NEC Direct View LED-F038i
(3.8mm F-Series Indoor)
NEC Direct View LED – Intelligent display solutions for a brighter world
The S[quadrat] F-Series by NEC provides crystal clear images for the ultimate visual
experience. With pixel spacing options of 1.2mm, 1.5mm, 1.9mm, 2.3mm, 2.7mm &
3.8mm the optimum display resolution can be achieved regardless of viewing distance;
plus, the front serviceable design allows easy access and quick maintenance when needed.
Designed for vibrant and colorful content visualization, the NEC direct view indoor LED series
is the ideal solution for auditoriums, reception areas, retail stores, control and meeting
BENEFITS
Each LED Panel can be configured with built in data and power redundancy ensuring the
display remains operational in the event of a single controller or power supply fault
Modules are front and rear serviceable allowing placement in difficult to access areas
Pixel cards are upgradable to a finer pixel pitch. A Full HD 3.8mm display can be
upgraded to 4K at a later date without changing the modules or mounting structure
Pixel cards are hot-swappable and can be replaced without turning the display off
Black SMD LED’s provide a smooth surface, low reflectance and high contrast
rooms, museums, broadcast studios and airports or train stations. NEC offers full design &
planning services plus post installation support, ensuring you get a custom tailored solution
allowing you to focus on what’s most important – your business
All rights reserved in favor of their respective owners. All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All specifi cations are
subject to change without notice.
©2018 NEC Display Solutions of America, Inc. and the NEC logo are registered trademarks of NEC.
www.necdisplay.com
Cat.No. 25.NEC.80.GL.UN.239 | 8.15.2018
DISPLAY
Panel Technology Direct View LED
Pixel Con guration 3-1 SMD (Black)
Panel Resolution 160 x 90
Pixel Pitch 3.8mm
Brightness (typical/maximum) 396/1200cd/m2
Display 80,000 hours
Contrast Ratio(typical) 3000:1
Viewing Angle 80/80 horizontal / 80/80 vertical
Dimming Capability 256 levels
Color Processing 18 bit
Displayable Colors 281 Trillion
Refresh Rate(Hz) 3000
Orientation Landscape
Connectivity
Input Terminals
Digital: DVI-D Dual Link in/out or HDMI
External Control: RS232 / USB
External Control USB
PowerConsumption(typical)
On 280Watts/sqm
Max 740Watts/Sqm
Physical Speci cations
Dimensions (W x H x D) [mm] 608 x 342 x 90mm
Weight [kg] 20.9lbs (9.5kg)
Environmental Conditions
Operating Temperature 32° to 104°f / 0° to 40°c
Environmental Conditions 10% to 90%
Storage Temperature 32° to 104°f / 0° to 40°c
Servicability
Front & Rear Service
IP Level
IP30
Accessories
Controller
Mounting Frame
Pixel Card Service tool
Onsite Installation
NEC Direct View LED-F038i (3.8mm F Series Indoor) - Technical Specifi cation
