USER GUIDE
THE FIRST SMARTWATCH
WITH NO COMPROMISES
Thanks for choosing MyKronoz ZeTime, you’re now part of the global
family of ZeTime owners who have decided together with us to
break the rules of traditional smartwatches to deliver a companion
device with no compromises. ZeTime was born in Switzerland,
home country of the traditional watch industry and this is why it has
been thought and developed with a lot of care and passion with
only the final owner in mind. ZeTime is assembled with some high
quality materials and technologies to make it not only an amazing
smartwatch but certainly a beautiful piece of jewelry you’ll be proud
of wearing every day.
Stainless Steel Watch Case: ZeTime comes in 6 dierent colors of
high grade stainless steel to suit your style and your tastes but more
importantly guarantee you the best durability over time.
Natural Sapphire Glass: In order to provide the best watch
possible, it was mandatory for us not to make any sacrifices on the
type of glass we were using on ZeTime. That’s why we selected
a special sapphire glass that works perfectly with our customized
touch panel.
Customized TFT Screen & Smart Movement: To be a revolutionary
smartwatch we had to achieve something that nobody did before!
Delivering a watch with a full round TFT display combined
together with a smart mechanical movement controlled by the
watch CPU. The result is mind-blowing and oers an absolutely
unique user experience.
5 ATM Certification: Because our watches accompany us pretty
much everywhere we go, we have built ZeTime to oer the best
performance in all kinds of environments and especially when in
contact with water.
Up to 30 days battery life: Thanks to our proprietary operating
system we’re not only able to oer perfect compatibility with both
Android and iOS devices but also to deliver unprecedented battery
life for a smartwatch. 3 days in fully operational smart mode and an
additional 30 days once the screen is o, guaranteeing that you’ll
never be out of juice for keeping track of time.
- 3 -
- 39 -
1. Charging
2. Battery life
3. Set up
4. Calibration
5. System requirements
6. Incoming calls
7. Missed calls
8. SMS
9. Notifications
10. Reminders
11. Activity
12. Inactivity alerts
13. Heart rate
14. Sleep
15. Alarm
16. Camera remote
17. Music control
18. Anti-lost function
19. Weather forecast
20. Stopwatch
21. Timer
22. Find my phone
23. Customize your watch
24. Home time zone
25. Wrist flick
26. Left hand mode
27. Night mode
28. Settings
29. Firmware update
30. Watch band
31. Accessories
32. Tech. specs
- 08 -
- 09 -
- 10 -
- 11 -
- 12 -
- 13 -
- 14 -
- 15 -
- 16 -
- 17 -
- 18 -
- 22 -
- 23 -
- 24 -
- 25 -
- 26 -
- 27 -
- 28 -
- 28 -
- 29 -
- 31 -
- 31 -
- 32 -
- 32 -
- 33 -
- 33 -
- 34 -
- 35 -
- 36 -
- 37 -
- 38 -
- 39 -
TABLE OF CONTENTS
- 4 -
Color
touchscreen
Upper
button
Smart
crown
Lower
button
OVERVIEW
I UPPER BUTTON
Press to light up the screen, return to home page from any menu
or put the device in standby mode.
I LOWER BUTTON
• Press to light up the screen, go one step back in the menu
structure, exit a menu or have access to your calendar events from
your home page.
• Press & Hold to Power ON/OFF.
I UPPER + LOWER BUTTON
Press & Hold the upper button and the lower button for 10 seconds
to reset the device.
Warning: all data stored into the device will be lost.
I SMART CROWN
• Turn the crown to navigate through the main menu.
• Press the crown to select an app.
• Double press to manually move the hands to 9:15
• Single press to enable night mode (from standby screen).
- 5 -
Marketing weekly
meeting with Fred...
NO! Thi...
Hi , Jack ! H...
Yes , I’m ve...
Long press
to change your
watch face.
Swipe right
to access
activity
menu.
Swipe down
to display
shortcuts
menu.
Tap once
To select an item
or open
a menu.
Tap twice
To return to
previous
page.
BASIC TOUCHSCREEN OPERATIONS
I FROM THE WATCH FACE
I FROM ANY SCREEN
Swipe left
to access
main
menu.
Swipe up
to display
notification
center.
X2
- 6 -
SMART CROWN OPERATIONS
Turn the crown
to navigate through the main menus.
-
Press the crown
to select an app.
-
Press twice
manually move the hands to 9:15 from any screen.
-
Press once
to enable night mode
from standby screen.
