L75ms Integrated Music System
Quick Start Guide
1. Verify Box Contents
1x L75ms Integrated Music System
1x Speaker Grille
1x RF Remote
1x Region Specic Power Cord
2. Determine Speaker Location
Set the bass contour switch based on the speakers proximity to side boundaries such as walls and inside a bookcase or cabinet.
When close to a boundary the switch should be in the -3dB position in order to maintain level bass response.
Away from side boundaries such as walls.
BASS
CONTOUR
0dB
-3dB
Close to side boundaries such as walls or when the speaker is
inside of a cabinet or bookcase.
BASS
CONTOUR
0dB
-3dB
3. Connect Physical Sources
Sub Out: Single RCA to
Powered Sub (Optional)
Aux In: 3.5mm (1/8in)
Stereo
Ethernet: Connect to
port on wireless router
for streaming
Phono: Stereo
RCA plus Ground
HDMI ARC: ARC from TV
4. Pair the Remote
-
1 2
Press & Hold >2 sec
Press & Hold >3 sec
www.JBL.com/Specialty-Audio
