Fingerprint Padlock
PL7001
Operation Manual
Unlock
I. Contents II. Part Name
PL7001 Fingerprint Padlock x1
User Manual x1
PL7001
Operation Manual
III. Specifications
V. Operation Instructions
VI. Audio and LED Indications
Set Up The First Administrator’s Fingerprint
2. Press and hold
the sensor for 3
seconds
Once the LED
flashes Red and
Green, lift your
finger
3. Repeat collecting
the same fingerprint
for 5 times
Successful fingerprint
collection:
LED flashes Blue
Failed fingerprint
collection:
LED flashes Red
4. When the
fingerprint was
stored, the LED
lights up Green
5. The LED will keep
flashing Red and
Green for adding the
second to tenth
fingerprints.
Without any setting,
it will exit the
Setting Mode
after 10 seconds
1. Unlock
PL7001
Set Up The 2nd to 10th Fingerprints
Remarks:
1.The first and second fingerprints are the administrators by default.
2.One of the administrators fingerprint will be need to authorize when adding fingerprints.
Delete All Fingerprints
Remarks:
Only the administrators can delete the fingerprints, all the fingerprints will be deleted at one time.
Setting Your Own Combination
1. Turn the Reset Button 90˚ clockwise
2. Scramble the Dials to set your own combination
3. Turn the Reset Button 90˚ counterclockwise back to
its original position
Your lock is now ready to open at its new combination
Emergency Unlock
1. Scramble the Dials to the combination you’ve set
2. Press the release button to unlock
Reset ModeSetting Mode
Description LED Indications Sound Effect
Press and hold the
sensor for 3 seconds
to enter the Setting
Mode
Flash
Green and Red
1 Short beep
Successful fingerprint
collection
Lighting Blue
for 0.5 sec
1 Short beep
Failed fingerprint
collection
Flash Red
3 times
3 Short beeps
Fingerprint stored
successfully
Lighting Green
for 1 sec
1 Long beep
Without any settings,
it will exit the Setting
Mode after 10 seconds
Green and Red
LED off
-
Description LED Indications Sound Effect
The administrator press
and hold the sensor for
3 second
The administrator keeps
holding until the LED
lights Blue to enter
Reset Mode, life the
finger
The administrator press
and hold the sensor to
erase all settings
Exit Reset Mode
Flash
Green and Red
Flash Blue
Lighting Red
Red LED off
1 Short beep
1 Short beep
-
1 Long beep
2 Short beeps
Description LED Indications Sound Effect
Successfully unlocked
by fingerprint
Failed to unlock by
fingerprint
Lighting Green
for 1 sec
Flash Red
2 times
1 Long beep
-
Sound Effect
-
Complete charging
Recharging
Description LED Indications
Continuous
Lighting Red
Continuous
Lighting Green
Recharging
Model
Battery
Battery Life
Idle Mode
Micro USB Input
Operation Temp
Storage Temp
Body Material
Weight
Unlock Mechanism
Groups of Fingerprint
PL7001 Fingerprint Padlock
50mAh 3.7V
Up to 1,500 times operations
Standby over 130 days
DC 5V / 500mA
-20°C ~ 70°C
-40°C ~ 85°C
Zinc Alloy, Hardened Steel
Net: 206g / Gross: 350g
Fingerprint / 4-digit pass code
Stores up to 10 fingerprints
45
55.5
92
32
23
2. The
Administrator
press and hold
the sensor for
3 seconds
Once the LED
flashes Red and
Green, lift your
finger
3. Repeat collecting
the same fingerprint
for 5 times
Successful fingerprint
collection:
LED flashes Blue
Failed fingerprint
collection:
LED flashes Red
4. When the
fingerprint was
stored, the LED
lights up Green
5.The LED will keep
flashing Red and
Green for adding
other fingerprints.
Without any setting,
it will exit the
Setting Mode
after 10 seconds
1. The
Administrator
unlock PL7001
1. Unlock PL7001 2. Press and hold the
sensor for 3 seconds,
the LED will flash Red
and Green
Keep holding until the
LED flashes Blue, lift
your finger
3. Press and hold the sensor,
the LED will light up Red
All fingerprints are deleted
2
1
Unit: mm
24
Ø 6.3
Shackle
Tricolor
LED
Release
Button
2
1
3
90˚
Fingerprint
Sensor
Micro USB
Port
Reset
Button
Combination
IV. Features
Low Battery Indicator
When batteries voltage ≤ 3.7V, each time it is successfully unlocked, the LED status
indicator will light up in Green for 1 sec and flash in Red 4 times.
PL7001 Fingerprint Padlock can still operate up to 100 cycles in low battery condition.
When batteries voltage ≤ 3.5V, PL7001 Fingerprint Padlock cannot be operated.
Battery Life
After each full charge, the PL7001 Fingerprint Padlock can be operated up to 1,500 times.
Without any operation (Idle mode), PL7001 can standby over 130 days.
Emergency Unlock
4-digit resettable combination for emergency unlock.
※ Fully charging your battery before use.
