1. Setup
If no numbers are visible on-screen, plug timer into an outlet and
let timer charge for 1 hour. Once charged, press the reset (
r
)
button in the lower right corner using a toothpick or pencil.
2. Set the time
Use up ( ) and down ( )
arrows to set current time,
take note of AM or PM time.
3. Programming
Options
Set your custom on & off time
and/or pick any of the presets
that suit your schedule!
I. Choose your custom on/off times
Press “my on time,” then use up ( ) and
down ( ) arrows to set on time. Press
“my off time,” then use up ( ) and
down ( ) arrows to set off time. (If
you set the “my on time” earlier
than the current time, it will not
turn on until the next day at
the time scheduled. Use the
Countdown to turn on the timer if
needed immediately.) When using
“my on” and “my off” times make
sure the blue light is lit next to the
button. The blue lights will only
illuminate when plugged into a wall outlet.
II. Preset schedules
There are 3 pre-programmed times
that run individually or simultaneously.
Choose from the following:
“evening” (5pm-12am)
“morning” (5am-8am)
“all night” (6pm-6am).
When a preset or custom program
is chosen, the blue LED indicator light
will turn on.
If a preset schedule does not fit your
needs, a custom on/off time can be used
to modify the preset. Example: Using “evening” (5pm-12am)
and adding a “my off time” of 10pm will create a 5pm-10pm
timer schedule.
III. Countdown
Press “countdown,” then
use up ( ) and down
( ) arrows to set from
1 minute to 24 hours.
The last countdown time
set will become the new
default until the countdown
button is pushed again.
Note: When daylight savings time occurs use the down
( ) and up ( ) arrows to adjust the time by 1 hour.
MADE IN CHINA
GE is trademark of General Electric Company and is under license by
Jasco Products Company LLC, 10 E. Memorial Rd., Oklahoma City, OK 73114.
This Jasco product comes with a 1-year limited warranty.
Visit www.jascoproducts.com for warranty details product registration.
Questions? Contact us at 1-800-654-8483 between 7:30AM–5:00PM CST.
Indoor/Plug-In
Digital Timer
WARNING
RISK OF ELECTRIC SHOCK
• PLUG DIRECTLY INTO AN ELECTRICAL OUTLET
• DO NOT USE IN WET LOCATIONS
• FULLY INSERT PLUG
• USE INDOORS ONLY
• UNPLUG TIMER BEFORE CLEANING
• KEEP CHILDREN AWAY
RISK OF FIRE
• DO NOT USE TO CONTROL APPLIANCES
THAT CONTAIN HEATING ELEMENTS
(COOKING APPLIANCES, HEATERS, IRONS, ETC.)
• DO NOT EXCEED ELECTRICAL RATINGS
• DO NOT USE WITH EXTENSION CORDS
28443, 26892 VERSION 02 6/19/15
Specifications:
125V 50/60 Hz
15A 1875W General Purpose/Resistive
10A 1250W Tungsten
1/2 HP
Works with dimmable
LED and CFL bulbs.
This device complies with part 15 of the FCC and Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1 this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encourage to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3(B)/NMB-3(B)
