LOCKSTATE
ELECTRONIC DEADBOLT LOCK
USER manual
3. Install Latch
KEYPAD ELECTRONIC DEADBOLT INSTALLATION INSTRUCTIONS a. Insert the latch and ensure it is parallell to the door face. Mark the outline of the faceplate, then take out the latch.

Newest Added: LS-DB5i-SN-B LS-L5i-SN-B LS-L5i-RB-B
The BACKSET is the distance between the center of cross bore and edge bore of the door. Adjustable latch fits both BACKSET of 2-3/8" (60mm) and 2-3/4" (70mm). Please follow the steps shown below for BACKSET adjustment. b. Chisel 1/8" (3mm) deep along the outline to allow the faceplate to be aligned with the door edge.
Latch Backset Adjustment : Rotate the latch case as diagram on the right for backset 2-3/4" (70mm) or reverse direction for 2-3/8" (60mm). c. Insert the latch and tighten it with screws.
Note : please use tapping screws for metal
2-3/4"
