What’s in the Box
1 52
6
3
7
4
8 9
01
Tap the button in the top corner, scan the camera's QR code, and
follow the on-screen instructions to complete the setup.
Devices
Cloud
You haven't added any device. Please click
the"+"button in the top right corner to add
Installation Tips
01/Installation Tips
• Position the camera 2-3 meters (7-10 ft) above the ground to
maximize the PIR motion sensor's detection range.
• For optimal detection, install the camera at an angle where
movement crosses its detection zones.
NOTE:
If a subject moves straight toward the camera, the PIR sensor
may fail to detect motion.
180°
180°
360°
02/Adjustable Angles
04
Argus MagiCam
Item No. : B210
@ReolinkTech https://reolink.com
Operational Instructions
02
Device Overview
Power Button Functions:
Power on:
Press and hold the button for 3 seconds.
Power off:
Press and hold the button for 3 seconds.
Factory reset:
Triple-press the button while the camera is on.
Status Indicators
Solid Blue:
Wi-Fi connected successfully
Flashing Red:
Wi-Fi connection failed
Installation Steps
NOTE:
Mount the camera on any clean, at surface using the
magnetic pad, or attach it directly to a metal surface.
Peel and stick.
Attach the camera.
21
05
Magnetic Mounting
A
❶ ❷
❽
❾
❸
❹
❺
❻
❼
❶ ❷
❽
❾
❸
❹
❺
❻
❼
❶
USB-C Port
❻
Daylight Sensor
❷
IR LED
❼
Status Light
❸
PIR Motion Sensor
❽
Power/Reset Button
❹
Microphone
❾
microSD Card Slot
❺
Speaker
Wall/Ceiling Mounting
B
Set up the Device
Set up the Camera Using a Smartphone
Slide the latch to unlock and remove the battery cover.
180°
180°
360°
03
Scan to download the Reolink App from the App Store or Google Play
store.
NOTE:
For a more secure mount, you can screw the base in place.
This keeps it from moving when removing the camera.
Place on a at surface.
Adjust camera angle.
21
Tabletop Placement
C
NOTE:
The camera is compatible with AA Lithum batteries only.
1.
Camera
6.
Pack of Screws
2.
Magnetic Bracket
7.
Mounting Template
3.
AA Batteries*
8.
Surveillance Sticker
4.
USB-C Cable
9.
Operational Instructions
5.
Magnetic Mount Pad
Insert the battery following the indicated direction.
180°
180°
360°
NOTE:
You can also power the device with an adapter (no battery
required). When both are connected, the adapter supplies
power, and the batteries remain inactive and will not charge.
Scan the QR code below for more information on using lithium AA
batteries
Drill holes.
Attach the base.
Mount the camera.
Adjust to optimal angle.
1 2
3 4
5
Insert anchors.
06
07
08
Specications
Dimensions: 68 * 68 * 28.8 mm
Weight: 108 g
Operating Temperature: -10°C to 55°C (14°F to 131°F)
Operating Humidity: 20%~85%
Weather Resistance: IP67 certied weatherproof
For more specications, visit the Reolink ofcial website.
58.03.010.0189
Troubleshooting
Important Safety Instructions
Camera is Not Powering On
Replace with new standard AA Lithium batteries and make sure they
are properly connected in the battery compartment.
Failed to Connect to Wi-Fi During Initial Setup Process
If the camera fails to connect to Wi-Fi, please try the following
solutions:
• Ensure that you have entered the correct Wi-Fi password.
• Put the camera closer to your router to ensure a strong Wi-Fi signal.
• Change the encryption method of the Wi-Fi network to WPA2-PSK/
WPA-PSK on your router interface.
• Change your Wi-Fi SSID or password and make sure that SSID is
within 31 characters and password is within 64 characters.
• Set your password using only the characters available on the
keyboard.
If the problem is not solved, please contact Reolink Support.
Please read the instructions carefully before using the device.
• If you use a power adapter to power the camera, please use a DC
5V adapter recommended by the manufacturer.
• Insert the batteries in the correct orientation as indicated by the
positive (+) and negative (-) markings in the battery compartment.
Always use non-rechargeable AA 1.5V lithium (lithium metal) batteries
as provided and specied for this product. Using incorrect batteries
may pose an explosion risk.
• Do not charge the included non-rechargeable batteries.And use it
only in temperatures ranging from -10°C and 55°C.
• Do not insert batteries in reverse. Batteries installed incorrectly may
short-circuit or become charged, causing overheating, leakage,
venting, rupture, explosion, re, or personal injury.
• Do not short-circuit batteries. If the + and - terminals come into
contact (e.g., with keys or coins in a pocket), a short circuit may occur,
resulting in leakage, venting, explosion, re, or personal injury.
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure statement
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 20cm between the radiator &
your body.
ISED Compliance Statements
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the device.
This equipment should be installed and operated with a minumum
distance of 20 cm between the radiator and your body.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Cet équipement doit être installé et utilisé avec une distance
minimale de 20 cm entre la source de rayonnement et votre corps.
