*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.
SAFETY AND INSTRUCTION MANUAL PLEASE READ CAREFULLY
T513003/T513003BLG
VL30
22.2V Cordless
3 in 1 Vacuum Cleaner
2
This box contains:
Instruction Manual
3 in 1 Vacuum Cleaner
Vacuum Cleaner
Battery Pack
AC Adaptor
Filter
Floor Head
2 in 1 Brush and Crevice Tool
Crevice Nozzle
Wall Mounting Kit
1. Charging port
2. Battery Pack
3. Battery release switch
4. Charging Indicator Lights
5. Power ON/OFF Speed Selection button
6. Speed Indicator
7. Dust tank lock button
8. Dust tank
9. Extension Pole release button
10. Extension pole
11. Floor Head Release Button
12. Floor head
13. Brush Roller
14. 2 in 1 Crevice Brush
15. Adaptor
16. Crevice Tool
Specifications:
4
5
3
6
7
9
10
11
13
8
1
16
1514
12
2
Technical Data:
Description: 22.2V Cordless 3 in 1 Vacuum Cleaner
Model: T513003/T513003BLG
Adaptor Input: 100-240V, 50/60Hz 0.4A
Adaptor Output: 27V 0.5A
Battery: 22.2V 2000MaH Li-Ions
Rated Power: 150W
Charging Time: Approx. 4 hours
Run Time: Approx. 35 minutes on the lowest setting
3
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
(Power adapters only)
Never open the power adapter, you risk getting an electric shock.
Only use the power adapter that is supplied with your product.
You must always connect the power adapter to the product before connecting to the mains power
supply.
The power adapter must be used indoors only, and must not be subjected to damp conditions.
The power adapter does not have any user serviceable parts.
If in doubt, consult a qualified electrician who will be pleased to do this for you.
If you need to remove the plug – disconnect it from the mains – and then cut it off of the mains lead
and immediately dispose of it in a safe manner. Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric shock.
WARNING:
Do not attempt to open any part of the power adaptor or plug.
4
Please read these notes carefully BEFORE using your
Tower appliance
Important Safety Information:
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer, its service
agent or a similarly
qualified person.
• DO NOT let the cord
hang over the edge of a
table or counter or let it
come into contact with
any hot surfaces.
• DO NOT place the
appliance near a heat
source.
• •The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those
supplied with this
product.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or the cable.
• Switch off and
unplug before fitting
or removing tools/
attachments, once
charged and before
cleaning.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not play
with the appliance.
• This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction
concerning use of the
appliance in a safe way
and understand the
hazards involved.
• Cleaning and user
maintenance should
not be undertaken
by children without
supervision.
• Take care when any
appliance is used near
pets.
• Not suitable for carpets
with long fibres as the
bristles will damage the
fibres.
5
• Keep the vacuum
cleaner moving over
the carpet surface
at all times to avoid
damaging the carpet
fibres.
• DO NOT use this
product for anything
other than its intended
use.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or
any other liquid.
• This appliance is for
household use only.
• DO NOT use the
appliance outdoors.
• DO NOT handle the
appliance or plug with
wet hands.
• Keep hair, loose
clothing, fingers and all
body parts away from
moving parts.
• DO NOT use to pick up
hazardous or abrasive
liquids (solvents,
corrosive products,
detergents, etc),
flammable liquids such
as alcohol, gasoline or
use in an area where
they might be present.
• DO NOT use the
appliance without the
dust container filter in
place.
• DO NOT pick up
anything that is burning
or smoking such as
cigarettes, matches or
hot ashes.
• DO NOT vacuum any
large, sharp, or broken
objects, such as pieces
of glass.
• DO NOT vacuum water
or any other liquid.
• Use extra care when
cleaning on stairs.
• Use only manufacturer’s
recommended
accessories.
• This product is fitted
with a thermal cut-out,
which will activate if the
motor overheats due
to blocked air inlets. If
the appliance cuts out,
allow it to cool for 1 hour,
then empty the dust
container and clean all
of the filters.
• In the unlikely event
the appliance develops
a fault, stop using
it immediately and
seek advice from the
Customer Support
Team:
+44 (0) 333 220 6066
6
Before First Use:
Read all instructions and safety information carefully before first use. Please retain this information
for future reference.
1. Remove the product from the box.
2. Remove any packaging from the product.
3. Please retain all packaging until you have checked and counted all the parts and the contents
against the parts list.
4. Charge the rechargeable battery
5. Dispose of the packaging in a responsible manner.
Charging the Unit:
1. This unit can be charged directly from the mains using the included mains adaptor.
2. Connect the adaptor’s jack to the unit’s charging port and plug the other end into an active
mains socket, ensuring the socket switch is turned to the ON position.
