31-5000590 Rev. 0 03-21 GEA
1) Prepare the surface in which the curtain guard is to be applied by removing dirt, dust, grease, oil, or any other
surface coating that may prevent adhesion. Avoid harsh chemical cleaning agents.
2) Take note of the curtain guard orientation in the figures below. The attachment tab of the curtain guard will be
closest to the wall.
3) To determine placement, position the curtain guard on the unit. On AZ45/65 Zonelines, the curtain guard should
be placed on the flat area above the discharge as opposed to the rounded surface directly above the discharge.
Center the part left to right above the PTAC air discharge. Record this location using painter’s tape or by lightly
marking the PTAC surface at both ends of the curtain guard with a pencil.
4) Remove the protective film covering the curtain guard.
5) Remove the backing tape from the adhesive strips on the curtain guard.
6) Aligning with one of your marks, carefully lay one end of the curtain guard down. Slowly lower the remaining
portion, making sure that the curtain guard meets the other mark.
7) Use fingers to apply pressure to the curtain guard directly above the adhesive strips to ensure good attachment to
the PTAC surface.
8) Remove painter’s tape or use an eraser to remove any pencil marks.
9) Position curtains in desired location behind the curtain guard.
Installation Instructions
for your new
RAK44
Curtain Guard for AZ45/65 Series
Zonelines and Hotpoint PTACs
(Compatibility with other models may vary)
Before you begin - Read these instructions completely and carefully.
IMPORTANT – OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer – Be sure to leave these instructions with the Consumer.
Note to Consumer – Keep these instructions with your Owner’s Manual for future reference.
