Page 1 of 13
Instruction Manual
STEAM MOP
Safety instructions
WARNING：Read all safety warnings and all instructions. Failure to follow the warnings and
instructions listed below may result in electric shock, fire and/or serious injury.
Page 2 of 13
Warning: When using electrical appliances, basics safety precautions,
including the following, should always be followed to reduce the risk of
fire, electric shock, personal injury and material damage.
●Read all of this manual carefully before using the appliance.
●The intended use is described in this manual. The use of any accessory
or attachment or the performance of any operation with this appliance
other than those recommended in this instruction manual may present a
risk of personal injury.
●Retain this manual for future reference.
Using your appliance
● Do not direct steam at people, animals, electrical appliances or
electrical outlets.
●Do not expose to rain.
●Do not immerse the appliance in the water.
●Do not leave the appliance unattended .Keep children away from unit
while in use.
●Do not leave the appliance connected to an electrical outlet when not in
use.
●Never pull the power cord to disconnect the appliance from the socket.
Keep the appliance cord away from heat, oil and sharp edges.
●Do not handle steam cleaner with wet hands.
●Do not pull or carry by cord, use cord as a handle, close door on cord,
Page 3 of 13
pull cord around sharp corners or expose cord to heated surfaces.
●Do not use appliance in an enclosed space filled with vapor given off
by oil-base paint thinner, some moth-proofing substances, flammable dust,
or other explosive or toxic vapors.
●do not use on leather, wax polished furniture or floors, synthetic fabrics,
velvet or other delicate, steam-sensitive materials.
●Do not use on any unsealed hard floor surfaces. Additionally, on
surfaces that have been treated with wax or some no-wax floors, the
sheen may be removed by the heat and steam action. It is always
recommended to test an isolated area of the surface to be cleaned before
proceeding. We also recommend that you check the use and care
instructions from the floor manufacturer.
●Never put descaling, aromatic, alcoholic or detergent products into the
steam mop, as this may damage it or make it unsafe for use.
●If the circuit breaker activates while using the steam function,
discontinue product use immediately and contact the customer support
center.(Beware of the risk of electrical shock.)
●The appliance emits very hot steam to sanitize the area of use. This
means that the steam head and cleaning pads get very hot during use.
！Caution: Always wear suitable shoes when using your steam mop
and when changing the accessories on your steam mop. Co not
wear slippers or open-toed footwear.
Page 4 of 13
●The lid may become hot during use.
●Care should be taken when using this appliance. DO NOT touch any
parts which may become hot during use.
●Do not use when micro-fiber cleaning pad not install correct.
Safety of others：
●This appliance can be used by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children
shall not play with this appliance
●The appliance shall not be left unattended while it is connected to the
supply mains.
●The appliance is not to be used if it has been dropped, if there are
visible signs of damage or if it is leaking
●Keep the appliance out of reach of children when it is energized or
cooling down.
Page 5 of 13
SAFETY GUIDELINES-DEFINITIONS
It is important for you to read and understand this manual. The
information it contains relates to protecting YOUR SAFETY and
PREVENTING PROBLEMS. The symbols below are used to help
you recognize this information.
！
DANGER
：
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
！
WARNING
：
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
！
CAUTION
：
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
NOTICE
：
Used without the safety alert symbol indicates a
potentially hazardous situation which, if not avoided, may result in
property damage.
Residual risks：
Additional residual risks may arise when using the tool which may
not be included in the enclosed safety warnings. These risks can
arise from misuse, prolonged use, etc.
Even with the application of the relevant safety regulations and the
implementation of safety devices, certain residual risks can not be
avoided. These include
●Injuries caused by touching any moving parts.
Page 6 of 13
●Injuries caused by touching any hot parts.
●Injuries caused when changing any parts or accessories.
●Injuries caused by prolonged use of the appliance. When using any
appliance for prolonged periods ensure you take regular breaks.
STANDARD FEATURES
A Main Body
B Holder
C Window Squeegee
D Small Scrub Brush
E Medium Scrub Brush
F Accessory Adaptor
G Angle Nozzle
H Grout Cleaning Tool
I Scraping Tool
J Measuring cup
K Microfiber Pad
L Garment Steamer Cloth
M Steam & Detergent head
N Carpet Gilder
Product Components
1 Folding button
2 Handle
3 Cord Holder
4 Steam head swivel
5 Lock Catch
6 Power Cord
7 Power Switch
8 Water Inlet
9 Indicator light
10 Steam Control Knob
11 Water Tank Cap
12 Water Tank Button
13 Water Tank
14 Detergent Tank
15 On/off switch
(for detergent choice)
Page 7 of 13
Function and specification
Function
⚫ Adjustable steam amount；
⚫ folding holder；
⚫ The split-type design；
⚫ removable water tank；
⚫ Steam output time：20 minutes
⚫ With a ready indicator. when the appliance is connected to power supply, turn on the
power switch, the indicate light will change to blue, meaning the mop is ready to emit
the steam.
