ELECTRONIC DEADBOLT & LEVER LOCK LS-5i USER manual
1 2 3 4 5
1 2 3 4 5
6 7 8 9 0
6 7 8 9 0
ATTENTION: Please do not use an “electronic screwdriver” for installation
INSTALLATIONS INSTRUCTIONS
1. CONFIGURE LATCH BACKSETThe BACKSET is the distance between the center of cross bore and edge bore of the door. Adjustable latch fits both BACKSET of 2-3/8” (60mm) and 2-3/4” (70mm). Please follow the steps shown below for BACKSET adjustment.
DEADBOLT BACKSET Rotate the latch case as diagram on the right for backset 2-3/4” (70mm) or reverse direction for 2-3/8” (60mm).
LEVER BACKSET
The backset shown on the left is 60mm (2-3/8”).
Pull the cam toward right to extend the backset to 70mm (2-3/4”).
The backset shown in figure C is 70mm (2-3/4”). Pull the cam back to left will ret
