwave energy actually penetrates food and is attracted to and absorbed by the water, fat, and
sugar molecules in the food. The microwaves cause the molecules in the food to move rapidly. The
rapid movement of these molecules creates friction and the resulting heat cooks the food.
Cooking techniques
Stirring
Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the
outside of the dish absorbs more energy and heats more quickly, so stir from the outside to the
center. The oven will turn off when you open the door to stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier parts
toward the outside of the turntable where they will receive more microwave energy. To prevent
overcooking, place thin or delicate parts toward the center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to prevent overcooking. Areas that need shielding
include poultry wing-tips, the ends of poultry legs, and the corners of square baking dishes. Use only
small amounts of aluminum foil. Larger amounts can damage your oven.
Turning
Turn foods over midway through cooking to expose all parts to microwave energy. This is especially
important with large items such as roasts.
Cooking guide
Standing
Food cooked in the microwave builds up internal heat and continues to cook for a few minutes
after the oven stops. Let food stand to complete cooking, especially food such as roasts and whole
vegetables. Roasts need this time to complete cooking in the center without overcooking the
outer areas. All liquids, such as soup or hot chocolate, should be shaken or stirred when cooking is
complete. Let liquids stand a moment before serving. When heating baby food, stir well and test the
temperature before serving.
Adding Moisture
Microwave energy is attracted to water molecules. Food that is uneven in moisture content should
be covered or allowed to stand so that the heat disperses evenly. Add a small amount of water to dry
food to help it cook.
Venting
After covering a dish with plastic wrap, vent the plastic wrap by turning back one corner so excess
steam can escape.W
English 31
Cooking guide
General cooking recommendations
• Dense foods, such as potatoes, take longer to heat than lighter foods. Food with a delicate texture
should be heated at a low power level to prevent it from becoming tough.
• Altitude and the type of cookware you are using can affect cooking time. When trying a new
recipe, use the minimum cooking time and check the food occasionally to prevent overcooking.
• Food with a non-porous skin such as potatoes or hot dogs should be pierced to prevent bursting.
• Frying with oil or fat is not recommended. Fat and oil can suddenly boil over and cause severe
burns.
• Some ingredients heat faster than others. For example, the jelly inside a jelly doughnut will be
hotter than the dough. Keep this in mind to avoid burns.
• Home canning in the microwave oven is not recommended because all harmful bacteria may not
be destroyed by the microwave heating process.
• Although microwaves do not heat the cookware, the heat from the food is often transferred to the
cookware. Always use pot holders when removing food from the microwave and instruct children
to do the same.
• Making candy in the microwave is not recommended as candy can heat to very high
temperatures. Keep this in mind to avoid injury.
Guide for cooking eggs in your microwave
• Never cook eggs in the shell and never warm hard-cooked eggs in the shell. They can explode.
• Always pierce whole eggs to keep them from bursting.
• Cook eggs just until set. They become tough if overcooked.
Guide for cooking vegetables in your microwave
• Vegetables should be washed just before cooking. Often, no extra water is needed. If you are
cooking dense vegetables such as cubed potatoes, carrots, or green beans, add about ¼ cup
water.
• Small vegetables (sliced carrots, peas, lima beans, etc.) will cook faster than larger ones.
• Whole vegetables, such as potatoes, acorn squash, or corn on the cob, should be arranged in a
circle on the turntable before cooking. They will cook more evenly if turned over after half the
cooking time.
• Always place vegetables like asparagus and broccoli with the stem ends pointing towards the
edge of the dish and the tips toward the center.
• When cooking cut vegetables, always cover the dish with a lid or vented microwavable plastic
wrap.
• Whole, unpeeled vegetables such as potatoes, squash, eggplant, etc., should have their skin
pricked in several spots before cooking to prevent them from bursting.
• For more even cooking, stir or rearrange whole vegetables halfway through the cooking time.
• Generally, the denser the food, the longer the standing time. (Standing time refers to the time
necessary for dense, large foods and vegetables to nish cooking after they come out of the oven.)
A baked potato can stand on the counter for ve minutes before cooking is completed, while a
dish of peas can be served immediately.
32 English
Cleaning and maintaining your microwave oven
Cleaning the door and door seals
Always ensure that the door seals are clean and that the door closes properly. Take particular care
when cleaning the door seals to ensure that no particles accumulate and prevent the door from
closing correctly. Wash the glass door with very mild soap and water. Be sure to use a soft cloth to
avoid scratching.