⚫ the angle of the rotation axis in the cleaner is greater；
⚫ Comprehensive accessories configuration；
Specification
⚫ Rated voltage：220-240V
⚫ Rated frequency： 50Hz
⚫ Output power：1300W (+5%,-10%)
⚫ water tank capacity： 300 ML
⚫ Waterproof level：IPX4
ASSEMBLY
NOTE: Each steam mop is 100% tested in the factory to ensure product performance and safety.
!WARNING: Before attempting any of the following operations, make sure that the appliance is
switched off and unplugged and that the appliance is cold and contains minimal or no water.
Spread handle
● Round the handle along spindle until click to fix handle
● Press Folding Button 1, turn the handle, the handle can become folded state.
Page 8 of 13
Attaching the steam head
● Slide the bottom end of main body into
the steam head M until Mop head Swivel
4 clicks into place
● The steam head M can be removed from the
Main body by pressing the Lock Button
on the Main body
Attaching a cleaning pad
⚫ Because of barb design at the bottom of steam head M, just place
a micro-fiber cleaning pad K to steam head, they can bond hard.
⚫ Place the front of your shoe onto the cleaning pad removal tab
and press down firmly.
Attaching Carpet Gilder
⚫ Press the micro-fiber cleaning pad K with main body to
Carpet gilder N by vertical pressure，until it into place.
⚫ Place the front of your shoe onto the cleaning pad removal tab
and press down firmly, carpet gilder will remove from steam head.
OPERATION
1. Filling the water tank
Method one:
Open the water tank cap 11 by counterclockwise
rotation, fill 300ML water use Measuring cup,
and then clockwise rotation to close water tank cap 11.
Method two：
Remove the water tank from main body, open the
water tank cap 11 by counterclockwise rotation, fill
the water tank from water faucet., and then clockwise
rotation to close water tank cap 11.
Install the water tank 13 to main body until it clicks into place.
2. Open the cap of Detergent Tank 14 and add the detergent into the tank if you need detergent
during cleaning.
3. Plug in the appliance to a grounded outlet.
4. When switch the appliance on, the indicator lights will turn red at the each side of water tank,
it indicate preheating. If the lights does not illuminate, please check the "troubleshooting"
section for more details.
5. It will takes approximately 20 seconds for preheating. Once the steam mop is ready to use, the
water tank will glow blue, the mop will emit the steam automatically.
Page 9 of 13
6. When clean the surface stained with grease or oil etc., you need press On/off switch 15 to
On position, then the detergent will emit together with the steam.
7. When the water tank full fill with water, it can work approximately 20 minutes.
NOTICE：If power off during preheating or after preheating, then power again, the
appliance will repeat above preheating action.
8. Add control volume by turn steam control knob 10
clockwise，and counterclockwise to reduce，User
can adjust steam volume according to different purpose
NOTICE：steam volume control by PCB, It will takes 3 seconds adaptation time
when you adjust steam volume .It is normal phenomenon.
9. When normal cleaning, the steam
head has big rotary angle, can clean
corners and also can clean low space.
USE AS A STEAM CLEANER IN HAND
⚫ Push Lock Catch, take the main body A out of Holder B, and also take out the power cord.
⚫ Install the accessory adaptor at the top of main body A, until it into place.
⚫ Press Lock Button on the main body to remove the accessory adaptor from main body A
⚫ Choose the appropriate accessories (check accessories use list),to align and implant to
accessory adaptor F, then turn clockwise, until it into place.
Page 10 of 13
ACCESSORIES CHAR：
!CAUTION!
Before cleaning any electrical appliance, check and follow appliance manufacture's cleaning
guidelines.
ACCESSORY
REQUIRED
ACCESSORIES THAT
MUST BE CONNECTED
TO THE ACCESSORY
ADAPTOR
SUGGESTD USE
Window Squeegee/Garment
Steaming Tool
Shower glass doors, mirrors, glass,
removing soap scum and grime.
Garment tool for taking wrinkles out
of garments, steaming draperies,
tablecloths, and more.
Small and Medium Scrub
brushes
Oven, microwaves, stove tops,
showers, bathtubs, faucet fixtures,
tile, grout, toys, refrigerators, etc.
Angle Nozzle
Stove tops, around faucet edges,
grout, microwaves , sinks, hard to
reach areas, etc.
Grout cleaning Tool
Cleaning all grout lines, sanded or
non-sanded.
Scraping Tool
Scraping baked on food, grime, and
grease.Removing residue or other
difficult substances from surfaces,
such as stove tops and ovens
Garment Steamer Cloth
For use when steaming garments,
draperies, table cloths,
etc.
Microfiber Pad
For general cleaning of hard floors
and refreshing carpets.
