II. Preset schedules
There are 3 pre-programmed times that run individually
or simultaneously. Choose from the following:
“evening” (5pm-12am)
“morning” (5am-8am)
“all night” (6pm-6am).
When a preset or custom program
is chosen, the blue LED indicator
light will turn on.
If a preset schedule does not fit your
needs, a custom on/o time can be
used to modify the preset. Example:
Using “evening” (5pm-12am) and
adding a “my o time” of 10pm will
create a 5pm-10pm timer schedule.
III. Countdown
This feature turns the light on for
a set period of time and turns
it o when time expires. Press
“countdown,” then use up ( ) and
down ( ) arrows to set from 1
minute to 24 hours. Once you reach
your desired time setting, simply
walk away and the timer will begin
counting down. Your last time setting
will be remembered the next time
you use the countdown feature.
Note: When daylight savings time
occurs use the up ( ) and down
( ) arrows to adjust the time
by 1 hour.
This device complies with part 15 of the FCC and Industry Canada license-exempt RSS stan-
dard(s). Operation is subject to the following two conditions: (1 this device may not cause harm-
ful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encourage to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3(B)/NMB-3(B)
1. Setup
If no numbers are visible on-screen, plug timer into an
outlet and let timer charge for 1 hour. Once charged,
press the reset (
r
) button in the lower right corner
using a toothpick or pencil.
2. Set the time
Use up ( ) and down ( )
arrows to set current time,
take note of AM or PM time.
3. Programming
Options
Set your custom on & o time
and/or pick any of the presets
that suit your schedule!
I. Choose your custom on/o times
Press “my on time,” then use up
( ) and down ( ) arrows to
set on time. Press “my o time,”
then use up ( ) and down
( ) arrows to set o time.
(If you set the “my on time”
earlier than the current time,
it will not turn on until the next
day at the time scheduled. Use
the Countdown to turn on the
timer if needed immediately.)
When using “my on” and “my
o” times make sure the blue
light is lit next to the button. The
blue lights will only illuminate when
plugged into a wall outlet.
MADE IN CHINA
Distributed by Jasco Products Company LLC, 10 E. Memorial Rd., Oklahoma City, OK 73114.
This Jasco product comes with a 1-year limited warranty.
Visit www.byjasco.com for warranty details.
Questions? Contact us at 1-800-654-8483 between 7:00AM–8:00PM CST.
RISK OF ELECTRIC SHOCK
• PLUG DIRECTLY INTO AN
ELECTRICAL OUTLET
• DO NOT USE IN WET LOCATIONS
• FULLY INSERT PLUG
• USE INDOORS ONLY
• UNPLUG TIMER BEFORE CLEANING
• KEEP CHILDREN AWAY
RISK OF FIRE
• DO NOT USE TO CONTROL APPLIANCES
THAT CONTAIN HEATING ELEMENTS
(COOKING APPLIANCES, HEATERS,
IRONS, ETC.)
• DO NOT EXCEED ELECTRICAL RATINGS
• DO NOT USE WITH EXTENSION CORDS
26892-P1 VERSION 01 10/11/16
Specifications:
125V 50/60 Hz
15A 1875W General Purpose/Resistive
10A 1250W Tungsten
1/2 HP
Works with dimmable
LED and CFL bulbs.
Indoor Digital
Simple Set
Plug-In Timer
WARNING
GE 53116
