ME21K6000AS
2.1 cu. ft. Over-the-Range Microwave
Features
• Smart Multi Sensor Cook
• Ceramic Enamel Interior
• LED Cooktop Lighting
• Simple Clean Filter
• Extra-Large 2.1 cu. ft. Capacity
• 1000 Watts Cooking Power
• 4-Speed/400 CFM Ventilation System
• Cooking Presets
• Eco Mode
• Turntable On/O
• Triple Distribution System
• Charcoal/Grease Vent Filter
• 10 Power Levels
• Two-Stage Programmable Cooking
• Smart & 1-Pound Defrost
• Chrome Rack
• Touch Control
• LED Display
Convenience
• Clock (12hr/24hr) with
Daylight Savings Time Adjustment
• Kitchen Timer
• End Signal
• Interior Light: LED
• Cooktop Lighting (LED):
High/Low/O
• Vent Fan Control: On/O/Delay O
• Turntable Control: On/O
• Child Safety Lock
• Sound On/O
Signature Features
Smart Multi Sensor
Available Color
Stainless Steel
SMART MULTI SENSOR
• Smart Multi Sensor automatically senses the temperature of foods at the rate
of 3 times per sec and controls its heating level and time to make the foods
the desired condition without overcooking.
CERAMIC ENAMEL INTERIOR
• Scratch-resistant and easy-to-clean interior.
• Effortlessly remove grease or oil from surfaces and protect against scratches.
LED DISPLAY
• Striking blue LED display adds clarity and style to your kitchen.
SIMPLE CLEAN FILTER
• Convenient, easy-to-access location is simple to eject with one touch and helps
you remember when to clean the lter.
Ceramic Enamel Interior
Actual color may vary. Design, specications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.
©2013 Samsung Electronics America, Inc. 85 Challenger Road, Ridgeeld Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com. Samsung is a registered trademark of Samsung Electronics Co. Ltd.
Specifications
• Oven Cavity: 2.1 cu. ft.
• Power Output: 1000 W
• Power Consumption: 17000 W/14.5 A
• Power Source: 120 V/60 Hz
• Control Method: Stainless Steel Digital
(Membrane Touch)
• Display: LED
• Cooking Control: 10 Power Levels Including Defrost
• Cooking Timer: Digital, up to 99 Minutes, 99 Seconds
• Microwave Distribution System: Rotating Turntable
+ Stirrer
• Glass Turntable Diameter: 14
3
⁄
16
"
• Chrome Rack (1)
• Vent Fan: 400 CFM
• Vent Fan Control: On/O/Delay O
• Cooktop Lighting: High/Low/O
• LED Interior Light
Warranty
One (1) Year All Parts and Labor
Ten (10) Years Parts on Magnetron
Product Dimensions & Weight (WxHxD)
Cavity Dimensions:
22
1
/
8
" x 14
7
/
8
" x 10
13
/
16
"
Outside Net Dimensions:
29
7
/
8
" x 18
3
/
16
" x 16
15
/
16
"
Weight: 59.2 lbs.
Shipping Dimensions & Weight (WxHxD)
Dimensions:
33
3
/
8
" x 19
7
/
16
" x 20
3
/
4
"
Weight: 65.9 lbs.
Color Model # UPC Code
Stainless Steel ME21K6000AS 887276170077
ME21K6000AS
2.1 cu. ft. Over-the-Range Microwave
Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.
©2011 Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660. Tel: 800-SAMSUNG www.samsung.com. Samsung is a registered trademark of Samsung Electronics Co. Ltd.
· This microwave oven is designed for
adaptation to the following three types of
ventilation:
A. Outside Top Exhaust (Vertical Duct)
B. Recirculating (Non-Vented Ductless)
C. Outside Back Exhaust
(Horizontal Duct)
· The space between the cabinets must be
30” wide and free of obstructions.
· This microwave oven is for installation over
ranges up to 36” wide.
· The Microwave must be level. Use a level
to make sure the cabinet bottom is level.