ZeTime is equipped with a smart crown to enhance the navigation
experience in the watch menus. It can be used from many
dierent screens to select, navigate or adjust some
settings. Pressing the crown will validate your selection.
- 7 -
SHORTCUTS
Swipe down from the main watch face
to access ZeTime shortcuts.
Weather
Instantly access the local
weather conditions and
next 3 days forecast.
Flight mode and
Bluetooth status
Brightness
Set screen brightness
for better visibility.
Vibration
Buzzer
Mute all notifications.
Turn on vibration
(default).
Turn on vibration & buzzer.
(Also enable customized setting
from the mobile app).
Turn on buzzer.
Flight mode is disabled.
Bluetooth is not connected.
Flight mode is enabled.
Flight mode is disabled.
Bluetooth is connected.
Helps you find your phone
as long it is in range
with your ZeTime.
Shows the remaining battery
level of your watch.
Heart rate
Keep track of your heart rate.
Monitor it.
Battery level
Find my phone
- 8 -
1.CHARGING YOUR ZETIME
We recommend you to initially charge your ZeTime for about
90 minutes before using it for the first time.
ZeTime will operate for up to 3 days in smartwatch mode and an additional
30 days in traditional mode.
ZETIME CHARGER CABLE
1. Position the back of your ZeTime on the charging dock.
2. Plug the USB cable into the charger.
3. Plug the large end of the USB cable into a USB power source.
4. A battery indicator will fill in to indicate charging is in progress and turn to
solid green when it’s fully charged.
5. Unplug the cable after ZeTime is charged.
When the battery level gets low, a low battery indicator will
appear on the watch screen.
i
- 9 -
2.BATTERY LIFE
Your ZeTime operates with a single battery, which powers
both the digital screen and analog movement in the most
energy ecient manner in order to oer up to 30 days battery
life on a single charge.
When fully charged, ZeTime will deliver about 3 days battery life in its fully
operational smartwatch mode, tracking your activity and alerting you of
incoming notifications or calls.
Once a certain minimum battery level will be reached, ZeTime will
automatically turn off the smartwatch functions to continue providing
an additional 30 days battery life to power the smart movement.
During this 30 days period, hands will only indicate the local time, no
additonal functions will be available.
You have the freedom to enable activity tracking together with analog
mode but this will aect the overall battery life. This operation can be
performed in the mobile app advanced settings (power o mode > Hands
running + Activity tracking).
CHARGE
The 3 days smartwatch function is an estimate based on the
anticipated average use of the device. Many features and functions
- such as the HR tracker and the touchscreen - consume more
energy, so your actual battery life may vary.
i
- 10 -
3.SET UP
When turning ON your ZeTime for the first time, you’ll be
prompted to download the ZeTime mobile app on your
smartphone in order to proceed to its initial set up.
I TO SET UP YOUR ZETIME
1. Ensure the Bluetooth is enabled on your mobile smartphone.
2. Download the ZeTime mobile app from the app store or the Google Play
Store.
3. Open ZeTime mobile App on your smartphone. Sign up if you are a new
member or Log in with your existing account. After entering your personal
information, follow the on-screen instructions.
4. Make sure ZeTime is nearby and select it in the list of devices.
5. A pairing request will appear on your smartphone. Press pair to accept it.
6. Then, you will receive a pairing request on your ZeTime display. Tap on the
screen to accept the pairing.
7. When ZeTime is successfully paired, you will be notified on both devices.
At the end of the setup process, you might be prompted to install a new
version of the watch firmware. We strongly advise you to do it before you start
using ZeTime. This will ensure that you have the most up to date software on
your device and benefit from all the latest features. Before the update make
sure to have more than 30% battery on your smartphone.
After the initial pairing, ZeTime will automatically connect to your
phone as long as it is turned on and within range. If you want to
pair your ZeTime with another account or smartphone, you first
need to unpair from the current one. On the mobile app, go to
Settings > click on Unpair ZeTime. Then, repeat the pairing procedure
described above.
i
- 11 -
4.CALIBRATION
During the set up process, you’ll be prompted to proceed to
hands calibration. This is a mandatory step to ensure your watch
is perfectly time-synched with your smartphone.
Calibration can be done after the set up process directly on the watch in the
settings or from the mobile app by following the steps below:
• Open your app.
• Click on Settings and then on Advanced Settings.
• Then, click on Calibration and follow the on-screen instructions.
