STACK BRACKET KIT
INSTALLATION INSTRUCTIONS
MODEL NUMBER MSTK1
version A - 5 - 2019
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
•
IMPORTANT
– Save these
instructions for local electrical
inspector’s use.
•
IMPORTANT
– Observe all
governing codes and ordinances.
•
Note to Installer – Be sure to
leave these instructions with the
Consumer.
•
Note to Consumer – Keep these
instructions for future reference.
•
Installation must be performed
by a qualifi ed installer.
•
Proper installation is the
responsibility of the installer.
FOR YOUR SAFETY
WARNING
•
Electric Shock Hazard.
Disconnect power before
installing. Failure to do so could
result in serious injury or death.
•
Potential Personal Injury. It is
recommended that more than
two people lift the dryer into
position because of its weight
and size. Failure to do so could
result in personal injury or
death.
•
Avoid Tipping and Rupture
of Utility Services. DO NOT
place the washer on top of the
dryer. Dryer must be securely
attached to the washer. Failure
to do so could result in death,
or property damage.
•
Mobile Home or Manufactured
Home Installation – Stacking of
a gas dryer is not permitted in a
mobile home or manufactured
home.
MINIMUM CLEARANCE OTHER
THAN ALCOVE OR CLOSET
INSTALLATION
For proper ventilation, minimum
clearance between the dryer
cabinet and adjacent walls or other
surfaces is:
•
0" either side
•
1" rear
Consideration must be given to
provide adequate clearance for
installation and service.
ALCOVE OR CLOSET
INSTALLATION
•
If your dryer is approved for
installation in an alcove or closet,
it will be stated on a label on the
back of the dryer.
•
The dryer MUST be vented to
the outdoors. Refer to Dryer
Installation Instructions for
details.
•
Minimum clearance between
dryer cabinet and adjacent walls
or other surfaces is:
0" either side
3" front and rear
•
Minimum vertical space from
the fl oor to overhead cabinets,
ceiling, etc. is 43" without
pedestal, 55" with pedestal and
84" stacked.
•
Closet doors must be louvered
or otherwise ventilated and must
contain a minimum of 60 square
inches of open area equally
distributed. If the closet contains
both a washer and a dryer, doors
must contain a minimum of
120 square inches of open area
equally distributed.
