SMARTCLEAN
®
USER GUIDE
2229F
More of a video
person? Find
instructional videos
for all sections with
this icon at
www.BISSELL.com/
videos
2
www.BISSELL.com.au
IMPORTANT SAFETY INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
» This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Cleaning
and user maintenance shall not be made by children
without supervision.
» Children should be supervised to ensure that they do
not play with the appliance.
» Unplug from electrical socket when not in use, before
cleaning, maintaining, or servicing the appliance, and
if your appliance has an accessory tool with a moving
brush, before connecting or disconnecting the tool.
» Do not immerse in water or liquid.
» Keep hair, loose clothing, fingers, and all parts of
body away from openings and moving parts of the
appliance and its accessories.
» Do not use to suck up water.
» Do not immerse in water for cleaning.
» The hose should be checked regularly and must not be
used if damaged.
» Always turn OFF this appliance before connecting or
disconnecting either hose or motorised nozzle.
» If the supply cable is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified person in order to avoid a hazard.
» Do not run appliance over cable.
» Do not use with damaged cable or plug.
» Keep cable away from heated surfaces.
» Do not pull or carry by cable, use cable as a handle,
close door on cable, or pull cable around sharp edges
or corners.
» If the appliance has a hand-held accessory like pet
brush, motor driven head, etc., the user shall avoid
entrapment.
» Do not leave appliance when plugged in.
» To unplug, grasp the plug, not the cable.
» Do not handle plug or appliance with wet hands.
» Turn OFF all controls before unplugging.
» The hose contains electrical wires. Do not use when damaged, cut or
punctured. Avoid picking up sharp objects.
» Plastic film can be dangerous. To avoid danger of suffocation, keep away
from children.
» Use only as described in this user guide.
» Use only manufacturer’s recommended attachments.
» If appliance is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water; do not attempt to operate it and have it
repaired at an authorised service center.
» Do not put any object into openings.
» Do not use with any opening blocked; keep free of dust, lint, hair, and
anything that may reduce air flow.
» Use extra care when cleaning on stairs.
» Do not use to pick up flammable or combustible liquids, such as petroleum,
or use in areas where they may be present.
» Do not pick up toxic material (chlorine bleach, ammonia, drain cleaner, etc.).
» Do not use appliance in an enclosed space filled with vapours given off by
oil-based paint, paint thinner, some moth-proofing substances, flammable
dust, or other explosive or toxic vapours.
» Do not pick up hard or sharp objects such as glass, nails, screws, coins, etc.
» Do not pick up anything that is burning or smoking, such as cigarettes,
matches or hot ashes.
» Do not use without filters in place.
» Do not use outdoors or on wet surfaces.
» CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
» The vacuum cleaner, handle, wand, hose and foot each contain electrical
connections and are not serviceable parts.
» This appliance is provided with double insulation. Use only identical
replacement parts.
SAVE THESE INSTRUCTIONS
ORIGINAL INSTRUCTIONS.
FOR OPERATION ON A 220-240 VOLT A.C. 50-60 HZ POWER
SUPPLY ONLY.
THIS MODEL IS FOR HOUSEHOLD USE ONLY.
IMPORTANT INFORMATION
» Keep appliance on a level surface.
» If your appliance has a motorised Brush Roll, do not leave machine running in the same spot without the handle fully upright.
READ ALL INSTRUCTIONS BEFORE USING YOUR APPLIANCE.
When using an electrical appliance, basic precautions should be observed, including the following:
3
www.BISSELL.com.au
Thanks for buying a BISSELL® vacuum!
We love to clean and we’re excited to share one of our innovative products
with you. We want your vacuum to work like new for the years to come,
so this guide has tips on how to use, maintain and, if there’s a problem,
troubleshoot.
Your vacuum needs a little assembly before getting to work, so flip to the
“Assembly” section and let’s get started!
Safety Instructions...........2
Product View................4
Assembly ...................5
Operations ..................5
Maintenance & Care .......6-9
Troubleshooting ............10
Guarantee...................11
Consumer Care..............11
What’s in the Box?
Base Unit Hose and HandleFoot Multi-Surface Nozzle
Dusting Brush
Extension Wand Crevice Tool
NOTE: Not all accessories come with every model. Be sure to check the carton for
additional tools.
4
www.BISSELL.com.au
1
4 5
2 3
Product View
Assembly
Push Hose Connector
into Base Unit and secure
with a click.
Push bottom of Extension
Wand into Foot and
secure with a click.
Push Handle end into top
of Extension Wand and
secure with a click.
Press button on Extension Wand to
adjust height.
Connect desired tool to handle.
1
2
4
5
6
7
3
1. 2-Position Handle
2. Extension Wand
3. Foot
4. Motorized Nozzle with
Tangle-Free Brush Roll
5. Dirt Tank
6. Base Unit
7. Hose Connector
5
www.BISSELL.com.au
21
3
Using Your SmartClean®
Adjust suction power by pressing the
buttons with the plus (+) or minus (-)
symbol on them depending on the level
of power you want.