Align the hour hand with the red
dot at the top of the screen, and
align the minute hand with the
hour hand, then press NEXT to
synch your ZeTime with your
smartphone.
To calibrate your watch, move
hands by slowly swiping your
finger around the virtual dial on
the smartphone screen. You
can fine-tune the position of the
hands by using the « + / - » on the
phone screen.
When travelling in another time zone, do not forget to synchronize your
watch with the mobile app in order to make it automatically adjust
to local time.
i
- 12 -
5.SYSTEM REQUIREMENTS
Visit www.mykronoz.com to get the latest compatibility list.
-
iOS
-
iOS 8+ devices with Bluetooth 4.0 BLE
iPhone 4s, 5, 5c, 5s, 6, 6s, 6s plus, 7, 7 plus, 8, 8 plus & X
iPad (3
rd,
4
th
and 5
th
generation), iPad Mini,
iPod touch (5
th
generation)
-
ANDROID
-
Selected Android 5.0+ devices that support
Bluetooth 4.0 BLE
ZeTime will sync the notifications of SMS, emails, social media,
calendar events, and personal life reminders once the ZeTime app
has been successfully installed on your smartphone .
i
It is required to install ZeTime mobile app on your smartphone to
properly set up and use your watch.
- 13 -
6.INCOMING CALLS
7.MISSED CALLS
When receiving a call, a notification will appear on your ZeTime.
You can accept or reject it straight from your wrist. The phone call
will occur on your smartphone, not on your watch.
Missed calls are visible in the notification center as well as in
the dedicated missed call app in the watch.
ANGELINA
INCOMING CALL
Android users can also reply to an incoming call by sending a
short preset text message or an emoji directly from their watch
(not available for iOS users).
To delete all your missed calls, long press the screen.
i
i
JENNIFER
STEPHANE
CINDY
MAXIM
- 14 -
8.SMS
With ZeTime you can receive and read your SMS straight from
your wrist. Thanks to its proprietary smart movement, ZeTime
detects the information that is displayed on the screen and
moves the hands horizontally to maximize visibility, allowing the
text to be seen clearly.
Quick reply (Android only): ZeTime allows you to reply using
emojis or preset short answers directly from your watch. You
can also create your own preset answers using the mobile app.
To delete all your SMS notifications, go on the SMS list and long
press the screen. To erase a specific SMS, select the message and
slide it to the left with your finger.
i
- 15 -
9.NOTIFICATIONS
ZeTime is able to receive virtually all notifications received by
your phone.
Calendar events: ZeTime synchronizes your events from your
calendar. You can see your next upcoming 16 events in your
ZeTime. Your smartwatch will notify you of upcoming events. You
can slide to discard this event.
i
Each notification will appear over your selected watch face with its dedicated
icon to identify the service. Some notifications may be identified with a blue
generic icon.
To read your notication, simply
touch the screen on the notification
area and it will open instantly.
Swipe left to delete
the notification.
Hands will automatically move
away from the text to facilitate
your reading.
Long press on your
notifications list to delete
them all.
- 16 -
NOTIFICATIONS SETTINGS:
When you open your ZeTime mobile app and select
Notifications in the settings menu, the following screen
will appear:
For each type of
notification you can select
the type of alert you want:
ring, vibrate or silent.
To set it up, simply
expand the option menu
by tapping on the
notification type.
Press on the slider buttons
to activate or disable
the notifications.
- 17 -
10.REMINDERS
You can set and manage reminders directly with ZeTime mobile
app. You can create up to 10 reminders and select the type,
time and schedule for them. For each reminder you can decide
the type of alert you want to receive (ringtone, vibration or both).
A single tap on your ZeTime helps dismisses the reminder. If not
dismissed, the same alert will repeat after two minutes.
I TO SET UP A REMINDER
• Op
en the ZeTime mobile app.
• Click on the reminder tab.
• Set up your preferred reminder type.
• Choose the date and time of the reminder.
I REMINDER ICON
After setting your reminders, you can find them in the corresponding
menu on your ZeTime.
i
Sport
- 18 -
11.ACTIVITY
ZeTime automatically tracks your activity throughout the day.
On the main application screen, you can view your daily activity
in real-time over your set goals and get a detailed report in
the mobile app.
Your watch has a built-in 3-axis accelerometer that allows you
to track your daily activity based on your movements. This,
together with your profile information, allows your watch to
calculate your steps, walking distance, minutes of activity and
calories burned. In order to get the most accurate results we
recommend you to wear your watch on your left wrist if you’re
a right handed and to your right one if you are a left handed.