Page 11 of 13
CLEANING AND MAINTENANCE
BE SURE THAT THE UNIT IS DISCONNECTED FROM THE POWER OUTLET WHEN
PERFORMING CLEANING
Drain the remaining water in the tank and clean the tank after every use.
Please use detergent to clean the accessories (Jet Nozzle and Round Brush) when they are dirty
then wash with cleaning water and air dry
How to decalcify the Water Tank interior
To clean calcium deposits that build up inside the Water Tank, add one or two tablespoons of
white vinegar to a full Water Tank close the Water Tank Cap and then shake the contents. DO
NOT TURN THE STEAMER ON.
Cleaning procedure to remove lime scale
If your steam mop begins to produce steam more slowly than usual or stops producing steam , you
may need to remove lime scale. Lime scale can develop over time on the metal parts and greatly
affect mop performance.
It is necessary to remove lime scale on regular basis every 25-50 times you use a full tank of water
or at least once a month, especially in areas with hard water.
The frequency of lime scale removal depends upon the hardness of your tap water and how often
you use the steam mop.
By using cleaning solution
1. Prepare a solution of 1/3 white vinegar and 2/3 tap water and add to the water tank.
2. Secure and position the unit to ensure steam released is aimed away from the floor or
surrounding objects and surface. Plug the unit in , turn the unit ON by pressing the power switch,
and allow the unit to produce steam until the vinegar/water solution is used up.
3. Repeat the above procedure as many times as necessary until a normal steam flow rate is
achieved.
4. Fill the water tank with fresh water and rinse out.
5. Fill the water tank with fresh water, attach to the unit and release steam through the system until
the water tank is empty.
WARNING
Don't leave the steamer unattended during the lime scale removal process and/or while in
use
NOTICE:
Perform a test cleaning on a suitable isolated area after each lime scale removal to ensure that
there is no debris left in the system.
Page 12 of 13
Cleaning blocked steamer accessories
Due to the high mineral content of water in some areas, you may notice that less steam comes out
from the Hand-Held steamer accessories
This may be caused by calcium buildup inside the tip of the nozzle
How to cleaning calcium buildup
We recommend using a spray lubricant. Spray a small burst or two of the lubricant inside the tip of
the Jet Nozzle. After spraying lubricant inside the component, till the steamer with water
according to the directions and run a continuous jet of steam through the affected accessory for
several minutes to remove the deposit once the steam pathway is clear , aim the steamer at a
neutral surface or cleaning cloth to make sure no debris is emitted.
This product contains no serviceable parts. Do not try to repair it yourself. Any servicing that
requires disassembly other than cleaning must be performed by a qualified appliance repair
technician.
ALL servicing should be done by an authorized service representative.
CLEANING MICROFIBER PAD
⚫ Machine washable on "warm" setting. Always use a mild detergent.
⚫ For best care results, lay flat to dry；
⚫ IMPORTANT：Allow the steamer to fully cool down before performing any maintenance or
troubleshooting checks.
⚫ IMPORTANT：Never use bleach or fabric softener when washing the microfiber cleaning
pad.
STORAGE
⚫ After the steamer is used, turn power off and then unplug the power cord.
⚫ Take out the water tank, and empty the residual water in the tank and clean the external
surface with a dry cloth. Until the steam mop cools down, clean appliances.
⚫ Remove the cleaning pad and wash it so that it will be ready for next use.；
⚫ Store product in a protected, dry area. Keep water funnel and measuring cup for future use.；
⚫ Keep out of reach of children.
Page 13 of 13
TROUBLESHOOTING
USE TROUBLESHOOTING GUIDE AS A FIRST STEP TO RESOLVE ANY PROBLEMS
YOU MAY BE EXPERIENCING.
All servicing should be done by an authorized service representative.
!WARNING!:TO REDUCE RISK OF PERSONAL INJURY-UNPLUG STEAMER BEFORE SERVICING AND
ALLOW TO COOL
PROBLEM
POSSIBLE REASON
POSSIBLE SOLUTION
Reduced steam or no steam
Water tank may be empty
Fill water into the water tank
Steam nozzle may be blocked
Clean steam nozzle
There is no power to the unit
Make sure unit is plugged in
Steam control Knob is in MIN.
T Turn steam control knob
clockwise
Blown fuse or breaker
Replace fuse or reset breaker
in home
Unit will not turn on
Power cord not plugged in
Plug cord into a working
circuit
Internal fuse is blown
Contact with customer service
Environment
Meaning of crossed –out wheeled dustbin:
Do not dispose of electrical appliances as unsorted municipal waste,
use separate collection facilities.
Contact you local government for information regarding the
collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can
leak into the groundwater and get into the food chain, damaging your health and well-being.
When replacing old appliances with new ones, the retailer is legally obligated to take back
Your old appliance for disposals at least free of charge.