WARNING
To reduce the risk of injury from moving parts while the vacuum is turned ON, always move the vacuum
via the rolling wheels by using the upper handle at the back of the vacuum. Do not carry the vacuum
while it is running. Always place vacuum on floor with handle in upright position when using tools.
Press Auto Button on back of unit for automatic floor
type sensing. The SmartClean canister will detect your
floor type and adjust suction as necessary.
Press the button on the
back left side of the
unit to power the unit
ON and OFF.
6
www.BISSELL.com.au
Emptying the Dirt Tank
1 2
Press Dirt
Tank Release
Button to
remove the
tank from the
unit.
Hold tank
over trash bin
and press the
button on the
bottom of the
tank to release
the tank door.
WARNING To reduce the risk of electric shock, turn Power Switch OFF and discon-
nect polarized plug from electrical outlet before performing maintenance or troubleshooting checks.
Cleaning the Filters
2
5
3
4 6
1
Remove foam filter
from the tank lid.
Replace both filters making
sure the flat felt filter is
inserted first.
Replace lid and turn
clockwise to lock in
place.
Remove flat filter
from the tank lid.
Both filters can be rinsed
to clean. Leave to dry for
24 hours before replacing.
With Dirt Tank removed twist
the top counter-clockwise and
pull up to remove.
24h
WARNING To reduce the risk of electric shock, turn Power Switch OFF and discon-
nect plug from electrical outlet before performing maintenance or troubleshooting checks. Do not oper-
ate vacuum with damp or wet filters or without all filters in place.
7
www.BISSELL.com.au
Cleaning the Filters (cont.)
7
10
13
8
11
14
9
12
Mesh filter can be rinsed
to clean. Let dry for 24
hours before replacing.
Push tabs inward and pull
out to remove back cover.
Replace mesh filter in
back cover. Make sure all
4 tabs are aligned with
their slots in the filter.
Replace pleated filter.
Pleated filter can be
rinsed to clean. Let dry
for 24 hours before
replacing.
Remove pleated filter
from back of unit.
Replace back cover of the
unit by pressing the tabs
inward to lock in place.
Remove mesh filter from
back cover.
24h
24h
8
www.BISSELL.com.au
Cleaning the Cyclonic System
Maintaining the Brush Roll
1
1
4
2
2
5
3
3
6
Turn cyclonic system
counter-clockwise to
release and remove from
the tank.
Use a coin to turn screws
counter-clockwise to
remove the sole plate.
Use a flat head
screwdriver to fit the belt
over the gear.
To replace the Brush Roll
to the foot, place the left
side of the Brush Roll
under the belt before
pushing down into place.
Replace sole plate to the
foot. Use coin to turn
them to lock into place.
Once screws are unlocked,
lift off sole plate.
Remove Brush Roll
from Foot.
Replace cyclonic system
and turn clockwise to lock
in place.
Cyclonic system can
be rinsed to clean. Let
dry for 24 hours before
replacing.
24h
WARNING To reduce the risk of electric shock, turn Power Switch OFF and discon-
nect plug from electrical outlet before performing maintenance or troubleshooting checks.
9
www.BISSELL.com.au
1 2 3
If there is a lack of suction,
turn OFF the unit and lift
up to access the plug on
the bottom of the unit.
Press tabs inward to
remove the plug.
Use the handle of a
broomstick or a similar
shaped object to push out
debris and unclog the unit.
Insert plug back into the
unit and press tabs inward
until you hear a “click”.
Clearing a Clog
21
Connect T-shaped hook on the Foot to
the T-shaped slot on the unit for in-use
storage positioning.
Connect T-shaped hook on the Foot to
the T-shaped slot on the bottom of the
unit for long term storage positioning.
Storing the Vacuum
10
www.BISSELL.com.au
Troubleshooting
Problem Possible causes Remedies
Brush Roll
doesn't
rotate
Brush Roll Button is turned
OFF.
Press the Brush Roll Power Button on
the handle.
Auto Button is turned OFF. Turn Auto Button ON.
Brush Roll has an obstruction
keeping it from rotating.
Power OFF unit and unplug to reset
brush motor, remove the brush and
remove debris before reinstalling.
Vacuum
won't pick up
dirt
Filters are dirty. Remove and wash the filters. Let them
dry for 24 hours before reinstalling.
Multi- Cyclonic system is dirty. Remove the separator from the Dirt
Tank and rinse to clean. Let it dry for 24
hours before reinstalling.
There is a clog in the vacuum. Power OFF and unplug unit. Remove
the cleanout cover on the bottom of
the vacuum and check for debris. Use a
broom handle to push debris through.
Do the same for the hose.
Dirt Tank is not seated
correctly.
Press the Tank Release Button to
release the Dirt Tank and align the tank
properly.
Hose is not connected. Push the hose connector in the port on
the canister until it "clicks" in place.
Hair wrapped around Brush
Roll.
Run vacuum back and forth on
clean carpet several times to release
wrapped hair.
There is a crack or hole in the
hose.
If there is a crack or hole, order a new
hose from BISSELL.com.au.