I FROM YOUR ZETIME
FOLLOW YOUR ACTIVITY:
• You can access the activity home screen simply by swiping to the right
from the watch face or selecting the corresponding menu from the first page
of the applications menu.
• Swipe down to see your number of steps, distance, calories and active
minutes. You can also use the smart crown to navigate inside this menu.
The activity tracker resets at midnight and ZeTime has the ability
to store up to 10 days of your activity data. Then, you will have
to synchronize your ZeTime with your mobile app in order to avoid
loss of data.
i
Overall activity Steps
Calories burned
Distance
Minutes of activity
- 19 -
I FROM ZETIME MOBILE APP
CUSTOMIZE YOUR ACTIVITY DASHBOARD:
When you have set up your watch with your mobile app, you will be able
to customize your Activity page at your convenience.
In order to do so, you just have to long press on one of your activity bars
for 3 seconds. Then you must hold this icon and make the entire
section slide down or up.
Long press on any of your activity bars for 3 seconds to save your modi-
fication.
- 20 -
SET UP ACTIVITY GOALS:
You can set your daily goals from the mobile app or in the activity
section of the watch settings.
We recommend you to set ambitious but realistic goals in order to
keep a healthy daily activity. You can obviously raise your goals over
time to increase your performance. On average it is recommended to have
at least 30 minutes of physical activity per day.
Your ZeTime tracks your progress towards a daily goal of your
choice. Some of the watch show a goal progress ring or bar to
keep you motivated. When you reach your goal, ZeTime vibrates
and displays a Goal achieved notification.
i
OK
- 21 -
SHARE YOUR ACTIVITY:
Use the sharing function to publish your daily activity or special workouts
on your preferred social networks.
1.
3.
2.
4.
1. Press on the top right icon to start sharing your activity data with your
friends and family.
2. You can choose an image (by sliding left and right) or take a picture
that you want to share.
3. When it’s done, select the top right button “next”.
4. Select your prefered network to share your daily activity report.
- 22 -
12.INACTIVITY ALERT
Thanks to these particular alerts, you’ll always make sure
to have the right amount of activity throughout the day.
You can set up when and how frequently you want to your
ZeTime to alert you.
I TO ENABLE THE INACTIVITY ALERT
• Go to the Settings menu of ZeTime mobile app.
• Click on Advanced settings and select Inactivity alert.
• Simply customize your inactivity alert pattern and click on Save
to enable it.
To dismiss an incoming inactivity alert, simply touch the screen or
press any button on the watch.
- 23 -
13.HEART RATE
Equipped with an optical heart rate sensor, ZeTime measures
manually or automatically your heart rate frequency throughout
the day.
I TO MEASURE YOUR HEART RATE
• Securely attach your ZeTime around your wrist.
• Go to the heart rate menu of your watch.
• Touch the screen or press the crown to start measuring your
heart rate.
It will take about 10 seconds to get the results displayed on your watch screen.
It is possible to set automated measurements from the mobile app. Simply
enable this function in the setting menu of the app and decide on the frequency
between each measurement.
I TO SET YOUR HEART RATE ALERT
ZeTime can also alert you when your heart rate is going above or below
preset limits. You can customize those limits in the mobile app settings.
Warning: Setting automatic HR on a very regular basis will impact
the battery life.
i
Measuring
- 24 -
14.SLEEP
With ZeTime you can monitor both the length and the quality
of your sleep. Detailed reports are available both in the mobile
app as well in the watch interface.
I START/EXIT SLEEP MODE MANUALLY FROM YOUR WATCH
• Press the sleep app icon of ZeTime main menu.
• Press on Start to enable sleep monitoring.
• Press on End to stop sleep monitoring.
I SLEEP GOALS FROM YOUR WATCH
• Sleep Goal is 8 hours by default.
• Slide to the right to set up your daily sleep goals to your most
suitable length.
I START/EXIT THE PRESET SLEEP MODE FROM ZETIME APP
• Go to the Advanced settings of the mobile app.
• Click on Preset sleep.
• Enable and adjust bed and awake time.
Don’t forget to save your settings before exiting.
If you forgot to enable Sleep mode on your watch, you can manually
add your sleep data from the mobile app. Open ZeTime App,
select Sleep, click on + at the bottom > Add sleep.
i
OK
LAST NIGHT
- 25 -
15.ALARM
To wake you up in the morning, or alert you at a certain time
of the day, you can set up alarms that gently vibrate and ring
at the chosen time.