3. During charging the 3 LED indicators illuminate incrementally until all lights are illuminated.
4. To disconnect the battery from the unit press the battery release switch and slide the battery
up and away from the unit.
5. To replace the battery slide back in to place until there is an audible click.
Turning the Appliance ON/OFF and Speed Selection:
1. Once the appliance is fully charged, press the On/Off/Speed Selection button located on the
handle to turn the unit on. The unit will operate at the low speed setting.
2. Press the ON/OFF/Speed Selection button again while the unit is in operation to select the
turbo speed setting.
3. Press the ON/OFF/Speed Selection button again while operating at the turbo speed setting to
turn the unit off.
Using the Extension Pole:
1. To connect the pole to the vacuum cleaner, push it into the corresponding slot on the main
body of the unit until it locks into place.
2. To remove the extension pole and use the vacuum cleaner as a handheld cleaner, press the
extension pole release button on the main body of the unit and pull the pole away.
Using the Accessories:
This vacuum cleaner comes with a 2 in 1 Brush and Crevice tool and a Crevice Nozzle for vacuuming
corners and cleaning delicate surfaces.
Note: Keep the brush free of fibres, hairs, and other objects that could impede proper functioning.
Always remove these types of objects when the brush picks them up.
7
Connecting an accessory to the extension pole:
Attach the accessory to the end of the extension pole. Ensure the accessory clicks in to place and is
firmly connected before turning on the appliance, to prevent it from falling off whilst in use.
Connecting an accessory to the handheld unit:
Attach the accessory to the slot at the front of the main body of the unit until it clicks into place.
Removing Accessories:
To remove the accessory press the release button on the accessory tool and pull away from the
extension pole or main unit.
Note: Use only on short-haired carpet. It should NOT be used on long-haired carpets as the fibres
will damage the system.
Troubleshooting
Problem Possible Solution
The vacuum will not
work
Ensure the vacuum cleaner is fully charged.
Check that there are no blockages to the dust tank or filter and remove
as necessary.
This appliance is equipped with a motor protective thermo¬stat. If for
some reason it overheats, the thermostat will automatically turn the
suction motor off. Should this occur, allow it to cool for 1 hour, then
empty the dust container and clean all of the filters.
Vacuum will not
pick-up or suction
power is weak
The dust container may be full, or the filter may require cleaning. Empty
the dust container and clean the filter.
There may be blockages in the filter or dust tank. Check for blockages
and clean the filter and dust tank.
Dust is escaping from
the vacuum
The filter may installed incorrectly, or the dust container may be full.
Empty the dust container and reassemble the filter system.
There is a strange
noise coming from
the vacuum.
The airflow may be restricted or blocked. Check for blockages and clean
the filter and pole.
Cleaning & Care
Emptying the Dust Tank:
Hold the unit over a bin and press the dust quick release button. Empty the
contents of the dust tank. Once empty, push the cover back into place until
there is an audible click.
Cleaning the Filter:
1. Press the filter release button to open the filter
housing.
2. Remove the filter from the dust tank.
3. Tap it lightly against a dustbin or sink to remove
particles.
4. Wash the filter regularly to ensure maximum
suction performance. Allow to dry thoroughly before
replacing it into the unit.
Cleaning the Unit Body:
1. Before cleaning the unit body, ensure the unit is disconnected from the mains supply and not
in operation.
2. Use a damp cloth to clean the unit body. Never use any abrasive cleaning materials or solvents,
as these could cause damage to the surface of the unit.
8
WARNING! DO NOT allow any liquids into the unit, as this could cause damage to the electrical
components and cause it to malfunction.
Cleaning floor head brush bar:
Remove fluff, hairs and other dirt from the brush regularly.
Clearing Blockages:
If the dust tank is overfilled, the filter is clogged up, or the vacuum picks up a larger piece of debris,
the vacuum may become clogged.
Should this occur, carry out the following steps to unclog the vacuum:
1. Check the dust tank and empty it if necessary.
2. Check the filter for any debris and rinse it under running water if necessary, as detailed in the
sections above.
3. Detach any attachments from the unit and check for blockages.
Storing the Appliance:
1. Store the appliance in a cool, dry place, preferably inside its original packaging, and out of the
reach of children.
9
Notes
10
Notes
11
Notes
0621.V1
thank you!
We hope you enjoy your appliance for many years
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to
the place of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in this
instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
Tower has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only extended to the maximum available for each particular
product upon registration of the product within 28 days of purchase. If you do not register the
product with us within the 28 day period, your product is guaranteed for 1 year only.
To validate your extended warranty, please visit
www.towerhousewares.co.uk and register with us online.
Please note that length of extended warranty offered is dependent on product type and that each
qualifying product needs to be registered individually in order to extend its warranty past the
standard 1 year.
Extended warranty is only valid with proof of purchase or receipt.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
+44 (0) 333 220 6066
