Copyright Creative Specialties International Literature #BA1350
1.
Position the mounting template on the w all in the desired location.
2. Using a level, align the template and tape it to the w all.
3.
4. Remove the template from the w all.
5. Fold ends of the plastic toggle together and insert into each hole in the w all.
6. Lightly tap anchors until flush w ith the w all.
7. One at a time, insert plastic pin into each of the anchors and lightly tap to
activate anchor. Remove pin and repeat on all anchors.
8. Remove mounting plates from the product assemblies by loosening each
setscrew.
9.
you) and insert screws through plate into anchors.
10. Tighten screws.
11. Loosen the 2 small screws on each of the end posts.
12. With the back of the mirror facing you, slide both end posts into position on
the mirror. Align the screw s with the holes in the back plates. Tighten all 4
screws.
13. Place entire mirror assembly over the mounting plates on the w all
(setscrews facing down). Tighten setscrews.
Oval Tilting Mirror
posts are
constructed of zinc and mirror is
constructed of 5MM thick glass.
DN
269
2BN
Oval Tilting Mirror
Brushed Nickel Finish
DN2692CH Oval Tilting Mirror
Chrome Finish
Cleaning Instructions:
Stock Number:
___________________Oval Tilting Mirror
By Creative Specialties
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
Oval Tilting Mirror
DN
26
92
Glenshire® Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