NOTE
If steam accumulates inside or outside the oven door, wipe with a soft cloth. Steam can accumulate
when you operate the oven when humidity is high and in no way indicates microwave leakage.
Cleaning the interior
CAUTION
To avoid injury, ensure that the microwave oven has cooled down before cleaning it.
CAUTION
Remove the glass tray from the oven when cleaning the oven or tray. To prevent the tray from
breaking, handle it with care and do not put it in water immediately after cooking. Wash the tray
carefully in warm sudsy water or in the dishwasher.
Cleaning the turntable and roller rings
Clean the roller rings periodically and wash the turntable as required. The turntable can be washed
safely in your dishwasher.
Cleaning and maintaining your microwave oven
Keeping your microwave oven clean improves its performance, wards off unnecessary repairs, and
lengthens its life.
Cleaning the exterior
It's best to clean spills on the outside of your microwave oven as they occur. Use a soft cloth and
warm, soapy water. Rinse and dry.
CAUTION
Do not get water into the vents. Never use abrasive products or chemical solvents such as ammonia
or alcohol as they can damage the appearance of your microwave.
WARNING
Unplug the microwave plug before cleaning.
Cleaning under your microwave oven
Regularly clean grease and dust from the bottom of your microwave using a solution of warm water
and detergent.
Cleaning the control panel
Wipe with a damp cloth and dry thoroughly. Do not use cleaning sprays, large amounts of soap and
water, abrasives, or sharp objects on the panel as it is easily damaged.
English 33
Cleaning and maintaining your microwave oven
Replacing the oven light
When replacing the oven light, make sure that you are wearing gloves to avoid injury from the heat of
the lamp.
1. Unplug the oven or turn off the power at the main
power supply.
2. Open the door.
3. Remove the vent cover mounting screws (2 middle
screws).
4. Slide the vent grille to the left, then pull it straight
out.
5. Remove the charcoal lter, if present.
6. Remove the screw securing the lamp cover.
7. Remove the lamp by pulling it out gently.
8. Replace the lamp with a 50 W halogen lamp.
9. Replace the lamp holder.
10. Replace the vent grille and re-insert the 2 screws.
11. Plug the oven in or turn on the power at the main
power supply. Reset the clock.
Storing and repairing your microwave oven
If you need to store your microwave oven for a short or extended period of time, choose a dust-free,
dry location. Dust and dampness may adversely affect the functionality of the microwave parts.
WARNING
Do not repair, replace, or service any part of your microwave oven yourself. Allow only a qualied
service technician to perform repairs. If the oven is faulty and needs servicing, or you are in doubt
about its condition, unplug the oven from the power outlet and contact your nearest service center.
Do not use the oven if the microwave oven is damaged, in particular, if the door or door seals are
damaged or the door does not close properly. This can be caused by a broken hinge, a worn out seal or
distorted/bent casing.
Do not remove the oven from its casing.
This microwave oven is for home use only and is not intended for commercial use.
Replacing the cooktop/night light
When replacing the cooktop/night light, make sure that you are wearing gloves to avoid injury from
the heat of the lamp.
LampLamp
1. Unplug the oven or turn off the power at the main
power supply.
2. Remove the screw from the light cover and lower
the cover.
3. Disconnect the wire connectors.
4. Remove the screw securing the LED lamp board.
5. Replace the LED lamp board.
NOTE
To purchase a new LED lamp board, visit an authorized Samsung service center or call
1-800-SAMSUNG (726-7864).
34 English
Cleaning and maintaining your microwave oven
Cleaning and maintaining your microwave oven
Replacing the charcoal lter
If your oven is vented to the inside, the charcoal lter should be replaced every
6 to 12 months and more often if necessary. The charcoal lter cannot be cleaned. To order a new
charcoal lter, contact the Samsung Parts at 1-800-627-4368 or your Samsung dealer. You can also
order online at www.samsungparts.com
The lter angleThe lter angle
The lter angleThe lter angle
1. Unplug the oven or turn off the power at the main
power supply.
2. Open the door.
3. Remove the vent grille mounting screws.
4. Slide the vent grille to the left, then pull it straight
out.
5. Push the hook and remove the old lter.
6. Slide a new charcoal lter into place. The lter
should rest at the angle shown.
7. Reinstall the vent grille and 2 screws, and then
close the door. Plug the oven in or turn on the
power at the main power supply. Reset the clock.
Cleaning the grease lter
Your microwave oven has reusable grease lter. The grease lter should be removed and cleaned at
least once a month or as required.