MODIFICATION:
Any changes or modications not expressly approved
by the grantee of this device could void the user's authority to
operate the device.
MODIFICATION :
les changements ou modications non expressément
approuvés par le fournisseur de licence de l'appareil sont
susceptibles d'annuler l'autorisation accordée à l'utilisateur de se
servir de l'équipement.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-
003 du Canada.
Operation of 5150-5350 MHz is restricted to indoor use only.
Le fonctionnement de 5150-5350 MHz est limité à une utilisation en
intérieur uniquement.
• Do not expose the camera with batteries to extremely low air
pressure environments, as this may cause an explosion.
• Do not place the camera with batteries in high-temperature
environments or expose it to direct lightning, as this may pose a re
risk.
• Do not strike or heavily compress the camera while batteries are
installed, as this may cause re or explosion.
• Do not use batteries that appear damaged, swollen, or
compromised in any way (e.g., leaking, emitting odors, dented,
corroded, rusted, cracked, melted, or scratched).
• Do not attempt to charge non-rechargeable (primary) batteries.
Charging them may generate gas and/or heat internally, leading to
leakage, venting, explosion, re, or personal injury.
• Remove exhausted batteries immediately from the equipment and
dispose of them properly. Leaving discharged batteries in the device
for long periods may cause electrolyte leakage, damaging the device
or causing personal injury.
• Remove batteries from equipment if it will not be used for an
extended period, unless for emergency purposes.
• Remove batteries immediately from malfunctioning equipment or
equipment expected to remain unused for a long period (e.g.,
camcorders, digital cameras, photo ashes). Partially or fully
discharged batteries are more prone to leakage than unused ones.
• Keep the camera and batteries out of reach of children.
• Do not ingest or swallow batteries. Ingestion may cause severe
internal burns or damage. Seek immediate medical attention if
ingestion is suspected.
• Keep the power port dry, clean, and free of debris.
• Always follow local safety laws and regulations when using the
camera.
09
Legal Disclaimer
To the maximum extent permitted by applicable law, this document
and the product described, with its hardware, software, rmware,
and services, are delivered on an "as-is" and "as-available" basis,
with all faults and without warranty of any kind. Reolink disclaims all
warranties, express or implied, including but not limited to, warranties
of merchantability, satisfactory quality, tness for a particular
purpose, accuracy, and non-infringement of third-party rights. In no
event will Reolink, its directors, ofcers, employees, or agents be liable
to you for any special, consequential, incidental or indirect damages,
including but not limited to damages for loss of business prots,
business interruption, or loss of data or documentation, in connection
with the use of this product, even if Reolink has been advised of the
possibility of such damages.
To the extent permitted by applicable law, your use of the Reolink
products and services is at your sole risk and you assume all
risks associated with internet access. Reolink does not take any
responsibilities for abnormal operation, privacy leakage or other
damages resulting from cyber attacks, hacker attacks, virus
inspections, or other internet security risks. However, Reolink will
provide timely technical support if required.
The laws and regulations related to this product vary by jurisdiction.
Please check all relevant laws and regulations in your jurisdiction
before using this product to ensure that your use conforms to the
applicable law and regulation. During the use of the product, you
must comply with relevant local laws and regulations. Reolink is not
10 Notification of Compliance
responsible for any illegal or improper use and its consequences.
Reolink is not liable in the event that this product is used with
illegitimate purposes, such as third-party rights infringement, medical
treatment, safety equipment, or other situations where the product
failure could lead to death or personal injury, or for weapons of mass
destruction, chemical and biological weapons, nuclear explosion,
and any unsafe nuclear energy uses or anti-humanity purposes. In
the event of any conicts between this manual and the applicable
law, the latter prevails.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation. Changes or
modications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
Hereby, REOLINK INNOVATION LIMITED declares that this device is
in
compliance with Cyber Security (Security Standards for Smart Devices)
Rules 2025. For the Statement of Compliance, visit the Web site https://
reolink.com/product-compliance/
Limited Warranty
This product comes with a 2-year limited warranty that is valid only if
purchased from Reolink Ofcial Store or a Reolink authorized reseller.
Learn more: https://reolink.com/warranty-and-return/.
NOTE:
We hope that you enjoy the new purchase. But if you are not
satisfied with the product and plan to return, we strongly suggest
that you reset the camera to factory default settings and take out the
inserted SD card before returning.
Terms and Privacy
Use of the product is subject to your agreement to the Terms of
Service and Privacy Policy at reolink.com
Technical Support
If you need any technical help, please visit our official support site
and contact our support team before returning the products,
https://support.reolink.com.
Terms of Service
By using the Product Software that is embedded on the Reolink
product, you agree to the terms&conditions between you and Reolink.
Learn more: https://reolink.com/terms-conditions/
Trademarks Acknowledgement
"Reolink" and other Reolink's trademarks and logos are the properties
of Reolink. Other trademarks and logos mentioned are the properties
of their respective owners.
REOLINK INNOVATION LIMITED
FLAT/RM 705 7/F FA YUEN COMMERCIAL BUILDING 75-77 FA YUEN
STREET MONG KOK KL HONG KONG