I TO SET AN ALARM FROM ZETIME APP
• Go to the Reminders Tab.
• Select Wake-up reminder.
• Set the alarm and click on Save.
For each alarm, ZeTime will vibrate and ring continuously for
1 minute. You can snooze wake up alarms several times. Snooze
length can be set in the advanced settings from the mobile app
or in the watch settings.
i
- 26 -
16.CAMERA REMOTE
ZeTime can be used as a remote control to take pictures from
your smartphone. This feature is useful when you want to take
a group photo or when you want to take a selfie.
I TO USE ZETIME AS A CAMERA REMOTE
• Go to the Settings tab of your ZeTime mobile app and click on Camera.
• Click on the Camera app icon on your watch.
• You can then, press the screen to start the countdown and take
photos.
Each picture taken from your ZeTime will appear on the image
gallery of your smartphone.
i
- 27 -
17.MUSIC CONTROL
With ZeTime you can take control of your favorite music player
on your Smartphone. If you’re using third party players like
Spotify or Deezer you’ll first need to connect your account with
the ZeTime mobile App in the Music settings menu.
On your ZeTime, you can see information about the track currently
playing, like artist and track name. If the app you’re using
does not broadcast track information, it won’t appear on your
ZeTime (iOS only).
i
From your IOS device
From your Android device
I TO CONTROL MUSIC
• First start the player on your phone.
• Go into the Music app on your ZeTime.
• Play, pause, skip tracks and adjust volume straight from your wrist.
Volume can also be adjusted using the digital crown.
- 28 -
18.ANTILOST FUNCTION
19.WEATHER FORECAST
This alert notifies you with a vibration or a sound (depending on
your watch settings) when your ZeTime is going out of range
(BT range 10m) from your phone. Note that you can turn this func-
tion o by disabling the Anti-lost alert in your application’s noti-
fication menu (Anti-lost alert is OFF by default).
You can check the weather forecast of your desired location on
your ZeTime, once you have set it up with the mobile app.
You can access the weather forecasts from shortcuts or the
main menu page.
Following this procedure, your ZeTime will display the weather forecast
of your select location. ZeTime will display the weather forecasts of the
present day and upcoming 3 days on a second page.
I TO SET THE WEATHER FORECAST
• Go to the Advanced Settings of the mobile app.
• Tap on Weather.
• Select Automatic mode to get weather forecasts based on your
GPS position.
• Select Manual mode for choosing your preferred location.
To change the temperature unit, go to the weather section
and select °C or F°.
i
GENEVA
WEATHER FORECAST
GENEVA
SUNNY
- 29 -
20.STOPWATCH
I TO USE THE STOPWATCH:
•
Open the stopwatch app in the watch menu. Start counting
by pressing the green play icon. You can track individual lap
performance by pressing the round green button while
measuring is on.
•
To stop counting, press the red button.
•
You can see the full lap-by-lap report by pressing the lap
counter at the top of the screen.
- 30 -
21.TIMER
I TO USE THE TIMER:
•
Open the timer app in the watch menu.
•
Adjust the countdown length by using the digital crown and
start counting by pressing the green button.
•
At the end of countdown, your watch will alert you with sound
and vibration.
22.FIND MY PHONE
If you misplace your phone, the Find my phone function will
make your phone ring or vibrate so you can easily find it. To
use this feature, ensure your phone and watch are within range
of each other (10m).
I TO ENABLE THIS FUNCTION
Press the find my phone app icon in the watch shortcuts or in the
main menu page, and click on the screen to enable it.
- 31 -
23.CUSTOMIZE YOUR WATCH
I TO CHANGE THE WATCH FACE FROM YOUR ZETIME
• Long press on the current watch face.
• Swipe left or right to go through the dierent watch faces available (you can
also use the crown).
• Tap on the one you want to select and use.
min
24
- 32 -
I TO CHANGE THE WATCH FACE FROM THE APP
• Go to the Settings tab of the mobile app.
• Click on Watch faces.
• Click on select your watch face.
I TO CREATE YOUR OWN WATCH FACE
• Go to the Settings tab of the mobile app.
• Click on Watch faces.
• Select Create your watch face.
You can create your own watch faces and store up to 4 of them inside the
watch memory.
1. Select one of our selected wallpapers, or use a photo from your library or
straight from your camera.
2. You can add up to 4 widgets on the watch face and a dial around the
screen.