To order a new grease lter, contact Samsung Parts at 1-800-627-4368 or your Samsung dealer. You
can also order online at www.samsungparts.com.
WARNING
To avoid the risk of personal injury or property damage, do not operate the oven hood without the
lter in place.
1. To remove the lter, slide it to the left (or right)
using the tab.
2. Soak the grease lter in hot water and a mild soap.
Rinse well and shake to dry. Brushing the lter
lightly can remove embedded dirt.
WARNING
Do not use ammonia or put the grease lter in the
microwave oven. The aluminum will darken.
3. To re-install the lter, slide it into the frame slot on
the left (or right), and then push it upwards and to
the right (or left) to lock it.
English 35
Troubleshooting
Troubleshooting
Check points
If you encounter a problem with your oven, rst check the tables starting below and try the
recommendations. If a problem persists, or if an information code keeps appearing on the display,
contact a local Samsung service center.
Problem Cause Action
General
The buttons cannot be
pressed properly.
Foreign matter may be caught
between the buttons.
Remove the foreign matter and
try again.
For touch models: Moisture is on
the exterior.
Wipe the moisture from the
exterior.
The Child Lock is activated. Deactivate the Child Lock.
The time is not displayed. Power is not supplied. Make sure power is supplied.
Conrm the microwave is
plugged in. Check your fuses or
circuit breakers.
The Eco (power-saving) function
is set.
Turn off the Eco function.
The oven does not work. Power is not supplied. Make sure power is supplied.
Conrm the microwave is
plugged in. Check your fuses or
circuit breakers.
The door is open. Close the door and try again.
The door open safety
mechanisms are covered by
foreign matter.
Remove the foreign matter and
try again.
The oven stops while in
operation.
The user has opened the door to
turn food over.
After turning over the food,
press the Start button again to
start operation.
Problem Cause Action
The power turns off during
operation.
The oven has been cooking for
an extended period of time.
After the oven has cooked for an
extended period of time, let the
oven cool.
The cooling fan is not working. Listen for the sound of the
cooling fan.
Trying to operate the oven
without food inside.
Put food in the oven.
There is not enough ventilation
space around the oven.
There are intake/exhaust outlets
on the front and rear of the
oven for ventilation. Check the
installation guide and make
sure that the microwave is far
enough away from walls and
cabinets for proper ventilation.
Several appliances or devices
are plugged into the same
outlet.
Unplug all other appliances or
devices from the outlet.
There is no power to the
oven.
Power is not supplied. Make sure power is supplied.
Conrm the microwave is
plugged in. Check your fuses or
circuit breakers.
There is a popping sound
during operation, and the
oven doesn't work.
Cooking food in a sealed
container or using a container
with a a tight lid.
Do not cook food in sealed
containers or in containers with
tight lids. Expanding steam from
the cooking food can cause the
containers to burst or the lids to
pop off.
36 English
Troubleshooting
Troubleshooting
Problem Cause Action
Heating is weak or slow. The oven may not work if too
much food is being cooked or
improper cookware is being
used.
To test the oven, put one cup
of water in a microwave-safe
container, put the container
in the oven, and then run the
microwave for 1-2minutes
to check whether the water is
heated. If the water is heated,
reduce the amount of food and
start the function again. Use a
cooking container with a at
bottom.
The warm function does not
work.
The oven may not work if too
much food is being warmed
or improper cookware is being
used.
To test the oven, put one cup
of water in a microwave-safe
container, put the container
in the oven, and then run the
microwave for 1-2minutes
to check whether the water is
heated. If the water is heated,
reduce the amount of food and
start the function again. Use a
cooking container with a at
bottom.
Problem Cause Action
The oven exterior gets too
hot during operation.
There is not enough ventilation
space around the oven.
There are intake/exhaust outlets
on the front and rear of the
oven for ventilation. Check the
installation guide and make
sure that the microwave is far
enough away from walls and
cabinets for proper ventilation.
Objects are on top of the oven. Remove all objects on the top of
the oven.
The door cannot be opened
properly.
Food residue is stuck between
the door and oven interior.
Clean the oven the door.
The oven does not heat. The oven may not work if too
much food is being cooked or
improper cookware is being
used.
To test the oven, put one cup
of water in a microwave-safe
container, put the container
in the oven, and then run the
microwave for 1-2minutes
to check whether the water is
heated. If the water is heated,
reduce the amount of food and
start the function again. Use a
cooking container with a at
bottom.
English 37
Troubleshooting
Problem Cause Action
There is electricity coming
from the oven.
The power source or power
outlet is not properly grounded.
