NEC Direct View LED – Intelligent display solutions for a brighter world
The NEC E Series provides cost conscience customers impressive LED imaging without
compromising on the service and support expected from the Sharp/NEC brand. With 4
popular different pixel pitch options (1.2mm, 1.5mm, 1.8mm, and 2.5mm) the optimum
display resolution can be achieved regardless of viewing distance. The E Series is designed
to deliver the advantages of a seamless dvLED display in a cost effective, accessible package.
Boardrooms, auditoriums, retail, and education are just some of the applications where the
NEC E series is designed to be integrated. NEC offers full planning and design, installation
and post installation maintenance support, ensuring you get a custom tailored solution
allowing you to focus on what’s most important – your business.
Benets
Front Serviceable Design minimizes downtime by providing easy access and quick
maintenance
Modular Design with a 16:9 aspect ratio and a 27” diagonal allows for an accessible
alternative to existing LCD video walls
Hot-Swappable Pixel Cards can be replaced without turning the display off
Thin and lightweight design allow for greater installation flexibility while also meeting
ADA requirements
NEC Direct View LED-E012i
(1.25mm E-Series Indoor)
Direct View LED Module LED-E012i
Display
Panel Technology Direct View LED
Pixel Configuration 3-1 SMD (Black)
Panel Resolution 480 x 270
Aspect Ratio 16:9
Pixel Pitch 1.25mm
Brightness (typical) 600cd/m²
Contrast Ratio (typical) 5000:1
Viewing Angle (typical) 85/85 horizontal / 80/80 vertical
Dimming Capability 256 levels
Color Processing Up to 16 bit
Displayable Colors 281 Trillion
Refresh Rate Up to 3840 Hz
Lifetime 100,000 hours
CONNECTIVITY
Input Terminals Digital 1x 1000BaseT RJ-45
External Control RS232 / USB
POWER CONSUMPTION
On (typical) 59 Watts
Max 125 Watts
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 23.6 x 13.3 x 1.1in / 600 x 337.5 x 29mm
Diagonal 27"
Weight (Net) 10.4lbs / 4.7kg
ENVIRONMENTAL
CONDITIONS
Operating Temperature -4° to 104°F / -20° to 40°C
Operating Humidity 10% to 80%
Storage Temperature -4° to 113°F / -20° to 45°C
Storage Humidity 10% to 85%
IP Rating IP20
LIMITED WARRANTY 2 years
NEC Direct View LED-E012i (1.25mm E Series Indoor) - Technical Specication
Cat.No. 25.NEC.80.GL.UN. | 08.08.2022
©2022 Sharp NEC Display Solutions of America, Inc. | All rights reserved.
All other brand or product names are trademarks or registered trademarks of their respective holders.