3. Once finished, simply save your creation and push it to the watch.
You can create up to 10 watch faces in the mobile app but only 4 will be
stored inside the watch.
1. 2. 3.
- 33 -
24.HOME TIME ZONE
ZeTime allows you to display two dierent time zones on
the same screen. With selected watch faces, analog hands
will provide the local time while a digital clock will provide
corresponding home time zone. This function is particularly
useful for people traveling regularly between time zones.
I TO ADJUST HOME TIME ZONE
• Go to the Advanced settings in the mobile app.
• Tap on Home Time Zone.
• Select your Time Zone city and save your setting.
25.WRIST FLICK
The wrist flick mode will enable you to light-up your screen
by simply lifting your wrist towards your face. By default
this feature is disabled in order to save battery life. You can
enable it from the watch setting menu in the display section.
- 34 -
27.NIGHT MODE
A single press on the crown activates a 10 seconds eye-pleasing
light to allow you to see the time at night.
I TO SELECT YOUR NIGHT MODE WATCH FACE
• Open the setting menu of the mobile app.
• In the Advanced settings select Night mode.
• Then choose the watch face you want.
26.LEFT HAND MODE
ZeTime is the only smartwatch to provide a full left-hand user
mode by rotating both on screen information and the analog
mechanism at 180° when worn on the right wrist.
I TO SET IT UP
• Open the Advanced settings of the mobile app.
• Select Left Hand mode and enable it.
This function is also available in the watch settings.
- 35 -
28.SETTINGS
GENERAL
Language:
set your language.
Unit:
choose between metric
or imperial.
Bluetooth:
enable or disable it.
Regulatory:
watch certification.
Watch Information:
view the firmware version
& serial number of the
device.
TIME
Time format:
change date and time
formats.
Home time zone:
set your local time zone.
Calibration:
set time of analog watch
hands.
ACTIVITY
Heart rate
set your minimum and
maximum heart rate
frequency.
Goals:
set your goals.
VIBRATION & SOUNDS
Vibration:
set your vibration mode.
Sounds:
set your sound mode.
Do not disturb :
set a time frame when you
don’t want to be disturbed.
Snooze:
adjust the snooze time.
DISPLAY
Watch face:
set your watch face.
Wrist flick:
enable or disable it.
Brightness:
change the screen
brightness.
Left mode :
enable it to wear your
watch on your right wrist.
Screen time out:
set the standby mode.
Night mode:
enable it and customize
the watch face.
RESET
Reset your watch to its
default settings.
- 36 -
29.FIRMWARE UPDATE
MyKronoz will provide regular firmware updates which you will
need to install in order to access our latest upgrades and fea-
tures for your watch. With Zetime, all these updates need to
be done by OTA (Over The Air) and through the mobile app.
Updates are performed over the air using the mobile app.
Before updating, make sure your phone and your watch have
more than 30% battery.
I IN ORDER TO UPDATE YOUR WATCH:
• Connect your ZeTime to the mobile app.
• If a new update is available you will be prompted from the
home screen.
• You must accept it in order to start the updating process.
During all the update process you must keep your watch near your
smartphone and your application must be open. Avoid using your
phone during the update process.
i
- 37 -
30.WATCH BAND
ZeTime uses standard 22mm (Regular) or 18mm (Petite) inter-
changeable wrist bands, in order to make it easy for you to
perfectly match your watch and your style.
1. Push the spring bar inward to release the strap from the watch case.
2. Push the spring bar inward while aligning it with the holes on either side
of the watch case.
3. Release the spring bar to secure the strap.
4. Verify that the strap is correctly fastened by gently tugging on the strap.
REGULAR
44mm
WATCH BAND
22mm
PETITE
39mm
WATCH BAND
18mm
- 38 -
31.ACCESSORIES
CHARGING STAND
2IN1 CHARGER
STANDARD CHARGER
I HOW TO USE THE 2IN1 CHARGER
The 2-in-1 charger has a built-in 400 mAh battery, allowing you to charge
your ZeTime when you are on the go with no power plug available. You can
fully charge your ZeTime up to 2 times with this built-in battery.
First of all you need to push the button at the back to put it in its operating position.
When connected to USB power source the 2-in-1 charger will operate
as such:
•
Without the watch on the charger, the LED will display in red as the built-in
battery is being charged. When fully charged LED will turn to solid blue.
•
With the watch on the charger, the LED display in red for 10 seconds. Once
fully charged, the LED will display in green for 10 seconds.