Make sure the power source
and power outlet are properly
grounded.
There is water dripping. Water or steam may be
generated by the cooking or
defrosting process, depending
on the food. This is not an oven
malfunction.
Let the oven cool and then wipe
with a dry dish towel.
There is steam coming
through a crack in the door.
Water or steam may be
generated by the cooking or
defrosting process, depending
on the food. This is not an oven
malfunction.
Let the oven cool and then wipe
with a dry dish towel.
There is water left in the
oven.
Water or steam may be
generated by the cooking or
defrosting process, depending
on the food. This is not an oven
malfunction.
Let the oven cool and then wipe
with a dry dish towel.
The brightness inside the
oven varies.
Changes in brightness reect
changes in power output. Power
output changes depending on
the functions in use.
Power output changes during
cooking are not malfunctions.
Cooking is nished, but the
cooling fan is still running.
To ventilate the oven, the
cooling fan continues to run for
about 3 minutes after cooking is
complete.
This is not an oven malfunction.
Pressing the Start button
operates the oven.
This happens when the oven is
not operating.
The microwave oven is designed
to start operating when you
press the Start button if it was
not operating.
Problem Cause Action
The thaw function does not
work.
The oven may not work if too
much food is being thawed or
improper cookware is being
used.
To test the oven, put one cup
of water in a microwave-safe
container, put the container
in the oven, and then run the
microwave for 1-2minutes
to check whether the water is
heated. If the water is heated,
reduce the amount of food and
start the function again. Use a
cooking container with a at
bottom.
The interior light is dim or
does not turn on.
The door has been left open for a
long time.
The interior light may
automatically turn off when the
Eco function operates. Close
and reopen the door or press the
Stopbutton.
The interior light is covered by
foreign matter.
Clean the inside of the oven and
check again.
A beeping sound occurs
during cooking.
If the Auto Cook function is
being used, this beeping sound
means it's time to turn over the
food.
After turning over the food,
press the Start button again to
restart operation.
The oven is not level. The oven is installed on an
uneven surface.
Make sure the oven is installed
on at, stable surface.
There are sparks during
cooking.
Metal containers are used
during cooking or thawing.
Do not use metal containers.
When power is connected,
the oven immediately starts
to work.
The door is not properly closed. Close the door and check again.
38 English
Troubleshooting
Troubleshooting
Information codes
If the microwave oven fails to operate, you may see an information code on the display. Check the
table below for the code, and then follow the directions.
Code Description Action
C-10
The GAS sensor is open.
Unplug the power cord of the oven, and then
contact a local Samsung service center.
The GAS sensor is shorted.
C-F0
The microwave has sensed
an internal communications
failure.
Unplug the power cord of the oven, and then
contact a local Samsung service center.
C-F1
Only occurs when
EEPROM Read or Write
is not working.
Unplug the power cord of the
oven, and contact a local SAMSUNG
Customer Care Center.
C-F2
A touch button has
malfunctioned.
Press Stop, and then try the button again.
C-d0
Control buttons are
touched over 10 seconds.
Clean the keys and check if there is water on
the surface around key. If it appears again,
turn off the microwave oven, let it sit for
more than 30 seconds, and then try setting
again. If this code re-appears, call your local
SAMSUNG Customer Care Center.
Problem Cause Action
Turntable
While turning, the turntable
comes out of place or stops
turning.
There is no roller ring, or the
roller ring is not properly in
place.
Install the roller ring properly
and then try again.
The turn table drags while
turning.
The roller ring is not properly in
place, there is too much food,
or the container is too large
and touches the inside of the
microwave.
Install the roller ring properly.
Adjust the amount of food. Do
not use containers that are too
large.
The turn table rattles while
turning and is noisy.
Food residue is stuck to the
bottom of the oven.
Remove any food residue stuck
to the bottom of the oven.
