Bluetooth Speaker (with Bass)
BKZQ02
User Manual
一、 Configuration Diagram
Sequence Number
component
Quantity(pcs)
Remarks
1
Bluetooth Speaker
Control Box
1
2
Speaker Y-Cable
1
3
Portable Speaker
2
4
Subwoofer
1
5
Power Cable
1
二、 Technical specifications
1. Input Voltage：DC29V
2. Input Current：1A
3. Rated Power：8W*2+16W
4. Frequency Response：20-20000Hz
5. Impedance：Min3.6Ω，MaX4.4Ω
6. Signal-to-Noise Ratio (SNR)：Min68dB
7. Bluetooth 5.0
三、 Instructions for Use
1.Device powers on and automatically enables Bluetooth, with the voice prompt "Power on".
2.Turn on your phone's Bluetooth, search for and pair with the device named "Subwoofer
Speaker_Nxxxxx". Upon successful connection, the voice prompt will say "Connected
successfully". A disconnect tone will sound when disconnected.
四、 List of Voice Prompts
Chinese-English Translation Table
Sequence
Number
Chinese
English
①
连接成功
Connected successfully
②
蓝牙断开
Disconnection
③
开机
Power on
FCC Regulations
⚫ This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
⚫ This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/ TV technician for help.
⚫ Changes or modifications not expressly approved by the manufacturer could void the user’s
authority to operate the equipment.
Radio Frequency (RF) Energy
This device is designed and manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the United States.
The exposure standard for wireless devices employing a unit of measurement is known as the Specific
Absorption Rate, or SAR. The SAR limit recommended by the general public is 1.6W/kg Averaged over
one gram of tissue by IEEE Std 1528.
The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated
as in compliance with the FCC RF exposure guidelines. While there may be differences between the SAR
levels of various devices and at various positions, they all meet the government requirements. SAR
compliance for body-worn operation is Based on SAR test exclusion, all values meet the SAR test
exclusion thresholds and are exempt from routine evaluation.