When not connected to USB power source:
•
Without the watch on the charger, the LED display in blue all the time.
(We highly recommend you to switch o the charger with the back button
located on the back of the charger).
•
With the watch on the charger, the LED will display in red for 10 seconds.
Once fully charged, the LED will display in green for 10 seconds.
Available as an optional charging
solution, the charging stand
is an elegant bedside or desk
charger made of aluminum to
perfectly match the modern
design of your ZeTime.
The perfect companion charger
for your ZeTime. Its thin and
sleek design will help you take
it with you everywhere you go
to ensure your watch never runs
out of juice.
- 39 -
33.TECH SPECS
Dimensions: Regular: 44 X 12.8 mm
Petite: 39 X 12.6 mm
Weight: Regular: 90g
Petite: 80g
Material: Stainless steel watch case available in silver,
black, titanium, pink gold & yellow gold
Watch band size: Regular: 22 mm
Petite: 18 mm
Connectivity Bluetooth BLE 4.2
Battery type: Regular: Li-iOn 200 mAh
Petite: Li-iOn 180 mAh
Battery life: Up to 30 days (watch mode)
Up to 3 days (smartwatch mode)
Mechanical hands
Vibrator & Buzzer
Charging time: 90 minutes
Memory : 10 days
Display type: TFT Color touchscreen with hole
Display size Regular: TFT 1.22 inches / 240*240 pixels
and resolution: Petite: TFT 1.05 inches / 240*240 pixels
Sensors: 3-axis accelerometer
& optical heart rate sensor
Operating temperature -10°C to + 60°C
Water resistance: 5 ATM*
International warranty: 1 year
What’s in the box: Charger dock, ZeTime, Get started guide.
* ZeTime is water resistant up to 50 meters. ZeTime is resistant to water
splashes, rain, submersion and showering. ZeTime can be used for
shallow water activities like swimming but should not be exposed to
water at high pressure, such as ocean waves or a waterfall. ZeTime
should not be used for scuba diving and water skiing. Do not expose
your ZeTime to soapy water, perfume, detergents, lotions, sunscreen,
and high velocity water. Please note that all bands are not appropriate
for water use. For example, leather band.
i
- 40 -
WARNING
I
Connecting the charging cable improperly may cause serious da-
mage to the device. Any damage caused by misuse is not covered by
the warranty. Unplug the cable after ZeTime is fully charged.
I
ZeTime unit and charging dock contain strong magnets that
may interfere with pacemakers, credit cards, watches and other
magnet-sensitive objects. If you use a pacemaker or any other
electronic medical device, please consult your physician before
wearing or handling ZeTime.
I
This product is not a medical device and should not be used to
diagnose or treat any medical condition.
I
ZeTime is water resistant up to 50 meters. ZeTime is resistant to water
splashes, rain, submersion and showering. ZeTime can be used for
shallow water activities like swimming but should not be exposed to
water at high pressure, such as ocean waves or a waterfall. ZeTime
should not be used for scuba diving and water skiing. Do not expose
your ZeTime to soapy water, perfume, detergents, lotions, sunscreen,
and high velocity water. Please note that all bands are not appro
-
priate for water use. For example, leather band
ABOUT THIS MANUAL
SUPPORT
The features of ZeTime and the contents of the user manual are
subject to change. To get the latest instructions on how to use
this product, please refer to the online user manual available on
www.mykronoz.com
MyKronoz is not responsible for any watch faces created by end
user. MyKronoz is not responsible for any content published online
by users. MyKronoz is only responsible for the content of pages it
publishes.
If you have any question or require assistance regarding our
product, please visit www.mykronoz.com/support/ or email us
SAFETY INSTRUCTIONS
Before using the device, read these instructions carefully.
BATTERY
•
ZeTime has built-in batteries. Do not disassemble the battery on your
own. KRONOZ LLC is not responsible for any damage or personal injury
caused by the removal of the battery or any component.
•
Do not expose your product to extremely high or low temperatures. Exces
-
sive temperature during charging could cause heat, smoke, fire or deforma
-
tion of the battery or even explosion. Do not expose the battery in the sun,
excessive smoke or dust. Charge the battery in a cool, ventilated room.
•
Do not open, crush, bend, deform, puncture or shred secondary cells
or batteries. In the event of a battery break or leak, prevent battery liquid
contact with skin or eyes. If this happens, immediately flush the areas with
water (do not rib the eye) or seek medical help.