English 39
Appendix
Appendix
Specications
Model ME21D*6500**AA ME21D*6500**AC
Oven Cavity 2.1 cu ft
Controls 10 power level, including Defrost
Timer 99 minutes, 99 seconds
Power Source 120 VAC, 60 Hz
Power Consumption
1700 W Microwave 1500 W Microwave
Microwave Power Output 1000 W 950 W
Cook Top Light LED lamp (2 EA)
Oven Light 50 W halogen lamp
Oven Cavity Dimensions (inches) 22
1
/
8
" (W) x 10
13
/
16
" (H) x 14
7
/
8
" (D)
Outside Dimensions (inches) 29
7
/
8
" (W) x 17
1
/
16
" (H) x 16
1
/
2
" (D)
Shipping Dimensions (inches) 33
3
/
8
" (W) x 20
13
/
16
" (H) x 19
3
/
8
" (D)
Net/Shipping Weight 58.9 lbs. / 65.5 lbs. (26.7 kg / 29.7 kg)
Warranty (USA)
SAMSUNG MICROWAVE OVEN
LIMITED WARRANTY TO ORIGINAL PURCHASER WITH PROOF OF PURCHASE
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA,
INC. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is
warranted by SAMSUNG against manufacturing defects in materials or workmanship for the limited
warranty period, starting on the date of delivery to the original consumer purchaser, of:
One (1) Year Parts and Labor
Ten (10) Years Magnetron Part (Part Only)
This limited warranty is valid only on products purchased and used in the United States that have
been installed, operated, and maintained according to the instructions attached to or furnished with
the product. To receive warranty service, the purchaser must contact SAMSUNG at the address or
phone number provided below for problem determination and service procedures. Warranty service
can only be performed by a SAMSUNG authorized service center. The original dated bill of sale and/or
proof of delivery must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's
authorized service center to receive warranty service.
SAMSUNG will provide in-home service within the contiguous United States during the warranty
period at no charge, subject to availability of SAMSUNG authorized servicers within the customer's
geographic area. If in-home service is not available, SAMSUNG may elect, at its option, to provide
transportation of the product to and from an authorized service center. If the product is located in an
area where service by a SAMSUNG authorized servicer is not available, you may be responsible for a
trip charge or required to bring the product to a SAMSUNG authorized service center for service.
To receive in-home service, product must be unobstructed and accessible to the service agent.
During the applicable warranty period, a product will be repaired, replaced, or the purchase price
refunded, at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing
a product, or replace the product with a new or reconditioned product. Replacement parts and
products are warranted for the remaining portion of the original product's warranty or ninety (90)
days, whichever is longer. All replaced parts and products are the property of SAMSUNG and you
must return them to SAMSUNG.
40 English
Warranty (USA)
Warranty (USA)
This limited warranty covers manufacturing defects in materials or workmanship encountered in
normal household, noncommercial use of this product and shall not cover the following: damage that
occurs in shipment, delivery, installation, and uses for which this product was not intended; damage
caused by unauthorized modication or alteration of the product; product where the original factory
serial numbers have been removed, defaced, changed in any way, or cannot be readily determined;
cosmetic damage including scratches, dents, chips, and other damage to the product's nishes;
damage caused by abuse, misuse, overheating due to overcooking, glass tray or turntable, pest
infestations, accident, re, oods, or other acts of nature or God; damage caused by use of equipment,
utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring
or connectors not supplied or authorized by SAMSUNG; damage caused by incorrect electrical line
current, voltage, uctuations and surges; damage caused by failure to operate and maintain the
product according to instructions; in-home instruction on how to use your product; service to correct
installation not in accordance with electrical or plumbing codes or correction of household electrical
or plumbing (i.e., house wiring, fuses, or water inlet hoses); and reduced magnetron power output
related to normal aging.
The cost of repair or replacement under these excluded circumstances shall be the customer's
responsibility.
Visits by an authorized servicer to explain product functions, maintenance or installation are not
covered by this limited warranty. Please contact SAMSUNG at the number below for assistance with
any of these issues.
Samsung will charge a repair fee for replacing an accessory or repairing cosmetic damage if the
damage to the unit and/or damage to or loss of the accessory was caused by the customer. Items this
covers include:
• Dented, scratched, or broken door, handle, out-panel, or control panel
• Broken or lost tray, guide roller, coupler, lter, or wire rack
Parts that SAMSUNG has determined can be replaced by the user may be sent to the customer for
installation. In SAMSUNG's discretion, an authorized servicer can be dispatched to perform such
installation.
EXCLUSION OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED
BY LAW. Some states do not allow limitations on how long an implied warranty lasts, so the above
limitations or exclusions may not apply to you. This warranty gives you specic rights, and you may
also have other rights, which vary from state to state.
LIMITATION OF REMEDIES
YOUR SOLE AND EXCLUSIVE REMEDY IS PRODUCT REPAIR, PRODUCT REPLACEMENT, OR REFUND
OF THE PURCHASE PRICE AT SAMSUNG'S OPTION, AS PROVIDED IN THIS LIMITED WARRANTY.
