High End Wine Cooler
25 Bole Capacity
HME030370N
Thank you for purchasing our quality appliance. Please be sure to read the entirety
of this user manual carefully prior to use of the product. If you have any questions
regarding the use of this product, please call 1-800-898-3002.
BEFORE FIRST USE:
To prevent any internal damage, it is very important to keep
refrigeration units (like this one) upright throughout their journey.
Please leave it standing upright and outside the box for 24 HOURS
before plugging it in.
In the event this product malfunctions or customer believes
it is defective, the customer should contact Customer Service
and retain the defective product pending further instructions.
Defective product should be clearly marked or stored where it
cannot be used again by mistake. Failure to retain the product
may impede hOme
™
’s ability to correct any legitimate problem
and may limit the extent to which hOme
™
may provide recourse.
Important Safety Instructions
Operating Instructions
Cleaning and Maintenance
Troubleshooting
Warranty
Manufacturing Info
Warning
Contact Us
6-9
10-15
16
17
18
18
18
18
TABLE OF CONTENTS
on bringing home your new appliance!
Cong ratulations
Don’t forget to register your product at homelabs.com/reg
for updates, coupons, and other relevant information.
Although greatly appreciated, product registration is not
required to activate any warranty.
6
• Before using this electrical appliance, carefully read these instructions and keep the user manual for
future reference.
• This appliance is intended to be used in household and similar applications such as staff kitchen areas
retail applications.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
• The appliance has to be unplugged before carrying out user maintenance on the appliance.
• Children should be supervised to ensure that they do not play with the appliance.
• Do not
appliance.
• Keep ventilation openings in the appliance enclosure or in the built-in structure, clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting process, other than
those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
•
of the appliance must be conducted by a specialist.
•
• The gaps between the cooler door and the cooler body are small, note not to put your hand in these
•
may lead to suffocation!
•
water so as not to affect the electrical insulation properties of the cooler.
• The cooler might not operate consistently when placed under lowest temperatures of the cooler for
an extended period of time.
• Do not use the cooler body, cooler door, etc. as pedal or support.
• When positioning the appliance, ensure the supply cord is not trapped or damaged.
• To
section on page 12.
• Take precautions to prevent an undue rise in the temperature of the wine while defrosting the cooler.
• A rise in temperature of the wine during manual defrosting, maintenance or cleaning could shorten
the storage life.
• Do not exceed the storage time(s) recommended by the wine manufacturers for any kind of wine.
Important Safety Instructions
7
Important Safety Instructions
•
to avoid damages to the compressor due to successive starts.
• The door keys of the cooler should be kept out of the reach of children and not in the vicinity of the
cooler appliance, in order to prevent children from being locked inside.
• Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
• Do not use extension cords or ungrounded (two prong) adapters.
DANGER
• Risk of child entrapment.
- Do not allow children to enter or climb the cooler to prevent that children are entrapped in the cooler
or injured by the falling cooler.
- Children should be supervised not playing in the vicinity of the cooler to avoid being entrapped in the
cooler accidentally.
- Before you throw away this product, take off the doors and leave the shelves in place so that
children may not easily climb inside.
• The cooler must be disconnected from the source of electrical supply before attempting to install
the accessories.
ELECTRICITY RELATED WARNINGS
• Do not pull the power cord when pulling the power plug of the cooler. Firmly grasp the plug and pull
out it from the socket directly.
• Do not use the product if the power cord is damaged or the plug is worn. The damaged power cord
hazard.
•
that the grounding electrode of the power socket is equipped with a reliable grounding line.
• Turn off the valve of the leaking gas and then open the doors and windows in case of leakage of gas
• To ensure safety, do not place socket, regulators, rice cookers, microwave ovens and other
appliances on top of the cooler.
WARNINGS RELATED TO PLACING ITEMS
•
• This product is a household cooler and can only be used for storage of wine. Do not use this
appliance for other purposes such as storing blood, drugs, or biological products.
• Do not place heavy objects on top of the cooler. These objects may fall when opening or closing the
door and cause accidents.
8
Important Safety Instructions
WARNINGS RELATED TO DISPOSAL
as to prevent damage to the environment or any other harm.
put the doors and shelves in a proper place, so as to prevent trapping of any child.
MEANING OF SAFETY WARNING SYMBOLS
Prohibition symbol
The symbol indicates prohibited matters, and those behaviors are forbidden.
Non-compliance with the instructions may result in product damages or
endanger the personal safety of users.
Warning symbol
The symbol indicates matters that must be followed, and those behaviors must
be strictly executed in line with the operation requirements. Non-compliance
with the instructions may result in product damages or endanger the personal
safety of users.
Note symbol
The symbol indicates matters to pay attention to, and these behaviors shall be
specially noted. Due precautions are needed or minor or moderate personal
injuries or damages to the product will be caused.
SAVE THESE INSTRUCTIONS
For Household Use Only
9
Operating Instructions
NAMES OF COMPONENTS
C P
The above picture is only for reference. The product you got may be slightly different.
