Over the past decade, video walls have become an increasingly popular digital signage choice.
That’s because they’re particularly effective at engaging people and delivering messages
efficiently. They offer larger, higher resolution images than a single display, and they can be built
to almost any configuration to fit a specific space or purpose.
Video walls have found homes in many different types of settings, including corporate offices,
retail stores, transportation hubs and sports venues, as well as command and control facilities.
When deciding which type of video wall installation is appropriate for your customers’ needs, a
basic decision is determining which of the two basic types of technologies — LCD or dvLED — is
best for the specific application. LCD and dvLED displays have very different features and benefits.
Liquid Crystal Displays
Liquid crystal display (LCD) panels are manufactured by inserting a layer of liquid crystal — a
substance that is part solid and part liquid — between two sheets of glass. When electricity is
applied to this layer, the crystals shift to create an image. Because the crystals do not produce their
own light, some type of backlighting is needed to display the image. Ironically, LEDs are the most
popular source of backlighting for LCD panels.
LCD panels are bright and provide high-resolution images at a modest cost. They also have
slim depths and are energy efficient. One major disadvantage of an LCD panel, however, is
that it requires a bezel. LCDs have been a popular choice for video walls, but when the panels
are connected to create a video wall, those bezels are visible and break up the overall image.
Although bezel widths continue to narrow, LCD bezels remain a visual distraction for video wall
installations.
Direct View LED
A light emitting diode (LED) is a tiny semiconductor that converts electricity into visible light. In
an LED panel, each color pixel has one red, one blue and one green LED. The combination of these
three colors enables the LED to create trillions of colors. In an LED panel, each LED produces light
itself, unlike an LCD panel, in which the backlight passes through the liquid crystal layer. That’s
where the name “direct view” LED (dvLED) originates.
LED panels have many advantages, including high brightness, superior contrast and viewing
angles, long life, energy efficiency and suitability for both indoor and outdoor applications. LED
panels are the ideal solution for video walls because they don’t have bezels. That means there are
no seams in the middle of the wall to distract viewers.
Choosing the Right Panel
LCD panels have traditionally been the popular choice for video walls, particularly for indoor
applications, and dvLEDs have been the go-to choice for outdoor installations. But due to
advances in LED technology, dvLEDs are now challenging the dominance of LCDs for indoor uses.
Selecting the best video wall solution for a specific indoor installation can be challenging. Here
are some considerations to keep in mind:
• Pixel pitch: Measured in millimeters, Pixel pitch is the distance between the center of
an LED pixel and the center of an adjacent pixel. A screen with a smaller pixel pitch has
more pixels overall and provide higher resolution images than a screen with a larger pixel
pitch. In general, a large screen that will be viewed from afar can have a relatively high
pixel pitch, but a screen that will be viewed from close up should have a small pixel pitch.
•
• Image quality: Look for sharp images and a solution that provides factory color-calibration.
• Brightness: Although more of a concern for outdoor installations, brightness
should still be considered for indoor video walls. Take into account the
ambient lighting conditions of an interior environment to ensure that the
video wall will have sufficient brightness to provide excellent viewability.
• Contrast: A high-efficiency LED chip will ensure deep contract, and black mask will boost
the contrast ratio.