Dirt is
escaping
from the
vacuum
Dirt Tank is full. Empty the tank.
Filters are missing or dirty. Check to see if filters in the tank and
filters under the filter door at the back
of the canister are installed and clean.
Vacuum is
hard to push
or pull
Suction is set too high. Open the Suction Control located
under the handle or use the Variable
Suction Controls on the canister.
High-pitched
noise.
There is a clog in the vacuum. Power OFF and unplug. Disconnect
hose from the canister to check for
clogs or debris. Follow instructions for
clean a clog above.
There is a clog in the pleated
filter.
Power OFF and unplug. Remove
pleated filter from the back of the
vacuum and rinse to clean, see page
7. Let it dry for 24 hours before
reinstalling.
WARNING
To reduce the risk of electric shock, turn Power Switch OFF and disconnect plug from electrical outlet
before performing maintenance or troubleshooting checks.
11
www.BISSELL.com.au
Visit the BISSELL website: www.BISSELL.com.au
When contacting BISSELL, have model number of cleaner available.
Please record your Model Number:
Please record your Purchase Date:
NOTE: Please keep your original sales receipt. It provides proof of the date
of purchase in the event of a guarantee claim. See guarantee for details.
This guarantee gives you specific legal rights, in addition to rights you may
have under the Australian Consumer Law. If you need additional instruction
regarding this guarantee or have questions regarding what it may cover,
please contact your local BISSELL Consumer Services on the details set
out below.
Limited 2 Year Guarantee
(from the date of purchase by
original purchaser)
Subject to the *CONDITIONS identified below, BISSELL will repair or replace
(with new, refurbished, lightly used, or remanufactured components or
products), at BISSELL’s option, free of charge, any defective or malfunctioning
part due to manufacturer defect. This guarantee applies to product used for
personal purposes, and not commercial or rental service. This guarantee does
not apply to fans or routine maintenance or consumable components such as
filters, belts, brush rolls, etc., damage or malfunction caused by negligence,
abuse, neglect, unauthorised repair, or any other use not in accordance with
the user guide. BISSELL recommends that the original packaging be kept
for the duration of the guarantee period in case such need arises within the
guarantee period that the item needs re-packing and transportation.
It may be necessary to obtain some of your personal information, such as a
mailing address, to fulfill terms of this guarantee. Any personal data will be
handled pursuant to BISSELL’s Privacy Policy, which can be found at
www.BISSELL.eu.
*CONDITIONS OF THE GUARANTEE
Subject to whether such loss is reasonably foreseeable, BISSELL and its
in-country distributors are not liable for incidental or consequential damages
of any nature associated with the use of this product.
FOR AUSTRALIAN CONSUMERS ONLY:
OUR GOODS COME WITH GUARANTEES THAT CANNOT BE EXCLUDED UNDER
THE AUSTRALIAN CONSUMER LAW. YOU ARE ENTITLED TO A REPLACEMENT
OR REFUND FOR A MAJOR FAILURE AND FOR COMPENSATION FOR ANY OTHER
REASONABLY FORESEEABLE LOSS OR DAMAGE. YOU ARE ALSO ENTITLED
TO HAVE THE GOODS REPAIRED OR REPLACED IF THE GOODS FAIL TO BE OF
ACCEPTABLE QUALITY AND THE FAILURE DOES NOT AMOUNT TO A MAJOR
FAILURE.
THIS GUARANTEE IS IN ADDITION TO OTHER RIGHTS OR REMEDIES UNDER LAW.
NOTHING IN THIS GUARANTEE EXCLUDES, LIMITS OR MODIFIES ANY LIABILITY
OF BISSELL WHICH IS IMPOSED BY LAW, OR LIMITS OR MODIFIES ANY REMEDY
AVAILABLE TO THE CONSUMER WHICH IS GRANTED BY LAW. TO MAKE A CLAIM
UNDER THIS GUARANTEE CONTACT BISSELL AUSTRALIA PTY LTD (DETAILS
BELOW). CONTACT BISSELL PRIOR TO RETURNING ANY GOODS. WHERE AGREED,
BISSELL WILL REIMBUSE REASONABLE POSTAGE / HANDLING COSTS (IF ANY)
FOR RETURNING GOODS TO BISSELL. TO CLAIM EXPENSES INCURRED IN MAKING
A CLAIM UNDER THIS GUARANTEE PLEASE PROVIDE BISSELL WITH A COPY OF
THE RECEIPT OF THE EXPENSES BY EMAIL OR POST.
If your BISSELL® product should require service or to claim under our limited guarantee,
please contact us as follows:
Website and Email:
www.BISSELL.com.au
www.BISSELL.co.nz
Telephone:
Australia: 1300-247-735
New Zealand: 0800-247-735
Write:
BISSELL AUSTRALIA PTY LIMITED
42 Rocco Dr.
Scoresby 3179
Victoria
Australia
Replacement parts and accessories are available for purchase.
To purchase visit www.BISSELL.com.au.
Consumer Guarantee
Consumer Care
©2019 BISSELL Inc.
All rights reserved. Printed in China
Part Number 161-9130 06/19
