Reolink
Home Hub Mini
Item No. : Hub 1 Lite
58.03.010.0083
@ReolinkTech https://reolink.com
REOLINK INNOVATION LIMITED
FLAT/RM 705 7/F FA YUEN COMMERCIAL BUILDING 75-77 FA YUEN STREET
MONG KOK KL HONG KONG
Operational Instructions
English English
1 2
What's in the Box
Power Adapter
Home Hub
1m Ethernet
Cable
EN
Content
Operational
Instructions
Operational
Instructions
01
01
02
03
04
05
06
07
08
09
What's in the Box ···································2
Device Overview ····································3
Connection Diagram ······························· 4
Access Home Hub via Smartphone ················ 5
Connect Devices to Home Hub ····················7
Specications ······································8
Important Safety Instructions ······················9
Legal Disclaimer ···································· 10
Notication of Compliance ························12
English English
3 4
Device Overview
Connection Diagram
Step 1:
Plug in the Home Hub and connect it to your home
router using the Ethernet cable provided.
Step 2:
Connect your phone to the same router that the
Home Hub is connected to.
02 03
❶
Indicator Light
❷
Button*
❸
Cooling Holes
❹
microSD Card Slot
❺
DC Input Port
❻
LAN Port
❼
USB Port
❸
❶ ❷
❹
❺
❻ ❼
Reset Note: Power off the
device to reset it. While
powered off
,
press and hold
the device button, then
reconnect the power until
you hear a beep.
English English
5 6
Step 2:
Launch the App, click “ ” at the top right, and scan
the QR code on your Home Hub to add it.
Access Home Hub via
Smartphone
Step 1:
Scan to download the Reolink App from the App Store
or Google Play store
Step 3:
Once the setup is complete, the LED indicator light will
turn blue.
04
English English
7 8
1. If your device is already set up, click the “ ” button
at the top right and choose to “add from device list”
or “add from LAN.”
2. If your device is not set up yet, click the “ ” button
at the top right and choose to “scan UID code.”
Connect Devices to Home Hub
There are two ways to add Reolink devices to your
Home Hub:
Attention:
When inserting the SD card into the slot,
make sure the side with the numbers is facing up and
push it gently inward until it clicks into place.
*You can also directly add devices to the Hub while
adding devices to the app.
Specications
Operating Temperature: -10°C~+45°C(14°F to 113°F)
Size:
Ф
94*127.8 mm
Weight: 220 g
For more specications, please visit https://reolink.com/.
Reolink Home Hub Mini
05
06
English English
9 10
Important Safety Instructions
Please read the instructions carefully before using the
device.
1. Replace only with the same or equivalent type of
accessories recommended by Reolink.
2. Do not use the device in an environment that exceeds
the recommended temperature range.
3. Do not use the device in an environment that exceeds
the recommended humidity range.
4. Do not attempt to disassemble, repair, or alter the
device by yourself.
5. Always follow the local safety laws and regulations
when using the device.
6. The device contains (or comes with) small components,
small plastic elements, and other small parts that
may cause choking hazards. Keep the device and its
accessories out of reach of children. Consult a physician
immediately if small parts are swallowed.
7. The device contains (or comes with) cables or cords
that may cause strangulation hazards. Keep the device
and its accessories out of reach of children.
Legal Disclaimer
To the maximum extent permitted by applicable law,
this document and the product described,with its
hardware, software, rmware, and services, are delivered
on an "as-is" and "as-available" basis, with all faults
and without warranty of any kind. Reolink disclaims all
warranties, express or implied, including but not limited
to, warranties of merchantability, satisfactory quality,
tness for a particular purpose, accuracy, and non-
infringement of third-party rights. In no event will Reolink,
its directors, ofcers, employees, or agents be liable to
you for any special, consequential, incidental or indirect
damages, including but not limited to damages for
loss of business prots, business interruption, or loss of
data or documentation, in connection with the use of
this product, even if Reolink has been advised of the
possibility of such damages.
To the extent permitted by applicable law, your use of
the Reolink products and services is at your sole risk and
07 08
English English
11 12
Notication of Compliance
FCC Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation. Changes or modications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
you assume all risks associated with internet access.
Reolink does not take any responsibilities for abnormal
operation, privacy leakage or other damages resulting
from cyber attacks, hacker attacks, virus inspections, or
other internet security risks. However, Reolink will provide
timely technical support if required.
The laws and regulations related to this product vary
by jurisdiction. Please check all relevant laws and
regulations in your jurisdiction before using this product
to ensure that your use conforms to the applicable law
and regulation. During the use of the product, you must
comply with relevant local laws and regulations. Reolink
is not responsible for any illegal or improper use and its
consequences. Reolink is not liable in the event that this
product is used with illegitimate purposes, such as third-
party rights infringement, medical treatment, safety
equipment, or other situations where the product failure
could lead to death or personal injury, or for weapons
of mass destruction, chemical and biological weapons,
nuclear explosion, and any unsafe nuclear energy uses
or anti-humanity purposes. In the event of any conicts
between this manual and the applicable law, the latter
prevails.
09
English English
13 14
FCC Radiation Exposure statement
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with
minimum distance 20cm between the radiator & your
body.
ISED Statement
This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device."
This equipment should be installed and operated with a
minumum distance of 20 cm between the radiator and
your body.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de
interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
English English
15 16
licence. L’exploitation est autorisée aux deux conditions
suivantes :
(1) l’appareil nedoit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.”
Cet équipement doit être installé et utilisé avec une
distance minimale de 20 cm entre le radiateur et votre
corps.
MODIFICATION:
Any changes or modications not
expressly approved by the grantee of this device could
void the user’s authority to operate the device
.
Toute modication non approuvé explicitement par
le fournisseur de licence de l’appareil peut entraîner
l’annulation du droit de l’utilisateur à utiliser l’appareil.
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
Operation of 5150-5350 MHz is restricted to indoor use
only.
Le fonctionnement de 5150-5350 MHz est limité à une
utilisation en intérieur uniquement.
Hereby, REOLINK INNOVATION LIMITED declares that this
device is in compliance with Cyber Security (Security
Standards for Smart Devices) Rules 2025. For the
Statement of Compliance, visit the Web site
https://
reolink.com/product-compliance/
Limited Warranty
This product comes with a 2-year limited warranty
that is valid only if purchased from Reolink Ofcial
Store or a Reolink authorized reseller. Learn more:
https://reolink.com/warranty-and-return/.
NOTE:
We hope that you enjoy the new purchase. But
if you are not satised with the product and plan to
return, we strongly suggest that you reset the camera
English English
17 18
Trademarks Acknowledgement
“Reolink” and other Reolink’s trademarks and logos
are the properties of Reolink. Other trademarks and
logos mentioned are the properties of their respective
owners.
to factory default settings and take out the inserted
SD card before returning.
Terms and Privacy
Use of the product is subject to your agreement to
the Terms of Service and Privacy Policy at reolink.com
Terms of Service
By using the Product Software that is embedded
on the Reolink product, you agree to the
terms&conditions between you and Reolink. Learn
more: https://reolink.com/eula/.
Technical Support
If you need any technical help, please visit our official
support site andcontact our support team before
returning the products, https://support.reolink.com.