•
Do not short-circuit. Short-circuiting can occur when a metallic object, such
as coins, causes direct connection of positive and negative terminals of the
battery. Short-circuiting may damage the battery.
•
Do not use batteries that have been damaged or have been exhausted.
•
Keep the batteries out of children’s reach and in a safe place to prevent
danger.
•
Do not place the batteries in the water. Do not expose your product to
water at high pressure, such as ocean waves or waterfall. Do not use your
product in a sauna or steam room.
•
Do not dispose of batteries in fire as they may cause explosion. Dispose
of used batteries in accordance with your local regulations (such as recy
-
cling). Do not dispose as household waste.
•
Use only the USB cable supplied to charge this battery. Do not charge
for more than 24 hours.
•
Do not attempt to repair or maintain the watch by yourself, service and
maintenance should be performed by authorized technicians.
- 41 -
- 42 -
USA
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions : (1) this device may not cause harmful interfe
-
rence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
CAUTIONS
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
FCC NOTICE
This equipment complies within the limits of a Class B digital device, pur
-
suant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protections against radio and TV interference in residential
areas. However, even during normal operation, this equipment may cause
TV or radio interference. If the equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try one or more of the
following corrective measures:
•
Reposition the receiving antenna.
•
Increase the distance between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit dierent from which
the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
REGULARY NOTICE
CANADA
INDUSTRY CANADA IC STATEMENT
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions :
(1) this device may not cause interference, and (2) this device must ac
-
cept any interference, including interference that may cause undesired
operation of the device.
Cet appareil est conforme à la norme CNR d’Industrie Canada applicable
aux appareils radio exempts de licence. Son utilisation est soumise aux
deux conditions suivantes: (1) cet appareil ne doit pas provoquer d’inter
-
férences et (2) cet appareil doit accepter toute interférence, y compris
les interférences qui peuvent causer un fonctionnement indésirable du
dispositif.
- 43 -
EUROPEAN UNION
CE DIRECTIVE
Declaration of conformity with regard to the EU Directive 2014/53/EC.
Kronoz LLC hereby declares that this device is in compliance with the
essential requirements and other relevant provisions of the R&TTE Di
-
rective 2014/53/EC. The complete declaration of conformity is available
on request via our customer service: [email protected]
Déclaration de conformité à l’égard de la directive européenne
2014/53/EC
Kronoz LLC déclare que cet appareil est conforme aux exigences es
-
sentielles et aux autres dispositions pertinentes de la directive R&TTE
2014/53/EC. La déclaration de conformité complète est disponible sur
demande auprès de notre service client: [email protected]
（1）使用30 分鐘請休息10 分鐘。
（2）未滿2歲幼兒不看螢幕，2歲以上每天看螢幕不要超過1 小時。
依據低功率電波輻射性電機管理辦法
第十二條
※經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用
者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條
※低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現
有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
-前項合法通信，指依電信法規定作業之無線電通信。
-低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性
電機設備之干擾。
ACCESS TO THE REQUIRED INFORMATION ON THE
ELABEL
Users can access the E-Label screen on ZeTime by going to Settings
> General > Regulatory. No special access codes or permissions are
required to go through the above steps beyond entering a user-de
-
fined password to protect against unauthorized access to the device.
Additional regulatory information are in « Regulatory notices » of this
document. The information is stored on the device, no special accessories
or supplemental plug-ins (e.g., a SIM/USIM card) are required to access
the information.
- 44 -
DISPOSAL AND RECYCLING INFORMATION
After the implementation of the European Directive 2002/96/EU in the
national legal system, the following applies : electrical and electronic
devices may not be disposed of with domestic waste. Consumers are
obliged by law to return electrical and electronic device at the end of their
service lives to the public collecting points set up for this purpose or point
of sale. Details to this are defined by the national law of the respective
country. This symbol on the product, the instruction manual or the pac
-
kage indicates that a product is subject to these regulations. By recycling,
reusing the materials or other forms of utilizing old devices, you are making
an important contribution to protecting our environment.
©2017 Kronoz LLC, all rights reserved. Kronoz LLC,
Avenue Louis-Casai 18 - 1209 Geneva - Switzerland
All brands or product names are or may be trademarks of their respective
owners.Pictures and specifications are not contractual. Les marques citées
sont des marques déposées par leur fabricant respectif. Photos et
caractéristiques non contractuelles.
Designed in Switzerland - Made in China
- 45 -
www.mykronoz.com
JOIN US @ MYKRONOZ
MORE THAN TIME