• The temperature in the cooler is 41-64 F , only used to store unopened bottled wine (Champagne,
red wine, white wine, or rose wine).
• Do not place food in the cooler to prevent bacterial contamination.
• Keep the interior of the wine cabinet dry.
TEMPERATURE CONTROL
Standby button Temperature increase button
Light button Temperature decrease button
Temperature display of upper zone
Conversion button of function of
upper zone and lower zone
Temperature display of lower zone
10
Display control
In the case of initial power-up, the whole screen will display relevant information for 3 seconds. You will
hear the start-up sound, followed by normal operation display.
Digital display area displays the fault code in the case of failure and the set temperature in the case of
normal operation.
This cooler can be controlled by gently touching buttons on the glass touch screen. The
display panel should be prevented from scratching by sharp objects and kept away from
operation of the cooler may be affected.
Standby function
Press the standby button for 5 seconds to access or exit the standby mode.
Light
The internal lamp will light up when the cooler door is open, and will be off when the cooler door is
closed.
You can also turn on or turn off the internal lamp by pressing the Light button. Once Light button is
activated, when open the door, the internal lamp will not turn off.
Temperature seing
• Temperature Adjustment
Press , the set temperature will increase by 1°F. Press , the set temperature will decrease by 1°F.
The temperature setting range of upper zone and lower zone is 41-57°F and 50-64°F respectively. The
• Conversion of Centigrade and Fahrenheit
Press both and for 5 seconds to switch between Centigrade and Fahrenheit.
• Limitation to Temperature Setting of Lower zone
The upper zone temperature should always be set lower than the lower zone temperature and should
not exceed the range of 4-14°F. For example, if the upper zone temperature is 50°F, the lower zone
temperature should be 54-64°F. And if the lower zone temperature is wrongly set, it will change to right
temperature automatically.
Error codes
If the failure happens, the display area will show corresponding error codes as shown below. Contact a
Error code Description
E1 Temperature sensor error of upper zone
E2 Temperature sensor error of lower zone
E6 Communication error
E9 High temperature alarm
Operating Instructions
11
Operating Instructions
PLACEMENT
• Before using the cooler, remove all packaging
materials including bottom cushions and foam pads
on the door and the cooler body.
• Avoid direct sunlight and heat sources such as stove,
heating radiator, etc.
•
right to adjust the feet for levelling if it is unstable).
•
(867-890mm).
START TO USE
•
•
• Do not connect cooler to electronic energy saving plug and a converter that can convert DC into AC
(E.g.: solar energy system, ship grid).
• Water drop or frost will be generated on the back side of cooler when compressor is running. Wiping
out frost or water drop is not necessary. The defrosted water will be collected into drain tank, then
HANDLE INSTALLATION
Please choose the following handle installation instruction according to your actual needs.
1. Put the handle on glass door through the two bolts.
>34
1
/
4
" (870mm)
34
1
/
4
" (870mm)
15" (380mm)
15
5
/
32
"-15
1
/
2
"
(385-395mm)
>22
1
/
2
" (573mm)
23
7
/
16
" (595mm)
12
Operating Instructions
HANDLE INSTALLATION (CONT.)
2.
REVERSING THE DOOR SWING
Warning:
door swing.
1. Remove the upper right hinge shaft (1) and remove the door body.
2. Remove the upper right hinge (2) and gently lift the door. Remove the lower hinge (3) and the lower
hinge shaft (4), the air shield (5) and its insert (6) by removing the corresponding screws as below
13
Operating Instructions
REVERSING THE DOOR SWING (CONT.)
3. Take out the left upper hinge (8) from the package box and install it to the upper left corner of the
cabinet. Install the left lower hinge shaft to the left hole of the left lower hinge. Install the left lower
hinge to the cabinet. Install the air shield and its insert. Then install the three plastic caps removed
from the left upper corner to the upper right corner.
4.
shaft hole cap to the left handle position. Remove the bottom support bracket (10) and install it to
the other side. Install the lower hinge shaft (11). Pay attention that the plastic anchor (12) should be
5.
6. Complete the door change and store the unused upper right hinge.
14
Operating Instructions
THE ARRANGEMENT OF BOTTLES
• Do not let bottles touch the back side of cooler in order to maintain good air circulation in the cooler.
• The total number may be different as it depends on the shape and size of various bottles.
• The capacity for bottle storage in the wine cabinet is based on the following marked bottle size.
Oversized bottle may impact the number of the bottles that can be stored in the wine cabinet.
1.2”
12”
8.5”
3”
ENERGY SAVING TIPS
• The Cooler shall be placed in a room dry and ventilated. The cooler cannot be put under direct
sunlight or next to heat source (such as radiator, stove. etc.), and a suitable insulation board shall be
applied if necessary.
• Shorten opening time of the cooler’s door.
15
Cleaning and Maintenance
If the cooler left unused for a long time, please:
1.
2.
