TDS-1095
PaxLock
Paxton
PaxLock Pro 2 - Mortise
The PaxLock Pro 2 - Mortise represents Paxton’s 3rd generation
of electronic door handle; oering a robust, featureful and
aesthetically pleasing product suitable for a multitude of
installations.
The new design has been created to be simple to install, intuitive
to use and backed up by Paxton’s market leading 5 year warranty.
The PaxLock Pro 2 - Mortise oers three modes of operation. It
can be used as a standalone oine device, connected to a Net2
system via a Paxton Net2Air bridge, or connected to a Paxton10
system via a Paxton10 Wireless Connector.
• Dual frequency reader
• Digital privacy button
• Suitable for external use (Reader side)
• Wireless real-time event reporting
• When PaxLock Pro - Mortise is unlocked the handle moves freely
• Standalone and online functionality in one unit
Overview
Features
TDS-1095
2
Specications
Battery type 4x AA 5 Alkaline
Electrical
System
Communication
Bluetooth®*
25
10
Battery life 55,000 Operations
Wireless
Default channel
Recommended wireless devices per Net2Air Bridge
2.4GHz (IEEE 802.15.4)
100 card packs (up to 5,000 tokens/users)
10,000
16,000
Door open time
Silent operation
1- 60 Seconds
Maximum total tokens
Maximum total users
No
Yes
Stored events
Hands free compatible
Door trac
Up to 75 uses per day
Low
Cloning resistance
Token compatibility
Paxton standard
EM4100/02
MIFARE®
HID Prox®
Frequency
Frequency
Frequency
Frequency
Frequency
Data read
Data read
Data read
Data read
Data read
Cloning resistance
Cloning resistance
Cloning resistance
Cloning resistance
Cloning resistance
Medium
Low
Low
Low
Serial number (CSN) & User memory
Serial number (CSN)
UID
User number/site code
125kHz
125kHz
Paxton encrypted
13.56 MHz
13.56 MHz
125kHz
AES 128 bit encrypted credential
High
TDS-1095
3
Lock case
Environment
Certication
Accessories and Sales codes
PaxLock Pro 2 - Mortise, Galaxy, black
PaxLock Pro 2 - Mortise, Eclipse, black
900-730-US
900-735-US
Backset
Operating temperature
2-3/4"
Reader side: -35°C ~ +66°C
Battery side: -0°C ~ +49°C
Fire resistance UL10C 3hrs
UL294 exterior rated (reader side only)
Rotation
Moisture resistance
Single action egress
≤45°
Yes
FCC Part 15
ISED
UL 294
Tested to ANSI Grade 1
UL10C/ ULC S104
Demo Kit
PaxLock Pro - US Demonstration kit, Mortise & Latch 900-692-US
Hardware
Door widths supported
Rear handle exit request
Low battery warning
Colour
Yes
Yes
Black
1-3/4" - 2-1/4"
15m/50ftBluetooth®*
AES128
Typical wireless range
Encryption
TDS-1095
4
128.50 mm
5.06”
39.50 mm
1.56”
21.50 mm
0.85”
44.50 mm
1.75”
43 mm
1.69”
89 mm
3.50”
87.50 mm
3.45”
177 mm
6.97”
126.50 mm
4.98”
130 mm
5.12”
128 mm
5.04”
85 mm
3.35”
47 mm
1.85”
44 mm
1.73”
41.50 mm
1.63”
98.50 mm
3.80”
64.50 mm
2.54”
63 mm
2.48”
Dimensions
© Paxton Ltd Draft Rev B