If the cabinets have a front overhang only,
with no back or side frame, install the
mounting plate down the same distance
as the front overhang depth. This will
keep the microwave level. depth of the
front overhang.
Specifications
· Oven Cavity: 1.8 cu. ft.
· Power Output: 1100 W
· Power Consumption: 1700 W / 14.5 A
· Power Source: 120 V / 60 Hz
· Control Method: Digital (Membrane Touch)
· Display: 1 Line VFD
· Cooking Control: 10 Power Levels including
Defrost and 12 Sensor Cook Options
· Cooking Timer: Digital, up to 99 Minutes, 99
Seconds
· Microwave Distribution System: Rotating Turntable
· Glass Turntable Diameter: 14
3
⁄16"
· Chrome Rack (1)
· Vent Fan: 400 CFM
· Vent Fan Control: On / Off / Delay Off
· Cooktop Lighting: High / Low / Off
Warranty
One (1) Year All Parts and Labor
Ten (10) Years Parts on Magnetron
Product Dimensions + Weight
Cavity Dimensions
(WxHxD) 20
13
⁄16" x 10
13
⁄16" x 14
9
⁄16"
Unit Outside Net Dimensions
(WxHxD) 29
7
⁄8" x 16
15
⁄16" x 17
5
⁄16"
Weight: 51.8 lbs / 23.5 kg
Shipping Dimensions + Weight
Dimensions: (WxHxD) 33
3
⁄8" x 19
7
⁄16" x 20
3
⁄16"
Weight: 61.2 lbs / 27.8 kg
Color Model # UPC Code
Stainless Steel SMH1816S 036725560451
White SMH1816W 036725560444
Black SMH1816B 036725560437
Installing your Microwave
FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE RECOMMEND THAT TWO PEOPLE
INSTALL THIS MICROWAVE OVEN. IMPORTANT: Do not grip or use handle during installation.
NOTE: If your cabinet is metal, use the nylon grommet around the power cord hole to prevent
cutting of the cord.
NOTE: We recommend using ller blocks if the cabinet front hangs below the cabinet
bottom shelf.
IMPORTANT: If ller blocks are not used, case damage may occur from over tightening screws.
NOTE: When mounting the microwave oven, thread power cord through hole in bottom of top
cabinet. Do not pinch cord or lift oven by pulling cord.
16 1/2"
30"
30" min.
SMH1816S
1.8 cu. ft. Over-the-Range Microwave
29
7
⁄
8
"
17
5
⁄
16
"
16
15
⁄16"
16
15
/
16
"
29
7
/
8
"
18
3
/
16
"
FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE RECOMMEND THAT TWO PEOPLE
INSTALL THIS MICROWAVE OVEN. IMPORTANT: Do not grip or use handle during installation.
NOTE: If your cabinet is metal, use the nylon grommet around the power cord hole to prevent
cutting of the cord.
NOTE: We recommend using ller blocks if the cabinet front hangs below the cabinet bottom shelf.
IMPORTANT: If ller blocks are not used, case damage may occur from overtightening screws.
NOTE: When mounting the microwave oven, thread power cord through hole in bottom of top
cabinet. Do not pinch cord or lift oven by pulling cord.
Dimensions
• This microwave oven is designed for
adaptation to the following three types
of ventilation:
A. Outside Top Exhaust (Vertical Duct)
B. Recirculating (Non-Vented Ductless)
C. Outside Back Exhaust (Horizontal Duct)
• The space between the cabinets must be
30" wide and free of obstructions.
• This microwave oven is for installation over
ranges up to 36" wide.
• The microwave must be level. Use a level to
make sure the cabinet bottom is level. If the
cabinets have a front overhang only, with no
back or side frame, install the mounting plate
down the same distance as the front overhang
depth. This will keep the microwave level.
Installing your Microwave
19"
30"
30" min.
Actual color may vary. Design, specications and color availability are subject to change without notice.
Non-metric weights and measurements are approximate.
©2016 Samsung Electronics America, Inc. 85 Challenger Road, Ridgeeld Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com.
Samsung is a registered trademark of Samsung Electronics Co. Ltd.
