WINDSCREEN HANDLING KIT 3PC
MODEL NO: WK1.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this tool.
8 DO NOT use the suction cup if any parts are damaged or missing as this may cause failure and/or personal injury.
9 Before each use, check condition of suction cup. Examine rubber pads for excessive glaze, cuts or roughness. If any component is worn
or damaged replace immediately.
8 DO NOT clean the suction cup with solvents or other harsh chemicals.
9 Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9 Use in a suitable work area. Keep area free from unrelated materials and ensure that there is adequate lighting.
WARNING! Always wear approved eye, face and hand protection when using the suction cup.
9 Remove ill fitting clothing. Remove ties, watches, rings, other loose jewellery and contain and/or tie back long hair.
9 Maintain correct balance and footing. DO NOT over reach, ensure the floor is not slippery, wear non-slip footwear.
9 Keep children and unauthorised persons away from the working area.
9 Ensure workpiece is secure before attaching and using the suction cup.
WARNING! Ensure that the surface to which the suction cup is to be attached is non-pourous, clean, dry and free from oil and grease.
8 DO NOT exceed the maximum pull capacity of the suction cup.
8 DO NOT use the suction cup for any purpose other than that for which it is designed.
8 DO NOT use the suction cup when you are tired or under the influence of alcohol, drugs or intoxicating medication.
9 When not in use, store in a safe, dry, childproof location.
8 DO NOT use any sharp object to loosen the suction cup as it may damage the rubber and prevent the tool from creating suction.
8 DO NOT attempt to attach the suction cup to a person as severe bruising and/or damage to internal organs can occur.
8 DO NOT allow anything to interfere with the free movement of the plunger whilst the suction cup is attached to a surface.
9 Keep fingers clear of suction release tag during use.
8 DO NOT allow anything else to touch the release tab whilst in the process of lifting e.g. other lifting gear or adjacent fixtures and fittings.
WARNING! This is a hand tool and must not be used in conjunction with a crane or any other lifting device.
2. INTRODUCTION
Two glass-reinforced plastic gripper handles with four Ø115mm lever operated suction pads. Powerful suction will handle 60kg of windscreen.
Supplied with ratchet tie down to x screen in position if required.
3. SPECIFICATION
Model No: ..............................WK1
Cup Diameter: ....................... Ø115mm
Maximum Lift Capacity: ..........60kg (Horizontal)
4. OPERATION
WARNING! Ensure that you read, understand and apply
Section 1 safety instructions.
IMPORTANT: The suction cup is designed to work best on
windscreens at a room temperature of 20ºC. Cold
temperatures, humidity and other surface contamination may
reduce the holding capacity of the tool. The tool may not be as
effective on other sheet materials such as plastic and metal.
Moisture and other contaminants will also reduce the slip
resistance of the cup.
4.1. Ensure that the windscreen to be moved is clean, dry
and free from oil and grease.
4.2. Remove the protective cover from the suction cups.
WK1.V2 | Issue 1 08/07/2019
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
4.3. Holding the handle, firmly push the suction cups onto the windscreen and close down the suction levers. The suction cups should now be
firmly attached and ready for use.
NOTE: The suction cup is designed for lifting, carrying and holding objects for a short period of time only. If circumstances cause an
object to be held for longer than expected, the grip must be checked frequently.
4.4. Only release the suction cups when the load has been set down. To release the suction cup from the surface to which it is attached, open
the suction lever, releasing the vacuum. DO NOT use any sharp object to loosen the suction cup as it may damage the rubber and
prevent the tool creating suction.
4.5. Refit the protective cover onto the suction cup and store it in a clean, dry, childproof location.
5. MAINTENANCE
5.1. Check condition of suction cup regularly, if damaged replace using genuine parts only.
5.2. Always keep suction cup clean and free of oil and grease. Clean regularly with a non-aggressive cleaner.
5.3. In order to preserve elasticity, do not expose rubber pads to sunlight over an extended period of time.
WK1.V2 | Issue 1 08/07/2019
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505. Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please log on to www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