SAMSUNG SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES,
INCLUDING BUT NOT LIMITED TO TIME WAY FROM WORK, HOTELS AND/OR RESTAURANT MEALS,
REMODELING EXPENSES, LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER
BENEFITS REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF
SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow
exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions
may not apply to you. This warranty gives you specic rights, and you may also have other rights,
which vary from state to state.
SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or
guarantee given by any other person, rm, or corporation with respect to this product shall be binding
on SAMSUNG.
To obtain warranty service, please contact SAMSUNG at:
Samsung Electronics America, Inc.
85 Challenger Road
Ridgeeld Park, NJ 07660
1-800-SAMSUNG (726-7864) and www.samsung.com/us/support
English 41
Warranty (CANADA)
In-home service will be provided during the warranty labor period subject to availability within the
contiguous United States. In-home service is not available in all areas. To receive in-home service,
the product must be unobstructed and accessible to service personnel. If during in-home service
repair can not be completed, it may be necessary to remove, repair and return the product. If in-home
service is unavailable, SAMSUNG may elect, at our option, to provide for transportation of our choice
to and from a SAMSUNG authorized service center. Otherwise, transportation to and from the
SAMSUNG authorized service center is the responsibility of the purchaser.
This limited warranty covers manufacturing defects in materials and workmanship encountered
in normal, noncommercial use of this product and shall not apply to the following, including, but
not limited to: damage which occurs in shipment; delivery and installation; applications and uses
for which this product was not intended; altered product or serial numbers; cosmetic damage or
exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of products,
equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs,
external wiring or connectors not supplied or authorized by SAMSUNG which damage this product
or result in service problems; incorrect electrical line voltage, uctuations and surges; customer
adjustments and failure to follow operating instructions, cleaning, maintenance and environmental
instructions that are covered and prescribed in the instruction book; problems caused by pest
infestations, and overheating or overcooking by user; glass tray or turntable; reduced magnetron
power output related to normal aging. SAMSUNG does not warrant uninterrupted or error-free
operation of the product.
Warranty (CANADA)
Samsung over-the-range (otr) microwave oven
Limited warranty to original purchaser
This SAMSUNG brand product, as supplied and distributed by Samsung Electronics
Canada, Inc. (SAMSUNG) and delivered new, in the original carton to the original
consumer purchaser, is warranted by SAMSUNG against manufacturing defects in
materials and workmanship for a limited warranty period of:
ONE (1) YEAR PARTS AND LABOR,
FIVE (5) YEARS PARTS WARRANTY FOR MAGNETRON
Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic defect if the
damage to the unit and/or damage to or loss of the accessory was caused by the customer. Items this
stipulation covers include:
• A Dented, Scratched, or Broken Door, Handle, Out-Panel, or Control Panel
• A Broken or missing Tray, Guide Roller, Coupler, Filter, or Wire Rack
User Replaceable Parts may be sent to the customer for unit repair. If necessary, a Service Engineer
can be dispatched to perform service.
This limited warranty begins on the original date of purchase, and is valid only on products purchased
and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG
for problem determination and service procedures. Warranty service can only be performed by a
SAMSUNG authorized service center. The original dated bill of sale must be presented upon request
as proof of purchase to SAMSUNG or SAMSUNG's authorized service center.
SAMSUNG will repair this product or replace it if cannot repair it, at our option and at no charge as
stipulated herein, with new or reconditioned parts or products if found to be defective during the
limited warranty period specied above. All replaced parts and products become the property
of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the
remaining original warranty, or ninety (90) days, whichever is longer.
42 English
Warranty (CANADA)
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND
NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY
AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY
OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT
SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR
PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT,
REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY
KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT
SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING,
PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER
AND PURCHASER'S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE,
MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE
NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER
THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR
EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or
limitation of incidental or consequential damages, so the above limitations or exclusions may not
apply to you. This warranty gives you specic legal rights, and you may also have other rights which
vary from state to state.
To obtain warranty service, please contact SAMSUNG at:
1-800-SAMSUNG (726-7864) or www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
Warranty (CANADA)
MemoMemo
Please be advised that the Samsung warranty does NOT cover service calls to explain product operation, correct improper installation, or perform normal cleaning or maintenance.
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
U.S.A
Consumer Electronics
1-800-SAMSUNG (726-7864) www.samsung.com/us/support
CANADA 1-800-SAMSUNG (726-7864)
www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
Scan the QR code* or visit
www.samsung.com/spsn
to view our helpful
How-to Videos and Live Shows
* Requires reader to be installed on your smartphone
Scan this with your smartphone
ME21D*6500****-00