3. Keep the cooler door open.
CLEAN THE COOLER
• Please turn off the power before cleaning, remove drinks or shelves, etc.
• Dust behind the cooler and on the ground shall be cleaned regularly to ensure the cooling and
energy saving effect.
• Check the door gasket regularly to make sure there is no debris. Clean the door gasket with a soft
cloth dampened with soapy water or diluted detergent.
• The interior of the cooler should be cleaned regularly to avoid odor.
• Use a soft cloth or sponge to clean the inside of the cooler, with two tablespoons of baking soda and
a quart of warm water. Then rinse with water and dry with a soft cloth. After cleaning, open the door
and let it dry naturally before turning on the power.
•
recommended to wipe them regularly with a soft rag, soft brush, etc. and when necessary, combined
with some auxiliary tools (such as thin sticks) to ensure no contaminants or bacteria accumulation in
these areas.
• Do not use soap, detergent, scrub powder, spray cleaner, etc., as these may cause odors in the
interior of the cooler or contaminate food.
• Clean the shelves with a soft cloth dampened with soapy water or diluted detergent. Then rinse with
water and dry with a soft cloth or dry naturally.
• The wooden wine rack should not be directly immersed in liquid to prevent cracking or mold after
moisture. The wooden wine rack should be cleaned with a dry soft cloth. The heavily contaminated
wooden wine rack should be cleaned with a soft cloth that has been wrung out, and dry naturally.
• Wipe the outer surface of the cooler with a soft cloth dampened with soap water, detergent, etc.,
and then wipe dry. Do not rub or scratch the surface of the glass door to prevent the door from
being broken or scratched.
• Do not use hard brushes, clean steel balls, wire brushes, abrasives (such as toothpaste), organic
solvents (such as alcohol, acetone, banana oil, etc.), boiling water, acid or alkaline items, which may
damage the cooler surface and interior. Boiling water and organic solvents such as benzene may
deform or damage plastic parts.
• Do not rinse directly with water or other liquids during cleaning to avoid short circuits or affect
electrical insulation after immersion. Water should not soak the operating control elements and
lighting system on the glass door.
NOTE:
Do not use detergent and solvent with sand or acid to clean the cooler.
16
Troubleshooting
PROBLEMS CAUSES AND SOLUTIONS
The cooler does not
operate
The cooler is not plugged and connected to power.
Low voltage.
Temperature control knob is not in the working area.
Failure in power or tripping circuit.
Long time operation of
compressor
It is normal that cooler operates for longer time to cool the wine in
summer when the ambient temperature is high.
Do not put too much wine bottles in the cooler at one time.
Frequent opening of the cooler door.
Illuminating light does
not turn on
The cooler is not connected to power, or the indicator light is damaged.
Loud noises
cooler accessories are properly placed.
Cooler enclosure heat
The cooler enclosure may emit heat during running especially in summer.
This is caused by the radiation of the condenser and is normal.
Condensation
Condensation will be detected on the exterior surface and door seals
of the cooler when the ambient humidity is high. This is normal. Simply
wipe with soft towel, and turn up the set temperature of the appliance
properly.
Buzz
Refrigerants circulating in the refrigerant lines will generate sound and
grunts. This is normal and will not affect the cooling effect.
Buzz will be generated by running compressor specially when starting up
or shutting down.
17
hOme
™
and unused from hOme Technologies, LLC or an authorized reseller, with an original proof of purchase
and where a defect has arisen, wholly or substantially, as a result of faulty manufacture, parts or
workmanship during the warranty period. The warranty does not apply where damage is caused by
™
The hOme
™
warranty covers all costs related to restoring the proven defective product through
repair or replacement of any defective part and necessary labor so that it conforms to its original
™
’s
exclusive obligation under this warranty is limited to such repair or replacement.
A receipt indicating the purchase date is required for any claim, so please keep all receipts in a safe
greatly appreciated, the product registration is not required to activate any warranty and product
registration does not eliminate the need for the original proof of purchase.
The warranty becomes
those provided by hOme
™
, are used. You may also arrange for service after the warranty expires at an
additional cost.
These are our general terms for warranty service, but we always urge our customers to reach out to
us with any issue, regardless of warranty terms. If you have an issue with a hOme
™
product, please
contact us at 1-800-898-3002, and we will do our best to resolve it for you.
to state, country to country or province to province. The customer may assert any such rights at their
sole discretion.
HME030370N
Warranty
Manufacturing Info
This manual is to be used with all items with the model number
SKU# : HME030370N
Keep all plastic bags away from children.
Warning
Contact Us
homelabs.com/chat
Mon–Fri 10AM–5PM EST
1-(800)-898-3002
Mon–Fri 10AM–5PM EST
Respond within twelve hours
CHAT W ITH US
CALL U S
EMAIL US
© 2019 hOmeLabs LLC
37 East 18 Street, 7th Floor
New York, NY 10003
For household
Use Only
1-800-898-3002
All rights reserved, hOme
®
. Printed in China.
